Summary of Contents for Symbol SPT 1700 Series

  • Page 2 Symbol reserves the right to make changes to any product to improve reliability, function, or design. Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein.

  • Page 3: Table Of Contents

    Troubleshooting on page 17 • Service Information on page 20. The SPT 1700 Product Reference Guide (part number 70-37544- xx) provides more detail about the applications available on the SPT 1700. See your Reseller or call Symbol Technologies to receive this document.

  • Page 4: Parts Of The Spt 1700

    S P T 1 7 0 0 S e r i e s Parts of the SPT 1700 The following illustration indicates each part of the SPT 1700 Terminal. Front View Laser Decode LED Center Scan Button Scroll Button Scroll Button (Up and Down) (Up and Down) Right Scan Trigger...
  • Page 5 Q u i c k R e f e r e n c e Parts of the SPT 1700 (continued) Back View Stylus Infrared Port Handstrap Connector Stylus Silo Speaker Reset Button Battery Compartment Lithium-Ion Battery Battery Latch Battery Latch Battery Cover Handstrap Connector Bottom View...

  • Page 6: Getting Started With The Spt 1700

    The battery included in the package (p/n 20-36098-01/ model number 1UF103450) must be used exclusively as the power source for the SPT 1700 series, and should not be used for any other purpose. Using the Cradle to Charge the Battery To charge the terminal’s battery using the CRD 1700 cradle:...
  • Page 7 Q u i c k R e f e r e n c e 3. Insert the SPT 1700 terminal in the cradle as shown: The terminal’s battery is fully charged after approximately two hours. You can also charge a terminal’s spare battery by inserting it in the spare battery charging slot on the back of the cradle.
  • Page 8 S P T 1 7 0 0 S e r i e s 2. Insert the cable into the bottom of the terminal. Synchronization/ Charging Cable 3. Plug the power cable into a wall outlet and plug the other end into the battery charging receptacle on the side of the Synchro- nization/Charging Cable.

  • Page 9: Installing The Battery

    Q u i c k R e f e r e n c e Installing the Battery To install the battery in your SPT 1700: 1. Open the latches on the battery cover and lift it away from the SPT 1700. Latch Latch 2.

  • Page 10: Starting The Spt 1700

    S P T 1 7 0 0 S e r i e s Starting the SPT 1700 After charging and installing the battery, start the terminal by pressing the red power button. If the terminal does not power on, perform a hard reset by following the instructions on page 14. Calibrating the Screen The first time you start your SPT 1700, the calibration screen appears.

  • Page 11: Using The Spt 1700

    Q u i c k R e f e r e n c e 3. Tap the exact center of each target that appears on the screen with the tip of the stylus. If, at any time, you need to recalibrate the digitizer, open the Preferences application, tap on the top right corner of the screen, and select the digitizer option from the pull down menu.

  • Page 12: Using The Contrast Control

    S P T 1 7 0 0 S e r i e s Using the Contrast Control The contrast control button is located on the lower right-hand side of the terminal. Contrast Control To adjust the contrast: 1. Press the contrast control button, which displays the contrast adjusting bar on the terminal’s screen.

  • Page 13: Icon Descriptions

    Q u i c k R e f e r e n c e Using the Onscreen Keyboard You can activate the on-screen keyboard any time you need to enter text or numbers on your SPT 1700. Note that you cannot enter Graffiti characters while using the on-screen keyboard.

  • Page 14: Scanning With The Spt 1700

    S P T 1 7 0 0 S e r i e s Scanning with the SPT 1700 The SPT 1700 has an integrated laser bar code scanner which, if your unit has been configured to use scanning input, allows you to collect data by scanning bar codes.

  • Page 15: Initiate The Spectrum24 Network Connection

    For information about configuring the SPT 1740 terminal for use in a Spectrum24 environment, please refer to the SPT 1700 Series Product Reference Guide, part number 70-37544- Resetting Your SPT 1700 Terminal Under normal circumstances, you will never have to use the reset button.
  • Page 16 S P T 1 7 0 0 S e r i e s Performing a Hard Reset A hard reset tells your SPT 1700 terminal to start over again and erase all records and entries stored in your SPT 1700 terminal. Therefore, never perform a hard reset unless a soft reset does not solve your problem.

  • Page 17: Attaching The Handstrap

    Q u i c k R e f e r e n c e Attaching the Handstrap The SPT 1700 has an optional handstrap which increases comfort when holding the terminal for extended periods of time. To attach the handstrap to the back of the terminal: 1.

  • Page 18: Maintaining The Spt 1700

    S P T 1 7 0 0 S e r i e s Maintaining the SPT 1700 Your SPT 1700 is designed to be reliable and to provide years of trouble-free service. However, you should observe the following general tips when using your SPT 1700: •...

  • Page 19: Troubleshooting

    Q u i c k R e f e r e n c e Troubleshooting SPT 1700 terminal does not turn on: • Adjust the contrast control. • Make sure the battery is fully charged and installed properly. • Replace the battery. If your SPT 1700 terminal still does not operate, try a soft reset;...
  • Page 20 Your SPT 1700 unit does not accept scan input: • Verify that the unit is loaded with a scanning application. See your System Administrator. • Check to be sure the bar code symbol is not defaced. • Be sure you are within proper scanning range.
  • Page 21 When the battery is low, the scanner shuts off before the terminal notifies you of the low battery condition. Note: If, after performing these checks, the scanner is still not reading symbols, contact your distributor or Symbol Technologies.

  • Page 22: Service Information

    It shall not apply to any product (i) which has been repaired or altered unless done or approved by Symbol, (ii) which has not been maintained in accordance with any operating or handling instructions supplied by Symbol, (iii) which has been...
  • Page 23 Customer will pay for the replacement product in case it does not return the replaced product to Symbol within 3 days of receipt of the replacement product. The process for return and customer’s charges will be in accordance with Symbol’s Exchange Policy in effect at the time of the exchange.
  • Page 24 S P T 1 7 0 0 S e r i e s • Keep objects that are used frequently within easy reach • Perform tasks at correct heights • Reduce or eliminate vibration • Reduce or eliminate direct pressure •...
  • Page 25 • EN 60 825-1 (EN 60 825) - Safety of Devices Containing Lasers Laser Devices Symbol products using lasers comply with US 21CFR1040.10, Subchapter J and IEC825/EN 60 825 (or IEC825-1/EN 60 825-1, depending on the date of manufacture). The laser classification is marked on one of the labels on the product.
  • Page 26 S P T 1 7 0 0 S e r i e s Scanner Labeling...
  • Page 27 Q u i c k R e f e r e n c e In accordance with Clause 5, IEC 0825 and EN60825, the following information is provided to the user: ENGLISH HEBREW CLASS 1 CLASS 1 LASER PRODUCT CLASS 2 LASER LIGHT DO NOT STARE INTO BEAM CLASS 2 LASER PRODUCT...
  • Page 28 For Frequently Asked Questions and tips on SPT 1700 operation, please visit the Symbol Palm website at http://www.symbol.com/palm. 70-37543-01 Revision B—June 1999 Symbol Technologies, Inc. One Symbol Plaza Holtsville, NY 11742-1300...
