SERVICE MANUAL
4
2003
XA001
1
Important Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2
Disassembly method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3
Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4
Description of major ICs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
DVD VIDEO PLAYER
XV-C5SL
TV
DVD
STANDBY/ON
EJECT DISPLAY
TV
DVD
TV1
TV2
TV3
1
2
3
TV4
TV5
TV6
4
5
6
TV7
TV8
TV9
7
8
9
TV-/-
TV0
MUTING
10
0
+10
TITLE/
TV/VIDEO
RETURN
GROUP
CANCEL
CH
+
–
+
VOL
VOL
ENTER
CH
–
PREVIOUS
NEXT
CLEAR
SELECT
SLOW
–
SLOW
+
3D
PHONIC
ZOOM
VFP
ANGLE
SUB TITLE
AUDIO
AMP VOL
REPEAT
DIMMER
TABLE OF CONTENTS
COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LTD.
Area Suffix
B -------------------------- U.K.
E ------ Continental Europe
EN ------- Northern Europe
EV --------- Eastern Europe
EE ---- Russian Federation
US ---------------- Singapore
UG -
Turkey,South Africa,Egypt
UB --------------- Hong Kong
No.XA001
2003/5
