MODEL W1851
10" HYBRID TABLE SAW 
/EXTENSION TABLE
W
OWNER'S MANUAL
(FOR MODELS MANUFACTURED SINCE 10/17)
Phone: (360) 734-3482 • Online Technical Support: techsupport@woodstockint.com
COPYRIGHT © JULY, 2017 BY WOODSTOCK INTERNATIONAL, INC. REVISED DECEMBER, 2017 (HE)
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT
THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC.
#19122BL  Printed in China

Advertisement

Table of Contents
loading

Related Manuals for Shop fox W1851

Summary of Contents for Shop fox W1851

  • Page 1   MODEL W1851 10" HYBRID TABLE SAW  /EXTENSION TABLE OWNER'S MANUAL (FOR MODELS MANUFACTURED SINCE 10/17) Phone: (360) 734-3482 • Online Technical Support: techsupport@woodstockint.com COPYRIGHT © JULY, 2017 BY WOODSTOCK INTERNATIONAL, INC. REVISED DECEMBER, 2017 (HE) WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC. #19122BL  Printed in China...
  • Page 2 This manual provides critical safety instructions on the proper setup, operation, maintenance, and service of this machine/tool. Save this document, refer to it often, and use it to instruct other operators. Failure to read, understand and follow the instructions in this manual may result in fire or serious personal injury—including amputation, electrocution, or death.

  • Page 3: Table Of Contents

    Contents INTRODUCTION........2 SHOP-MADE.SAFETY.ACCESSORIES..... 55 Contact Info ........2 Featherboards ........55 Manual Accuracy ........2 Push Sticks ........58 Controls & Components ......7 Push Blocks ........59 Narrow-Rip Auxiliary Fence & Push Block .. 60 SAFETY..........8 Outfeed & Support Tables ....62 Standard Machinery Safety Instructions ..

  • Page 4: Introduction

    Model W1851 (For Machines Mfd. Since 10/17) INTRODUCTION Contact.Info Manual.Accuracy We are committed to customer satisfaction. If We are proud to provide a high-quality owner’s you have any questions or need help, use the manual with your new machine! information below to contact us.
  • Page 5 Plug Included....................... Yes Included Plug Type..................6‐20 for 230V Recommended Plug Type................5‐20 for 115V Switch Type......START/STOP Push Button w/Large Shut‐Off Paddle & Disabling Pin Voltage Conversion Kit................ X1851224X for 115V Model W1851 Machine Specifications, Page 1 of 3...
  • Page 6 Fence Rail Width................... 2 in. Fence Rail Height..................1‐5/8 in. Miter Gauge Information Miter Gauge Slot Type.................. T‐Slot Miter Gauge Slot Size Width................3/4 in. Miter Gauge Slot Size Height................3/8 in. Model W1851 Machine Specifications, Page 2 of 3...
  • Page 7 Durable Powder‐Coated Finish Deluxe 2‐Position (High‐Low) Aluminum Rip Fence Easy‐Glide Fence System with Added Micro‐Adjustment Controls Standard & Dado Table Inserts Built‐In Dust Port on Blade Guard Included 10" x 40T Carbide‐Tipped Blade Model W1851 Machine Specifications, Page 3 of 3...
  • Page 8 Model W1851 (For Machines Mfd. Since 10/17) Identification Become familiar with the names and locations of the controls and features shown below to better understand the instructions in this manual. Left Miter Miter Blade ⁄ " Dust Dust Collection Extension...

  • Page 9: Controls & Components

    Model W1851 (For Machines Mfd. Since 10/17) Controls.&.Components Refer to Figures 1–4.and the following descriptions to become familiar with the basic controls of this machine. A. START/STOP Switch: Starts and stops the motor. The switch can be disabled for safety by inserting the disabling pin or a padlock (not included) through the START button.

  • Page 10: Safety

    Model W1851 (For Machines Mfd. Since 10/17) SAFETY SAFETY For.Your.Own.Safety, Read.Manual.Before.Operating.Machine The. purpose. of. safety. symbols. is. to. attract. your. attention. to. possible. hazardous. conditions.. This. manual.uses.a.series.of.symbols.and.signal.words.intended.to.convey.the.level.of.importance.of.the. safety.messages..The.progression.of.symbols.is.described.below..Remember.that.safety.messages.by. themselves. do. not. eliminate. danger. and. are. not. a. substitute. for. proper. accident. prevention. mea- sures—this.responsibility.is.ultimately.up.to.the.operator!
  • Page 11 Model W1851 (For Machines Mfd. Since 10/17) WEARING.PROPER.APPAREL..Do not wear FORCING.MACHINERY..Do not force machine. It clothing, apparel, or jewelry that can become will do the job safer and better at the rate for entangled in moving parts. Always tie back which it was designed.

