- Page 1 PLM860SAW Manual.qxd 7/31/03 2:27 PM Page 1 PLM860SAW 860MHz Channelized-Agile PLL Saw-Filtered A/V Modulator Installation and Operation Manual Operation www.picomacom.com Ph: 800-421-6511 Manual Rev. 06/03...
-
Page 2: Product Inspection
To insure proper installation and operation, take a moment to read this guide before proceeding with the installation. If you have any questions or comments about the PLM860SAW Channelized-Agile PLL Saw-Filtered A/V Modulator, please contact your dealer or have him contact the PICO MACOM Service Center at these phone numbers: 800-421-6511, 818-493-4300. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of un-insulated “dangerous voltage”... - Page 3 PLM860SAW Manual.qxd 7/31/03 2:27 PM 11. Power Sources: This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied to your home, consult your appli- ance dealer or local power company.
- Page 4 Easy lab retuning enables inventory savings and less down time. The PLM860SAW is shipped with all internal adjustments preset. FCC Docket 21006 offsets are standard. Pico Macom backs up this product with its industry leading 5-year limited warranty.
-
Page 5: Specifications
PLM860SAW Manual.qxd 7/31/03 2:28 PM PLM860SAW 860MHz Channelized-Agile PLL SAW-Filtered A/V Modulator VIDEO IN Channels: 113 Channels (CATV 23-135) Frequency Range: 216 - 860 MHz Output Impedance: 75 ohms RF Output Level: 45 to 55 dBmV typical, adjustable from front panel Frequency Accuracy/Stability: ±10 kHz, ±5 kHz in aeronautical band. -
Page 6: Operation And Controls
PLM860SAW Manual.qxd 7/31/03 2:28 PM Operation and Controls PLM860SAW PLM860SAW 860MHz Channelized-Agile PLL SAW-Filtered A/V Modulator Front Panel Control Power Indicator: The LED indicates unit is operating. Test Point: The -30 dB RF output test point is used to set the RF output level and monitor channel performance. -
Page 7: Installation Procedure
Installation Procedure PLM860SAW Signal Combining Methods PICO MACOM recommends connecting the headend components in the following manner: Each of the modulators, signal processors or strip ampli- fiers output are connected to a combining network. Either a PHC-12G or a PHC-24G headend combiner may be used to accomplish this purpose. -
Page 8: Warranty
We will issue an invoice for the List Price of the loaner unit plus shipping costs. When you receive the loaner unit, pack the failed unit in the loaner unit’s box and ship it freight prepaid to Pico Macom for repair. When you receive the repaired unit, a new RMA number will be provided in the box. Carefully pack the loaner unit and affix the new RMA number on the box and ship it back to us for full credit excluding shipping costs.
