- Page 1 TANDBERG TFT-LCD Color Monitor FS-L4205C User Guide General Specification...
- Page 2 INFORMATION TO USER : General Specification...
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. Product Drawing------- ------------------------------------------------------------------------------ 1 2. Column Specification- ----------------------------------------------------------------------------- 3 3. Standard signal Table ------------------------------------------------------------------------------4 4. Signal Connector Pin Assignments------------------------------------------------------------5 5. Specification ------------------------------------------------------------------------------------------7 General Specification... -
Page 4: Product Drawing
1. Product Drawing 1. Product Drawing Unit : mm General Specification... -
Page 5: Column Specification
2. Column Specification Power HDMI 1 HDMI 2 HDMI 3 RS-232 RS-232 Specker switch Input Output Input General Specification... -
Page 6: Standard Signal Table
3. Standard signal Table PC Supported Mode Resolution Horizontal Vertical Clock Frequency(KHz) Frequency(Hz) Frequency(MHz) 15.6 13.5 NTSC 15.7 13.5 640x480 29.5 23.625 800x600 31.5 35.4375 800x600 35.5 800x600 48.875 1024x768 47.3 720p(1280x720) 37.5 74.25 720p(1280x720) 74.25 720p(1280x720) 148.5 720p(1280x720) 148.5 1280x1024 1280x768 47.7... -
Page 7: Signal Connector Pin Assignments
4. Signal Connector Pin Assignments 1. HDMI1, HDMI2, HDMI3 Pin No. Assignment Pin No. Assignment TMDS Data2+ Ground_Clock Shield Ground_Data2 TMDS Clock- Shield TMDS Data2- No Connection TMDS Data1+ No Connection Ground_Data1 TMDS SCL Shield TMDS Data1- TMDS SDA TMDS Data0+ Ground Ground_Data0 TMDS Power... - Page 8 3. RS-232 input(D-Sub 9Pin) Pin No. Assignment Pin No. Assignment RS-232 ID No Connection RS-232 RXD Input No Connection RS-232 TXD Input 5V Power No Connection No Connection Ground 4. RS-232 Output(D-Sub 9Pin) Pin No. Assignment Pin No. Assignment No Connection No Connection RS-232 RXD Out No Connection...
-
Page 9: Specification
5. Specification 5. Specification Model FS-L4205C Type A-si TFT Active matrix Screen size 106.7Cm (Diagonal) Maximum Resolution 1920X1080@60Hz Pixel pitch 0.4845(H)mmX0.4845 (V)mm LCD PANEL Display colors 1.06Billon (RGB 10-bit data) Contrast Ratio(Typ.) 1000:1 Viewing Angle(Typ.) 89/89/89/89 Response Time(Typ.) Luminance(Typ.) 700cd/m2...