  • Page 12: Additional Safety For Table Saws

    Model W1851 (For Machines Mfd. Since 10/17) Additional.Safety.for.Table.Saws Serious cuts, amputation, or death can occur from contact with rotating saw blade during operation. Workpieces, broken blades, or flying particles thrown by blade can blind or strike operators or bystanders with deadly force. To reduce the risk of these hazards, operator and bystanders MUST completely heed the hazards and warnings below.

  • Page 13: Preventing Kickback

    Model W1851 (For Machines Mfd. Since 10/17) Preventing.Kickback • Never move the workpiece backwards or try to back it out of a cut while the blade is moving. If you cannot complete a cut for Below are ways to avoid the most common...

  • Page 14: Glossary Of Terms

    Model W1851 (For Machines Mfd. Since 10/17) Glossary.of.Terms The following is a list of common definitions, terms and phrases used throughout this manual as they relate to this table saw and woodworking in general. Become familiar with these terms for assembling, adjusting or operating this machine.

  • Page 15: Electrical

    Model W1851 (For Machines Mfd. Since 10/17) ELECTRICAL Circuit.Requirements This machine must be connected to the correct size and type of power supply circuit, or fire or electrical damage may occur. Read through this section to determine if an The. machine. must. be. properly. set. up.

  • Page 16: Grounding Requirements

    Model W1851 (For Machines Mfd. Since 10/17) Grounding.Requirements This machine MUST be grounded. In the event of certain types of malfunctions or breakdowns, grounding provides a path of least resistance for electric current to travel—in The. machine. must. be. properly. set. up.

  • Page 17: Converting Voltage To 115V

    Model W1851 (For Machines Mfd. Since 10/17) Converting.Voltage.to. 115V 115V/230V The voltage conversion MUST be performed by an MOTOR electrician or qualified service personnel. The voltage conversion procedure consists of rewiring the motor and installing the correct plug. A wiring diagram is...

  • Page 18: Setup

    Model W1851 (For Machines Mfd. Since 10/17) SETUP Unpacking This machine has been carefully packaged for safe This machine presents transportation. If you notice the machine has been serious injury hazards damaged during shipping, please contact your authorized to untrained users. Read Shop Fox dealer immediately.

  • Page 19: Inventory

    Model W1851 (For Machines Mfd. Since 10/17) Inventory The following is a list of items shipped with your machine. Before beginning setup, lay these items out and inventory them. Note: If you cannot find an item on this list, carefully check around/inside the machine and packaging materials.
  • Page 20 Model W1851 (For Machines Mfd. Since 10/17) Box.Contents.Cont'd (Figures.13–14) ....Qty Front Rail Tube 62" ........1 U. Front Rail Tape Scale ........1 Front Rail 57"..........1 W. Rear Rail 55" ..........1 X. Fence Assembly ..........1 Y. Extension Table ..........1 Fasteners (Figure 15) ........Qty Z.

  • Page 21: Hardware Recognition Chart

    Model W1851 (For Machines Mfd. Since 10/17) Hardware.Recognition.Chart USE THIS CHART TO IDENTIFY HARDWARE DURING THE INVENTORY/ASSEMBLY ⁄ " ⁄ " ⁄ " PROCESS. ⁄ " ⁄ " ⁄ " ⁄ " ⁄ " ⁄ " ⁄ " ⁄ "...

  • Page 22: Cleaning Machine

    Model W1851 (For Machines Mfd. Since 10/17) Cleaning.Machine To prevent corrosion during shipment and storage of your machine, the factory has coated the bare metal surfaces of your machine with a heavy-duty rust prevention compound. Gasoline.and.petroleum. products.have.low.flash. If you are unprepared or impatient, this compound can points.and.can.explode.

