Summary of Contents for Powerware 3105
- Page 1 Product Catalog North America March 2005...
- Page 2 Eaton offers a comprehensive selection of Powerware power management solutions to grow with your changing requirements in today's digital networking economy. From the desktop to the data center, we deliver a complete solution through our line of Powerware AC and DC power systems, connectivity options, software, and world-class service offerings. Whatever your application, Eaton is your one-stop partner for all your power protection needs.
- Page 3 The nine power problems listed below are potentially harmful to both your data and your hardware. Powerware products offer three levels of power protec- tion: Series 3, Series 5, and Series 9. Based on the parameters defined by your application, you can select an uninterruptible power system (UPS) from the series that best matches your power protection needs.
-
Page 4: Load Segments
Using Powerware LanSafe™ power management software, you can independently control load segments, which are groups of recep- tacles on the rear panel of the Powerware UPS. This feature, avail- able on Powerware 5115RM, 5125, 9120 and 9125 models, enables you to manage scheduled shutdowns and sequential startups of protected loads. - Page 5 Powerware Single-phase UPS Products Powerware Series 3 Single-phase UPS Power Power Power Failure Surge Powerware 3105 Features and Benefits • Protect small office and home 350–700 VA office equipment from power outages, surges, and sags • Save space with a compact...
- Page 6 • Delivers smooth, continuous power with pure sine wave output • Protects your equipment from power fluctuations with Buck and Boost voltage regulation EATON CORPORATION Powerware Product Catalog Over- voltage • Protects equipment connected by network or phone wiring from “back door” power...
- Page 7 Powerware Single-phase UPS Products Powerware 5125 Features and Benefits • Extends battery service life and 1000–2200 VA provides advanced warning of the end of useful battery life with ABM Technology • Prolongs backup time with Extended Battery Modules • Extends battery backup time...
- Page 8 ABM Technology • Preserves battery power through a wide input voltage range • 5U models (5000–6000 VA) deliver maximum power density EATON CORPORATION Powerware Product Catalog Over- Harmonic Line Switching Frequency Distortion voltage...
- Page 9 8–15 kVA in less space with a 0.9 power factor—protecting more equip- ment and leaving more room for expansion • Supports Powerware Hot Sync for paralleling of multiple mod- ules for redundancy or extra capacity • Increases battery life through...
- Page 10 PDU was designed to be fully compatible with most single phase rackmount UPSs and features standard surge and spike protec- tion. Since the Powerware PDU is compatible with a variety of Powerware equipment and other manufacturer’s equipment, the installation process is quick and easy. With the Powerware PDU, it’s never been a more convenient time to complete your total...
- Page 11 Powerware three-phase solu- battery maintenance. Available tions are backed by a best-in- on almost all of the Powerware class services organization. 9390s, ABM Technology uses More than 300 North American an innovative three-stage...
- Page 12 Powerware 9330 10–40 kVA sets the standard for availability. By incorporating many features found only in UPS products at a higher kVA range, the Powerware 9330 offers the highest level of reliability of any UPS in its class. Features and Benefits •...
- Page 13 Three-phase UPS Products Powerware 9390 Built upon 40 years of power management experience, perfor- mance and continuous innovation, the Powerware 9390 combines 40–160 kVA extensive customer research with technical innovation to deliver the next-generation of power protection. The result is a UPS that...
- Page 14 UPS designed for an office or computer room to provide optimal protection. To meet the demands of these applications, Eaton offers an industrial Powerware BP Series that is built to deliver optimal performance in rugged locations.
- Page 15 The Powerware STS is a high-speed switch that can transfer electrical loads from one AC power source to another in a fraction of a single electrical cycle. The Powerware STS eliminates the chance of a loss of power to critical loads by properly coordinating with the electrical distribution system. During a fault condition, the STS continues to conduct current, allowing downstream circuit breakers to work selectively.
-
Page 16: Surge Protection
Other Power Protection Products DC Power Systems Eaton provides a range of Powerware DC power solutions to provide high-reliability and cost- effective 48V battery-backed DC power for your data network and telecommunications equip- ment. Eaton offers the industry’s only custom-designed solution for providing long-duration backup 48V DC power to power-over-Ethernet devices compliant with the new IEEE standard 802.3af. - Page 17 Powerware Single- and Three-phase Software Products Delivering a full line of Powerware software, strategic equipment, and connectivity devices, Eaton pro- vides the perfect solution. Implementing these key components along with our UPS products allows you to get the most out of your power protection system.
- Page 18 • Extensive, multi-vendor device-driven library interfaces so you can manage all your infrastructure equipment from a single system EATON CORPORATION Powerware Product Catalog • Displays vital UPS information with an intuitive, graphic format for non-technical personnel • Compiles a full year of UPS...
- Page 19 CELLWATCH ies to the point where they are unable to provide adequate backup Software time for your UPS or fail completely. Powerware CELLWATCH soft- Advanced monitoring of ware provides the solution to ensure your batteries are continuously your UPS batteries for monitored and mission-critical systems are fully protected.
- Page 20 Status@aGlance page from Powerware’s new LanSafe v5 software Powerware Powerware Extensions for Network Management Systems simplify Extensions UPS network management tasks by allowing you to monitor, diag- for Network nose, configure, set alarms, schedule self-tests, check battery, gather...
- Page 21 Eaton's Powerware offering additionally includes connectivity products - accessory hardware options used to link Powerware UPS products to external communication devices. Eaton provides a variety of connectiv- ity products to ensure communication compatibility with a variety of external devices through the Web, serial, USB, relays, or SNMP.
- Page 22 Card ® additional X-Slot cards. The Expansion Chassis is pre-configured Increasing the flexibil- with the Powerware Modbus Card, which serves as the interface to ity and effectiveness Modbus networks and as the integral communications controller for of power protection the remaining two slots.
- Page 23 Eaton Services for Powerware Solutions Eaton provides world-class service for all Powerware AC, DC, software, and connectivity products. With over 300 customer service engineers (CSE) in North America and 1,200 international authorized service providers, we have more service personnel than any other UPS manufacturer. We are there when and...
- Page 24 India: 91.11.2649.9414 to 18 Germany: 49.7841.666.0 Singapore/SEA: 65.6829.8888 Italy: 39.02.66.04.05.40 Norway: 47.23.03.65.50 Sweden: 46.8.598.940.00 Powerware, CoreLogic, ABM, FERRUPS, United Kingdom: 44.1753.608.700 FORESEER, PowerVision, PowerPass, DC Expert, LanSafe, ConnectUPS, PowerHandler and CELLWATCH are trade names, trademarks, and/or service marks of Eaton Power Quality Corporation or its subsidiaries and affiliates.
