RS-855 lcd PROFESSIONAL REMOTE CAR STARTER WITH ALARM SYSTEM & 2-WAY LCD COMMUNICATION OPERATION MANUAL THIS PRODUCT IS DESIGNED FOR PROFESIONAL INSTALLATION ONLY...
TABLE OF CONTENTS: A. REMOTE TRANSMITTER OPERATION …………………….………. 4 B. BUTTON LOCK ……………………………………………….……...…. 5 C. LED DISPLAY .……………..……..……………………….……………. 5 D. CHIRP INDICATOR ..………..………..……………………………..…. 5 E. PARKING LIGHT ………..………………………………………..….…. 6 F. ALARM OPERATION CONDITION .…..…………………………...…. 6 G. ACTIVE ARMING – ARM & LOCK .……..……………...……………. 6 Defective Sensor Reminder Silent Arming / Disarming Shock Sensor By-Pass...
Page 3
REMOTE START OPERATION: A. TO REMOTE START THE VEHICLE ………..…………..…………. 14 Safe Start (Child safety mode) B. TO OPERATE THE VEHICLE WHILE RUNNING ON THE REMOTE START……………………………………………………………………14 C. TEMPORARY STOP FEATURE …………………..………...….…… 14 D. TURBO TIMER START FEATURE ……………………………………15 D. TIMER / TEMPERATURE START ……………….………..………… 15 3 Hours Timer Start With Temperature-Control Off 3 Hours Timer Start With Temperature-Control Daily Timer Start...
As with any product that performs automatic functions, there are certain safety precautions that you must practice and be aware of. 1. Keep the transmitter out o f children’s reach. 2. Do not leave anyone in the vehicle while running on remote control. 3.
SILENT ARMING / DISARMING: Press the transmitter same time will arm or disarm your security system, No chi rp sound will be heard, arm / disarm confirmation will be through the vehicles parking lights only. SHOCK SENSOR BY-PASS: Press the within 3 seconds will arm the security system and by-pass the shock sensor.
System Disarm Doors Trigger Shock SensorTrgr Ignition Trigger TAMPER DISARMING : If alarm is triggered upon disarm, the systems siren will chirp 4 times, and parking light flash 3 times. PATHWAY ILLUMINATION: This feature turns the parking light seconds upon a unlock signal and for 10 seconds upon the lock signal. TWO STEPS DOOR UNLOCK: This feature will independently unlock the driver’s door only when disarming the security system.
4. Within 15 seconds, enter your chosen of the second digit code by pressing and releasing the Valet Switch. 5. Turn the ignition switch “OFF” position. 4] Chirps form siren/horn, [3] flash from parking light to indicate the system was disarmed. Note 1: You must override the alarm within 60 seconds.
1. Press and hold the button for 3 second. The alarm will immediately sound. 2. During panic mode, the normal function of this transmitter button will be disabled. The transmitter buttons can be used to lock and unlock the door (if the option is installed), however once the button is pressed, the vehicle’s starter disable device, (where installed) will be disengaged allowing the vehicle to start.
Ignition Trigger CLEAR THE FLASH ICON AND MELODY SOUND: While triggering the alarm the LCD screen will alert user through melody sound and flashing trigger icon, press the button 3 times within 3 seconds will clear the flash icon and stop melody sound on the LCD screen transmitter. STOP THE MELODY SOUND ONLY: While triggering the alarm the LCD screen will alert user through melody sound and flashing trigger icon, press any button on the...
TRIGGER THE ANTI CAR -JACKING MODE: 3-timer circuits will function as follows: First timer: 50 seconds after the system has been triggered. The siren will start chirping for 15 seconds. During this 15 seconds period of chirping, you will be alerting to push the valet switch once to turn off the car-jacking feature.
melody sound continues sounding from you Remote LCD Transmitter and “ ” indication flashes on the LCD screen. 1. Press the transmitter button first, within 3 seconds press ) button to activate outdoor driver paging function , It responds with chirps of the vehicle, a melody sound and "...
Press the transmitter (5) and same time to active Channel 5 function. Channel 5 is user-programmable timer output. You may program the built-in timer to send a ground signal for any time duration from 1 second to 120 seconds. For instance, this timer output may be used to turn on the headlight, power window or sunroof.
