1 *
020489
1
COVER FRONT
2 *
099458
2
DUCT TOP/BOTTOM
3
087871A
1
RADIATOR
4
022034B
1
HOSE REDUCER 2" x 1-3/4"
5
098186
1
VENTURI (40KW-80KW)
0A5096B
1
VENTURI CAC 26" (100KW)
0A5096C
1
VENTURI CAC 22" (125KW)
0A5096A
1
VENTURI (EMISSION)
6**
099710
1
GUARD LOWER FAN
7**
099715
1
GUARD FAN
8
0A5095A
1
SUPPORT SIDE LH (CAC)
0A5095B
1
SUPPORT SIDE RH (CAC)
098311
1
SUPPORT SIDE LH
098311A
1
SUPPORT SIDE RH
9
0A2770
1
TANK SURGE
10
099448
1
BRACKET SURGE TANK
11
046627
1
CAP RADIATOR
12
029032
1
HOSE 9/32 ID
13
058612
2
CLAMP HOSE #88 5.12 - 6.00
14
039253
2
SCREW HHC M8-1.25 X 20 G8.8
15
022145
2
WASHER FLAT M8-5/16 ZINC
16
0A7165
1
HOSE LOWER
17
0A2126
1
HOSE UPPER 5.0L
18
099667D
6
NUT SPRINGCLIP 3/8-16
27
042561
5
CLAMP HOSE #36 1.88 - 2.75
28
035685
1
CLAMP HOSE #28 1.32 - 2.25
29
052250
10'
TAPE FOAM 1 X 1
052250
14.5'
TAPE FOAM 1 X 1 (W/AFTERCOOLER)
30
035461
1
BARB STRAIGHT 3/8 X 1/4 X 1.72
31
040173
2
CLAMP HOSE #5.5 .62 - .62
32
047290
40"
HOSE RES 3/8 SINGLE BRAID
33
036865
1
DRAINCOCK
34
052617
6
SCREW HHC M12-1.75 X 20 G8.8
35
049808
6
WASHER FLAT M12
36
029745
6
SCREW HHC 3/8-16 X 1 G5
37
040105
3"
HOSE RES 2 3PLY RAD HOS
38
090283
1
CAP RADIATOR (7 PSI)
40
046526
6
WASHER LOCK M10
41
022131
12
WASHER FLAT M10-3/8 ZINC
42**
047411
4
SCREW HHC M6-1.0 X 16 G8.8
43**
022097
4
WASHER LOCK M6-1/4
44
052860
6
NUT HEX LOCK FLANGE M12-1.75
45
051756
6
SCREW HHC M10-1.5 X 20 G8.8
46**
022473
4
WASHER FLAT M6-1/4 ZINC
47
022237
6
WASHER LOCK 3/8
57 *
047411
12
SCREW HHC M6-1.0 X 16 G8.8
58 *
022097
12
WASHER LOCK M6-1/4
59 *
022473
12
WASHER FLAT M6-1/4 ZINC
60
040173
3
CLAMP HOSE #5.5 .62 - .62
61
029032
24"
HOSE 9/32 ID
62
029032
30"
HOSE 9/32 ID
63
035587
24"
HOSE RES 1" CVR NEOPR SAE-20R3
64
057824
2
CLAMP HOSE #16 .87 - 1.50
65
022129
2
WASHER LOCK M8-5/16
66
049340
1
BARB ELBOW 3/8 X 1/4 X 1.04
67**
090388
12
SCREW TAP M6X12 YEL CHR
OIL COOLER COMPONENTS (GEARBOXES ONLY)
50
099251
1
COOLER OIL
51
047411
4
SCREW HHC M6-1.0 X 16 G8.8
52
022473
4
WASHER FLAT M6-1/4 ZINC
53
052857
4
NUT LOCK M6-1.0
54
056460
2
BARB ELBOW 5/8 X 1/2 X 1.21
55
057822
5
CLAMP HOSE #8 .53 - 1.00
56
065386
2
HOSE RES 5/8 -40/+300 SAE100RG 7' LONG
AFTER COOLER PARTS (100 & 125KW UNITS)
19
0A5260A
2
HOSE 3" DIA X 3" LONG
20
080773A
3"
HOSE 3" DIA
21
086133E
6
CLAMP HI TORQUE 2.75 - 3.625
22
0D8150
1
CHARGE AIR COOLER ASSY 13TBS
0A5160
1
AFTERCOOLER (GEARBOX & EMISSION)
23
0A5098A
1
TUBE CAC
24
0A5097A
1
TUBE CAC
25
071296A
3"
HOSE 2" DIA
26
086133C
2
CLAMP HI TORQUE 1.75 - 2.625
39
039253
6
SCREW HHC M8-1.25 X 20 G8.8
48
022129
6
WASHER LOCK M8-5/16
49
022145
6
WASHER FLAT M8-5/16 ZINC
68
0D3397
1
DECAL, CAUTION HOT SURFACES
*OPTIONAL STONE GUARD.
**FAN GUARD (KIT 0D9246), STANDARD, NOT USED
WITH OPTIONAL LEVEL ONE GUARDING.
