Cisco IOS XR Advanced System Command Reference for the Cisco
XR 12000 Router, Release 5.1.x
Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: 408 526-4000
800 553-NETS (6387)
Fax: 408 527-0883
Text Part Number: OL-30353-01

Advertisement

Table of Contents
loading

Related Manuals for Cisco XR 12000

Summary of Contents for Cisco XR 12000

  • Page 1 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x Americas Headquarters Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 http://www.cisco.com Tel: 408 526-4000 800 553-NETS (6387) Fax: 408 527-0883 Text Part Number: OL-30353-01...
  • Page 2 Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL: www.cisco.com/go/trademarks . Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company.

  • Page 3: Table Of Contents

    C H A P T E R 2 show arp trace show captured packets show cfgmgr trace show im database show imds interface brief show netio chains Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 4 C H A P T E R 4 show system verify show tech-support show tech-support aps show tech-support asic show tech-support bcdl show tech-support bundles Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 5 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 6 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 7: Obtaining Documentation And Submitting A Service Request

    Preface The Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Series preface contains these sections: • Changes to This Document, page vii • Obtaining Documentation and Submitting a Service Request, page vii Changes to This Document This table lists the technical changes made to this document since it was first printed.
  • Page 8 Preface Obtaining Documentation and Submitting a Service Request Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x viii OL-30353-01...

  • Page 9: Asic Driver Commands

    29 • show controllers pse qfp system state, page 31 • show controllers pse uidb , page 32 • show packet-memory, page 33 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 10: Controller Pse Tcam Location

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Task ID Task ID Operation sonet-sdh read, write dwdm read, write interface read, write Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 11 Related Commands Command Description show controllers pse, on page 23 Displays display packet switching engine (PSE) information in the egress or the ingress stage. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 12: Show Controllers Plim Asic Egress-Channel Bay

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Task ID Task ID Operations interface read Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 13 The “Buffer Almost Full Threshold” is expressed in hexadecimal format. Tx Queuing ASIC port number Identifies the SPI4.2 transmit port. 1 System Packet Level Interface 4.2 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 14: Show Controllers Plim Asic Ingress-Channel Bay

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Task ID Task ID Operations interface read Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 15 ------------------ <-- Buffer End (0x31fff) RxLen EDRAM buffer threshold settings: ====================================== ------------------ <-- Buffer Start (0x0) |------------------|<-- SPI4 AEmpty0 (0xc80) |------------------|<-- SPI4 AEmpty1 (0x1900) Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 16 Buffer Almost Full Threshold An increment counter which indicates that the transmit buffer is almost full. The “Buffer Almost Full Threshold” is expressed in hexadecimal format. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 17 Identifies the SPI4.2 transmit port. RxEDRAM buffer threshold settings Displays embedded DRAM receive buffer threshold counter settings in hexadecimal format. 2 System Packet Level Interface 4.2 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 18: Show Controllers Plim Asic Spa Bay

    The following sample output is from the show controllers plim asic spa bay command: RP/0/0/CPU0:router# show controllers plim asic spa bay 0 location 0/4/CPU0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 19 Layer 2 Length Adjust. When a length entry has been read or is being written, this bit contains the value of the L2LA field. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 20 Tstat bus. Selects rising or falling edge as the active transmit SClk edge. DIP4 Match Total number of 2-bit DIP4 packets that met specific match clauses. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 21 SPA. 3 online insertion and removal 4 Extended Flow Control 5 security policy index 6 2-bit Diagonal Interleaved Parity 7 megahertz Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 22: Show Controllers Plim Asic Statistics

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Task ID Task ID Operations interface read root-system read Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 23 Number of octets received or transmitted on the interface. TotalPkts Number of total packets received or transmitted on the interface. UnicastPkts Number of unicast packets received or transmitted on the interface. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 24 Number of packets (including bad packets) received or transmitted that were between 1519 and 1548 octets in length inclusive (excluding framing bits but including FCS octets). Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 25 (FCS error) or a bad FCS with a non-integral number of octets (assigned error). DeferralAbort Number of deferral aborts that occurred on this segment. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 26 RxFiFO Drop Displays the receive FIFO drop information. PAR Tail Drop Displays PAR tail drop information. TxFIFO Drop Displays transmitted FIFO drop information. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 27: Show Controllers Plim Asic Spaqfpbridgectrl

    Examples The following example shows how to display summarized PLIM ASIC SPAQFPBridgeCtrl driver information: RP/0/RP00/CPU0router# show controllers plim asic SPAQFPBridgeCtr Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 28: Show Controllers Plim Asic Summary

    The following example shows how to display summarized PLIM ASIC information for all locations: RP/0/0/CPU0:router# show controllers plim asic summary Node: 0/1/CPU0 -------------------------------------- Instance# 0 Summary info: -------------------------------------- Name : PLASPA Version Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 29 Node whose information is displayed. Information is displayed for each node’s SPA and its interfaces. Instance PLIM ASIC identifier. This is the PLIM ASIC associated with the specified location. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 30 • Key—AISC key, in hexadecimal format. • Hkey—ASIC registry key. • Hkey idx—ASIC registry key index. 8 Universal interface descriptor block Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 31: Show Controllers Pse

    Operations interface read drivers read Examples The following command shows how to use the show controllers pse command: RP/0/0/CPU0:router# show controllers pse egress gather Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 32: Show Controllers Pse Mem

    Operations interface read drivers read Examples The following command shows how to use the show controllers pse mem command: RP/0/RP0/CPU0:router# show controllers pse mem Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 33: Show Controllers Pse Statistics

    The instance { 0 | 1} keywords were replaced by the egress and ingress keywords. Release 3.6.0 The all keyword was changed from required to optional. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 34 60380 IPv6 not enabled EOAM EFM feature disable drop Debug Stats Count ----------- ----- PPE idle counter 84330433181953 Node 0/0/CPU0 Egress PSE Stats -------------------------------- Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 35 Identifies the node whose PSE statistics are displayed. The node ID is expressed in the rack/slot/module notation. PSE 0, Statistics Info Displays all statistics maintained by the PSE. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 36 ASIC Driver Commands show controllers pse statistics Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 37: Show Controllers Pse Qfp Statistics

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Task ID Task ID Operations interface read cisco-support read Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 38 Summary of Statistics for QFP 1 Dropped packets: 0 Incoming packets: 0 Outgoing packets: 0 Incoming IPC packets: 0 Outgoing IPC packets: 0 Punted packets: 0 Injected packets: 0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 39: Show Controllers Pse Qfp System State

    The following command shows how to run the show controllers pse qfp system state command: RP/0/0/CPU0:router# show controllers pse qfp system state location 0/1/cpu0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 40: Show Controllers Pse Uidb

    Examples The following command shows how to use the show controllers pse uidb command: RP/0/RP0/CPU0:router# show controllers pse uidb trace Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 41: Show Packet-Memory

    (Optional) Displays detailed packet memory information for the designated node. The node-id argument is entered in the rack/slot/module notation. Command Default Displays information about all packet memory. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 42 The show packet-memory command can be used to display the total number of packet and particle headers, along with the packet memory that is currently allocated in the system. Task ID Task ID Operations basic-services read Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 43 Packet Feature Specific Variable (FSV) Scratch pad shared among the features in the packet path, listing hangs of the packet header. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 44 ASIC Driver Commands show packet-memory Field Description Packet trace Data associated with the packet header to help tracing a packet in the system. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 45: Chapter

    This module describes commands used for troubleshooting routers running Cisco IOS XR software. The commands in this chapter with the cisco-support task ID are used in the Cisco IOS XR Troubleshooting Guide for Cisco XR 12000 Series Router as part of the troubleshooting process. For information about commands with the cisco-support task ID that are not documented in this chapter, please contact Cisco Technical Support.
  • Page 46 83 • show uidb trace, page 86 • show uidb index , page 88 • watchdog threshold memory, page 91 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 47: Show Arp Trace

    ARP-EVENT: Processing VLAN ) 5 19:54:15.434 ipv4_arp/slow 0/RP0/CPU0 5# t1 ARP-EVENT: Interface not up0 5 19:54:15.437 ipv4_arp/slow 0/RP0/CPU0 1# t3 ARP-EVENT: IMP caps add suc0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 48 5 19:54:15.567 ipv4_arp/slow 0/RP0/CPU0 t1 ARP-EVENT: updating arp-idb ip) 5 19:54:15.567 ipv4_arp/slow 0/RP0/CPU0 t1 ARP-EVENT: clearing ARP AIB en0 5 19:54:15.581 ipv4_arp/fast 0/RP0/CPU0 t1 ARP-EVENT: Completing IDB ifh:0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 49 ARP-EVENT: updated aib entry (0 5 23:35:45.392 ipv4_arp/slow 0/RP0/CPU0 t1 ARP-EVENT: updated aib entry (0 5 23:43:24.043 ipv4_arp/slow 0/RP0/CPU0 t1 ARP-EVENT: updated aib entry (0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 50 6 17:04:23.052 ipv4_arp/pkt 0/RP0/CPU0 t1 PROBE: MgmtEth0/RP0/CPU0/0 exceE 6 17:23:16.303 ipv4_arp/slow 0/RP0/CPU0 t1 ARP-EVENT: updated aib entry (0 Related Commands Command Description show arp Displays the ARP. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 51: Show Captured Packets

    Command Default No default behavior or values Command Modes EXEC Command History Release Modification Release 3.2 This command was introduced. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 52 Source, destination, and type or length values in the Ethernet header. IPV$ Depending on the type of packet, the layer 3 packet header follows. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 53: Show Cfgmgr Trace

    These traces are not present if the original active RP has ever reloaded (for example, if there have been any RP switchover events since the system first booted). Task ID Task ID Operations cisco-support read Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 54: Configuration Manager

    Apr 26 11:56:55.677 cfgmgr/common 0/RP0/CPU0 t1 Config media returned from dis. Related Commands Command Description show cfgmgr commitdb Displays the contents of the commit database for the configuration manager. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 55: Show Im Database

    For more information about the syntax for the router, use the question mark (?) online help function. location node-id Displays IM database information for a specified node. The node-id argument is entered in the rack/slot/module notation. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 56 1500/1500 State (constraint): UP (UP) Callback: OWN GROUP OWNER - ID 17[-] Ctrl Flags: CFG_RDY|RDY|DNLD|INTF Instance ID: Checkpoint: 48 bytes Resource in NetIO: TRUE Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 57 0x010802c0 Gi0/0/0/6.108 1518 4 10 GDP|LDP|L3P|OWN 0x010802e0 Gi0/0/0/6.109 1518 4 10 GDP|LDP|L3P|OWN 0x01080300 Gi0/0/0/6.110 1518 4 10 GDP|LDP|L3P|OWN 0x01080320 Gi0/0/0/6.111 1518 4 10 GDP|LDP|L3P|OWN Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 58 0x01180190 BE1080 4 GDP|LDP 0x011801b0 BE1083 4 GDP|LDP 0x011801d0 BE1084 4 GDP|LDP 0x011801f0 BE1085 5 12 GDP|LDP 0x01180210 BE1085.1 6 GDP|LDP 0x01180230 BE1085.102 7 GDP|LDP Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 59: Show Imds Interface Brief

    4474 14 (hdlc) 0x00080070 Bundle-Ether28 0x104ab up 1514 30 (ether) 0x00080090 Bundle-Ether28.1 0x10cab up 1500 107 (dot1q) 0x000800b0 Bundle-Ether28.2 0x10cab up 1500 107 (dot1q) Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 60 Table 11: show imds interface brief Field Descriptions Field Description name Interface name. state Interface state. MTU associated with the interface. encap Base encapsulation associated with the interface. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 61: Show Netio Chains

