TANDBERG
TFT-LCD Color Monitor
FS-S2301F
User Guide
General Specification
Table of
Contents
Previous
Page
Next
Page
1
2
3
4
5
Advertisement
Table of Contents
Related Manuals for TANDBERG FS-S2301F
Monitor TANDBERG FS-L4201C User Manual
Tft-lcd color monitor (11 pages)
Monitor TANDBERG 0100400003AA User Manual
52 inch dual color tft lcd monitor (23 pages)
Monitor TANDBERG FS-L4205C User Manual
Tft-lcd (9 pages)
Monitor TANDBERG FS-S5201C User Manual
Tft-lcd color monitor (11 pages)
Monitor TANDBERG 1000 MXP User Manual
Tandberg user manual monitor tandberg 1000 mxp (280 pages)
Monitor TANDBERG T1 Administrator's Manual
Tandberg monitor administrator guide (64 pages)
Summary of Contents for TANDBERG FS-S2301F
Page 1
TANDBERG TFT-LCD Color Monitor FS-S2301F User Guide General Specification...
Page 2
INFORMATION TO USER : General Specification...
Page 3
TABLE OF CONTENTS 1. Product Drawing------- ------------------------------------------------------------------------------1 2. Connector Specification- --------------------------------------------------------------------------2 3. Standard signal Table ------------------------------------------------------------------------------3 4. Signal Connector Pin Assignments------------------------------------------------------------4 5. Specification ------------------------------------------------------------------------------------------5 General Specification...
Page 4: Product Drawing
1. Product Drawing Unit : mm General Specification...
Page 5: Connector Specification
2. Connector Specification KEY I/F Service Port DC in Power Switch Touch Control HDMI 2 HDMI 1 *AC power cord and signal cables are not included in this package. General Specification...
Page 6: Standard Signal Table
3. Standard signal Table PC Supported Mode Resolution Horizontal Vertical Clock Frequency(KHz) Frequency(Hz) Frequency(MHz) 15.6 13.5 NTSC 15.7 13.5 640x480 29.5 23.625 800x600 31.5 35.4375 800x600 37.879 60.317 800x600 46.875 49.5 720p(1280x720) 37.5 74.25 720p(1280x720) 74.25 720p(1280x720) 148.5 720p(1280x720) 148.5 1366x768 48.3 87.75...
Page 7: Signal Connector Pin Assignments
4. Signal Connector Pin Assignments 1. DVI1,DVI2 Pin No. Assignment Pin No. Assignment TMDS Data2+ Ground_Clock Shield Ground_Data2 TMDS Clock- Shield TMDS Data2- No Connection TMDS Data1+ No Connection Ground_Data1 TMDS SCL Shield TMDS Data1- TMDS SDA TMDS Data0+ Ground Ground_Data0 TMDS Power Shield...
Page 8: Specification
4. Mini din connector Pin No. Assignment Pin No. Assignment I2C SDA Power (5V) I2C SCL Ground Ground Switch Input 3 Switch Input 1 Power (5V) Switch Input 2 General Specification...
Page 9
5. Specification Model FS-S2301F Type TFT Active matrix Screen size 23 inch (Diagonal) Maximum Resolution 1920X1080@60Hz Pixel pitch 0.2655(H)mmX0.2655(V)mm LCD PANEL Display colors 16.7M (RGB 8-bit data) Contrast Ratio(Typ.) 3000:1 Viewing Angle(CR≥10,Typ.) 89/89/89/89 Response Time(Typ.) 25ms Luminance(Typ.) 300cd/m2 Synchro Horizontal Frequency...
