Create the Alias for the Nimble Storage Array and Management Systems
Procedure
1 Run the display fc login vsan <<net_fcoe_vsan_a_id>> command to get the port WWNs of the array
and management servers in <<net_fcoe_vsan_a_id>>.
<HPE>disp fc login vsan 100
Interface VSAN FCID
Fc1/2/13
100
Fc1/2/14
100
Fc1/2/15
100
Fc1/2/16
100
Vfc711
100
Vfc721
100
2 Initiate another SSH session to <<nimble_admin_ip>> and log in as admin. Execute the fc --list command.
Nimble OS $ fc --list
Array: sstor01
------+-----+-------+------+----+-----------------------+-----------------------
Name
Ctrlr Admin
------+-----+-------+------+----+-----------------------+-----------------------
fc5.1 A
online yes
fc6.1 A
online yes
fc9.1 A
online yes
fc10.1 A
online yes
fc5.1 B
online yes
fc6.1 B
online yes
fc9.1 B
online yes
fc10.1 B
online yes
3 Back at the switch, enter system-view and run the vsan <<net_fcoe_vsan_a_id>> command.
system-viewvsan <<net_fcoe_vsan_a_id>>
4 Using the output from the Nimble Storage array as your guide, create an alias for the first Nimble Storage
array port logged in to the fabric (the items in the preceding switch output example that begin with
system-view vsan <<net_fcoe_vsan_a_id>> Fc).
The following example shows creating a zone alias for the fc5 port on controller A of the Nimble array,
which is connected to switch port Fc1/2/13.
zone-alias name <<nimble_system_name>>-CA-fc5
member pwwn 56:c9:ce:90:7c:99:ae:01
quit
5 Repeat step 4 for all of the other ports from the Nimble Storage array that are connected and logged in
to <<net_fcoe_vsan_a_id>>.
6 Create the aliases for the vFC interfaces of each management server that is logged in to the fabric (the
items in the preceding example that begin with Vfc).
system-viewzone-alias name <<mgmt_server_1_hostname>>-LOM1
member pwwn 10:00:34:64:a9:ba:d9:21 <-This is the Port WWN of Vfc711 in the
above example output
quit
7 Repeat this procedure for the other management servers and their vFCs in the configuration.
8 Repeat this entire procedure for <<net_fcoe_vsan_b_id>> and its associated Nimble Storage array and
that management server ports that are connected and logged in to it.
©
Copyright
2017 by Nimble Storage, Inc. All rights reserved.
Node WWN
0xe30001 56:c9:ce:90:7c:99:ae:00 56:c9:ce:90:7c:99:ae:01
0xe30000 56:c9:ce:90:7c:99:ae:00 56:c9:ce:90:7c:99:ae:03
0xe30003 56:c9:ce:90:7c:99:ae:00 56:c9:ce:90:7c:99:ae:05
0xe30002 56:c9:ce:90:7c:99:ae:00 56:c9:ce:90:7c:99:ae:07
0xe30005 20:00:34:64:a9:ba:d9:21 10:00:34:64:a9:ba:d9:21
0xe30004 20:00:34:64:a9:b9:98:29 10:00:34:64:a9:b9:98:29
Fabric
Link WWNN
Status
8G 56:c9:ce:90:7c:99:ae:00 56:c9:ce:90:7c:99:ae:01
8G 56:c9:ce:90:7c:99:ae:00 56:c9:ce:90:7c:99:ae:02
8G 56:c9:ce:90:7c:99:ae:00 56:c9:ce:90:7c:99:ae:03
8G 56:c9:ce:90:7c:99:ae:00 56:c9:ce:90:7c:99:ae:04
8G 56:c9:ce:90:7c:99:ae:00 56:c9:ce:90:7c:99:ae:05
8G 56:c9:ce:90:7c:99:ae:00 56:c9:ce:90:7c:99:ae:06
8G 56:c9:ce:90:7c:99:ae:00 56:c9:ce:90:7c:99:ae:07
8G 56:c9:ce:90:7c:99:ae:00 56:c9:ce:90:7c:99:ae:08
Documentation Feedback
Port WWN
WWPN
63