    No default behavior or values. Command Modes EXEC Command History Release Modification Release 3.8.0 This command was introduced. Release 3.9.0 No modifications. Release 4.0.0 No modifications. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 62 <0x795236c0, 0x081cf598> < 0> txm_nopull <60> <0x79516cd0, 0x0817cbd8> < 0> <22> (ether_sock) Stats IN: 0 pkts, 0 bytes; OUT: 0 pkts, 0 bytes Encap: Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 63 Displays protocol registrations for media changes. show netio subblock Displays Netio subblock information. Displays Netio trace data. show netio trace Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 64: Show Netio Clients

    XIPC drops/total: OutputQ: 0/0 HighOutputQ: 0/15682677 PuntbackQ: 0/0 Counters (error/total): Output (0/15682677) Puntback (0/0) Jump (0/0) Input Punt XIPC InputQ XIPC PuntQ ClientID Drop/Total Drop/Total Cur/High/Max Cur/High/Max -------------------------------------------------------------------------------- Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 65 Displays protocol registrations for media changes. show netio media registrations show netio subblock Displays Netio subblock information. show netio trace Displays Netio trace data. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 66: Show Netio Db

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Task ID Task ID Operation cisco-support read Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 67 Displays protocol registrations for media changes. show netio subblock Displays Netio subblock information. show netio trace Displays Netio trace data. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 68: Show Netio Idb

    No default behavior or values Command Modes EXEC Command History Release Modification Release 3.2 This command was introduced. Release 3.8.0 Changed the interface-type interface-instance arguments to required ones. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 69 Stats Type Chain_node <caps num> <function, context> <drop pkts, drop bytes> <7> (arp) Stats IN: 0 pkts, 0 bytes; OUT: 0 pkts, 0 bytes Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 70 Value assigned to the interface by the netio for identification. IN unknown proto pkts Number of packets sent to netio that had an unknown protocol type. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 71 Number of bytes in for the address family. Pkts Out Number of packets out for the address family. Bytes Out Number of bytes out for the address family. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 72 Displays protocol registrations for media changes. show netio subblock Displays Netio subblock information. show netio trace Displays Netio trace data. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 73: Show Netio Media-Registrations

    RP/0/0/CPU0:router# show netio media-registrations location 0/2/0 Registrations by L3 for media (change/upgrade) changes L3 Protocol Callback L2 Media -------------------------------------------- clns 0x795f978c atm_mux_vc atm_nlpid_vc atm_snap_vc atm_sub Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 74 Displays Netio IDB information. show netio subblock Displays Netio subblock information. show netio trace Displays Netio trace data. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 75: Show Netio Subblock

    (Optional) Displays Netio subblock information for a specified node. The node-id argument is entered in the rack/slot/module notation. Command Default No default behavior or values. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 76 0x7a020890 <0x081c2a88> <0x03001e00> <POS0_2_0_0.1 > < 2> <0x081c2acc> <0x03001f00> <POS0_2_0_1.1 > < 2> Related Commands Command Description show netio chains Displays Netio chains information. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 77 Displays Netio IDB information. Displays protocol registrations for media changes. show netio media registrations show netio trace Displays Netio trace data. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 78: Show Netio Trace

    (Optional) Displays unique entries with counts verbose (Optional) Displays internal debugging information wrapping (Optional) Displays wrapping entries Command Default No default behavior or values. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 79 6 (fint_n2n), caps 92 (fint_n2n), op ADD, chain D, data len 0 Jan 11 15:04:16.646 netio/chains--- 0/0/CPU0 t1 Chains: update IDB chain, ifhandle 0x01000100, prot Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 80 Displays Netio IDB information. Displays protocol registrations for media changes. show netio media registrations show netio subblock Displays Netio subblock information. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 81: Show Sysdb Connections

    Examples The following example shows the output of the show sysdb connections command. RP/0/0/CPU0:router# show sysdb connections detail location 0/1/CPU0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 82 N Verf susp: Client connid: 00000000 Connected at: Jul 14 19:31:47.316 "/debug/node/11/LR/sysmgr/" From: sysmgr (jid 79, nid 0/1/CPU0, tid 7) Connid: 00000013 Refcount: 0002 Options: 00000032 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 83: Show Sysdb Trace Verification Location

    The output shows that changes to the SysDB local plane were verified and accepted. RP/0/0/CPU0:router# show sysdb trace verification location 0/3/CPU0 Timestamp reg handle connid action path 323 wrapping entries (4096 possible, 299 filtered, 622 total) Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 84 This table describes the significant fields shown in the display. Table 13: show sysdb trace verification location Field Descriptions Field Description Timestamp Time of the verification. Job identifier of the verification. Thread identifier. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 85 Verifier has accepted the verification request. Related Commands Command Description Displays system database client connection shared show sysdb connection path shared-plane plane data for a specific path. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 86: Show Sysdb Trace Verification Shared-Plane

    To use this command, you must be in a user group associated with a task group that includes appropriate task IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 87 Client has registered with sysDB server for verification. Related Commands Command Description show sysdb connection path shared-plane Displays sysDB client connection shared plane data for a specific path. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 88: Show Tbm Hardware

    Displays prefix-related information. location node-id Displays tree bitmap hardware-related information for a specified node. The node-id argument is entered in the rack/slot/module notation. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 89 PLU: Num Writes : 3064 PLU: Num Copies : 2197 PLU Memory Channel Statistics: ----------------------------- Number of compactions: 0 FCRAM0 Chan: 110 (Pages: 5, 1% used) Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 90 PLU: Num Copies Number of copies to the PLU portion of the hardware. PLU Memory Channel Statistics Usage levels of each channel in the PLU memory. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 91: Show Uidb Data

    Displays micro-IDB index data information for a specified node. The node-id argument is entered in the rack/slot/module notation. Command Default No default behavior or values Command Modes EXEC Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 92 -> prog: DONE ->count: 0 -------------------------------------------- BUNDLE IFHANDLE: 0 TUNNEL IFHANDLE: 0 L2 ENCAP: 3 ============================================ General 16 bytes: ------------------------ IFHANDLE: 0x12800a STATUS: 1 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 93 86 Displays UIDB trace data debugging information that helps in troubleshooting the problem. show uidb data-dump Displays UIDB data information in hexadecimal format. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 94: Show Uidb Trace

    Examples The following example shows the sample output from the show uidb trace command: RP/0/0/CPU0:router sh uidb trace init loc 0/6/CPU0 -------------------------------------------------------------------------- Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 95 Related Commands Command Description show uidb data, on page 83 Displays UIDB index data information. show uidb data-dump Displays UIDB data information in hexadecimal format. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 96: Show Uidb Index

    Ingress-index Egress-index --------------------------------------------------------------------------- 0/1/CPU0 0/1/CPU0 GigabitEthernet0_1_5_0 Main interface 0/1/CPU0 GigabitEthernet0_1_5_1 Main interface 0/1/CPU0 GigabitEthernet0_1_5_2 Main interface 0/1/CPU0 GigabitEthernet0_1_5_3 Main interface 0/1/CPU0 GigabitEthernet0_1_5_4 Main interface Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 97 Name of the interface. Interface-Type Type of interface. Ingress-index Value associated with ingress processing on the interface. Egress-index Value associated with egress processing on the interface. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 98 83 Displays micro-interface descriptor block index data information. show uidb data-dump Displays micro-interface descriptor block data information in hexadecimal format. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 99: Watchdog Threshold Memory

    This table lists the recommended memory threshold value calculations if the minor threshold is set to 20 percent, the severe threshold is set to 10 percent, and the critical threshold is set to 5 percent. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 100 The following example shows how to configure the memory available for each alarm threshold: RP/0/0/CPU0:router #configure RP/0/0/CPU0:router(config)# watchdog threshold memory location 0/RP0/CPU0 minor 30 severe 20 critical 10 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 101: Fabric Management Commands

    112 • show controllers fabricq queue, page 115 • show controllers fabricq registers, page 118 • show controllers fabricq tofab, page 121 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 102: Clear Fabricq Counters All

    RP/0/0/CPU0:router(admin)# clear fabricq counters all location 0/1/CPU0 Related Commands Command Description show controllers fabricq frfab, on page 108 Displays output from the fabric statistics associated with the fabric queue driver. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 103 Fabric Management Commands clear fabricq counters all Command Description show controllers fabricq tofab, on page 121 Displays to fabric statistics associated with the fabric queue driver. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 104: Clear Fabricq Counters Frfab

    The following example shows how to clear the from fabric queue counters for the location 0/1/CPU0: RP/0/0/CPU0:router# admin RP/0/0/CPU0:router(admin)# clear fabricq counters frfab location 0/1/CPU0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 105 Related Commands Command Description show controllers fabricq frfab, on page 108 Displays output from the fabric statistics associated with the fabric queue driver. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 106: Clear Fabricq Counters Tofab

    The following example shows how to clear all to fabric queue counters for the location 0/1/CPU0: RP/0/0/CPU0:router # admin RP/0/0/CPU0:router(admin)# clear fabricq counters tofab location 0/1/CPU0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 107 Related Commands Command Description show controllers fabricq tofab, on page 121 Displays to fabric statistics associated with the fabric queue driver. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 108: Show Controllers Fabric

    Use the show controllers fabric command to display various registers associated with the fabric cards and state information associated with the fabric control software. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 109 Primary Clock Mode CSC_0 Redundant CSC_0 Redundant CSC_0 Redundant CSC_0 Redundant CSC_0 Redundant CSC_0 Redundant CSC_0 Redundant CSC_0 Redundant CSC_0 Redundant CSC_0 Redundant CSC_0 Redundant Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 110: Show Controllers Fabricq Drop

    RP. Use the detail keyword to display detailed output. The show controllers fabricq drop command is typically used for debugging purposes. Note Task ID Task ID Operations root-system read, write Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 111 Drop counter for packets transmitted over MBUS (Not supported) Tx-DIS: Drops because the tofab transmission is disabled From Fabric dropped packets: ---------------------------- Slot Rx-REF Rx-PKT Rx-DEC Rx-Total Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 112 From Fabric dropped packets Displays statistics about the received packets that were dropped. Slot Slot that contains the fabric card whose statistics are displayed. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 113 Displays the hardware registers of the chopper and assembler FPGAs. show controllers fabricq tofab, on page 121 Displays to fabric statistics associated with the fabric queue driver. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 114: Show Controllers Fabricq Errors

    The following is sample output from the show controllers fabricq errorscommand for location 0/1/CPU0: RP/0/0/CPU0:router# admin RP/0/0/CPU0:router(admin)# show controllers fabricq errors location 0/1/CPU0 Location 0/1/0: ToFab Errors: Error Type Error Count Max Rate Rate Exceeded Count ----------------------------------------------------------- Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 115 Displays the hardware registers of the chopper and assembler FPGAs. show controllers fabricq tofab, on page 121 Displays to fabric statistics associated with the fabric queue driver. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 116: Show Controllers Fabricq Frfab

    Command Default From fabric statistics are displayed for all route processors (RPs) on the router Command Modes Administration EXEC Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 117 From Fabric Error Stats: ------------------------ Bigger than MTU pkts Corrupted pkts SPD pkt count No IDB drops IDB queue tail drops Chan corrupted pkts Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 118 106 Displays the count of hardware errors associated with the fabric queue driver. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 119 Displays the hardware registers of the chopper and assembler FPGAs. show controllers fabricq tofab, on page 121 Displays to fabric statistics associated with the fabric queue driver. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 120: Show Controllers Fabricq Output

    Task ID Operations root-system read, write Examples The following is sample output from the show controllers fabricq output command for location 0/1/CPU0: RP/0/0/CPU0:router# admin Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 121 Average service time of all the packets sent to that slot. Timeouts Number of times a packet’s service time has exceeded a threshold of 200 milliseconds (the packet is dropped). Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 122 Displays the hardware registers of the chopper and assembler FPGAs. show controllers fabricq tofab, on page 121 Displays to fabric statistics associated with the fabric queue driver. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 123: Show Controllers Fabricq Queue

