Switch Chassis

Switch Backplane

S 7750 C
WITCH
The chapter describes the following Switch 7750 components:
Switch Chassis
■
Switch Backplane
■
Fabric Module
■
Fabric 32 Submodules
■
I/O Modules
■
Power Module
■
Power Distribution
■
External PoE Power System
■
Fan Assembly
■
Switch 7750 Specifications
■
The Switch 7750 is available with a 4-Slot or 7-Slot chassis. Table 3 lists the
hardware features of each model.
Table 3 Hardware Features of the Switch 7750 Models
Fabric slots
I/O module slots
Fan slot
AC Power module slots
The Switch 7750 backplane is part of the integrated chassis and delivers
high-speed data transfer between the Fabric and I/O modules. The backplane
bandwidth capacity is 96 Gbps.
The backplane supports the following functions:
Interconnection of signals between modules
■
Provides communication channels
■
Hot swapping for modules
■
Automatic recognition of slots
■
Distribution of power and management of the power supply for the system
■
OMPONENTS
4-Slot Chassis
1
3
1
2
7-Slot Chassis
1
6
1
3
