Model 28052 Se ries
5.8GHz DECT Multi-handset
Speakerphone/Answering System
User's Guide
Your new GE telephone system is EXPANDABLE up to a total of 6 handsets (by purchase of
optional Model 28002 handset with charge cradle)
Equipment Approval Information
Your telephone equipment is approved for connection to the Public Switched Telephone Network and is in compliance with
parts 15 and 68, FCC Rules and Regulations and the Technical Requirements for Telephone Terminal Equipment
published by ACTA.
1 Notification to the Local Telephone Company
On the bottom of this equipment is a label indicating, among other information, the US number and Ringer Equivalence
Number (REN) for the equipment. You must, upon request, provide this information to your telephone company.
The REN is useful in determining the number of devices you may connect to your telephone line and still have all of
these devices ring when your telephone number is called. In most (but not all) areas, the sum of the RENs of all devices
connected to one line should not exceed 5. To be certain of the number of devices you may connect to your line as
determined by the REN, you should contact your local telephone company.
A plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the
applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant telephone cord and modular plug is
provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. See
installation instructions for details.
Notes
• This equipment may not be used on coin service provided by the telephone company.
• Party lines are subject to state tariffs, and therefore, you may not be able to use your own telephone equipment if you
are on a party line. Check with your local telephone company.
• Notice must be given to the telephone company upon permanent disconnection of your telephone from your line.
• If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of this
product does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult
your telephone company or a qualified installer.
Model 28052
XXXXXXXX
xx-xx
Printed in China
US Number is located on the cabinet bottom.
REN Number is located on the cabinet bottom.
Advertisement
Table of Contents
Related Manuals for GE 28052EE2-A
Summary of Contents for GE 28052EE2-A
-
Page 1: Equipment Approval Information
5.8GHz DECT Multi-handset Speakerphone/Answering System User’s Guide Your new GE telephone system is EXPANDABLE up to a total of 6 handsets (by purchase of optional Model 28002 handset with charge cradle) Equipment Approval Information Your telephone equipment is approved for connection to the Public Switched Telephone Network and is in compliance with parts 15 and 68, FCC Rules and Regulations and the Technical Requirements for Telephone Terminal Equipment published by ACTA. -
Page 2: Interference Information
2 Rights of the Telephone Company Should your equipment cause trouble on y our line which may harm the telephone network, the telephone company shall, where practicable, notify you that temporary discontinuance of service may be required. Where prior notice is not practicable and the circumstances warrant such action, the telephone company may temporarily discontinue service immediately. -
Page 3: Before You Begin
Parts Checklist (for model 28052EE1-A) Make sure your package includes the items shown here. For Model 28052EE2-A there will be ONE additional handset, charge cradle, belt clip, battery pack and cover than shown above. For Model 28052EE3-A there will be TWO additional handsets, charge cradles, belt clips, battery packs and covers than shown above. -
Page 4: Handset Layout
Important Installation Guidelines • Avoid sources of noise and heat, such as motors, fluorescent lighting, microwave ovens, heating appliances and direct sunlight. • Avoid areas of excessive dust, moisture and low temperature. • Avoid other cordless telephones or personal computers. •... -
Page 5: Installing The Phone
Installing the phone Installing the Handset Battery NOTE: You must connect the handset battery before use. CAUTION: To reduce the risk of fire or personal injury, use only the Thomson Inc. approved model Nickel-metal Hydride battery (Ni-MH), which is compatible with this unit. 1. -
Page 6: Programming The Telephone
• Press the LANGUAGE button on front of base to change to the FRENCH voice prompt. The unit announces “OPTION FRANCAISE “ and Fr shows in the message counter. • Press the LANGUAGE button again to change to the SPANISH voice prompt. The unit announces “SELECCION ESPANOL”... - Page 7 (▼ or ▲) 3. Press the cid/vol button to scroll to ROOM MONITOR. 4. Press mute/menu button to enter ROOM MONITOR menu, ROOM MONITOR EXTENSION? shows in the display. 5. Use the touch tone pad to enter the handset number to be monitored, either 1 or 2. NOTE: When this phone system is expanded (up to 6 handsets by purchase of optional Model 28002 handset with recharge cradle), handsets are named HANDSET 1, HANDSET 2, HANDSET 3, HANDSET 4, HANDSET 5 and HANDSET 6 respectively.
- Page 8 VIP Melody This features allows you to assign a specific melody to someone you want to get your attention when the person calls. When a VIP melody is assigned and that person calls, the unit rings the normal ring for the first ring and then follows with VIP melody ring.
