36. Routing Status

36. Routing Status
Figure 36.1. Routing Status Menu
The Routing Status menu is accessible under routing/status.

36.1. IPv4

Figure 36.2. IPv4 Kernel Active Routing Table
The path to the IPv4 Kernel Active Routing table is routing/status/ipv4routes.
It is possible to create a route on a locally connected broadcast network (i.e. without
a gateway) without also bringing up a corresponding IP address on that interface.
For example, it would be possible to add
which has an IP address of
192.168.1.0/24
Subnet
Synopsis: string
The network/prefix.
Gateway Address
Synopsis: string
The gateway address.
Interface Name
Synopsis: string
The interface name.
Route Type
Synopsis: string
The route type.
Route Weight
Synopsis: string
The route weight.
ROX™ v2.2 User Guide
10.0.1.1 but no corresponding alias address on the
subnet.
422
to
192.168.1.0/24
