Adjusting volume

1 Turn the [VOL] knob to the left or
right.
Turn to the right:
Increases the volume.
Turn to the left:
Decreases the volume.
ATTENTION
Press the [MUTE] button for less than one second to
mute the sound or restore it.
CAUTION
Do not adjust the volume or other controls while driving
the vehicle. Do so only while parked in a safe location.
Basic Operation
English

Detaching the front panel

The front panel of the main unit can be removed.
By removing this panel when you leave the vehicle, you can prevent the theft of the main unit.

How to remove the detachable panel

Press the [▲(OPEN)] button.
1
The front panel opens.
2 Detaching the front panel.
Hold the right side of the front panel and,
while pushing the panel toward the left,
pull it toward you to remove it.
3 Put the front panel into the case.
Push to open the front panel case and put the front panel in it.

How to attach the detachable panel

1 With the front panel open, hold its
right side, and clip its left side into the
mounting hooks of the main unit.
While pushing the front panel toward
2
the left, insert its right side into the
main unit until you hear a click.
3
Close the front panel manually.
CAUTION
• If you drop the detachable panel or subject it to
impact, it may be damaged or malfunction.
• Do not attempt to detach or attach the detachable
panel while driving since this could cause an accident.
• Store the detachable panel in a location free
from humidity, dust, and water.
• Do not leave the detachable panel in locations that are
likely to become hot, like the dashboard and surroundings.
