Emissions

The United States Environmental Protection
Agency (US EPA)
Resources Board (CARB), for engines/equip-
ment certified to California standards) requires
that this engine/equipment complies with
exhaust and evaporative emissions stan-
dards. Locate the emissions compliance decal
on the engine to determine applicable stan-
dards. For emissions warranty information,
please reference the included emissions war-
ranty. It is important to follow the maintenance
specifications in the manual to ensure that the
engine complies with the applicable emissions
standards for the duration of the product's life.
TABLE 2. Product Specifications
Generator Specifications
Rated Power
Starting Power
Rated AC Voltage
Rated AC Load at 120V
Rated Frequency
Dimensions L x W x H (in/mm)
Weight (dry)
** Operating Temperature Range: -13 deg. C (8 deg. F) to 40 Deg. C (104 Deg. F). When operated
above 25 deg. C (77 deg. F) there may be a decrease in power.
** Maximum wattage and current are subject to, and limited by, such factors as fuel Btu content,
ambient temperature, altitude, engine condition, etc.. Maximum power decreases about 3.5% for
each 1,000 feet above sea level; and will also decrease about 1% for each 6° C (10° F) above 16°
C (60° F) ambient temperature.
Engine Specifications
Engine Type
Displacement
Spark Plug Part Number
Spark Plug Type
Spark Plug Gap (in/mm)
Fuel Capacity / Type
Oil Type
Oil Capacity
Run Time at 50% Load
* Go to www.generac.com or contact an IASD for replacement parts.
Owner's Manual for Portable Generator
(and California Air
2200i
1700 W
2200 W
120V
14.1 Amps**
60 Hz
19.8 x 11.5 x 17.9 (504 x 293 x 454)
48 lb. (21.8 kg)
2200i
Single Cylinder, 4-stroke
80 cc
0K95530157
E6TC / E6RTC / BPR6HS or equivalent
0.024-0.028 (0.6-0.7)
4.5 L (1.18 U.S. gallons) / Unleaded
Add Engine Oil
See
0.35 L (0.36 qt.)
7.0 Hours
5