    The following is detailed sample output from the show controllers fabricq queue command for the location 0/1/CPU0: RP/0/0/CPU0:router# admin RP/0/0/CPU0:router(admin)# show controllers fabricq queue detail location 0/1/CPU0 Location 0/1/0: Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 124 EnQueued Number of entries enqueued for that queue. DeQueued Number of entries dequeued for that queue. Cur-Entrys Number of entries currently for that queue. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 125 Displays the hardware registers of the chopper and assembler FPGAs. show controllers fabricq tofab, on page 121 Displays to fabric statistics associated with the fabric queue driver. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 126: Show Controllers Fabricq Registers

    The following is sample output from the show controllers fabricq registers command for location 0/1/CPU0: RP/0/0/CPU0:router# admin RP/0/0/CPU0:router(admin)# show controllers fabricq registers location 0/1/CPU0 Location 0/1/0: Chopper Registers: Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 127 00000033 Low Pri Req level 00000030 High Pri Req level 00000060 Free Queue Size 00001000 Free Queue Base 0B3A6000 Free Queue Rd Pointer 0B3A6380 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 128 FPGAs. show controllers fabricq tofab, on page 121 Displays to fabric statistics associated with the fabric queue driver. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 129: Show Controllers Fabricq Tofab

    Command Default Statistical information is displayed for all route processors (RPs) on the router Command Modes Administration EXEC Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 130 This table describes the significant fields shown in the display. Table 24: show controllers fabricq tofab Field Descriptions Field Description Tx-pkts Number of packets sent to that slot. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 131 Displays information about the hardware queues of the performance route processor chopper and assembler FPGAs. show controllers fabricq registers, on page Displays the hardware registers of the chopper and assembler FPGAs. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 132 Fabric Management Commands show controllers fabricq tofab Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 133: Tech-Support Commands

    Tech-Support Commands This module describes commands used for displaying the output of show commands using Cisco IOS XR software software. The command output varies depending on the router platform and configuration. The show tech-support commands all display common data from commands such as show version . Each show tech-support command also generates and gathers relevant data for a specific area.
  • Page 134 • show tech-support sysdb, page 362 • show tech-support terminal, page 366 • show tech-support tty, page 371 • show tty details, page 374 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 135: Show System Verify

    Examples The following example shows how to prepare for system verification: RP/0/0/CPU0:router# show system verify start Storing initial router status ... done. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 136 - Verified Syslog Messages : [OK] System may not be stable. Please look into WARNING messages. This table describes the significant fields shown in the display. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 137 Total number packets input to the interface Bytes Input Total number of bytes input to the interface Packets Output Total number of packets output by the interface Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 138 Number of virtual interfaces neighbors Number of OSPF neighbors configured neighbors_adj Number of OSPF configured neighbors that are ‘adjacent’ Syslog Messages on router Number of syslog messages Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 139: Show Tech-Support

    • nvram: filename • rcp: filename • slot0: filename • slot1: filename • tftp: filename background (Optional) Specifies that the command runs in the background. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 140 This command is not required during normal use of the router. Note The following show commands run automatically when you run the show tech-support command: • show running-config • show version • show interfaces Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 141 • show controllers fabricq eio links all • show controllers pse eio links all • show controllers plim asic pla eio links all • show controllers fia eio links all Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 142 • admin show controllers fabric sfe s3 all detail • show environment all See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 143 Connected to CRS-1_2 Bundle-Ether 28.3 ipv4 address 10.0.31.1 255.255.255.0 dot1q vlan 31 interface Bundle-POS24 bundle minimum-active bandwidth 2488320 bundle minimum-active links 1 ipv4 address 10.10.24.1 255.255.255.0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 144: Show Tech-Support Aps

    (Optional) Specifies that the command output is displayed on the terminal. location (Optional) Specifies a node. node-id (Optional) Node ID. The node-id argument is entered in the rack/slot/module notation. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 145 The following example shows a truncated output of the show tech-support aps command: RP/0/0/CPU0:router# show tech-support aps show-only terminal ------------------------------------------------------------------------------- show tech-support aps ------------------------------------------------------------------------------- ---------------------------------- show aps ----------------------------------- no aps group found Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 146 Rx power = 0.0160 mW, -18.0 dBm Tx power = 0.0000 mW, -inf dBm Tx laser current bias = 0.0 mA Port SONET0/6/0/1: Status: Up Loopback: None Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 147 10000 ms Path delays trigger: 0 ms, 0 ms (configured), clear: 10000 ms Last clearing of "show controllers SONET" counters never Detected Alarms: SLOS Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 148 S1S0(tx): 0x0 S1S0(rx): 0x0 / Framing Derived PATH TRACE BUFFER : STABLE Remote hostname : PE21_C12406 Remote interface: POS0/2/0/3 Remote IP addr : 10.121.4.21 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 149 B1 = 10e-6 B2 = 10e-6 B3 = 10e-6 Optics type: None Clock source: internal (actual) line (configured) Rx S1: 0x0 Tx S1: 0xf Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 150 BIP(B2) = 0 PATH AIS = 0 FEBE = 0 BIP(B3) = 0 LOP = 0 NEWPTR = 0 PLM = 0 UNEQ = 0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 151 Alert reporting enabled for: B1-TCA B2-TCA B3-TCA Framing: SONET SPE Scrambling: Enabled C2 State: Stable C2_rx = 0xFF (255) C2_tx = 0x16 (22) / Scrambling Derived Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 152 Remote Rx(K1/K2): F1/F Remote Tx(K1/K2): 00/0 BER thresholds: SF = 10e-3 SD = 10e-6 TCA thresholds: B1 = 10e-6 B2 = 10e-6 B3 = 10e-6 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 153 Rx power = 0.0193 mW, -17.1 dBm Tx power = 0.0000 mW, -inf dBm Tx laser current bias = 0.0 mA Port SONET0/6/4/6: Status: Up Loopback: None Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 154 10000 ms Path delays trigger: 0 ms, 0 ms (configured), clear: 10000 ms Last clearing of "show controllers SONET" counters never Detected Alarms: SLOS Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 155 Clock source: internal (actual) internal (configured) Rx S1: 0x0 Tx S1: 0xf Optical Power Monitoring (accuracy: +/- 1dB) Not Supported ------------------------------------------------------------------------------- show tech-support aps complete ------------------------------------------------------------------------------- Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 156: Show Tech-Support Asic

    (Optional) Node ID. The node-id argument is entered in the rack/slot/module notation. Command Default No default behavior or values Command Modes Administration EXEC Command History Release Modification Release 3.4.0 This command was introduced. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 157 Use the show tech-support asic command to save an ASIC snapshot. This command generates ASIC information that can be useful for Cisco Technical Support representatives when troubleshooting a router. See 'Obtaining Documentation and Submitting a Service Request' section on page iii in the Preface for Cisco Technical Support contact information.
  • Page 158 RP/0/0/CPU0:router(admin)# show tech-support asic all inst 0 dir net/node0_RP0_CPU0/ harddisk:/asic_snapshots/ results in following files being created with contents.. # pwd /net/node0_RP0_CPU0/harddisk:/asic_snapshots # ls -lrt total 980 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 159: Show Tech-Support Bcdl

    • slot0: filename • slot1: filename • tftp: filename background (Optional) Specifies that the command runs in the background. compressed (Optional) Displays compressed command output. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 160 See the Cisco IOS XR Software command references for information about these commands and descriptions of their command output. The Cisco IOS XR Software command references are located at the following URL: Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x...
  • Page 161 0 2061 17 0 38431 38432 grp mpls_lsd_v6, gid 2062, sg cnt 1, agent jid 114, node 0/ /CPU0, pulse 7, n0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 162 38431 6895816 0 fib_mgr 114782 0/4/CPU1 0 2061 38431 6895816 0 fib_mgr group mpls_lsd_v6, gsp gid 2062, 6 consumers, agent jid 114, node 0/RP0/CPU0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 163 2060, sg cnt 1, agent jid 113, node 0/RP0/CPU0, pulse 38430 lwg fd csmr hdlr-act dnld-act susp wait-lck seq pulse-tot pulse-out Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 164 0:00:00:0026 bcdl_agent 10 Receive 0:00:01:0441 0:00:08:0542 bcdl_agent 10 Receive 0:00:13:0163 0:00:00:0000 bcdl_agent ------------------------------------------------------------------------------- Job Id: 112 PID: 479443 Executable path: /disk0/hfr-base-3.8.0.20I/sbin/bcdl_agent Instance #: 3 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 165 0:00:04:0881 0:00:04:0595 bcdl_agent 10 Condvar 160:22:56:0168 0:00:00:0003 bcdl_agent 10 Receive 160:26:09:0766 0:00:00:0000 bcdl_agent 10 Nanosleep 0:00:16:0666 0:00:00:0019 bcdl_agent 10 Receive 0:00:16:0589 0:00:00:0001 bcdl_agent --More--. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 166: Show Tech-Support Bundles

    (Optional) Displays the command output with no compression. interface (Optional) Collects information about a specific interface. type Interface type. For more information, use the question mark (?) online help function. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 167 Redirecting the output to a file also makes sending the output to your Cisco Technical Support representative easier. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 168 Preface for Cisco Technical Support contact information. See the Cisco IOS XR Software command references for information about these commands and descriptions of their command output. The Cisco IOS XR Software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html...
  • Page 169 172.29.52.47 255.255.255.0 interface MgmtEth0/RP0/CPU0/0 description Connected to Lab LAN ipv4 address 172.29.52.70 255.255.255.0 interface MgmtEth0/RP1/CPU0/0 description Connected to Lab LAN ipv4 address 172.29.52.71 255.255.255.0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 170 Connected to P2_CRS-8 POS 0/1/0/1 ipv4 address 10.12.8.1 255.255.255.0 interface POS0/1/0/2 shutdown interface POS0/1/0/3 shutdown interface POS0/1/4/0 description Connected to P2_CRS-8 POS 0/1/4/0 bundle id 24 mode active Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 171 10.13.4.1 255.255.255.0 interface POS0/6/4/7 description Connected to PE7_C12406 POS 0/5/0/1 ipv4 address 10.71.4.1 255.255.255.0 interface Serial0/1/1/0 shutdown interface Serial0/1/1/1 shutdown interface Serial0/1/1/2 shutdown interface Serial0/1/1/3 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 172 10.1.1.1 nsf cisco area 0 mpls traffic-eng interface Bundle-POS24 interface Loopback0 passive enable interface GigabitEthernet0/1/5/1 interface GigabitEthernet0/1/5/2 interface GigabitEthernet0/6/5/1 interface GigabitEthernet0/6/5/2 interface POS0/1/0/1 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 173 POS0/6/4/7 interface GigabitEthernet0/1/5/2 interface GigabitEthernet0/6/5/1 interface GigabitEthernet0/6/5/2 mpls ldp router-id 10.1.1.1 neighbor graceful-restart interface Bundle-POS24 interface GigabitEthernet0/1/5/1 interface GigabitEthernet0/1/5/2 interface GigabitEthernet0/6/5/1 interface GigabitEthernet0/6/5/2 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 174 36890 eth_server 36897 attach_server Reply 114:08:46:0323 12301 mqueue 41005 reddrv Reply 0:00:00:0141 36890 eth_server 110726 lpts_fm Reply 114:05:43:0881 381043 node 0/RP0/Ca node: node0_6_CPU0 ------------------------------------------------------------------ Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 175 Stack Trace #0 0xfc1e6d90 #1 0xfc1e6d88 #2 0xfc1e53a0 #3 0xfc1e826c #4 0xfc16b0c8 #5 0xfc16a7e4 #6 0xfc16a324 #7 0xfc16e7a8 #8 0xfc16ea08 #9 0x48200e20 Registers info Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 176 DLL Info DLL path Text addr. Text size Data addr. Data size Version /hfr-os-3.6.0.16I/lib/libinfra.dll 0xfc15a000 0x000397b0 0xfc194000 0x000000 /hfr-os-3.6.0.16I/lib/libc.dll 0xfc1ce000 0x0007b6e0 0xfc24a000 0x00002000 0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 177: Show Tech-Support Cef