  • Page 23: Machine Placement

    Model W1851 (For Machines Mfd. Since 10/17) Machine.Placement Weight.Load Physical.Environment Refer to the Machine.Specifications for the The physical environment where your machine is weight of your machine. Make sure that the operated is important for safe operation and the surface upon which the machine is placed will longevity of its components.

  • Page 24: Assembly

    Model W1851 (For Machines Mfd. Since 10/17) Assembly Before beginning the assembly process, refer to Items. Needed.for.Setup and gather everything you need. Ensure all parts have been properly cleaned of any heavy-duty rust-preventative applied at the factory (if applicable). Be sure to complete all steps in the assembly procedure prior to performing the Test.Run.
  • Page 25 Model W1851 (For Machines Mfd. Since 10/17) 5. Thread a handwheel lock knob into center of each Handwheel handwheel and tighten, then thread a handle onto Lock Knob each handwheel and tighten (see Figure 20). 6. Inspect extension wings and main table mating surfaces for burrs or foreign materials that may inhibit assembly.
  • Page 26 Model W1851 (For Machines Mfd. Since 10/17) 9. Attach front rail to table and extension wings with Front (4) M8-1.25 x 35 flat head screws, 8mm flat washers, Rail 8mm lock washers, and M8-1.25 hex nuts, as shown Equal in Figure 24. Make sure top of rail is parallel with table top before fully tightening fasteners.
  • Page 27 Model W1851 (For Machines Mfd. Since 10/17) 14. Attach extension table to front rail with (2) M8-1.25 x 20 flat head cap screws, 8mm flat washers, 8mm lock washers, and M8-1.25 hex nuts (see Figure.27). 15. Attach extension table to rear rail with (2) M8-1.25 x 25 cap screws, (4) 8mm flat washers, (2) 8mm lock washers, and (2) M8-1.25 hex nuts (see Figure.27).
  • Page 28 Model W1851 (For Machines Mfd. Since 10/17) 20. Slide fence up against right hand edge of miter slot, and lock it in place. Examine how fence lines up Fence with miter slot (see Figure.30). Miter Slot Note: It is permissible for back of fence to pivot outward not more than ⁄...
  • Page 29 Model W1851 (For Machines Mfd. Since 10/17) 24. Re-install fence, move it over to just touch blade, Indicator Line and verify that indicator line is directly over "0" mark. — If you need to correct position of indicator line, loosen button head screws on pointer window, adjust pointer window so line is over "0"...

  • Page 30: Dust Collection

    Model W1851 (For Machines Mfd. Since 10/17) Dust.Collection Recommended.CFM.at.Dust.Port:....500.CFM+ Do not confuse this CFM recommendation with the rating of the dust collector. To determine the CFM at the dust port, you must consider these variables: (1) CFM rating of...

  • Page 31: Test Run

    Model W1851 (For Machines Mfd. Since 10/17) Test.Run Once assembly is complete, test run the machine to ensure it is properly connected to power and safety components are functioning properly. Serious. injury. or. death. can. result. from. using. this. machine. BEFORE.

  • Page 32: Operations

    Model W1851 (For Machines Mfd. Since 10/17) OPERATIONS General This machine will perform many types of operations that are beyond the scope of this manual. Many of these operations can be dangerous or deadly if performed incorrectly. The instructions in this section are written with the understanding that the operator has the necessary knowledge and skills to operate this machine.

  • Page 33: Workpiece Inspection

    Model W1851 (For Machines Mfd. Since 10/17) Workpiece.Inspection Some workpieces are not safe to cut on this Large/Loose.Knots. Loose knots can become • machine or may need to be modified before they dislodged during the cutting operation. can be safely cut.

  • Page 34: Non-Through & Through Cuts

    Model W1851 (For Machines Mfd. Since 10/17) Non-Through.&.Through. Cuts Non-Through.Cuts A non-through cut is a sawing operation where the blade Fence does not protrude above the top face of the wood stock, Saw Blade as shown in Figure.39. Workpiece Examples of non-through cuts include dadoes and rabbets.

  • Page 35: Blade Size Requirements

    Model W1851 (For Machines Mfd. Since 10/17) Blade.Size.Requirements When choosing a main blade, make sure the blade size meets the requirements listed below. The thickness of the blade body and teeth can be measured with calipers or any precision measuring device.
  • Page 36 Model W1851 (For Machines Mfd. Since 10/17) Laminate.Blade.Features.(Figure.44): • Best for cutting plywood or veneer • 40-80 teeth • Triple chip tooth profile • Very shallow gullet Triple Chip Thin.Kerf.Blade: A blade with thinner kerf than a Blade standard blade. Since the spreader/riving knife included...

