Data
ON
LAN
Flashing
Rear Panel
Rear Panel Port and Button Definition
Connector
The power button is for turn on or turns off the router.
POWER
Button
Power
Power connector with 10V DC 1.0 A
The reset button can restore the default settings of device. To restore factory
defaults, keep the device powered on and push a paper clip into the hole.
Reset
Press down the button over 5 seconds and then release.
Router is successfully connected to a device through the Ethernet port. If the
Ethernet
LED is flashing, the Router is actively sending or receiving data over that port.
The RJ-11 connector allows data communication between the modem and the
Line
ADSL network through a twisted-pair phone wire.
network.
Modem is trying to establish a connection to telecom's network.
Data is transferred between Router and Internet.
Link
TX or RX activity.
