Icom IC-M35 Service Manual page 21

[MAIN UNIT]
REF PARTS
NO. NO.
C340 4030016790 S.CER ECJ0EB1C103K
C341 4030008890 S.CER C1608 JB 1H 273K-T
C350 4030016790 S.CER ECJ0EB1C103K
C351 4030016790 S.CER ECJ0EB1C103K
C360 4030016790 S.CER ECJ0EB1C103K
C361 4030016950 S.CER ECJ0EB1A473K
C363 4030016950 S.CER ECJ0EB1A473K
C364 4030016950 S.CER ECJ0EB1A473K
C365 4030016950 S.CER ECJ0EB1A473K
C366 4030016950 S.CER ECJ0EB1A473K
C367 4030016950 S.CER ECJ0EB1A473K
C370 4030018070 S.CER ECJ0EC1H300J
C371 4030017400 S.CER ECJ0EC1H220J
C372 4030016930 S.CER ECJ0EB1A104K
C373 4030018900 S.CER ECJ0EB0J474K
C374 4030018900 S.CER ECJ0EB0J474K
C375 4030018900 S.CER ECJ0EB0J474K
C377 4030017740 S.CER ECJ0EB1E821K
C378 4030017780 S.CER ECJ0EB1E472K
C379 4030017420 S.CER ECJ0EC1H470J
C380 4030017460 S.CER ECJ0EB1E102K
C381 4030017460 S.CER ECJ0EB1E102K
C382 4030018860 S.CER ECJ0EB0J105K
C383 4030018860 S.CER ECJ0EB0J105K
C384 4030016930 S.CER ECJ0EB1A104K
C385 4030016790 S.CER ECJ0EB1C103K
C386 4030018900 S.CER ECJ0EB0J474K
C387 4030017460 S.CER ECJ0EB1E102K
C389 4550007520 S.TAN F931A106MAABMA
C390 4030017460 S.CER ECJ0EB1E102K
C391 4030017460 S.CER ECJ0EB1E102K
C392 4030017460 S.CER ECJ0EB1E102K
C393 4030016950 S.CER ECJ0EB1A473K
C394 4030016950 S.CER ECJ0EB1A473K
C410 4030017420 S.CER ECJ0EC1H470J
C411 4030017420 S.CER ECJ0EC1H470J
C412 4030017420 S.CER ECJ0EC1H470J
C413 4030017420 S.CER ECJ0EC1H470J
C414 4030017440 S.CER ECJ0EC1H221J
C415 4030017440 S.CER ECJ0EC1H221J
C417 4030017460 S.CER ECJ0EB1E102K
C421 4030016790 S.CER ECJ0EB1C103K
C422 4030016950 S.CER ECJ0EB1A473K
C423 4550004040 S.TAN TEESVA 0J 685M8R
C424 4030017460 S.CER ECJ0EB1E102K
C426 4030018860 S.CER ECJ0EB0J105K
C427 4030016930 S.CER ECJ0EB1A104K
C428 4030016960 S.CER ECJ0EB1C183K
C429 4030016960 S.CER ECJ0EB1C183K
C430 4030017730 S.CER ECJ0EB1E471K
C431 4030016930 S.CER ECJ0EB1A104K
C432 4030017460 S.CER ECJ0EB1E102K
C433 4030016930 S.CER ECJ0EB1A104K
C434 4030016950 S.CER ECJ0EB1A473K
C435 4030018890 S.CER ECJ0EB0J224K
J250 6450001910 CON HSJ1594-010150
J252 6510022691 S.CON 06FLT-SM2-TB(LF)(SN)
J253 6510021901 S.CON BM02B-ASRS-TF(LF)(SN)
DS240 5040003060 S.LED SML-512WWT86
DS241 5040003060 S.LED SML-512WWT86
DS242 5040002310 S.LED SML-311YTT86
DS243 5040002310 S.LED SML-311YTT86
DS244 5040002310 S.LED SML-311YTT86
DS245 5040002310 S.LED SML-311YTT86
DS246 5030003000 LCD S11000 <SUC>
MC250 7700002710 MIC EM6027P-46C33-G <HOR>
S250 2260002840 SWI SKHLLFA010
W1 9011710006 WIR 24/00/030/W01/W01 <TJM> [CHN]
9011710006 WIR 24/00/030/W01/W01<TJM>
9011710006 WIR 24/00/030/W01/W01 <TJM> [EUR]
9011710006 WIR 24/00/030/W01/W01 <TJM> [UK]
9011710006 WIR 24/00/030/W01/W01 <TJM> [FRG]
9011710006 WIR 24/00/030/W01/W01 <TJM> [HOL]
W2 9031680010 WIR 24/04/030/W01/W01 <TJM> [CHN]
9031680010 WIR 24/04/030/W01/W01<TJM>
9031680010 WIR 24/04/030/W01/W01 <TJM> [EUR]
9031680010 WIR 24/04/030/W01/W01 <TJM> [UK]
9031680010 WIR 24/04/030/W01/W01 <TJM> [FRG]
9031680010 WIR 24/04/030/W01/W01 <TJM> [HOL]
EP2 6910014690 S.BEA MPZ1608S221A-T
EP3 6910014690 S.BEA MPZ1608S221A-T
EP4 6910012350 S.BEA MMZ1608Y 102BT
EP5 6910012350 S.BEA MMZ1608Y 102BT
EP6 6910012350 S.BEA MMZ1608Y 102BT
EP7 6910012350 S.BEA MMZ1608Y 102BT
EP360 8930077940 LCD SRCN-3168-SP-N-W (SHJ)
MP20 8510016470 S.CAS 2775 VCO CASE
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
LOCATION
B 97.4/30.6
B 94.9/34.3
T 104.3/24.8
B
T 97.7/19.1
T 90.4/41.1
T
T 94.9/41.3
T 96.6/41.3
T 99.3/40.7
T 93.1/41.3
B
B 95.6/32.1
B 84.7/35.9
T 87.5/35.2
T 89.9/37.8
T
B
B
B 12.2/25.4
T 87.3/13.4
T 99.5/14.3
B 27.6/46.2
B 13.9/37.8
B 79.8/44.3
B
T
T 91.3/41.5
B 90.9/23.5
B 105.1/29.3
B 60.4/45.2
B 103.2/34.4
T 97.5/41.3
T 92.2/41.5
T 105.3/41.8
T 103.4/46.4
T 109.6/38.1
T 100.8/44.3
T 100.8/45.2
T 103.4/45.5
B 14.1/39.1
B 52.6/47.6
B 45.2/39.4
B 54.3/44.5
B 75.8/37.6
B 73.9/42.1
B 74.4/43.3
B 69.2/45.3
B 69.1/44.1
B
B 74.3/35.2
T 98.4/41.3
B 68.7/38.2
B 73.7/39.7
B 99.5/27.7
B 86.1/39.3
B 78.9/39.3
T
T
T
T 62.9/34.8
T 47.7/18.4
T 62.9/17.6
[EUR-1]
[EUR-1]
B
B 80.4/13.4
T
T 105.4/39.8
T 111.8/35.7
T 104.8/45.4
B 51.5/13.3
S.=Surface mount
H/V
88.1/27
94/41.3
95/30.9
89/38.1
9.1/28.2
9.4/26.1
9.1/35.1
90/39.3
68.5/42
92.2/4.7
99.7/4.7
47.7/34
72.3/16
103/43.1
6 - 4
