The SuperStack
3 Baseline 10/100 Switch is a versatile,
easy-to-use unmanaged switch. It is ideal for users who want the
high-speed performance of 10/100 switching but do not need
sophisticated management capabilities. The Baseline 10/100
Switch is shipped ready for use. No configuration is necessary.
The Baseline 10/100 Switch has 12 or 24 shielded RJ-45,
10/100Mbps auto-negotiating ports on the front panel. Each port
automatically determines the speed and duplex mode of the
connected equipment and provides a suitable switched
connection.
The Baseline 10/100 Switch is suited for office use where it can
be free standing, or rack mounted (in a wiring closet or
equipment room).
The Baseline 10/100 Switch comes with:
T
One power cord for use with the Baseline 10/100 Switch
T
Four self-adhesive rubber pads
T
One mounting kit
The Switch can be powered either from the AC mains supply, or
through an optional 3Com SuperStack 3 Advanced Redundant
Power System (3C16071B). Contact your supplier for details.
The Baseline 10/100 Switch provides high performance switched
connections to 10Mbps and 100Mbps hubs, servers and
workstations that require a dedicated switched link.
3 Baseline 10/100 Switch 12-Port (3C16464B) and
