Summary of Contents for Planar PX2611W
-
Page 3: Table Of Contents
Contents Preface ...2 Installation...4 Unpacking... 4 Adjust height and angle of Tilt stand ... 5 Connecting the Display ... 5 Connecting the AC Power ... 6 Connecting the USB Hub ... 6 Setting Up the LCD Monitor... 6 Power Management System... 6 Display Controls ...7 User Controls... -
Page 4: Preface
Preface This manual is designed to assist users in setting up and using the LCD Monitor. Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. -
Page 5: Important Safety Instructions
Important Safety Instructions Please read the following instructions carefully. This manual should be retained for future use. 1. To clean the LCD Monitor screen: -- Power off the LCD Monitor and unplug the AC Cord. -- Spray a non-solvent cleaning solution onto a rag. -- Gently clean the screen with dampened rag. -
Page 6: Installation
If you find that any of these items is missing or appears damaged, contact your dealer immediately. Register Your Planar Products Today Thank you for choosing Planar. To assure you receive all the benefits of your Planar product and services, register your Planar product today. Visit our website to register your product at http ://www.planar.com/support/product_registration.html... -
Page 7: Adjust Height And Angle Of Tilt Stand
Adjust height and angle of Tilt stand The monitor screen may be raised or lowered and tilted (-5 to 40 degree). To raise or lower the monitor screen, place hands on each side of the monitor screen and lift or lower to the desired height as shown in the right figure. -
Page 8: Connecting The Ac Power
Connecting the AC Power 1. Connect the power cord to the LCD Monitor.(See Fig. 1-4) 2. Connect the power cord to an AC power source. 3. Turn the AC power switch to On. Connecting the USB Hub 1. Connect the “A“ end of the USB cable to your computer. 2. -
Page 9: Display Controls
Display Controls User Controls A brief description and the location of all LCD Monitor functions controls and indicators Push to turn ON or turn Off. MENU Activates OSD main menu. EXIT Exit OSD display / DV mode hot key. SOURCE Select DVI or D-SUB signal source. -
Page 10: Adjusting The Monitor's Display
Adjusting the Monitor's Display The monitor has four function control buttons to select among functions shown on OSD menu, designed for easy user-viewing environments. OSD Function Menu To activate the OSD Main menu, simply press ”Menu” button , the menu diagram will pop up on the screen as shown on Fig. -
Page 11: Function Description
Function Description Figure Function The following DV mode display setting can be selected by DV MODE OSD (STANDARD/TEXT/sRGB/MOVIE/GAMING/PHOTO) Default setting: TEXT Adjust the brightness. BRIGHTNESS Factory setting: 100.0% Adjust the image contrast. CONTRAST Factory setting:50.0% Adjust the sharpness. SHARPNESS Factory setting: 50% AUTO CONTRAST Adjust the CONTRAST to the optimal value for the... - Page 12 Choose different color temperature (9300K, 7500K, sRGB, USER). Color Temperature Default is USER. USER mode adjustable. Adjust the contrast and brightness of each color of the white balance. GREEN Allows you to adjust the Red/Green/Blue color gain. BLUE GAIN GREEN Allows you to adjust the Red/Green/Blue color offset.
- Page 13 Provide information about resolution, H/V frequencies, Information and polarity of the input signal. This OSD informs the user the current signal that is displayed. Input Select This OSD will automatically turn off after 2 seconds or by pressing the “Exit” key. This OSD gives a warning when the selected input signal is not active.
-
Page 14: Target Color Coordinates
Target color coordinates Color Temp. u’ v’ When the monitor is displayed for the first time and the Auto Adjust resolution is 800x600 and above, the monitor will auto (Analog Input adjust itself. Only) To manually execute the Auto Adjust function, press the Auto button. -
Page 15: Osd Lock Out Function
OSD Lock Out Function OSD Lock Function allows you to lock out the OSD menu and the button keys. To activates the OSD lock function, the monitor must be in a normal display mode and the information menu as shown in fig-2-4 must be activated. Then follow the instructions below. Option 1: OSD lock –... -
Page 16: Technical Information
Technical Information Specifications LCD Panel Size Display Type Resolution Display Dot Display Area (mm) Display Color Video Input Signal Input Impedance Polarity Amplitude Multi-mode Supported Control Power switch Brightness Contrast Horizontal Position Vertical Position Phase Clock Display Mode Setup Others USB Hub ( optional ) Upstream Downstream... -
Page 17: Power Management
Power Management Mode Power Consumption* DPM ON 135W maximum DPM OFF 2W maximum DC switch off 1W maximum Disconnected 2W maximum Meeting VESA DPM requirements measured from AC Input end of AC power cord. Sync Input Signal Polarity Plug & Play External Connection Power Input (AC input) Video Cable... -
Page 18: Standard Timing Table
Standard Timing Table If the selected timing is NOT included in table below, this LCD monitor will use the most suitable available timing. FH (KHz) FV (Hz) POLARITY TIMING NAME 640x350 31.469 VGA-350 70.087 640x400 31.469 VGA-GRAPH 70.087 640x480 31.469 VGA-480 59.94 640x480... - Page 19 (75Hz) 75.06 1280x720 44.772 (60Hz) 59.855 1280x960 (60Hz) 1280x960 (70Hz) 1280x960 (75Hz) 1280x1024 VESA-1024-60Hz 1280x1024 VESA-1024-75Hz 1360x768 60Hz 1440x900 55.469 Red. BLKing 60Hz 59.901 1440x900 55.935 60Hz 59.887 1440x900 70.635 75Hz 74.984 1680x1050 64.674 Red. BLKing 60Hz 59.883 1680x1050 65.29 60Hz 59.954 1680x1050...
-
Page 20: Troubleshooting
Troubleshooting This LCD Monitor has pre-adjusted using factory standard VGA timings. Due to the output timing differences among various VGA cards in the market, users may initially experience an unstable or unclear display whenever a new display mode or new VGA card is selected. Attention This LCD Monitor Supports Multiple VGA Modes.