  • Page 37: Blade Installation

    Model W1851 (For Machines Mfd. Since 10/17) Blade.Installation Review this section, even if your saw blade came pre- installed. Items.Needed. To.reduce.risk.of.injury,. Leather Work Gloves ........1 Pair always. disconnect. Arbor Wrench ............1 power. to. saw. before. changing. blades.. Since. To install blade, do these steps: the.blade.is.sharp,.use.
  • Page 38 Tapered Edge Recess Model W1851 (For Machines Mfd. Since 10/17) Arbor Nut 5. Install new blade, flange, and arbor nut on arbor, as Threads Tapered Edge shown in Figure.48, with upper teeth facing front of Arbor Nut Flange saw. Ensure the tapered edge of the flange faces the...

  • Page 39: Blade Guard Assembly

    Model W1851 (For Machines Mfd. Since 10/17) Blade.Guard.Assembly The term "blade guard" refers to the assembly that consists of the clear polycarbonate shield and dust Dust Enclosure enclosure, the spreader, and the anti-kickback pawls on each side of the spreader (see Figure.49). Each of these...
  • Page 40 Model W1851 (For Machines Mfd. Since 10/17) 4. Slide blade guard spreader all the way down into adjustment block, then rotate knurled knob so it Flat Head Cap disengages bracket and locking pin engages hole in Screw (1 of 4) center of spreader.
  • Page 41 Model W1851 (For Machines Mfd. Since 10/17) Anti-Kickback.Pawls Arresting Hooks The anti-kickback pawls allow the workpiece to travel in only one direction. If the workpiece moves backwards, such as during a kickback, the pawls will dig into the workpiece to slow or stop it.

  • Page 42: Riving Knife

    Model W1851 (For Machines Mfd. Since 10/17) Riving.Knife The riving knife works in the same manner as the spreader on the blade guard assembly. It is a metal plate Minimum 1mm Height Difference that prevents the newly cut workpiece from pinching the Maximum 5mm backside of the blade and causing kickback.

  • Page 43: Ripping

    Model W1851 (For Machines Mfd. Since 10/17) Ripping Ripping means cutting with the grain of a natural wood workpiece. In man-made materials such as MDF or plywood, ripping simply means cutting lengthwise. Serious. injury. can. be. caused. by. kickback.. Kickback. is. a. high-speed.

  • Page 44: Crosscutting

    Model W1851 (For Machines Mfd. Since 10/17) Crosscutting "Crosscutting" means cutting across the grain of a natural wood workpiece, usually with a miter saw. In other man- made materials, such as MDF or plywood, crosscutting means cutting across the width of the workpiece.

  • Page 45: Miter Cuts

    Model W1851 (For Machines Mfd. Since 10/17) Miter.Cuts A miter cut is an angled crosscut. Miters are usually cut in the same manner as crosscuts, using the miter gauge and a predetermined mark on the workpiece. To.perform.a.miter.cut,.do.these.steps: 1.. Ensure that blade guard/spreader is installed.

  • Page 46: Flip Stop

    Model W1851 (For Machines Mfd. Since 10/17) Flip.Stop The flip stop can be positioned anywhere along the top of the miter fence and secured in place with a lock lever Flip Stop Lock (see Figure.63), the same distance away from the blade Lever as your desired width of cut.

  • Page 47: Dado Cutting

    Figure.65 shows a cutaway view of a dado cut being made with a dado blade. Fence The Model W1851 can accommodate dado blades up to Workpiece 10" in diameter. We recommend keeping the riving knife installed if using a 10" diameter dado blade. Although the riving knife thickness will not match the dado blade Figure.65..Example of a dado being cut...
  • Page 48 Model W1851 (For Machines Mfd. Since 10/17) Cutting.Dadoes.with.a.Dado.Blade Because dado blades are much wider than standard blades, they place a greater amount of force against the Never try to cut a warped board by workpiece when cutting. This additional force increases pushing it flat against the table.
  • Page 49 Model W1851 (For Machines Mfd. Since 10/17) Cutting.Dadoes.with.a.Standard.Blade A ripping blade (described on Page.33) is typically the best blade to use when cutting dadoes with a standard Blade Cut 1 blade because it removes sawdust very efficiently. Fence Workpiece To.use.standard.saw.blade.to.cut.dadoes,.do.these.

