Porter-Cable 7414 Instruction Manual

Double insulated 7"/9" disc sander
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
283800 - 07-31-00.QXD
Instruction
manual
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2000 Porter-Cable Corporation
9/23/02
1:34 PM
Page 1
Double Insulated
7"/ 9" Disc Sander
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
ESPAÑOL: PÁGINA 13
FRANÇAISE : PAGE 25
MODEL 7414
IMPORTANT
Part No. 283800-007

Advertisement

Table of Contents
loading

Related Manuals for Porter-Cable 7414

Summary of Contents for Porter-Cable 7414

  • Page 1 283800 - 07-31-00.QXD 9/23/02 Instruction manual To learn more about Porter-Cable visit our website at: http://www.porter-cable.com Copyright © 2000 Porter-Cable Corporation 1:34 PM Page 1 ESPAÑOL: PÁGINA 13 FRANÇAISE : PAGE 25 Double Insulated 7"/ 9" Disc Sander MODEL 7414...

  • Page 2: General Safety Rules

    283800 - 07-31-00.QXD 9/23/02 GENERAL SAFETY RULES WARNING! READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow all instructions listed below, may result in electric shock, fire and/or serious personal injury. WARNING: SOME DUST CREATED BY POWER SANDING, SAWING, GRINDING, DRILLING, AND OTHER CONSTRUCTION ACTIVITIES contains chemicals known to cause cancer, birth defects or other reproductive harm.
  • Page 3 283800 - 07-31-00.QXD 9/23/02 operating power tools may result in serious personal injury. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts. Avoid accidental starting.

  • Page 4: Specific Safety Rules And Symbols

    Do not install woodcarving blade on this grinder. WARNING: There are certain applications for which this tool was designed. Porter-Cable strongly recommends that this tool NOT be modified and/or used for any application other than for which it was designed. If you have any questions relative to its application DO NOT use the tool until you have written Porter-Cable and we have advised you.

  • Page 5: Additional Safety Rules For Paint Removal

    283800 - 07-31-00.QXD 9/23/02 ... three-phase alternating current with neutral ... direct current ... no load ... alternating or direct current ... Class II Construction ... splash-proof construction ... watertight construction …/min ... revolutions or reciprocation per minute ADDITIONAL SAFETY RULES FOR PAINT REMOVAL WARNING: Extreme care should be taken when removing paint.

  • Page 6: Extension Cord Selection

    Wash hair and body thoroughly with soap and water. MOTOR Many Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate on the tool. Several models, however, are designed for A.C.

  • Page 7: To Start And Stop The Machine

    283800 - 07-31-00.QXD 9/23/02 grinding operations when used with appropriate recommended accessories. The Model 7414 can be used as a grinder when equipped with the appropriate 7" or 9" Type 27 guard and grinding wheel (see ACCESSORIES section of manual).
  • Page 8 283800 - 07-31-00.QXD 9/23/02 INSTALLATION: Insert threaded end of handle into handle clamp (A) Fig. 1A. Turn handle clockwise and tighten securely. CHANGING POSITIONS: Loosen handle by turning 2 full turns counterclockwise. Push in on handle and move handle to desired location.

  • Page 9: Operation

    283800 - 07-31-00.QXD 9/23/02 WARNING: Always make sure the wheel guard is positioned between operator and the wheel, so that flying chips or pieces of a wheel that might break will be deflected away from the operator (see Fig. 3). TO INSTALL GRINDING WHEEL CAUTION: DISCONNECT MACHINE FROM POWER CIRCUIT.

  • Page 10: Sanding Tips

    Move sander in long sweeping overlapping strokes as you go back and forth. Do not move sander in a circular motion or stay in one spot too long as this will produce swirls and an uneven finish. The weight of the sander applies sufficient pressure for fast stock removal.

  • Page 11: Maintenance

    CENTER. At approximately 100 hours of use, take or send your tool to your nearest Authorized Porter-Cable Service Station to be thoroughly cleaned and inspected; worn parts replaced, when necessary; relubricated with fresh lubricant, if required; reassembled with new brushes; and performance tested.
  • Page 12 PORTER-CABLE LIMITED ONE YEAR WARRANTY Porter-Cable warrants its Professional Power Tools for a period of one year from the date of original purchase. We will repair or replace at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period.
  • Page 13 Porter-Cable products should be obtained by contacting any Porter-Cable Distributor, Authorized Service Center, or Porter-Cable Factory Service Center. If you do not have access to any of these, call 888-848-5175 and you will be directed to the nearest Porter-Cable Factory Service Center.
