MF920V
Quick Start Guide
1

Advertisement

Table of Contents
loading

Related Manuals for Zte MF920V

Summary of Contents for Zte MF920V

  • Page 1 MF920V Quick Start Guide...
  • Page 2 Getting to Know Your Device Appearance The following figure is for your reference only. 1. *External antenna connectors (not all the devices support) 2. Charging/micro-USB jack 3. Indicator light 4. Power key • Press and hold for about 3 seconds to power on/off your device.
  • Page 3 Getting to Know Your Device Indicator lights Indicator Status Description Red solid / The battery is low. Please blinking charge the battery. Green The battery is being Battery blinking charged. The battery level is middle Green solid or high. Your device is not being Light off charged.
  • Page 4 Getting to Know Your Device Indicator Status Description Error status. Not registered to the mobile network, no micro-SIM card inserted or no network service avail- able. Registered to the 2G/3G Green solid mobile network. Network Connected to the 2G/3G Green mobile network and data is blinking being transferred.
  • Page 5 Getting to Know Your Device Connection Scenarios The device allows multiple clients to surf on the Inter- net at the same time. The following figure is for your reference only. 4G Mode: A micro-SIM card can be used to access the Internet.
  • Page 6 Installing Your Device 1. Open the micro-SIM card cover. NOTE: Do not remove the cover roughly, because it is con- nected with the device. 2. Install a micro-SIM card to the micro-SIM card slot. WARNING! Your device does not support SIM cards, nano-SIM cards or any other non-standard micro-SIM cards.
  • Page 7 Connecting to Your Device Using Wi-Fi 1. Power on your device. 2. Ensure that your computer or other client devices have enabled Wi-Fi, and search for available wireless networks. NOTE: Refer to your Wi-Fi-enabled client device manual for further details on how to search for wireless networks. If you use a computer, you need to set your computer to obtain an IP address automatically.
  • Page 8 Connecting to Your Device Using a USB Cable 1. Connect a computer to your device with a USB cable. 2. Power on your device. The operating system detects and identifies new hardware, and automatically installs the software. NOTE: If the system does not automatically launch installation, you can double-click the device installation icon in My Computer to install the software.
  • Page 9 Logging in to the 4G Mobile Hotspot Configuration Page 1. Ensure that the connection between your device and the client device is correct. 2. Launch the Internet browser and enter http://192.168.0.1 in the address bar. 3. Enter the password to log in to the 4G Mobile Hotspot configuration page.
  • Page 10 Accessing the Internet After a client device is successfully connected to your device, you can access the Internet in Automatic or Manual mode. The default mode is Automatic. Mode Operation Your device is automatically connected Automatic to the Internet, and you can surf on the Internet through the client.
  • Page 11 Configuring Your PC The following procedure describes how to configure the Internet Protocol in Windows 7 for your Wi-Fi con- nection. 1. Right-click Network and select Properties. 2. Select Change adapter settings. 3. Right-click Wireless Network Connection and select Properties. 4.
  • Page 12 Warning and Notice To the Users • If inadequately shielded, some electronic devices, for example, the electronic system of vehicles, may be affected by the electromagnetic interference caused by the device. Consult the manufacturers of such devices before using the device if necessary. •...
  • Page 13 Warning and Notice • Do not touch the inner antenna area unless necessary. Otherwise the performance of the device may be affected. • Do not use the device in an enclosed environment or where heat dissipation is poor. Prolonged work in such space may cause excessive heat and raise ambient temperature, which may lead to automatic shutdown of the device for your safety.
  • Page 14 An operating temperature between -10°C and +60°C and humidity between 5% and 95% are recommended. Using Battery Do not change the built-in rechargeable battery in your device by yourself. The battery can only be changed by ZTE or ZTE authorized service provider.
  • Page 15 End users’ mishandling, misuse, negligence, or improper installation, disassembly, storage, servicing or operation of the product. iv. Modifications or repairs not provided by ZTE or a ZTE-certified individual. v. Power failures, surges, fire, flood, accidents, and actions of third parties or other events outside ZTE’...
  • Page 16 Limitation of Liability ZTE shall not be liable for any loss of profits or indirect, special, incidental or consequential damages resulting from or arising out of or in connection with using of this...
  • Page 17 ZTE Corporation. The manual is published by ZTE Corporation. We re- serve the right to make modifications on print errors or update specifications without prior notice.
  • Page 18 Troubleshooting Problem Recommended Action • Install the software, and run the The connection installation program in the path between your of My Computer. device and a PC • If the driver of your device is through a USB abnormal, reinstall the software. cable cannot be You need to uninstall the established.
  • Page 19 Use only one network adapter not be visited. in your PC. • Do not use any proxy server. Getting More Help You can get help by: Sending an email to support@zte.com.au • Visiting www.ztemobiles.com.au • Calling the service hotline: 1300 789 475 •...
  • Page 20 ZTE CORPORATION NO. 55, Hi-tech Road South, Shenzhen, P.R.China Postcode: 518057...