    (Optional) Specifies detailed CEF debugging information. brief (Optional) Specifies a brief CEF debugging information. (Optional) Specifies that the command output is saved to a specified file. file Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 178 (Optional) Specifies that the command runs in the background. (Optional) Displays compressed command output. compressed uncompressed (Optional) Displays the command output with no compression. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 179 • show cef {ipv4 | ipv6 | mpls} drop • show ipv4 interface brief • show cef {ipv4 | ipv6} summary • show cef {ipv4 | ipv6 | mpls} interface Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 180 • show mpls forwarding (if the mpls keyword is specified) See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html...
  • Page 181 0.0.0.0/0 172.29.52.1 200 mpls ldp router-id 10.1.1.1 neighbor graceful-restart interface GigabitEthernet0/1/5/1 interface GigabitEthernet0/1/5/2 interface POS0/1/0/1 ssh server xml agent tty xml agent corba http server Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 182 Reply 0:00:00:0000 16405 eth_server 16412 ksh-aux Reply 236:24:19:0271 8199 devc-ser8250 16413 attach_server Reply 236:24:24:0493 8204 mqueue 20516 1 reddrv_listener Reply 0:00:04:0086 16405 eth_server Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 183: Show Tech-Support Cfgmgr

    If not used, the output scrolls (that is, it does not stop for page breaks). Press the Ctrl+C keys to stop the command output. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 184 'Obtaining Documentation and Submitting a Service Request' section on page iii in the Preface for Cisco Technical Support contact information. See the Cisco IOS XR Software command references for information about these commands and descriptions of their command output. The Cisco IOS XR Software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 185 172.29.52.72 255.255.255.0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 186 10.16.4.1 255.255.255.0 interface GigabitEthernet0/1/5/3 shutdown interface GigabitEthernet0/1/5/4 shutdown interface GigabitEthernet0/1/5/5 shutdown interface GigabitEthernet0/1/5/6 description Connected to P2_CRS-8 GE 0/1/5/6 bundle id 28 mode active Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 187 P1_CRS-8 password encrypted 070C285F4D06 ppp authentication chap pap ppp chap password encrypted 1511021F0725 interface POS0/6/0/0 description Connected to P11_CRS-4 POS 0/2/1/0 ipv4 address 10.111.4.1 255.255.255.0 interface POS0/6/0/1 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 188 SONET0/1/4/2 clock source internal controller SONET0/1/4/3 clock source internal controller SONET0/6/0/0 clock source internal controller SONET0/6/0/1 clock source internal controller SONET0/6/0/3 clock source internal Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 189 POS0/6/0/3 interface POS0/6/4/4 interface POS0/6/4/6 interface POS0/6/4/7 interface SBC1 passive enable interface SBC2 passive enable mpls traffic-eng router-id Loopback0 mpls oam rsvp interface POS0/6/0/1 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 190 POS0/6/4/6 interface POS0/6/4/7 ssh server xml agent tty xml agent corba http server sbc service-1 service-location preferred-active 0/4/CPU0 sbc service-2 service-location preferred-active 0/4/CPU1 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 191 Tech-Support Commands show tech-support cfgmgr ---------------------- show configuration failed startup ---------------------- !!10:28:35 UTC Thu Oct 11 2007 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 192: Show Tech-Support Chdlc

    (Optional) Specifies a node. node-id (Optional) Node ID. The node-id argument is entered in the rack/slot/module notation. rack (Optional) Displays a list of racks. Command Default None. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 193 Examples The following example how to run the show tech-support chdlc command on the router: RP/0/0/CPU0:router# show tech-support chdlc interface gigabitEthernet 0/6/5/0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 194: Show Tech-Support Control-Ethernet

    If not used, the output scrolls (that is, it does not stop for page breaks). Press the Ctrl-C keys to stop the command output. file Specifies that the command output is saved to a specified file. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 195 To use this command, you must be in a user group associated with a task group that includes appropriate task IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 196 • show controller backplane ethernet trace node-id See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html The show tech-support control-ethernet command also generates log files which are not listed.
  • Page 197 Copyright (c) 2009 by Cisco Systems, Inc. ROM: System Bootstrap, Version 1.51(20080807:092259) [CRS-1 ROMMON], P2_CRS-8 uptime is 1 day, 18 hours, 10 minutes System image file is "bootflash:disk0/hfr-os-mbi-3.8.0.20I/mbihfr-rp.vm" Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 198 Built on Wed Oct 29 16:18:36 DST 2008 By iox30.cisco.com in /auto/ioxbuild6/production/3.8.0.20I.DT_IMAGE/hfr/wor0 hfr-fwdg, V 3.8.0.20I[DT_IMAGE], Cisco Systems, at disk0:hfr-fwdg-3.8.0.20I Built on Wed Oct 29 16:13:27 DST 2008 By iox30.cisco.com in /auto/ioxbuild6/production/3.8.0.20I.DT_IMAGE/hfr/wor0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 199 Tech-Support Commands show tech-support control-ethernet --More-- Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 200: Show Tech-Support Dsc

    • nvram: filename • rcp: filename • slot0: filename • slot1: filename • tftp: filename (Optional) Specifies that the command runs in the background. background Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 201 The following show commands run automatically when you run the show tech-support dsc command: • show dsc all See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 202 #0 0xfc177518 [MsgReceivev] trace_back: #1 0xfc161354 [msg_receivev] trace_back: #2 0xfc161160 [msg_receive] trace_back: #3 0xfc16479c [event_dispatch] trace_back: #4 0xfc164958 [event_block] trace_back: #5 0x48200f34 [<N/A>] ENDOFSTACKTRACE Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 203 Instance #: 1 Version ID: 00.00.0000 Respawn: ON Respawn count: 1 Max. spawns per minute: 12 Last started: Fri Mar 16 14:56:35 2007 Process state: Run Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 204 10 Receive 0:00:52:0856 0:00:00:0176 dsc 10 Receive 326:49:44:0414 0:00:00:0001 dsc 10 Receive 0:00:00:0083 0:00:01:0127 dsc 10 Receive 0:00:00:0643 0:00:00:0019 dsc 55 Receive 0:00:00:0060 0:14:49:0966 dsc Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 205: Show Tech-Support Ethernet

    (Optional) Node ID. The node-id argument is entered in the rack/slot/module notation. rack (Optional) Specifies a list of racks. Command Default IPv4 is the default. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 206 • show mpls forwarding (if the mpls keyword is specified) See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x...
  • Page 207 --------------- show context [15:01:53.820 UTC Thu Dec 17 2009] --------------- ------------------------------------------------------------------------------- show tech-support ether common ------------------------------------------------------------------------------- ++++++++ show ethernet driver trace [15:01:55.942 UTC Thu Dec 17 2009] ++++++++ Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 208 NetIO Dec 16 16:33:25.801 gether/0/main 0/RSP0/CPU0 1# t4 ETH_INFO: Binding to NetIO Dec 16 16:33:25.819 gether/0/main 0/RSP0/CPU0 1# t4 ETH_INFO: Connection to NetIO succeeded Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 209 Dec 16 16:33:46.118 gether/0/fast 0/RSP0/CPU0 1# t4 HW API: Get Autoneg called for Mg0/RSP0/CPU0/1 (0x00000080) (bay=0, port=1) Autoneg configured: speed not restricted, duplex not restricted, flowcontrol not restricted Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 210 Mg0/RSP0/CPU0/0 (0x00000040) (bay=0, port=0) new state: enabled, hw link down Dec 16 16:34:32.916 gether/0/main 0/RSP0/CPU0 1# t4 ETH_EVENTS: FSM action: Port admin state enabled event for Mg0/RSP0/CPU0/0 (0x00000040); succeeded; link state: DOWN Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 211: Show Tech-Support Fabric

    If not used, the output scrolls (that is, it does not stop for page breaks). Press the Ctrl-C keys to stop the command output. file (Optional) Specifies that the command output is saved to a specified file. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 212 Use the show tech-support fabric command to run show commands that display information specific to fabric debugging. This command generates fabric information that can be useful for Cisco Technical Support Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 213 • show controllers cpuctrl devices ingressq pdma queue all act • show controllers cpuctrl devices egressq pdma queue all act • show controllers cpuctrl devices fabricq pdma queue all act Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 214 Tech-Support Commands show tech-support fabric See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 215 0/SM2/SP FC/S(SP) IOS XR RUN PWR,NSHUT,MON 0/SM3/SP FC/S(SP) IOS XR RUN PWR,NSHUT,MON MSC: 0/1/CPU0 is running DRP: 0/4/CPU0 is running MSC: 0/6/CPU0 is running Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 216 Total number of FGIDs in the system is 1000000 Current number of InUse FGIDs in the system is 1012 High Water Mark of InUse FGIDs in the system is 1512 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 217: Show Tech-Support Gsp

    Press the Ctrl-C keys to stop the command output. Specifies that the command output is saved to a specified file. file Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 218 To use this command, you must be in a user group associated with a task group that includes appropriate task IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 219 Use the show tech-support gsp command to run show commands that display information specific to GSP debugging. GSP is a common IPC utilized in Cisco IOS XR software to communicate between nodes. This command would be used to determine if there are any issues with GSP communication between nodes. This command generates GSP debugging information that can be useful for Cisco Technical Support representatives when troubleshooting a router.
  • Page 220 : 65535 attrs :[0x9 0x4] STATIC, CLOSED, PRIVATE ADMIN PLANE addr : 01 00. 00 00. 27 74 addr flags addr media Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 221 : 1 0. 0 0. 27 75. 0 0 seq addr flags seq addr media seq_snv nodecnt seq_snv sns cnt seq snv[0] : 0x701 Number of sync variables: 0 ************************ Nodevec Entries Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 222 RSI id :0x810 node str :0/SM1/SP node state node nacked node next seqnum node next ctrl seq:f node mbr cnt node uc tx seqnum :0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 223: Show Tech-Support Igmp Snooping

    If not used, the output scrolls (that is, it does not stop for page breaks). Press the Ctrl+C keys to stop the command output. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 224 • show pkgfs trace location all • show install trace loadpath location node-id • show install trace io location node-id • show install trace instdir-lr location node-id Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 225 • show filesystem location node-id • run diskinfo (various) See the Cisco IOS XR Software command references for information about these commands and descriptions of their command output. The Cisco IOS XR Software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 226 By sjc-lds-524 in /auto/srcarchive3/production/3.9.0/asr9k/workspace for c4.2.1-p0 asr9k-mcast, V 3.9.0[00], Cisco Systems, at disk0:asr9k-mcast-3.9.0 Built on Mon Dec 14 13:33:02 UTC 2009 By sjc-lds-524 in /auto/srcarchive3/production/3.9.0/asr9k/workspace for c4.2.1-p0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 227 ---------------------- show running-config igmp snooping ---------------------- igmp snooping profile prof1 ttl-check disable router-alert-check disable ----------------- show igmp snooping summary statistics debug ----------------- Bridge Domains: Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 228 Cfg Msgs Sent: BDXC Send: Errors: None Network Statistics (elapsed time since last cleared 6d20h): Socket Event: Network Connection Open Event: Network Connection Close Event: Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 229 IGMP Group Specific Queries: IGMP G&S Specific Queries: IGMP V2 Reports: IGMP V3 Reports: IGMP V2 Leaves: IGMP Global Leaves: PIM Hellos: Rx Packet Treatment: Packets Flooded: Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 230 Tech-Support Commands show tech-support igmp snooping Packets Forwarded To Members: Packets Forwarded To Mrouters: Packets Consumed: Rx Errors: None Rx Other: None Tx Errors: None Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 231: Show Tech-Support Install

