Fujitsu STYLISTIC Q507 Operating Manual page 13

Left-hand side
1
1 = Tether eyelet
2 = Combined headphones and microphone
port (audio combo jack)
3 = USB 3.0 port (protected by cover)
4 = microHDMI port (protected by cover)
Right side
1 = USB 2.0 port (protected by cover)
2 = Shortcut button
3 = Volume down button
4 = Volume up button
Fujitsu
2 3 4
1
5 6 7
5 = microSD card slot (protected by cover)
6 = Battery charging indicator (orange)
7 = DC input connector (DC IN)
(protected by cover)
2 3 4
5 = ON/OFF button
6 = Stylus garage
7 = Tether eyelet
Ports and controls
5 6 7
11
