angle is negative. If the end of the bat is above your hands, the
angle is positive. The optimal elevation angle is -25 degrees.
Customizing Your Device
Bluetooth Settings
Hold
to open the menu, and select Bluetooth.
Turn On: Turns on Bluetooth wireless technology.
NOTE: Other Bluetooth settings appear only when Bluetooth
wireless technology is enabled.
Turn Off: Turns off Bluetooth wireless technology.
Pair Phone: Allows you to pair your device with a compatible
Bluetooth enabled smartphone.
Bat Settings
Hold
to open the menu, and select Bats. Bat settings are set
individually for each batter. You can configure additional bat
settings using the Impact app.
Switch Bat: Allows you to change between bats configured
using the Impact app.
Bat Length: Allows you to adjust the length of the current bat.
Coaching Settings
Hold
to open the menu, and select Coaching. Coaching
settings are configured individually for each batter.
Cumulative: Enables quick tips based on cumulative analysis of
a batter's swing.
Off: Disables quick tips.
Changing Handedness
The Impact device uses your handedness to calculate the
correct swing analysis data. You can use your Impact device to
change your handedness at any time. Handedness settings are
configured individually for each batter.
1
Hold
to open the menu.
2
Select Handedness.
3
Select the handedness for the selected batter.
System Settings
Hold
to open the menu, and select System.
About: Shows device and regulatory information.
Add Batter: Manually adds a batter to the device.
Units: Sets the unit of measure for speed measurements.
Tones: Sets preferences for audible tones with alerts or key
presses.
Date and Time: Sets the date and time.
Language: Sets the device language.
Customizing Your Device
NOTE: Changing the text language does not change the
language of user-entered data.
Software Update: Updates the device software when updates
are available.
Device Information
Specifications
Battery type
Radio frequency/protocol
Operating temperature range
Charging temperature range
Water resistance
*The device withstands incidental exposure to water of up to 1 m
for up to 30 min. For more information, go to
/waterrating.
Product Updates
On your computer, install Garmin Express
/express).
This provides easy access to these services for Garmin devices:
• Software updates
• Product registration
Device Care
Avoid extreme shock and harsh treatment, because it can
degrade the life of the product.
Do not use a sharp object to clean the device.
Avoid chemical cleaners, solvents, and insect repellents that can
damage plastic components and finishes.
Do not store the device where prolonged exposure to extreme
temperatures can occur, because it can cause permanent
damage.
Cleaning the Device
Even small amounts of sweat or moisture can cause corrosion
of the electrical contacts when connected to a charger.
Corrosion can prevent charging and data transfer.
1
Wipe the device using a cloth dampened with a mild
detergent solution.
2
Wipe it dry.
After cleaning, allow the device to dry completely.
Rechargeable Lithium-ion battery
2.4 GHz Bluetooth enabled device
From -10º to 60ºC (from 14º to 140ºF)
From 0º to 40°C (from 32º to 104°F)
IEC 60529 IPX7*
www.garmin.com
(www.garmin.com
™
NOTICE
NOTICE
3