    (Optional) Node ID. The node-id argument is entered in the rack/slot/module notation. rack (Optional) Displays the list of racks. Command Default Output is logged to the terminal screen. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 232 • show install package all detail • show install log verbose • show running-config sanitize • show redundancy • show logging • show platform • show install active detail Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 233 • show filesystem location node-id • run diskinfo (various) See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 234 Built on Thu Mar 15 00:18:08 UTC 2007 By cisco.com in /auto/3.8.0 ------------------------- show install active summary ------------------------- Active Packages: disk0:hfr-sbc-3.8.0 disk0:hfr-pagent-3.8.0 disk0:hfr-fpd-3.8.0 disk0:hfr-doc-3.8.0 disk0:hfr-diags-3.8.0 disk0:hfr-mgbl-3.8.0 disk0:hfr-mcast-3.8.0 disk0:hfr-mpls-3.8.0 disk0:hfr-k9sec-3.8.0 disk0:comp-hfr-mini-3.8.0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 235 Inventory Manager on HFR fabric-fgid V[ci-35/17] Fabric Multicast management component fabric-fsdb V[ci-35/12] Fabric State management component hfr-fabricq V[ci-35/13] Fabric Queue Manager. Driver for the fabric queueing ASIC. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 236: Show Tech-Support L2Tp

    If not used, the output scrolls (that is, it does not stop for page breaks). Press the Ctrl+C keys to stop the command output. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 237 Redirecting the output to a file also makes sending the output to your Cisco Technical Support representative easier. This command collects relevant data for Layer 2 tunneling protocol-related issues that can be useful for Cisco Technical Support representatives when troubleshooting a router. See 'Obtaining Documentation and Submitting a Service Request' section on page iii in the Preface for Cisco Technical Support contact information.
  • Page 238 ------------ show l2tp counters control session fsm state current ------------- Current State Count ====================== Init Idle Wt-Sock Wt-CC Proc-ICRQ Wt-Rx-ICCN Proc-ICCN Wt-Tx-ICRQ Wt-Tx-ICRP Wt-Tx-ICCN Wt-Rx-ICRP Proc-ICRP established Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 239 Respawn count: 1 Max. spawns per minute: 12 Last started: Thu Oct 11 19:25:05 2007 Process state: Run Package state: Normal core: TEXT SHAREDMEM MAINMEM Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 240 Tech-Support Commands show tech-support l2tp Max. core: 0 Level: 999 Placement: ON startup_path: /pkg/startup/l2tp.startup Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 241: Show Tech-Support L2Vpn

    If not used, the output scrolls (that is, it does not stop for page breaks). Press the Ctrl+C keys to stop the command output. rack (Optional) Displays the list of racks. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 242 Redirecting the output to a file also makes sending the output to your Cisco Technical Support representative easier. This command collects information for Layer 2 VPN related issues that can be useful for Cisco Technical Support representatives when troubleshooting a router. See 'Obtaining Documentation and Submitting a Service Request' section on page iii in the Preface for Cisco Technical Support contact information.
  • Page 243 Boot device on node 0/4/CPU0 is disk0: Package active on node 0/4/CPU0: hfr-sbc, V 3.6.0.16I[SIT1_IMAGE1], Cisco Systems, at disk0:hfr-sbc-3.6.0.16I Built on Tue Oct 2 15:07:32 DST 2007 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 244 2 15:58:47 DST 2007 By iox42.cisco.com in /auto/ioxbuild2/production/3.6.0.16I.SIT1_IMAGE1/hfr/8 hfr-fpd, V 3.6.0.16I[SIT1_IMAGE1], Cisco Systems, at disk0:hfr-fpd-3.6.0.16I Built on Tue Oct 2 14:48:41 DST 2007 By sjce-gf-071.cisco.com in /auto/ioxbuild2/production/3.6.0.16I.SIT1_IMAGE8 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 245 2 14:48:32 DST 2007 By sjce-gf-071.cisco.com in /auto/ioxbuild2/production/3.6.0.16I.SIT1_IMAGE8 hfr-mcast, V 3.6.0.16I[SIT1_IMAGE1], Cisco Systems, at disk0:hfr-mcast-3.6.0.16I Built on Tue Oct 2 14:26:29 DST 2007 By sjce-gf-061.cisco.com in /auto/ioxbuild2/production/3.6.0.16I.SIT1_IMAGE8 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 246: Show Tech-Support Lrd

    If not used, the output scrolls (that is, it does not stop for page breaks). Press the Ctrl+C keys to stop the command output. location (Optional) Specifies a node. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 247 (SDR) architecture. The system always has at least one SDR at any time. It collects relevant information when issues arise with the SDR management within the system. This command can be useful for Cisco Technical Support representatives when troubleshooting a router. See 'Obtaining Documentation and Submitting a Service Request' section on page iii in the Preface for Cisco Technical Support contact information.
  • Page 248 Received 23 currently connected lrd clients eFLAGS cFLAGS _______________________________ 168027 77863 0x11 0x204 81963 0x10 0x200 168024 168026 200800 0x1f 204909 209006 0x23 0x84 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 249 ------------LRD LOG START FOR NODE node0_RP0_CPU0------------ 10/11 10:19:16.309 1 main: ---LRD starting--- 10/11 10:19:16.325 1 main: **********LRD on Node=0x201********** 10/11 10:19:16.327 1 main: mutex init for inv_mutex DONE. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 250 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 251 (0x30207) (-1) LC(2) 0/2/CPU0 0x841 RUNNING_MBI(5) RUNNING_ENA(6) (0x30207) (-1) LC(2) 0/3/CPU0 0x851 BRINGDOWN(7) NOT_PRESENT(0) (0x3020a) (-1) Sw State Info for Node = node0_RSP0_CPU0 ----------------------------------------------------------------------------------- Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 252 RUNNING_ENA(6) (0x100302) (-1) LC(2) 0/0/CPU0 0x821 RUNNING_MBI(5) RUNNING_ENA(6) (0x30207) (-1) LC(2) 0/2/CPU0 0x841 RUNNING_MBI(5) RUNNING_ENA(6) (0x30207) (-1) LC(2) 0/3/CPU0 0x851 BRINGDOWN(7) NOT_PRESENT(0) (0x3020a) (-1) Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 253 Dec 14 11:23:21.511 lrd/sntf 0/RSP0/CPU0 t13 : 0/132/1 RUNNING_ENA Dec 14 15:42:37.504 lrd/sntf 0/RSP0/CPU0 t13 : 0/133/1 PRESENT Dec 14 15:42:37.608 lrd/sntf 0/RSP0/CPU0 t13 : 0/133/1 BOOTING Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 254 ---------- show ltrd-trace server [17:21:39.392 UTC Fri Dec 18 2009] ---------- ++++++++++ show ltrd-trace server [17:21:39.548 UTC Fri Dec 18 2009] ++++++++++ lrd_show_ltrace -F lrd/sreg -TP1 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 255 ++++++++++ show ltrd-trace server [17:21:40.326 UTC Fri Dec 18 2009] ++++++++++ lrd_show_ltrace -F lrd/sreg -TP2 29 wrapping entries (64 possible, 0 filtered, 29 total) Client re-Registrations: Curr-msg-op New-Msg-op Event-flags Card-flags ----------------------------------------------------------------------------------- Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 256 Dec 14 11:20:18.381 lrd/supd 0/RSP0/CPU0 t1 : 0/RSP0/CPU0(0x1 ADMIN BAND INFRA BAND Active 0x11 Dec 14 11:20:54.823 lrd/supd 0/RSP0/CPU0 t4 : 0/RSP0/CPU0(0x1 INFRA BAND FINAL BAND Active 0x11 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 257: Show Tech-Support Mpls Ldp

    If not used, the output scrolls (that is, it does not stop for page breaks). Press the Ctrl+C keys to stop the command output. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 258 This command is not required during normal use of the router. Note See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 259 Built on Tue Oct 2 13:53:07 DST 2007 By iox26.cisco.com in /auto/ioxbuild2/production/3.6.0.16I.SIT1_IMAGE1/hfr/8 hfr-base, V 3.6.0.16I[SIT1_IMAGE1], Cisco Systems, at disk0:hfr-base-3.6.0.16I Built on Tue Oct 2 13:51:10 DST 2007 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 260 V 3.6.0.16I[SIT1_IMAGE1], Cisco Systems, at disk0:hfr-pagent-3.6.0.I Built on Tue Oct 2 15:58:47 DST 2007 By iox42.cisco.com in /auto/ioxbuild2/production/3.6.0.16I.SIT1_IMAGE1/hfr/8 hfr-fpd, V 3.6.0.16I[SIT1_IMAGE1], Cisco Systems, at disk0:hfr-fpd-3.6.0.16I Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 261: Show Tech-Support Mpls Optical-Uni

    If not used, the output scrolls (that is, it does not stop for page breaks). Press the Ctrl+C keys to stop the command output. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 262 This command is not required during normal use of the router. Note See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 263 ----------------------- show mpls optical-uni lmp ipcc ------------------------ ---------------------------- show mpls lmp clients ---------------------------- -------------------- show mpls optical-uni diagnostics All -------------------- ---------------------- show mpls optical-uni timers all ----------------------- Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 264 Present Time: 16/10/2007 17:09:06 O-UNI timers presently active for nodes: IP addr. Type Name Set@ Timeout ---------- -------- ------------ -------------------- ------- Present Time: 16/10/2007 17:09:06 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 265: Show Tech-Support Mpls Rsvp

    (Optional) Specifies that the command runs in the background. background compressed (Optional) Displays compressed command output. uncompressed (Optional) Displays the command output with no compression. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 266 MPLS RSVP debugging. This command generates RSVP debugging information that can be useful for Cisco Technical Support representatives when troubleshooting a router. See 'Obtaining Documentation and Submitting a Service Request' section on page iii in the Preface for Cisco Technical Support contact information. This command is not required during normal use of the router.
  • Page 267 • show rsvp trace client • show rsvp debug-error See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 268 Refreshed LSP count: 0 LSP count recovered from checkpoint: 0 Proxy Senders: 0 Proxy Reservations: 0 Proxy Listeners: 1 TMB allocation: 0 Local Routes: 22 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 269 Path delete Path delete Path error Path error Path change Path change Matching Resv create Matching Resv create Matching Resv change Matching Resv change Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 270 Listener Resv create Listener Resv create Listener Resv change Listener Resv change Listener Resv delete Listener Resv delete Restart Time Restart Time Recovery Done Recovery Done Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 271: Show Tech-Support Mpls Traffic-Eng

    (Optional) Displays the tunnel name that is used by the RSVP process. tunnel name (Optional) Name for the tunnel. terminal Specifies that the command output is displayed on the terminal. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 272 This command is not required during normal use of the router. Note See the Cisco IOS XR Software command references for information about these commands and descriptions of their command output. The Cisco IOS XR Software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 273 IF DELETE NOTFN from IM MESSAGE to RSVP MESSAGES from RSVP MESSAGES to IGP SYSDB VRFNs SYSDB APPLYs MESSAGE to LSD MESSAGES from LSD Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 274 Node: 0/1/CPU0 Unresolved drops packets : Unsupported drops packets : Null0 drops packets : No route drops packets : No Adjacency drops packets : Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 275 Tech-Support Commands show tech-support mpls traffic-eng Checksum error drops packets : Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 276: Show Tech-Support Multicast

