MOVXI RaH, #16FLoHex
Operands
Ra
#16FLoHex
Opcode
LSW: 1110 1000
MSW: IIII IIII
Load the low 16-bits of RaH with the immediate value #16FLoHex. #16FLoHex
Description
represents the lower 16-bits of an IEEE 32-bit floating-point value. The upper 16-bits of
RaH will not be modified. MOVXI can be combined with the MOVIZ or MOVIZF32
instruction to initialize all 32-bits of a RaH register.
RaH[15:0] = #16FLoHex
RaH[31:16] = Unchanged
Flags
Flag
Modified
This is a single-cycle instruction.
Pipeline
Example
; Load R0H with pi = 3.141593 (0x40490FDB)
MOVIZ RaH, #16FHiHex
See also
MOVIZF32 RaH, #16FHi
SPRUEO2A – June 2007 – Revised August 2008
Submit Documentation Feedback
Move Immediate to the Low 16-bits of a Floating-Point Register
floating-point register (R0H to R7H)
A 16-bit immediate hex value that represents the lower 16-bits of an IEEE 32-bit
floating-point value. The upper 16-bits will not be modified.
0000 1III
IIII Iaaa
TF ZI
No No
MOVIZ R0H,#0x4049
MOVXI R0H,#0x0FDB
NI ZF NF
No No No
; R0H = 0x40490000
; R0H = 0x40490FDB
Instructions
LUF LVF
No No
Instruction Set 101
