This Quick Start Guide tells you how to install your 3Com
EtherLink
Figure 1 shows the four types of 3Com ISA adapters and their
backplates, connectors, and cabling types.
3C509B-TPO
Connector
type
Cabling 10BASE-T
type
Figure 1 Backplates for 3Com ISA Adapters

Getting Started

Open the shipping container carefully and verify that you
have received the adapter you ordered. Inspect the adapter
for damage. If you find any damage, contact your network
supplier and the carrier that delivered the package.
CAUTION: Each adapter is packed in antistatic material to
protect it during shipment. To avoid damaging any
static-sensitive components after removal from the container,
be sure to reduce any static electricity on your person. One way
to do this is to touch the metal chassis of your computer.
S
UICK TART
®
III Parallel Tasking
3C509B coax
LED
RJ-45 AUI and
BNC
Thick coax
Thin coax
®
16-bit ISA adapter.
3C509-TP 3C509B-COMBO
LED
AUI and AUI, BNC,
RJ-45 RJ-45
10BASE-T 10BASE-T
Thick coax Thick coax
Thin coax
®
LED
RJ-45
connector
AUI
connector
BNC
connector
