Summary of Contents for TANDBERG FS-L4201C

  • Page 1 User Manual English TFT-LCD Color Monitor FS-L4201C Printed in Korea www.tandberg.net Part No. 942667020001 - 01...
  • Page 2: Table Of Contents

    Table of Contents INFORMATION TO USER : Parts This equipment has been tested and found to comply with the limits of a Connection to Signal Source Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful Out Drawing of product interference in a residential installation.This equipment generates, uses and Name and Function...
  • Page 3: Parts

    This monitor do not provide any other accessaries and 24 Pin DVI Connector for Digital TMDS peripheral devices (ex,speaker and signal cable) because 15 Pin D-Sub connector for Analog RGB the Tandberg's reguest. MONITOR User s Manual MONITOR User s Manual...
  • Page 4: Out Drawing Of Product

    O ut Drawing of product < Power source connection > < Signal cable connection> D-Sub Analog(Data in) DVI Digital Coaxial S/PDIF Input AC Inlet Audio amp Output AC on/off swith 1. Use 220 V or 110 V. (Free Voltage) 2. Connect monitor and Signal Source via Signal cable 3.
  • Page 5: Name And Function

    Power Management Feature Front side Rear side Power management system of this monitor can not be corresponded with VESA DPMS when the display video signal is none because the specific character of Tandberg system Status LED Sign Power Consumption Normal mode...
  • Page 6: Adjusting Osd

    Adjusting OSD Functions Remote signal wirdow This window is for the receiving signal from remote controller Do not hide this window. Power Indicating LED Green : Normal mode RED : Standby mode On-Screen Display (OSD) Function Button PICTURE MENU : With OSD deactivated, Activated to OSD menu With OSD activated, Exit from main menu or sub menu.
  • Page 7: Standard Signal Table

    Standard Signal Table IMAGE PC Supported Mode 1. IMAGE SIZE Horizontal Frequency Vertical Frequency Clock Frequency Resolution Change the image size (Scaling mode) (Full,Fill aspect, 1:1) (KHz) (Hz) (MHz) 2. SHARPNESS (640 X 480) 25.175 31.5 Set the sharpness of image (Softest,Softest,Normal,Sharp,Sharpest) 3.
  • Page 8: Pin Assignment Table Of Signal Connector

    Pin assignment table of signal connector Pin No. Assignment Pin No. Assignment Pin No. Assignment Ground Speaker ID4 Green Ground-Sync Speaker ID3 Blue Ground Speaker ID2 Ground DDC Data DDC 5V Standby H.Sync Speaker ID1 Speaker Out Left- Cable Connection check V.Sync Ground-Red DDC Clock...
  • Page 9: Specification

    Specification Troubleshooting Model FS-L4201C Power LED is dark. Check the power connection. Type a-si TFT Active matrix No picture. (Refer to page 5) Screen Size 106.7cm (Diagonal) Maximum Resolution 1366 X 768@ 60 Hz Pixel Range 0.681(H) mm X 0.227(V) mm Display Colors 16.7M (RGB 8-bit data)
  • Page 10: Warning

    Warning To prevent damage or loss, please read this warning carefully. Check the resolution and frequency of computer and video card, and set up Double images or When connecting/disconnecting the plug, pull out again in reference to the current monitor 'ghosts'.
  • Page 11 19 - English...
