Safety and operating instructions
Petrol drills and breakers
CP Drill
www.cp.com

Advertisement

Table of Contents
loading

Related Manuals for Chicago Pneumatic CP Drill

Summary of Contents for Chicago Pneumatic CP Drill

  • Page 1 Safety and operating instructions Petrol drills and breakers CP Drill www.cp.com...
  • Page 2 CP Drill 9800 1669 01 | Original instructions...
  • Page 3 CP Drill Contents Contents Introduction............... 5 About the Safety and operating instructions.
  • Page 4 Safety and operating instructions CP Drill 9800 1669 01 | Original instructions...

  • Page 5: Introduction

    CP Drill Safety and operating instructions Introduction Thank you for choosing Chicago Pneumatic brand products. For over a century, the Chicago Pneumatic brand has represented performance and innovation in the pneumatic tool industry. Today the brand is found around the world on a range of pneumatic and hydraulic tools that includes breakers, rock drills, chipping hammers, clay-diggers, picks and busters, scabblers, pumps and a whole lot more.

  • Page 6: Safety Instructions

    Safety and operating instructions CP Drill Drugs, alcohol or medication Safety instructions WARNING Drugs, alcohol or medication To reduce the risk of serious injury or death to Drugs, alcohol or medication may impair your yourself or others, read and understand the Safety judgment and powers of concentration.
  • Page 7 CP Drill Safety and operating instructions ► Avoid contact with the warm exhaust pipe or the WARNING Unexpected movements bottom of the machine. The working tool is exposed to heavy strains when the machine is used. The working tool may break Never drill in an old hole.
  • Page 8 Safety and operating instructions CP Drill ► Wear washable or disposable protective clothes WARNING Dust and fume hazard at the worksite, and shower and change into clean Dusts and/or fumes generated or dispersed when clothes before leaving the worksite to reduce...
  • Page 9 CP Drill Safety and operating instructions WARNING Projectiles WARNING Vibration hazards Failure of the work piece, of accessories, or even of Normal and proper use of the machine exposes the the machine itself may generate high velocity operator to vibration. Regular and frequent exposure projectiles.

  • Page 10: Maintenance, Precautions

    Safety and operating instructions CP Drill ► Never grab, hold or touch the working tool when ► The machine has a silencer, check that it is in place using the machine. and in good working condition. Participate in health surveillance or monitoring, Always use hearing protection.

  • Page 11: Storage, Precautions

    CP Drill Safety and operating instructions CAUTION High temperature The machine's front cover, exhaust gas, exhaust pipe and accessible metallic parts can be hot during and after operation. Contact with any of these can lead to burns. Never touch a hot front cover.

  • Page 12: Overview

    Spark plug cover Design and function Silencer Function selector CP Drill is a combined drilling and hammering Tool retainer machine. It is equipped to be used for breaking asphalt and concrete and for drilling in concrete and granite. Equipped with the right accessories, the...

  • Page 13: Transport

    CP Drill Safety and operating instructions The CE symbol means that the machine is Transport EC-approved. See the EC Declaration of Conformity which is delivered with the WARNING Fuel hazard machine for more information. The fuel (petrol and oil) is extremely flammable and...

  • Page 14: Working Tool

    Safety and operating instructions CP Drill Filling procedure 22mm 108mm 1. Stop the engine and let it cool down before filling the tank. 2. The machine must be in the upright position when filling with fuel. 3. Release the filler cap slowly to let any pressure escape.

  • Page 15: Operation

    CP Drill Safety and operating instructions 1. Stop the machine and wait until the working tool has cooled down. 2. Fit or remove the working tool. 3. Close the tool retainer by using your foot. WARNING Vibration hazard Using inserted tools that do not fulfil the criterias...

  • Page 16: Function Selector: Drilling And Breaking

    Safety and operating instructions CP Drill Function selector: Drilling Start and stop and breaking Cold start and warm-up 1. Remove the fuel cap and check the fuel level. > Drilling Secure the cap before start. Turn the function selector downwards. This will engage rotation and flushing air.

  • Page 17: Operating

    CP Drill Safety and operating instructions Restarting a warm machine Operating 1. Check that the choke is open (in position WORK). Starting a cut 2. Pull the starter handle. Stand in a stable position with your feet well away ♦...

  • Page 18: Drilling

    Safety and operating instructions CP Drill Working at high altitude Ground probing To get the best result when working at high altitude, do the following: If the machine is started on the top of long tools Check that the air filter is in good condition.

  • Page 19: Every Day

    CP Drill Safety and operating instructions ♦ For major service of the machine, contact the 1. Unscrew the air filter cover. nearest authorised workshop. 2. If the air filter is very dirty, it must be replaced. ♦ For carburettor adjustments, contact the nearest Never wash the air filter.

  • Page 20: Troubleshooting

    Safety and operating instructions CP Drill Removing the old starter cord 8. Pull the starting handle carefully, in order to locate the cover correctly. 1. Remove the three bolts from the protective cover of the starting mechanism. 9. Fit and tighten the hexagonal bolts.

  • Page 21: Disposal

    CP Drill Safety and operating instructions Disposal A used machine must be treated and deposed of in such a way that the greatest possible portion of the material can be recycled and any negative influence on the environment is kept as low as possible, and in respect to local restrictions.

  • Page 22: Technical Data

    Safety and operating instructions CP Drill Technical data Products Description Tool shank size, mm (in.) Part number CP Drill 22 X 108 ( ⁄ ⁄ 8318 0900 40 Machine data CP Drill Type 1 cylinder, two-stroke, air cooled Cylinder displacement (cc) Power kw (hp) 2.0 (2.7)

  • Page 23: Noise And Vibration Data

    Declared values Declared values Sound pressure Sound power Three axes values EN ISO 11203 2000/14/EC EN ISO 28927-10 r=1m dB(A) rel guaranteed dB(A) rel value spreads Type 20µPa CP Drill (breaking) CP Drill (drilling) 9800 1669 01 | Original instructions...

  • Page 24: Ec Declaration Of Conformity

    Safety and operating instructions CP Drill EC Declaration of Conformity EC Declaration of Conformity (EC Directive 2006/42/EC) We, Construction Tools PC AB, hereby declare that the machines listed below conform to the provisions of EC Directive 2006/42/EC (Machinery Directive) and 2000/14/EC (Noise Directive), and the harmonised standards mentioned below.
  • Page 25 CP Drill 9800 1669 01 | Original instructions...
  • Page 26 CP Drill 9800 1669 01 | Original instructions...
  • Page 27 CP Drill 9800 1669 01 | Original instructions...
  • Page 28 2015-03 | No. 9800 1669 01 © Copyright Construction Tools PC AB...