  • Page 50: Rabbet Cutting

    Model W1851 (For Machines Mfd. Since 10/17) Rabbet.Cutting Commonly used in furniture joinery, a rabbet cut is an L-shaped groove cut in the edge of the workpiece. Rabbets can be cut with either a dado blade or a standard Dado. blades. have. a. higher. risk. of.
  • Page 51 Model W1851 (For Machines Mfd. Since 10/17) Cutting.Rabbets.with.a.Standard.Blade A ripping blade is typically the best blade to use for cutting rabbets when using a standard blade because it removes sawdust very efficiently. (See Page.33 for blade details.) Also, a sacrificial fence is not required when cutting rabbets with a standard blade.

  • Page 52: Resawing

    Model W1851 (For Machines Mfd. Since 10/17) Resawing Resawing is the process of cutting a thick piece of stock into one or more thinner pieces. Resawing. operations. require. proper. IMPORTANT: Although resawing can be done with a table procedures. to. avoid. serious. injury.
  • Page 53 Model W1851 (For Machines Mfd. Since 10/17) To.build.a.resaw.barrier,.do.these.steps: #8 x 2" ⁄ " 1. Cut your wood pieces to specified size. If you are Wood Screw using hardwood, cut pieces oversize, then joint and plane them to correct size to make sure they are square and flat.
  • Page 54 Model W1851 (For Machines Mfd. Since 10/17) To install an auxiliary fence, do these steps: Knob Flat Washer (1 of 3 1. Cut auxiliary fence board to size. If you are using hardwood, cut board oversize, then joint and plane board to correct size to make sure board is square and flat.
  • Page 55 Model W1851 (For Machines Mfd. Since 10/17) Resawing.Operations The table saw motor is pushed to its limits when resawing. If the motor starts to bog down, slow down You. may. experience. kickback. during. your feed rate. Motor overloading and blade wear can this.procedure..Stand.to.the.side.of.the.
  • Page 56 Model W1851 (For Machines Mfd. Since 10/17) 8. Plug in table saw, turn it ON, and use a push stick or push block to feed workpiece through blade, using a slow and steady feed rate. The. danger. of. kickback. increases.

  • Page 57: Shop-Made.safety.accessories

    Model W1851 (For Machines Mfd. Since 10/17) SHOP-MADE.SAFETY.ACCESSORIES Featherboards Easily made from scrap stock, featherboards provide an We.recommend.using.a.bandsaw. added degree of protection against kickback, especially for.making.fingers.in.the.next.step. when used together with push sticks. They also maintain because.it.tends.to.be.safer..A.table. pressure on the workpiece to keep it against the fence saw.can.be.used,.but.it.will.over-cut.
  • Page 58 Model W1851 (For Machines Mfd. Since 10/17) 4. Rout a ⁄ "– ⁄ " wide slot 4"–5" long in workpiece and 1"–2" from short end of featherboard (see Figure. "— " Slot 82). 1"—2" 5. Cut a miter bar approximately 5" long that will fit in table miter slot, as shown in Figure.83.
  • Page 59 Model W1851 (For Machines Mfd. Since 10/17) Mounting.Featherboard.w/Clamps 1. Lower saw blade, then adjust fence to desired width The. featherboard. should. be. placed. and secure it. firmly. enough. against. the. workpiece. to. keep. it. against. the. fence. but. not. 2. Place workpiece against fence, making sure it is 1" in so.

  • Page 60: Push Sticks

    Model W1851 (For Machines Mfd. Since 10/17) Push.Sticks Supporting: A second push stick can be used to keep the workpiece firmly against the fence while cutting. When using a push stick in this When used correctly, push sticks reduce the risk manner, only apply pressure before the blade;...

  • Page 61: Push Blocks

    Model W1851 (For Machines Mfd. Since 10/17) Push.Blocks The notched end of the push block is then used to push the workpiece the rest of the way through the cut, keeping the operator's hands at When used correctly, a push block reduces a safe distance from the blade.

