SERVICE MANUAL
RADIO RECEIVER
• This Service Manual contains information about the difference between
FR-A305 (HS) and FR-A305 (EZ). If requiring the other information,
see Service Manual of FR-A30/A300/A305/A306 (D, LH, EZ, HR),
(S/M Code No. 09-989-283-9FP).
FR-A305
SPECIFICATIONS
Power source:
AC 220 V, 60 Hz
Output:
280 mW (EIAJ)
Power consumption:
10 W
Frequency range:
FM: 87.5 – 108 MHz
AM: 530 – 1,605 kHz
Antennas:
FM wire antenna
Ferrite bar antenna for AM
Dimensions
137 (W) x 160 (H) x 128 (D) mm
(W x H x D):
Weight:
672 g
S/M Code No. 09-00A-424-2S2
HS
