PORTABLE
PD SERIES
SERVICE MANUAL
Models:
Cooling-only
MPPD-12CRN1-BH9
MPPD-14CRN1-BH9
MPPD-12CRN1-BI0(small body)
PD1
PDA
North America Air Conditioner
Heat pump
MPPD-12HRN1-BH9
MPPD-14HRN1-BH9
Electronic heater
MPPD-12ER-NB4
PD3
PDB(panel used for small body)
R R
Dual-hose
MYPD-12CRN1-QB6
PD
(standard panel)
Advertisement
Table of Contents
Related Manuals for Midea MPPD-12CRN1-BH9
Summary of Contents for Midea MPPD-12CRN1-BH9
-
Page 1: Service Manual
North America Air Conditioner PORTABLE PD SERIES SERVICE MANUAL Models: Cooling-only Electronic heater Heat pump Dual-hose MPPD-12CRN1-BH9 MPPD-12ER-NB4 MPPD-12HRN1-BH9 MYPD-12CRN1-QB6 MPPD-14CRN1-BH9 MPPD-14HRN1-BH9 MPPD-12CRN1-BI0(small body) (standard panel) PDB(panel used for small body) - Page 2 1. DIMENSION Unit Dimension mm(inch) Single-hose 454(17.9) 700(27.6) 365(14.4) (small body) 397(15.6) 765(30.1) 467(18.4) Single-hose 467(18.4) 765(30.1) 478(18.8) Double-hose ...
-
Page 3: Operation Modes
2. OPERATION MODES AND INSTRUCTIONS Optional 2.1 OPERATION MODES UP(+) AND DOWN(-) BUTTON POWER BUTTON Power switch on/off. Used to adjust (increasing/ decreasing) temperature settings SLEEP/ECO BUTTON (2 ℉/1℃increments) in a range of Used to initiate the SLEEP/ECO 62 ℉(17℃) to 88℉(30℃) or the operation. -
Page 4: Timer Button
FOLLOW ME/TEMP SENSING TIMER BUTTON (OPTIONAL) Used to initiate the AUTO ON start NOTE:This feature can be activated time and AUTO OFF stop time program, from the remote control ONLY. in conjuction with the & buttons. The remote control servesas a remote The timer on/off indicator light thermostat allowing for the precise illuminates under the timer on/off... -
Page 5: Heat Operation
TIMER OPERATION HEAT OPERATION (cooling only models without) When the unit is on, press the Timer button will initiate the Auto-off stop Press the "MODE" button until the program, the TIMER OFF indicator "HEAT" indicator light comes on. light illuminates. Press the UP or Press the ADJUST buttons "+"... -
Page 6: Electronic Function
SLEEP OPERATION Press this button, the selected temperature will increase(cooling) or decrease(heating) by 2 30 minutes.The temperature will then increase ℉/ ℃ (cooling) or decrease (heating) by another 2 after an additional 30 ℉/ ℃ minutes. This new temperature will be maintained for 7 hours before it returns .to the originally selected temperature. -
Page 7: Characteristic Of Temperature Sensor
TABLE A: CHARACTERISTIC OF TEMPERATURE SENSOR Temp. Resistance Temp. Resistance Temp. Resistance ℉ ℉ /℃ ℃ KΩ ℉ ℉ /℃ ℃ KΩ ℉ ℉ /℃ ℃ KΩ 62.6/17 14.6181 111.2/44 4.3874 15.8/-9 58.7079 64.4/18 13.918 113/45 4.2126 17.6/-8 56.3694 66.2/19 13.2631 114.8/46 4.0459... -
Page 8: Operation Modes And Functions
3. 3 Operation Modes and Functions 3.3.1 Auto mode function requirement TS range is 62 ℉ ℉ ℃ ℃). When T1<TS-1, select the setting temperature of TS-1 for Heating operation’s temperature. When TS+2≥T1≥TS-1,select the Fan-only mode. When T1>TS+2, select the setting temperature(TS ) for Cooling operation’s temperature. - Page 9 When the unit is off, the compressor stops at first, and the indoor/outdoor fan will stop for a delay of 5seconds. (If it operates at heating mode, the outdoor fan will be off for a delay of 30 seconds). The ION/TIMER functions are valid at the cooling mode. 3.3.4 Drying mode function requirement At Drying mode, TS can’t be controlled by display panel, and LED display as T1.
- Page 10 The ION/TIMER functions are valid at the heating mode. 3.4.6 Heating mode function requirement(for Heat Pump) TS range is 62 ( 17 ℉ ℉ ℃ ℃). T1≤TS+41 , compressor operates; ℉( ℃) T1﹥TS+42.8 , compressor stops; ℉( ℃) T1﹤41 ℉( ℃), heat pump mode is invalid;...
- Page 11 It’s invalid for compressor’s delay operation protection when unit is at defrosting function mode. On defrosting process, if malfunction occur, or power off, or change for non-heating mode, unit will esc defrosting function mode. At Heat pump mode, if P1 occurs, compressor, indoor/outdoor fan stop immidiately.
- Page 12 c) Circuit component of PCB is bad. Solution: a) Check the wire between display panel and PCB, make sure the connection is ok. b) Restart the unit. If it can not resume after 2 minutes, please replace the display panel. c) Restart the unit.
- Page 13 Not cool enough Causation: a) The windows or doors in the room are open. b) There are heat sources inside the room. c) Exhaust air duct is not connected or blocked. d) TS is too high. e) Air filter is blocked by dust. Solution: a) Make sure all the windows or doors are closed.
-
Page 14: Internal Structure
5. INTERNAL STRUCTURE Temperature sensor Evaporator Centrifugal fan Compressor Water pump Indoor fan motor Capacitor of compressor Condenser Water level sensor ... - Page 15 Display board Temperature sensor Display board Water level switch Relay Louver motor Outdoor motor Indoor motor Power on/off Capacitor of fan motor Electronic control box ...
-
Page 16: Exploded View
6. EXPLODED VIEW 6. 1 Single-hose model 39 1 . 32 6 . 2 5 . 1 6 . 1 5 . 1 8 . 1 4 . 5 1 . 5 2 . 2 4 . 1 10 5 3 . 2 3 . - Page 17 Drain pipe Pipe temperature sensor assembly Drain stopper Indoor temperature sensor assembly Drain stopper Air exhaust volute shell assembly Chassis assembly 32.1 Asynchronous motor 27.2 Shaded pole motor 32.2 Cover of air exhause volute shell 27.4 Spring 32.3 Connector of air exchaust duct 27.5 Water wheel 32.4...
- Page 18 Part name Part name Front panel assembly Window sealing board II Front panel Remote controller Signal receiving board assembly Power cord cover Adorn board Cover of drain connector Upper panel Drain pipe Horizontal louver Drain stopper Bracket Drain stopper Gear wheel Chassis assembly Gear wheel 27.2...