  • Page 62: Narrow-Rip Auxiliary Fence & Push Block

    Model W1851 (For Machines Mfd. Since 10/17) Narrow-Rip.Auxiliary. Fence.&.Push.Block There are designs for hundreds of specialty jigs that can be found in books, trade magazines, and on the internet. ⁄ " Hardwood These types of jigs can greatly improve the safety and Length of Table consistency of cuts.
  • Page 63 Model W1851 (For Machines Mfd. Since 10/17) Using.Auxiliary.Fence.and.Push.Block Auxilliary Fence 1. Place auxiliary fence on table and clamp it to fence at both ends, then adjust distance between auxiliary fence and blade—this determines how wide Blade workpiece will be ripped (see Figure.96).

  • Page 64: Outfeed & Support Tables

    Model W1851 (For Machines Mfd. Since 10/17) Outfeed.&.Support.Tables One of the best accessories for improving the safety and Support Outfeed ease of using a table saw is simply placing a large table Table Table (outfeed table) behind the saw to catch the workpiece (see Figure.99).

  • Page 65: Accessories

    Model W1851 (For Machines Mfd. Since 10/17) ACCESSORIES Table.Saw.Accessories The following table saw accessories may be available through your local Woodstock International Inc. Dealer. If you do not have a dealer in your area, these products are also available through online dealers.
  • Page 66 Model W1851 (For Machines Mfd. Since 10/17) D4061—5-Pc..Safety.Kit. Comes with four table saw jigs, essential for safe operation. Includes two push blocks, push stick, featherboard, and combination saw and router gauge. Featherboard fits ⁄ " x ⁄ " miter slots.
  • Page 67 Model W1851 (For Machines Mfd. Since 10/17) Power.Feeders.will make light work out of those big jobs with greater accuracy and safety. The.Model.W1765.features a ⁄ HP, 110V, 1.8 Amp motor. The Model.W1766 features a ⁄ 220V, 4 Amp motor. Both models feature forward/reverse, X/Y/Z adjustment, multiple feed speeds, and synthetic rubber wheels.

  • Page 68: Maintenance

    Lubricate leadscrew (Page 67). • Cleaning.&.Protecting Cleaning the Model W1851 is relatively easy. Vacuum excess wood chips and sawdust, and wipe off the remaining dust with a dry cloth. If any resin has built up, use a resin- dissolving cleaner to remove it.

  • Page 69: Lubrication

    Model W1851 (For Machines Mfd. Since 10/17) Lubrication It is essential to clean components before lubricating them because dust and chips build up on lubricated components and make them hard to move. Simply adding more grease to them will not yield smooth moving components.

  • Page 70: Service

    Model W1851 (For Machines Mfd. Since 10/17) SERVICE General This section covers the most common service adjustments or procedures that may need to be made during the life of your machine. If you require additional machine service not included in this section, please contact Woodstock International Technical Support at (360) 734-3482 or send e-mail to: techsupport@woodstockint.com.
  • Page 71 Model W1851 (For Machines Mfd. Since 10/17) 4. Tilt blade away from 0° by about 5°, so there is Trunnion room for 90° stop collar to move. Bracket Set Screws 5. Open motor door, loosen set screws shown in Figure.

  • Page 72: Miter Slot To Blade Parallelism

    Model W1851 (For Machines Mfd. Since 10/17) Miter.Slot.to.Blade. Parallelism Your table saw will give the best results if the miter slot and the rip fence are adjusted parallel to the blade. If either of these are not exactly parallel, your cuts and your finished work will be lower in quality, but more importantly, the risk of kickback will be increased.
  • Page 73 Model W1851 (For Machines Mfd. Since 10/17) 6. Loosen (4) table mounting bolts securing table top to base (see Figure.111), and lightly tap table in direction needed to square table to blade. Mounting 7.. Repeat Steps.2–6 until blade and miter slot are Bolts parallel, then retighten table mounting bolts.

