CSAT-5060 50 Watt C-Band Transceiver
Remote Control
Arguments
for
Command Command
(Instruction or
Parameter Code and Response
Type qualifier) to Query
Remote SPA= 4 bytes,
Address numerical
(Physical
Address)
Remote SBR= 4 bytes
Baud rate
Set RTC DAY= 6 bytes,
Date numerical
Set RTC TIM= 6 bytes,
Time numerical
Clear All CAA= None
Stored
Alarms
Re-Initialize IAP= None
Retrieved
Alarms Point
Description of Arguments
Note that all arguments are ASCII
numeric codes between 48 and 57.
Command or Query.
Physical Address - between 0001 and 9999.
Resolution 0001.
Example: SPA=0890
Command or Query.
Baud Rate, as follows:
1200 = 1200 baud,
2400 = 2400 baud,
4800 = 4800 baud,
9600 = 9600 baud,
19K2 = 19200 baud.
38K4 = 38400 baud.
A command in the form mmddyy, where; dd = day of the
month, between 01 and 31, mm = month of the year,
between 01 and 12 and yy = year, between 97 and 96
(1997 to 2000, then 2000 to 2096)
Example: DAY=042457 would be April 24, 2057
A command in the form hhmmss, indicating the time
from midnight, where hh = hours, between 00 and 23;
mm = minutes, between 00 and 59, and ss = seconds,
between 00 and 59
Example: TIM=231259 would be 23 hours, 12 minutes
and 59 seconds from midnight.
Command only
Instructs the slave to clear all Stored Events
This command takes no arguments.
Command only
Instructs the unit to zero the retrieved alarms pointer to
allow the user to retrieve the complete stored alarms
log.
Response to
Command
(Slave to Master)
SPA= (message ok)
SPA? (received ok,
but invalid
arguments found)
SBR= (message ok)
SBR? (received ok,
but invalid
arguments found)
DAY= (message ok)
DAY? (received ok,
but invalid
arguments found)
DAY* (message ok,
but not permitted in
current mode
TIM= (message ok)
TIM? (received ok,
but invalid
arguments found)
TIM* (message ok,
but not permitted in
current mode
CAA= (message ok)
IAP=(message ok)
A-11
MN/CSAT506050.IOM
Query
(Instruction
code and Response to query
qualifier) (Slave to Master)
SPA? SPA=xxxx
(same format as command
arguments)
SBR? SBR=xxxx
(same format as command
arguments)
DAY? DAY=xxxxxx
(same format as command
arguments
TIM? TIM=xxxxxx
(same format as command
arguments
N/A N/A
N/A N/A
Revision 0