- Page 9 NOTE: If you select Toll Saver (TS) the unit answers after the 3rd ring if there are NEW messages, OR the unit answers after the 5th ring if there are NO new messages. This allows user to access their answerer from another location and then hang up after 4 rings to save long distance charges.
-
Page 10: Telephone Operation
7. If you select YES, press the mute/menu button to confirm. You will hear a confirmation tone. Then HANDSET X DEREGISTERED shows in the display to confirm the handset is deregistered. NOTE: When you complete the de-registration process, HANDSET NEEDS REGISTRATION shows in the display. - Page 11 Call Timer After you press the talk/flash button on the handset, the built-in call timer shows on the display and counts the length of time of the call in minutes and seconds. Auto Standby If you place the handset in the cradle while the handset is off the hook (during a call), the call is automatically disconnected. Ringer HI/LOW/OFF (Shortcut) There are two ways to set the ringer to HI/LOW/OFF.
- Page 12 1. During a conversation, press the MUTE button on base or mute/menu button on the cordless handset. MUTE ON shows in the display. 2. Press the MUTE button on base or mute/menu button on the cordless handset to cancel and return to your phone conversation.
- Page 13 Provided you subscribe to Call Waiting Caller ID service from your phone company; if you receive an incoming call and you are using the GE multi handset system, a beep indicates the presence of a Call Waiting call on the line. The Call Waiting Caller ID information will be displayed and stored in the history of all handsets in the system.
- Page 14 Storing CID Records in phonebook You may also store CID information in the phonebook. NOTE: It is important that you format CID records correctly BEFORE storing in phonebook as you cannot reformat CID records stored in phonebook. 1. Make sure the phone is OFF (not in talk mode). 2.
-
Page 15: Answering System Operation
3. Use the cid/vol (▼ or ▲) buttons to scroll to DELETE RECORDS. 4. Press the mute/menu button to confirm, display will show the records. 5. Use the cid/vol (▼ or ▲) buttons or key in alphabet to move to desired record, press the delete/int/conf button, DELETE? shows on the display. -
Page 16: Remote Access
Erasing Messages You may erase messages in the following three ways: To erase a message while it is playing 1. Press and release the PLAY/STOP button. 2. Press the repeat or SKIP buttons to select and play the message you want to erase. 3. -
Page 17: Changing The Battery
Memory Full When answering system memory is full, the system answers after 10 rings, beeps and waits for you to enter the 3-digit security code. If you don’t enter the security code within 8 seconds, the phone hangs up. You should erase some messages so the answering system can record new messages. NOTE: The unit also answers after the 10th ring if it is turned off. -
Page 18: Handset Sound Signals
Handset Sound Signals__________________________________ Troubleshooting Guide__________________________________ Telephone Solutions No dial tone • Check or repeat installation steps: Make sure the base power cord is connected to a working electrical outlet. Make sure the telephone line cord is connected to the base and the wall jack. •... -
Page 19: General Product Care
• Charge indicator fails to turn on General Product Care__________________________________ To keep your unit working and looking good, follow these guidelines: • Avoid dropping the handset, as well as other rough treatment to the phone. • Clean the phone with a soft cloth. •... -
Page 20: Accessory Information
Accessory Information___________________________________ DESCRIPTION MODEL NO. Handset Replacement Battery AC Power converter Belt Clip Belt Clip Handset charge cradle To place order, have your Visa, MasterCard, or Discover Card ready and call toll-free 1-800-338-0376. A shipping and handling fee will be charged upon ordering. We are required by law to collect appropriate sales tax for each individual state, country, and locality to which the merchandise is being sent. - Page 21 If you purchased your product outside the USA: • This warranty does not apply. Contact your dealer for warranty information. Instructions For Optional/Additional Handset(s)_____ This phone is EXPANDABLE up to a total of 6 handsets (by additional purchase of the optional Model 28002 handset with charge cradle).
- Page 22 Extra Charging Cradle 1. Plug the AC power converter of the extra charging cradle into the electrical outlet. 2. Place the handset in the extra charging cradle. The charge indicator turns on, verifying the battery is charging. 3. Allow the phone to charge for 16 hours. Registration YOU MUST REGISTER THE HANDSET TO THE MAIN BASE BEFORE USE! After the optional handset has charged for 16 hours on the extra charger, HANDSET NEEDS REGISTRATION shows in...
