Exploded Parts Diagram

5
6
7
8
9
10
11
26
Pool Wall
or Skimmer
24 25
23
27
28 28 29
27
No. Part# Description
1 5-2005 Propeller Grid
2 9-100-5117 Screw, 8-32 x 3/8" SS Pan Head
3 5-2000 Top Housing Assembly
4 5-6000 Propeller
5 9-100-1114 Hub Cap
6 9-100-5107 E-clip, Stainless Steel
7 9-100-1108 Ball Bearing*
8 5-4005 Tire, MaxTrax
9 5-4000 Wheel Assembly
10 5-5200 Belt Kit, Small and Large*
11 9-100-7011 Shield, Bearing*
12 5-1020 Pulley/Retainer Clip
13 5-4500 Axle Block Assembly
14 5-1010 Belt Tensioner Block
15 9-100-5130 Lock Washer, Axle Block
16 9-100-5115 Screw, 8-32 x 3/4" SS Pan Head
17 5-1000 Frame
1
8
9
11
7
13
12
14
13
15
16
17
18
19
2
27
21
27
2
To The
Polaris
30
Qty
1
12
1
1
3
7
6
® * 3
3
1
3
1
3
1
8
8
1
www.polarispool.com
2
3
2
4
18
20
13
15
2
16
9
2
22
2
No. Part# Description
18 5-2010 Flotation, Top, Front and Rear
19 5-5000 Power Module Assembly
20 5-5060 Swivel Assembly
21 5-2050 Bottom Housing
22 5-3000 Bottom Plate*
23 5-7100 Universal Adapter
24 5-7000 Flow Regulator
25 5-7250 Elbow, 45-degree
26 5-7200 Elbow, 90-degree
27 5-5570 Single, Standard Hose
28 5-7300 Hose Weight
29 5-5580 Leader Hose
30 5-7050 Flow Indicator
11
10
7
8
7
6
5
Qty
1
1
1
1
1
1
1
1
1
12
2
1
1
* Wear items not covered by warranty.