    If not used, the output scrolls (that is, it does not stop for page breaks). file (Optional) Specifies that the command output is saved to a specified file. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 277 (Optional) Specifies a VPN routing and forwarding (VRF) instance. vrf-name (Optional) Name of VRF. Command Default Output is logged to the terminal screen. Command Modes EXEC Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 278 PIM, IGMP, and mcast. This command generates multicast information that can be useful for Cisco Technical Support representatives when troubleshooting a router. See 'Obtaining Documentation and Submitting a Service Request' section on page iii in the Preface for Cisco Technical Support contact information.
  • Page 279 • show mfib hardware resource-counter location node-id • show mfib hardware adjacency detail location node-id • show mfib hardware route accept-bitmap detail source-address location node-id Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 280 Tech-Support Commands show tech-support multicast See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL:http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID Task ID...
  • Page 281 ------------------------------------------------------------------------------- No process aborts found ------------------------------------------------------------------------------- node: node0_4_CPU0 ------------------------------------------------------------------------------- 03/27/2007 08:18:35.326 chkpt_proxy(3) (jid 373) abnormally terminated, restart scheduled ------------------------------------------------------------------------------- node: node0_4_CPU1 ------------------------------------------------------------------------------- Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 282 0:00:00:0000 16405 eth_server 16412 ksh-aux Reply 283:52:34:0211 8199 devc-ser8250 16413 attach_server Reply 283:52:39:0432 8204 mqueue 20516 1 reddrv_listener Reply 0:00:01:0053 16405 eth_server node: node0_4_CPU0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 283: Show Tech-Support Netflow

    (Optional) Node ID. The node-id argument is entered in the rack/slot/module notation. (Optional) Displays the list of racks. rack Command Modes EXEC Command History Release Modification Release 3.9.0 This command was introduced. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 284 This command is not required during normal use of the router. See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html...
  • Page 285 Jan 18 07:41:40.057 netflow/nfmgr 0/1/CPU0 t1 Got NRS class handle=0x4000004e for classname=NetflowFlowRecordMapClass. Jan 18 07:41:40.059 netflow/nfmgr 0/1/CPU0 t1 Got NRS class handle=0x4000004f for Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 286 Jan 18 07:41:40.153 netflow/nfmgr 0/1/CPU0 t1 Fobj has no more references. Doing cleanup..Jan 18 07:41:40.153 netflow/nfmgr 0/1/CPU0 t1 Cleaning up FSM{smm} Jan 18 07:41:40.153 netflow/nfea 0/1/CPU0 t1 Fmon limit check: index=0,ifh=0x6000780,fmm=fmm,proto=ipv4,dir=input Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 287 Cleaning up FSM{smm} Jan 18 07:43:41.920 netflow/nfmgr 0/1/CPU0 t1 Unregistering from FMM{fmm} with ENS/NRS. Jan 18 07:43:41.920 netflow/nfmgr 0/1/CPU0 t1 Fobj reference 0x50020af4 was deleted successfully Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 288 Cerr='ifmgr' detected the 'warning' condition 'One of the arguments is invalid' ----------- show flow trace all [09:29:25.734 UTC Mon Jan 18 2010] ------------ Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 289: Show Tech-Support Nrs

    If not used, the output scrolls (that is, it does not stop for page breaks). Press the Ctrl+C keys to stop the command output. rack (Optional) Displays the list of racks. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 290 This command is not required during normal use of the router. Note See the Cisco IOS XR Software command references for information about these commands and descriptions of their command output. The Cisco IOS XR Software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 291 0xfc5e4000 0x000436f0 0xfc628000 0x00000b3c /pkg/lib/libsysdb.dll 0xfc629000 0x00050b00 0xfc67a000 0x00000b74 /pkg/lib/cerrno/libsysmgr_error.dll 0xfc585058 0x00000f94 0xfc4feee4 0x000000880 /pkg/lib/libsysdbutils.dll 0xfc690000 0x0000d378 0xfc5ddabc 0x0000046c /pkg/lib/cerrno/libsysdb_error_v1v2.dll 0xfc6a0000 0x00001e08 0xfc575e6c 0x00000 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 292: Show Tech-Support Password

    If not used, the output scrolls (that is, it does not stop for page breaks). Press the Ctrl+C keys to stop the command output. location (Optional) Specifies a node. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 293 Cisco Technical Support representatives when troubleshooting a router. See 'Obtaining Documentation and Submitting a Service Request' section on page iii in the Preface for Cisco Technical Support contact information. This command is not required during normal use of the router.
  • Page 294 172.29.52.72 255.255.255.0 hw-module service sbc location 0/4/CPU0 hw-module service sbc location 0/4/CPU1 interface Bundle-Ether28 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 295 10.12.29.1 255.255.255.0 dot1q vlan 29 interface Bundle-Ether28.2 description Connected to P2_CRS-8 Bundle-Ether 28.2 ipv4 address 10.12.30.1 255.255.255.0 dot1q vlan 30 interface Bundle-Ether28.3 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 296: Show Tech-Support Pfi

    If not used, the output scrolls (that is, it does not stop for page breaks). Press the Ctrl+C keys to stop the command output. location (Optional) Specifies a node. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 297 This command is not required during normal use of the router. Note See the Cisco IOS XR Software command references for information about these commands and descriptions of their command output. The Cisco IOS XR Software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 298 Oct 11 19:24:10.699 ifmgr/errors 0/RP0/CPU0 t1 Failed to bind to pfi_ifh serve' Oct 11 19:24:10.699 ifmgr/mdr 0/RP0/CPU0 t1 IM received LR state 0x4 from sysmr Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 299 Oct 11 19:24:11.831 ifmgr/download 0/RP0/CPU0 t10 Sending pulse code 124 to imp0 Oct 11 19:24:12.008 ifmgr/register 0/RP0/CPU0 t10 im_notify_queue: Inserting ca] Oct 11 19:24:12.331 ifmgr/register 0/RP0/CPU0 t10 im_notify_queue: Inserting ca] Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 300: Show Tech-Support Placement

    (Optional) Specifies that the command runs in the background. compressed (Optional) Displays compressed command output. (Optional) Displays the command output with no compression. uncompressed Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 301 This command is not required during normal use of the router. Note See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 302 Oct 11 19:24:07.350 properties Inserting Nodetypeaffinity (4832b950) (value -402 Oct 11 19:24:07.402 properties Inserting Nodetypeaffinity (4832b9b8) (value -40) Oct 11 19:24:07.562 properties Inserting Nodetypeaffinity (4832baf0) (value 100) Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 303: Show Tech-Support Pos

    (Optional) Displays the command output with no compression. Collects information about a specific interface. interface type Interface type. For more information, use the question mark (?) online help function. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 304 Press the Ctrl+C keys to stop the command output. Command Modes EXEC Command History Release Modification Release 3.2 This command was introduced. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 305 This command is not required during normal use of the router. Note See the Cisco IOS XR Software command references for information about these commands and descriptions of their command output. The Cisco IOS XR Software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 306 30 interface Bundle-Ether28.3 description Connected to P2_CRS-8 Bundle-Ether 28.3 ipv4 address 10.12.31.1 255.255.255.0 dot1q vlan 31 interface Bundle-POS24 description Connected to P2_CRS-8 Bundle-POS 24 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 307 172.29.52.46 255.255.255.0 interface MgmtEth0/4/CPU1/0 description Connected to Lab LAN ipv4 address 172.29.52.47 255.255.255.0 interface MgmtEth0/RP0/CPU0/0 description Connected to Lab LAN ipv4 address 172.29.52.70 255.255.255.0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 308: Show Tech-Support Ppp

    (Optional) Displays the command output with no compression. Collects information about a specific interface. interface type Interface type. For more information, use the question mark (?) online help function. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 309 Redirecting the output to a file also makes sending the output to your Cisco Technical Support representative easier. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 310 This command is not required during normal use of the router. Note See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...

  • Page 311: Show Tech-Support Qos

    (Optional) Specifies a node. location node-id (Optional). Node ID. The node-id argument is entered in the rack/slot/module notation. rack (Optional) Displays the list of racks. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 312 The following example shows a sample output of platform independent QoS information for the show tech-support routing qos command: RP/0/0/CPU0:router# show tech-support qos pi ------------------------------------------------------------------------------- show tech-support qos pi ------------------------------------------------------------------------------- ------------------------------------------------------------------------------- show tech-support qos pi ------------------------------------------------------------------------------- Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 313 Package active on node 0/1/CPU0: asr9k-scfclient, V 3.9.0[00], Cisco Systems, at disk0:asr9k-scfclient-3.9.0 Built on Mon Dec 14 12:38:43 UTC 2009 By sjc-lds-524 in /auto/srcarchive3/production/3.9.0/asr9k/workspace for c4.2.1-p0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 314 By sjc-lds-524 in /auto/srcarchive3/production/3.9.0/asr9k/workspace for c4.2.1-p0 asr9k-os-mbi, V 3.9.0[00], Cisco Systems, at disk0:asr9k-os-mbi-3.9.0 Built on Mon Dec 14 12:12:19 UTC 2009 By sjc-lds-524 in /auto/srcarchive3/production/3.9.0/asr9k/workspace for c4.2.1-p0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 315 Gi0/1/0/16 admin-down admin-down ARPA 1514 1000000 Gi0/1/0/17 admin-down admin-down ARPA 1514 1000000 Gi0/1/0/18 admin-down admin-down ARPA 1514 1000000 Gi0/1/0/19 admin-down admin-down ARPA 1514 1000000 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 316 1 end-class-map policy-map a class b set dscp af11 class class-default end-policy-map flow monitor-map fmm record ipv4 cache entries 10000 cache timeout active 70 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 317 GigabitEthernet0/1/0/12 shutdown interface GigabitEthernet0/1/0/13 shutdown interface GigabitEthernet0/1/0/14 shutdown interface GigabitEthernet0/1/0/15 shutdown interface GigabitEthernet0/1/0/16 shutdown interface GigabitEthernet0/1/0/17 shutdown interface GigabitEthernet0/1/0/18 shutdown interface GigabitEthernet0/1/0/19 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 318 GigabitEthernet0/1/0/36 shutdown interface GigabitEthernet0/1/0/37 shutdown interface GigabitEthernet0/1/0/38 negotiation auto l2transport interface GigabitEthernet0/1/0/39 shutdown interface GigabitEthernet0/2/0/0 shutdown interface GigabitEthernet0/2/0/1 shutdown interface GigabitEthernet0/2/0/2 shutdown Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 319 GigabitEthernet0/1/0/28 input Total targets: 1 Targets (applied as child policy): Total targets: 0 ---------- show policymap targets [09:11:35.467 UTC Mon Jan 18 2010] ---------- Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 320: Show Tech-Support Rdsfs

    (Optional) Specifies that the command runs in the background. compressed (Optional) Displays compressed command output. (Optional) Displays the command output with no compression. uncompressed rack (Optional) Displays the list of racks. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 321 RDSFS debugging and is relevant to bring to a ready state. This command generates RDSFS debugging information that can be useful for Cisco Technical Support representatives when troubleshooting a router. See 'Obtaining Documentation and Submitting a Service Request' section on page iii in the Preface for Cisco Technical Support contact information.

  • Page 322: Show Tech-Support Rib

    (Optional) Specifies that the command runs in the background. background compressed (Optional) Displays compressed command output. uncompressed (Optional) Displays the command output with no compression. ipv4 (Optional) Displays the IPv4 command output. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 323 This command is not required during normal use of the router. Note See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...