  • Page 74: Spreader Or Riving Knife Alignment

    Model W1851 (For Machines Mfd. Since 10/17) Spreader.or.Riving.Knife. Alignment Checking.Alignment The blade guard spreader/riving knife must be aligned with the blade when installed. If the spreader/riving knife is not aligned with the blade, then the workpiece will be forced sideways during the cut, which will increase the risk of kickback.
  • Page 75 Model W1851 (For Machines Mfd. Since 10/17) Adjusting.Alignment The spreader/riving knife mounting position can be adjusted into alignment with the blade using the set screws on the spreader/riving knife mounting block. Tool.Needed. Hex Wrench 2.5mm ..........1 Set Screw (1 of 4)

  • Page 76: Fence Adjustments

    Model W1851 (For Machines Mfd. Since 10/17) Fence.Adjustments There are four main adjustments for the fence: height off the table, squareness, parallelism with the miter slot, and clamping pressure. These adjustments are interconnected and some repetition may be needed when adjusting.
  • Page 77 Model W1851 (For Machines Mfd. Since 10/17) 8. Place square on table and against face of fence, as shown in Figure 119, to check if fence is square to table. 90° Square Fence — If fence is square to table, proceed to Parallelism &...
  • Page 78 Model W1851 (For Machines Mfd. Since 10/17) 7. Remove fence, then alternately loosen and tighten rear fence set screws in equal amounts to adjust rear of fence until it is parallel with miter slot. 8. Loosen both front lock nuts (see Figure 117 on Page 74).

  • Page 79: Fence Scale Calibration

    Model W1851 (For Machines Mfd. Since 10/17) Fence.Scale.Calibration The fence scale indicator window, shown in Figure 122, can be calibrated with the fence scale if you notice that Screws your cuts do not accurately match what is shown on the fence scale.

  • Page 80: Table/Dado Insert Adjustment

    Model W1851 (For Machines Mfd. Since 10/17) Table/Dado.Insert. Adjustment The table/dado insert must sit perfectly flush with the table to provide a smooth, continuous surface for the workpiece to slide over. The insert is held in place by a magnet and sits on top of four adjustment screws (see Figure 123).

  • Page 81: Miter Gauge Adjustments

    Model W1851 (For Machines Mfd. Since 10/17) Miter.Gauge.Adjustments The miter gauge can be adjusted so it is perpendicular to the blade and snug in the T-slot. Positive Stop Set Screws Knob Tools.Needed. 90° Square ............1 45° Square ............1 Hex Wrench 2mm ..........1 Hex Wrench 2.5mm ..........1...

  • Page 82: Belt Tension & Replacement

    Model W1851 (For Machines Mfd. Since 10/17) Belt.Tension.&. Replacement The drive belt stretches slightly as the saw is used. Most of the belt stretching will happen during the first 16 hours of use, but it may continue through continued use.

  • Page 83: Troubleshooting

    Model W1851 (For Machines Mfd. Since 10/17) Troubleshooting The following troubleshooting tables cover common problems that may occur with this machine. If you need replacement parts or additional troubleshooting help, contact our Technical Support. Note: Before contacting Tech Support, find the machine serial number and manufacture date, and if available, your original purchase receipt.
  • Page 84 Model W1851 (For Machines Mfd. Since 10/17) Operation PROBLEM POSSIBLE.CAUSE CORRECTIVE.ACTION 1. Remount rip fence. Adjust fence (Page 76) to Rip fence 1. Rip fence mounted/adjusted incorrectly. does not move ensure adjustment screws are not too tight. smoothly. 2. Rails dirty or sticky.

  • Page 85: Electrical Safety Instructions

    Model W1851 (For Machines Mfd. Since 10/17) Electrical.Safety.Instructions These pages are current at the time of printing. However, in the spirit of improvement, we may make changes to the electrical systems of future machines. Compare the manufacture date of your machine to the one stated in this manual, and study this section carefully.

  • Page 86: Electrical Components

    Model W1851 (For Machines Mfd. Since 10/17) Electrical.Components Circuit Capacitors Breaker ON/OFF Switch Figure 129. Motor capacitors. Figure 131. Switch box components. Motor Junction Figure 130. Motor junction box. -84-...

  • Page 87: Wiring Diagram

    Model W1851 (For Machines Mfd. Since 10/17) Wiring.Diagram SWITCH BOX ON/OFF SWITCH 115 VAC 230 VAC 5-20 Plug (As Recommended) 6-20 PLUG Neutral Load Line Rewired for 115V KEDU HY56 20A 230V 35A 120V Ground Ground Rewired for 115V Read...