1. Press first, within 3 seconds press and hold buttons at the same time for 2 seconds . One long beeping sound and the “ ” timer icon will be displayed on the LCD screen indicating the system is back to the first transceiver pin code.
2. The user presses the transmitter start the vehicle. B. TO OPERATE THE VEHICLE WHILE RUNNING ON THE REMOTE START: To operate the vehicle while the engine is running on the remote start, 1. Insert the ignition key and turn it to “ON” (not the start) position. 2.
or drops below the preprogrammed temperature level. The system will monitor the air temperature every 3 hour and will only start the engine during extreme cold temperatures. There are three temperature levels to choose from. Daily Timer Start: The feature is very useful for the driver who wants to run the vehicle punctually at the same time next morning.
If you installed the optional temperature sensor, you can monitor, through the LCD screen, the present indoor temperature of the passenger compartment before cooling or heating your vehicle. Press the transmitter buttons first, within 3 seconds press the ) button, the in-door temperature will be shown on the LCD screen.
LCD REMOTE CONTROL TRANSMITTER: Note: If the system is interfered by stronger radio frequency around, sources of high voltage electric power or such Obstacles like tall buildings and so on, the transmission range may get shorter as the system uses low out put powered frequency. A.
B. THE REMOTE LCD ICONS WITH FUNCTION: Door Lock Your vehicle doors are locked Armed Mode Your vehicle is in armed mode Remote Transmission You are transmitting the signal to control unit Door Open Warning Doors are illegally opened (Zone 3) Shock Sensor Trigger Trigger on Shock...
Vibration Mode Remote Control vibrates when the system is triggered Driver paging Someone is paging you in front of your vehicle E. PROGRAMMING OF THE LCD REMOTE TRANSMITTER: Transmitter Button Description LCD screen lamp turns on (1 second) 5 seconds. Timer Programming Mode.
Entry: 1. Press & hold the button for 5 seconds, with one melody sound and icon on the LCD screen to indicate entry the “power save mode”. 2. Under the “Active Arming Mode” and Disarm mode. Turn the ignition switch to on, the LCD remote transmitter will automatically entry the “Power Save Mode”...
8. Low Battery Indication: When the power of the battery weakens, it has two short “bi” sound and flash icon while pressing the button of the LCD screen transmitter. 9. Set Up Fixed Count Down Timer: 1. Press the button first, within 3 seconds press and hold the button for 2 seconds, the LCD screen will shows 2.
Page 24
Daily Timer Start Timer Press & hold the Setting Flash button for 2 seconds. icon and “Hours” for adjusting EXIT: Press and hold the button for 2 seconds or leave it for 10seconds, the system will exit the programming mode. 1.
Page 25
PM 6:xx 4. Press the button once again then the “Minutes” digit flashes for adjusting. 5. Press the button to decrease or increase the “Minutes” digit until PM 6:30 6. Press the button once again then OFF” setting 7. Press the button to start the “Alert Alarm Timer”, and the “ON”...
Page 26
3. Press the button to decrease or increase the hour digit until AM 6:00 4. Press the button once again then the minute digit flashes. 5. Press the button to decrease or increase the minutes digit until AM 6:30 6. Press the button for 2 seconds with one-melody sound to confirm exit the timer program mode.
Page 27
IMPORTANT NOTE: Any damages to the alarm system resulting from an installation performed by anyone other than a professional installation technician authorized by a dealer of Auto Page will void the product’s warranty. This WARRANTY CARD is for your record. However, AutoPage reserves the right to request you to submit this WARRANTY CARD, which must have complete information to receive warranty service.
Page 28
Serial # _______________ CUSTOMER TO COMPLETE Mr./Mrs./Ms. ___________________________ ________________________________ Your Name (Please Print) ___________________________ ________________________________ Address ___________________________ ________________________________ City, State, Zip Code ___________________________ ________________________________ Telephone Number ___________________________ ________________________________ Year / Make / Model of Vehicle ________________________________ “Proof of Purchase” w hich includes the store name and date of purchase must accompany all warranty returns.
Page 29
1815 West 205 Street Suite 101 Torrance, California 90501-1525 Main Office: 310-618-2002 Customer Service: 800-262-2527 Ext. 462 www.autopageusa.com...