  • Page 324: Show Tech-Support Routing Bfd

    (Optional) Specifies that the command runs in the background. background compressed (Optional) Displays compressed command output. uncompressed (Optional) Displays the command output with no compression. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 325 Use the show tech-support routing bfd command to run show commands that display information specific to BFD debugging. This command generates BFD debugging information that can be useful for Cisco Technical Support representatives when troubleshooting a router. See 'Obtaining Documentation and Submitting a Service Request' section on page iii in the Preface for Cisco Technical Support contact information.
  • Page 326 • show controllers pse statistics location node-id See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html...
  • Page 327 1 reddrv_listener Reply 0:00:02:0206 16405 eth_server ------------------------------ show bfd location ------------------------------ Location: 0/1/CPU0 IPV4 Sessions Up: 0, Down: 0, Standby: 0, Total: 0 Location: 0/1/SP Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 328: Show Tech-Support Routing Isis

    (Optional) Specifies that the command runs in the background. compressed (Optional) Displays compressed command output. (Optional) Displays the command output with no compression. uncompressed Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 329 See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x...
  • Page 330 No IS-IS isp IPv4 Unicast levels found IS-IS Router: isp System Id: 0000.0000.0000 (Not configured, protocol disabled) IS Levels: level-1-2 Manual area address(es): Routing for area address(es): Non-stop forwarding: Disabled Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 331 - IS-IS (redistributed from another instance) Maximum parallel path count: 8 IS-IS isp checkpoint interface Interface Handle CircNum DIS Areas Chkpt ID No 'checkpoint interfaces' found in IS-IS isp Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 332 30 (ether) state: 3 (up) mtu: 1514 protocol count: 4 control parent: 0x00000000 data parent: 0x00000000 protocol capsulation state --------------- -------------------- --------------- -------- 7 (arp) Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 333: Show Tech-Support Routing Ospf

    Press the Ctrl-C keys to stop the command output. file Specifies that the command output is saved to a specified file. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 334 To use this command, you must be in a user group associated with a task group that includes appropriate task IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 335 OSPF debugging. This command generates OSPF debugging information that can be useful for Cisco Technical Support representatives when troubleshooting a router. See 'Obtaining Documentation and Submitting a Service Request' section on page iii in the Preface for Cisco Technical Support contact information. This command is not required during normal use of the router.
  • Page 336 The common non-ospf information such as version, placement info, logging and so on are not included. See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 337 POS0/1/0/1 is up, line protocol is up Internet Address 10.12.8.1/24, Area 0 Process ID 100, Router ID 10.1.1.1, Network Type POINT_TO_POINT, Cost: 1 Transmit Delay is 1 sec, State POINT_TO_POINT, Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 338 Last flood scan time is 0 msec, maximum is 0 msec Neighbor Count is 1, Adjacent neighbor count is 1 Adjacent with neighbor 10.2.2.2 Suppress hello for 0 neighbor(s) Multi-area interface Count is 0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 339: Show Tech-Support Routing Ospfv3

    • nvram: filename • rcp: filename • slot0: filename • slot1: filename • tftp: filename background (Optional) Specifies that the command runs in the background. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 340 OSPFv3 debugging. This command generates OSPFv3 debugging information that can be useful for Cisco Technical Support representatives when troubleshooting a router. See 'Obtaining Documentation and Submitting a Service Request' section on page iii in the Preface for Cisco Technical Support contact information.
  • Page 341 • show ospfv3 database • show ospfv3 route See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 342 V 3.8.0.20I[DT_IMAGE], Cisco Systems, at disk0:hfr-k9sec-3.8.0.20I Built on Wed Oct 29 16:59:58 DST 2008 By iox26.cisco.com in /auto/ioxbuild6/production/3.8.0.20I.DT_IMAGE/hfr/wor0 hfr-mgbl, V 3.8.0.20I[DT_IMAGE], Cisco Systems, at disk0:hfr-mgbl-3.8.0.20I Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 343 By iox3.cisco.com in /auto/ioxbuild6/production/3.8.0.20I.DT_IMAGE/hfr/work0 hfr-k9sec, V 3.8.0.20I[DT_IMAGE], Cisco Systems, at disk0:hfr-k9sec-3.8.0.20I Built on Wed Oct 29 16:59:58 DST 2008 By iox26.cisco.com in /auto/ioxbuild6/production/3.8.0.20I.DT_IMAGE/hfr/wor0 --More-- Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 344: Show Tech-Support Routing Rpl

    (Optional) Specifies that the command runs in the background. compressed (Optional) Displays compressed command output. (Optional) Displays the command output with no compression. uncompressed Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 345 • show sysdb reg notif path /ipc/gl/policy_lang/policies/routing/ policy-name /pxl s See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html...
  • Page 346 Mon Nov 10 18:53:03.975 PST DST router isis lab is-type level-2-only net 49.1122.0000.0000.0002.00 interface Loopback0 passive address-family ipv4 unicast interface POS0/1/0/2 address-family ipv4 unicast interface POS0/1/0/3 address-family ipv4 unicast Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 347 00000312 0/RP0/CPU0 0002 00000592 '/cfg/gl/rip/.*/.*/ord_t/policy-in' 00000312 0/RP1/CPU0 0002 00000568 '/cfg/gl/rip/.*/.*/ord_t/policy-in' 00000312 0/RP0/CPU0 0002 00000594 '/cfg/gl/rip/.*/.*/ord_t/policy-out' 00000312 0/RP1/CPU0 0002 00000569 '/cfg/gl/rip/.*/.*/ord_t/policy-out' 00000312 0/RP0/CPU0 0002 00000590 '/cfg/gl/rip/.*/.*/ord_t/defaultinformation' Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 348 00000312 0/RP0/CPU0 0002 00000544 '/cfg/gl/ip-bgp/.*/.*/ord_b/.*/gbl/edm/ord_' 00000312 0/RP1/CPU0 0002 00000531 '/cfg/gl/ip-bgp/.*/.*/ord_b/.*/gbl/edm/ord_' 00000312 0/RP0/CPU0 0002 00000582 '/cfg/gl/ip-bgp/.*/.*/ord_b/.*/gbl/edm/ord_' 00000312 0/RP1/CPU0 0002 00000561 '/cfg/gl/ip-bgp/.*/.*/ord_b/.*/gbl/edm/ord_' 00000312 0/RP0/CPU0 0002 00000549 '/cfg/gl/ip-bgp/.*/.*/ord_b/.*/nbr/.*/edm/.' --More- Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 349: Show Tech-Support Serial

    (Optional) Displays the command output with no compression. (Optional) Collects information about a specific interface. interface type Interface type. For more information, use the question mark (?) online help function. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 350 Press the Ctrl+C keys to stop the command output. Command Modes EXEC Command History Release Modification Release 3.2 This command was introduced. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 351 This command is not required during normal use of the router. Note See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 352 Connected to P2_CRS-8 Bundle-Ether 28.2 ipv4 address 10.12.30.1 255.255.255.0 dot1q vlan 30 interface Bundle-Ether28.3 description Connected to P2_CRS-8 Bundle-Ether 28.3 ipv4 address 10.12.31.1 255.255.255.0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 353: Show Tech-Support Sanitized

    (Optional) Specifies that the command runs in the background. background (Optional) Displays compressed command output. compressed uncompressed (Optional) Displays the command output with no compression. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 354 This command is not required during normal use of the router. See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html...
  • Page 355 <removed> <removed> alias <removed> <removed> alias <removed> <removed> alias <removed> <removed> alias <removed> <removed> alias <removed> <removed> alias <removed> <removed> alias <removed> <removed> control-plane management-plane Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 356 10.0.0.14 255.0.0.0 interface GigabitEthernet0/1/5/1 description <removed> ipv4 address 10.0.0.14 255.0.0.0 interface GigabitEthernet0/1/5/2 description <removed> ipv4 address 10.0.0.14 255.0.0.0 interface GigabitEthernet0/1/5/3 shutdown interface GigabitEthernet0/1/5/4 shutdown Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 357 <removed> interface POS0/1/4/3 description <removed> ipv4 address 10.0.0.14 255.0.0.0 encapsulation ppp ppp pap sent-username <removed> password encrypted <removed> Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 358 10.0.0.14 255.0.0.0 interface POS0/6/0/1 description <removed> ipv4 address 10.0.0.14 255.0.0.0 interface POS0/6/0/2 shutdown interface POS0/6/0/3 description <removed> ipv4 address 10.0.0.14 255.0.0.0 interface POS0/6/4/0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 359: Show Tech-Support Services

    • slot0: filename • slot1: filename • tftp: filename (Optional) Specifies that the command runs in the background. background compressed (Optional) Displays compressed command output. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 360 Use the show tech-support services command to run show commands that display information specific to the services diversion infrastructure, which is used with the service blade offerings for the Cisco IOS XR platforms. This command generates tech-support information that relates to services debugging information that can be useful for Cisco Technical Support representatives when troubleshooting a router.
  • Page 361 Standby node boot Thu Oct 11 19:17:51 2007: 6 days, 17 hours, 31 minutes ago Standby node last went not ready Thu Oct 11 20:13:05 2007: 6 days, 16 hours, 36o Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 362 #1 0xfc1e6d88 #2 0xfc1e53a0 #3 0xfc1e826c #4 0xfc16b0c8 #5 0xfc16a7e4 #6 0xfc16a324 #7 0xfc16e7a8 #8 0xfc16ea08 #9 0x48200e20 Registers info 00000000 4811bc50 48215204 00000000 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 363: Show Tech-Support Snmp

    • harddiska: filename • harddiskb: filename • nvram: filename • rcp: filename • slot0: filename • slot1: filename • tftp: filename location (Optional) Specifies a node. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 364 This command is not required during normal use of the router. See the Cisco IOS XR Software command references for information about these commands and descriptions of their command output. The Cisco IOS XR Software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html...

  • Page 365: Show Tech-Support Spaipc

    (Optional) Displays the command output with no compression. (Optional) Collects information about a specific interface. interface type Interface type. For more information, use the question mark (?) online help function. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 366 See 'Obtaining Documentation and Submitting a Service Request' section on page iii in the Preface for Cisco Technical Support contact information. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 367 This command is not required during normal use of the router. Note See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 368 172.29.52.70 255.255.255.0 interface MgmtEth0/RP1/CPU0/0 description Connected to Lab LAN ipv4 address 172.29.52.71 255.255.255.0 interface GigabitEthernet0/1/5/0 description Connected to P2_CRS-8 GE 0/1/5/0 ipv4 address 10.12.16.1 255.255.255.0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 369 10.14.8.1 255.255.255.0 interface GigabitEthernet0/1/5/2 description Connected to PE6_C12406 GE 0/4/0/1 ipv4 address 10.16.4.1 255.255.255.0 interface GigabitEthernet0/1/5/3 shutdown interface GigabitEthernet0/1/5/4 shutdown interface GigabitEthernet0/1/5/5 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 370: Show Tech-Support Sysdb

    (Optional) Displays compressed command output. uncompressed (Optional) Displays the command output with no compression. shared-plane (Optional) Displays the data for the shared plane. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 371 This command is not required during normal use of the router. Note See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 372 /pkg/lib/libss_common.dll 0xfc1c7000 0x000088f0 0xfc147994 0x00000274 /pkg/lib/libc.dll 0xfc1d0000 0x0007b6e0 0xfc24c000 0x00002000 /pkg/lib/lib_procfs_util.dll 0xfc252000 0x00004e8c 0xfc196cc0 0x000002a8 /pkg/lib/libplatform.dll 0xfc25e000 0x0000e144 0xfc26d000 0x00002000 /pkg/lib/libsyslog.dll 0xfc26f000 0x0000564c 0xfc25d258 0x00000328 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 373 481ffbc4 00000001 00000000 00000000 registers_info: registers_info: 00000001 481ffb38 00000001 48230000 registers_info: registers_info: 48220000 24000024 48238e60 00000000 registers_info: registers_info: 00000001 481ffaf8 48230000 00000000 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 374: Show Tech-Support Terminal