  • Page 88: Parts

    Model W1851 (For Machines Mfd. Since 10/17) PARTS Body 2 3 4 21 20 27 28 29 REF PART # DESCRIPTION REF PART # DESCRIPTION X1851001 EXTENSION WING X1851019 HEX NUT M5-.8 X1851002 CAP SCREW M10-1.5 X 25 X1851020 FLAT WASHER 5MM...

  • Page 89: Trunnion

    Model W1851 (For Machines Mfd. Since 10/17) Trunnion 106-1 106-7 106-5 106-3 106-2 106-4 106-6 106-8 106-9 106-11 106-10 105 106 127 128 101 102 122 123 108 109 119 120 136 137 138 182 181 183 172 120 -87-...
  • Page 90 Model W1851 (For Machines Mfd. Since 10/17) Trunnion.Parts.List PART # DESCRIPTION REF PART # DESCRIPTION X1851101 LOCK NUT M16-2 148 X1851148 SPRING BRACKET X1851102 FLAT WASHER 16MM 149 X1851149 FLANGE RING X1851103 CAP SCREW M8-1.25 X 20 150 X1851150 FLAT HD CAP SCR M5-.8 X 50...

  • Page 91: Power Switch

    Model W1851 (For Machines Mfd. Since 10/17) Power.Switch 224X (for 115V conversion) 222-1 PART # DESCRIPTION REF PART # DESCRIPTION X1851221 TAP SCREW M3.5 X 19 X1851227 LOCK WASHER 5MM X1851222 S/S SWITCH W/STOP PADDLE KEDU HY56 X1851228 FLAT WASHER 5MM...

  • Page 92: Blade Guard

    Model W1851 (For Machines Mfd. Since 10/17) Blade.Guard 301 302 303 REF PART # DESCRIPTION REF PART # DESCRIPTION X1851301 FLAT HD CAP SCR M4-.7 X 10 X1851319 ANTI-KICKBACK PAWL X1851302 GUARD SUPPORT (FRONT) X1851320 SPACER X1851303 GUARD SUPPORT (REAR) X1851321 BUTTON HD CAP SCR M4-.7 X 6...

  • Page 93: Miter Guage

    Model W1851 (For Machines Mfd. Since 10/17) Miter.Guage PART # DESCRIPTION PART # DESCRIPTION X1851401 GUIDE BAR X1851417 BUTTON HD CAP SCR M4-.7 X 6 X1851402 ANGLE SCALE X1851418 LOCKING HANDLE M8-1.25 X 24 X1851403 RIVET 2.5 X 8 BLIND, STEEL...

  • Page 94: Fence

    Model W1851 (For Machines Mfd. Since 10/17) Fence REF PART # DESCRIPTION REF PART # DESCRIPTION X1851501 GLIDE PAD X1851512 LOCK NUT M10-1.5 X1851502 KNURLED NUT M12-1.75 X1851513 BUTTON HD CAP SCR M5-.8 X 8 X1851503 SET SCREW M12-1.75 X 16...

  • Page 95: Fence Rails

    Model W1851 (For Machines Mfd. Since 10/17) Fence.Rails PART # DESCRIPTION PART # DESCRIPTION X1851601 GUIDE-TUBE END CAP 50 X 40MM X1851612 REAR FENCE RAIL X1851602 FENCE GUIDE TUBE X1851613 CAP SCREW M10-1.5 X 25 X1851603 FRONT FENCE RAIL X1851614...

  • Page 96: Labels & Cosmetics

    Model W1851 (For Machines Mfd. Since 10/17) Labels.&.Cosmetics AMPUTATION Removing blade If blade guard is Disconnect power HAZARD! guard increases removed for a before changing Always keep fingers and risk of injury—it special cut, some blades or blade hands away from...
  • Page 97 Model W1851 (For Machines Mfd. Since 06/17)
  • Page 98 Fold along dotted lIne place stamp Here Woodstock international inc. p.o. box 2309 bellingham, Wa 98227-2309 Fold along dotted lIne tape along edges--please do not staple...

  • Page 99: Warranty

    Woodstock International, Inc. will repair, replace, or arrange for a dealer refund, at its expense and option, the Shop Fox machine or machine part proven to be defective for its designed and intended use, provided that the original owner returns the product prepaid to an authorized warranty or repair facility as designated by our Bellingham, Washington office with proof of their purchase of the product within two years, and provides Woodstock International, Inc.