    Cisco Technical Support representatives when troubleshooting a router. See 'Obtaining Documentation and Submitting a Service Request' section on page iii in the Preface for Cisco Technical Support contact information. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x...
  • Page 375 This command is not required during normal use of the router. Note See the Cisco IOS XR software command references for information about these commands and descriptions of their command output. The Cisco IOS XR software command references are located at the following URL: http://www.cisco.com/en/US/products/ps5845/prod_command_reference_list.html Task ID...
  • Page 376 172.29.52.47 255.255.255.0 interface MgmtEth0/RP0/CPU0/0 description Connected to Lab LAN ipv4 address 172.29.52.70 255.255.255.0 interface MgmtEth0/RP1/CPU0/0 description Connected to Lab LAN ipv4 address 172.29.52.71 255.255.255.0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 377 Connected to P2_CRS-8 POS 0/1/0/1 ipv4 address 10.12.8.1 255.255.255.0 interface POS0/1/0/2 shutdown interface POS0/1/0/3 shutdown interface POS0/1/4/0 description Connected to P2_CRS-8 POS 0/1/4/0 bundle id 24 mode active Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 378 10.12.32.1 255.255.255.0 encapsulation ppp ppp pap sent-username P1_CRS-8 password encrypted <removed> ppp authentication chap pap ppp chap password encrypted <removed> interface POS0/1/4/3 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 379: Show Tech-Support Tty

    (Optional) Displays the command output with no compression. location node-id (Optional) Specifies a node. The node-id argument is entered in the rack/slot/module notation. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 380 Tue Sep 04 09:41:22 UTC 2012 Waiting for gathering to complete ........ Tue Sep 04 09:44:31 UTC 2012 Compressing show tech output Show tech output available at 0/RP0/CPU0 : Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 381 Tech-Support Commands show tech-support tty harddisk:/showtech/showtech-tty-2012-Sep-04.094121.UTC.tgz ++ Show tech end time: 2012-Sep-04.094432.UTC ++ Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 382: Show Tty Details

    IBuf Count 1077467 1077452 40582 The following example shows output of the show tty details location 0/RP0/CPU0 command: RP/0/0/CPU0:router# show tty details location 0/RP0/CPU0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 383 ---- ---- ---- ---- 8201 ---- ---- ---- ---- Session Id Exec Pid Master Pid PTY Count Net Count IBuf Count 1077467 1077452 40582 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 384 Tech-Support Commands show tty details Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 385: Watchdog Commands

    406 • show reboot history, page 408 • show reboot last, page 410 • show reboot pcds, page 413 • show watchdog, page 416 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 386: Show Critmon Context

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Use theshow critmon context command to display information about the context for the wd-critical-mon process. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 387 PunchTimestamp : 02/10/2008 01:11:10 PunchCounter ------------------------------------------------------------------------------ Ticker context info (Node: 0/2/CPU0) ------------------------------------------------------------------------------ CPU# Ticker counter : 61 Ticker last ran timestamp : 02/10/2008 01:11:10 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 388 Timestamp for the last time the wd-critical-mon ticker thread was run. Watcher context info wd-critical-mon watcher thread context information that is used for the node. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 389 Displays information about the trace data for the library error for the critical monitor. show critmon trace lib-info, on page 401 Displays trace data for the library information for the critical monitor. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 390: Show Critmon Deadline

    IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator for assistance. Use the show critmon deadline command to display information about the deadline monitoring. Task ID Task ID Operations cisco-support read Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 391 Activated Field specifies that deadline monitoring is activated or not. tick address Tick memory address for the client application. timeout vale(sec) Deadline timeout value. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 392 Displays information about the trace data for the library error for the critical monitor. show critmon trace lib-info, on page 401 Displays trace data for the library information for the critical monitor. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 393: Show Critmon Statistics

    Specifies all locations. Command Default No default behavior or values Command Modes EXEC Administration EXEC Command History Release Modification Release 3.6.0 This command was introduced . Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 394 10/22/2007 15:48:39 1497 10/22/2007 16:03:39 1498 10/22/2007 16:18:39 1497 10/22/2007 16:33:39 1498 10/22/2007 16:48:39 1497 10/22/2007 17:03:39 1498 10/22/2007 17:18:39 1497 10/22/2007 17:33:39 1498 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 395 10/22/2007 17:55:37 4455 cpu:0 10/22/2007 18:10:37 4454 cpu:0 10/22/2007 18:25:37 4454 cpu:0 10/22/2007 18:40:37 4455 cpu:0 10/22/2007 18:55:36 4455 cpu:0 10/22/2007 19:10:36 4455 ------------------------------------------------------------------------------ Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 396 ------ ------ ------------------- ---------- ------------ cpu:0 10/22/2007 14:25:41 4454 cpu:0 10/22/2007 14:40:41 4455 cpu:0 10/22/2007 14:55:41 4454 cpu:0 10/22/2007 15:10:41 4455 cpu:0 10/22/2007 15:25:41 4455 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 397 10/22/2007 16:10:41 wdsysmon 10/22/2007 16:25:41 wdsysmon 10/22/2007 16:40:41 wdsysmon 10/22/2007 16:55:40 wdsysmon 10/22/2007 17:10:40 wdsysmon 10/22/2007 17:25:40 wdsysmon 10/22/2007 17:40:40 wdsysmon 10/22/2007 17:55:40 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 398 10/22/2007 19:03:52 1495 10/22/2007 19:18:52 1495 ------------------------------------------------------------------------------ CPU congestion history (Node: 0/1/CPU0) ------------------------------------------------------------------------------ No congestion history ------------------------------------------------------------------------------ Deadline monitoring statistics info (Node: 0/1/CPU0) ------------------------------------------------------------------------------ Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 399 History of CPU congestion. Deadline monitoring statistics info Deadline monitoring statistics information that is used for the node. client Name of deadline monitoring client. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 400 Displays information about the trace data for the library error for the critical monitor. show critmon trace lib-info, on page 401 Displays trace data for the library information for the critical monitor. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 401: Show Critmon Trace All

    Node ID. The node-id argument is entered in the rack/slot/module notation. Specifies all locations. Command Default No default behavior or values Command Modes EXEC Administration EXEC Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 402 Displays information about the trace data for the library error for the critical monitor. show critmon trace lib-info, on page 401 Displays trace data for the library information for the critical monitor. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 403: Show Critmon Trace Error

    Node ID. The node-id argument is entered in the rack/slot/module notation. Specifies all locations. Command Default No default behavior or values Command Modes EXEC Administration EXEC Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 404 Displays information about the trace data for the library error for the critical monitor. show critmon trace lib-info, on page 401 Displays trace data for the library information for the critical monitor. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 405: Show Critmon Trace Info

    Node ID. The node-id argument is entered in the rack/slot/module notation. Specifies all locations. Command Default No default behavior or values Command Modes EXEC Administration EXEC Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 406 Displays information about the trace data for the library error for the critical monitor. show critmon trace lib-info, on page 401 Displays trace data for the library information for the critical monitor. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 407: Show Critmon Trace Lib-Error

    Node ID. The node-id argument is entered in the rack/slot/module notation. Specifies all locations. Command Default No default behavior or values Command Modes EXEC Administration EXEC Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 408 Displays trace data for an information type for the critical monitor. show critmon trace lib-info, on page 401 Displays trace data for the library information for the critical monitor. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 409: Show Critmon Trace Lib-Info

    Node ID. The node-id argument is entered in the rack/slot/module notation. Specifies all locations. Command Default No default behavior or values Command Modes EXEC Administration EXEC Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 410 Displays trace data for an information type for the critical monitor. show critmon trace lib-error, on page 399 Displays information about the trace data for the library error for the critical monitor. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 411: Show Reboot First

    1 00:00:00.000 : wd-critical-mon[79]: HW Watchdog: registratir DRP/0/4/CPU0:Jun 10 11:24:12.258 : init[65540]: %OS-INIT-7-MBI_STARTED : total DRP/0/4/CPU0:Jun 10 11:24:28.088 : insthelper[59]: %INSTALL-INSTHELPER-7-START_ DRP/0/4/CPU0:Jun 10 11:24:38.547 : insthelper[59]: %INSTALL-INSTHELPER-7-PKG_DO Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 412 DRP/0/4/CPU0:Jun 10 21:58:05.646 : sysmgr[78]: debug_d(1) (jid 143) (pid 147522d DRP/0/4/CPU0:Jun 13 16:40:50.173 : exec[65690]: %SECURITY-login-6-AUTHEN_SUCCES DRP/0/4/CPU0:Jun 13 16:41:45.619 : syslog_dev[76]: debug_d[143]: sysdb_find fai' Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 413 410 Displays the latest crash information. show reboot pcds, on page 413 Displays Persistent Critical Data Store critical information for the last ungraceful reboot. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 414: Show Reboot Graceful

    [0x46ad85b7b5] Map ingressq PCI base address.ingressq_phy_base = 0xa0000000, in0 [0x46ad8af9ba] Perform Node isolation from Fabric. ingressq_phy_base = 0xa000008 [0x46ad8afe88] Complete Kernel dumper platform task without dumping. rc: 0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 415 410 Displays the latest crash information. show reboot pcds, on page 413 Displays Persistent Critical Data Store critical information for the last ungraceful reboot. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 416: Show Reboot History

    Process: mbi-hello Traceback: fc15b1a0 fc15b290 482 0020c fc1d5fb0 0 0 Thu Aug 16 16:32:35 2007 0x21000106 Cause: All fabric links down on Fabric Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 417 410 Displays the latest crash information. show reboot pcds, on page 413 Displays Persistent Critical Data Store critical information for the last ungraceful reboot. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 418: Show Reboot Last

    RP/0/0/CPU0:router# show reboot last crashinfo location 0/1/CPU0 Crashinfo Timestamp: Wed Oct 10 19:04:02 2007 20071010 10:04:03 Crash Reason: Cause code 0x2000004f Cause: MBI-HELLO reloading node on receivin0 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 419 DBAT2L # 0xf000006a DBAT3U # DBAT3L # 0xf0000022 Segment Registers Index # SR-Value 10 # 11 # 12 # 13 # 14 # 15 # Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 420 Displays reboot information for the last graceful reboot. show reboot pcds, on page 413 Displays Persistent Critical Data Store critical information for the last ungraceful reboot. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 421: Show Reboot Pcds

    000050 00000974 00000000 30464fe4 ffffff00 ...t..0FO..000060 b8000003 b8000007 b8000003 b8000007 ....000070 0b0f0b0f 13911300 b8000013 b8000017 ....000080 470ca354 01000300 00001c44 00000000 G..T..D..Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 422 0004e0 b8000003 b8000007 b8000003 b8000007 ....0004f0 0b0f0b0f 13911300 b8000013 b8000017 ....000500 470ca35f 01000300 00001c7a 00000000 G.._..z..000510 00000987 00000000 30464fe4 ffffff00 ..0FO..Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 423 408 Displays reboot information for the last graceful reboot. show reboot last, on page 410 Displays the latest crash information. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...

  • Page 424: Show Watchdog

    Use the show watchdog command to display information about the memory states or thresholds for a specified location. You can display the default or configured memory thresholds. Task ID Task ID Operations basic-services read Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 425 Free Memory: 2623.671 MB Memory State: Normal Related Commands Command Description watchdog threshold memory Configures the value of memory available for each alarm threshold. Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 426 Watchdog Commands show watchdog Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01...
  • Page 427 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x OL-30353-01 IN-1...
  • Page 428 Cisco IOS XR Advanced System Command Reference for the Cisco XR 12000 Router, Release 5.1.x IN-2 OL-30353-01...

Table of Contents
