1
0A6320
1
CONTROL PANEL BOTTOM
2
0A6324
1
CONTROL PANEL FRONT
3
0A6322
1
CONTROL PANEL RIGHT SIDE
4
0A6321
1
CONTROL PANEL LEFT SIDE
5
0E3550
1
CHASSIS, UNIVERSAL
6
0C8320
1
HARNESS E PNL. WAUK (W/FS)
7
SEE TABLE B
1
CIRCUIT BREAKER
8
044213
1
RESIST MISC 10RX12W
9
025192
1
RECTIFIER MSC 2A 600V 1N5062
10
SEE TABLE A
1
RESISTOR 2
11
055444
1
HEAT SINK
12
030468
1
WASHER STEP NYLON .20
13
049939
1
RECTIFIER MSC 12A 600V 1N1206R
14
039271
1
FITTING 90DEGREE 3/4
15
034616
1
FITTING STRAIGHT 3/4
16
0A3392
1
DECAL TERMINAL STRIP
17
0C8229
1
DECAL E PNL TS#2 (W/FS)
18
0A6577
1
DECAL TERMINAL STRIP TB3
19
0C2688
1
DECAL TERMINAL STRIP TB4
20
048850
REF.
BLOCK TERM 20A 5 X 6 X 1100V
22
061286
1
AUDIBLE ALARM
23
055089
1
CONN ELEC AMP M-N-L 15PLUG PNL
24
0E2693A
1
SWITCH MUSHRM HEAD/ARROWS 40MM
25
0E2693C
3
CONTACT BLOCK D5-3 X 01 W/2 1417
26
071361
1
POTENTIOMETER PNL 5K +/-10% 2.25W
27
050123
1
KNOB PLASTIC .25 SHAFT
28
055349
1
INSULATOR
29
0A4087
1
MASTER CONTROL BOX
30
0C8481
REF.
BULB-PANEL LIGHT-12V
0E3703
REF.
LIGHT PANEL WITH LUG
083288
REF.
LIGHT 28VDC .17A MIN BAYNT MNT
31
070082
1
LIGHT BLOCKER
32
032300
1
FUSE HOLDER
33
022676
1
FUSE 15A X AGC15
34
070054
1
AMMETER AC 0-50
070055
1
AMMETER AC 0-100
070056
1
AMMETER AC 0-150
070057
1
AMMETER AC 0-300
070058
1
AMMETER AC 0-400
070059
1
AMMETER AC 0-600
070060
1
AMMETER AC 0-800
075323
1
AMMETER AC 0-1000
075324
1
AMMETER AC 0-1600
075325
1
AMMETER AC 0-2000
35
070043
1
METER VOLT AC 0-300
070044
1
METER VOLT AC 0-600
36
070042
1
METER FREQUENCY 55-65HZ
070042A
1
METER FREQUENCY 240V 45-55HZ
37
061945
1
SWITCH 6A AMP/V SELECTOR
38
067680
1
ASSY VOLTAGE REGULATOR 60HZ
092952
1
ASSY VOLTAGE REGULATOR 50HZ
40
0A2275
1
DOOR-STOP RAM PANEL
41
0A2400A
1
TRUNKING 180MM
42
0A1441B
1
COVER PLATE AVR
43
0C1127
1
DECAL AVR COVER
44
0A1441C
1
COVER PLATE E-GOV
45
0A3394
1
DECAL E-GOV COVER
46
030809
1
GROMMET 11/16 X 1/8 X 7/16
47
028739
2
TIE WRAP 4" WHITE
48
0C2323
12
SCREW PHM SWAGE 6-32 X 5/8 Z/YC
49
036901
4
SCREW PPHM #6-32 X 3/8
50
022155
7
WASHER LOCK #6
51
036918
8
SCREW PPHM #8-32 X 1/2
52
022264
8
WASHER LOCK M4
53
038150
4
WASHER FLAT #8 ZINC
54
022471
4
NUT HEX #8-32 STEEL
55
033120
1
SCREW HHM 10-32 X 3/8
56
033121
13
SCREW HHM 10-32 X 1/2
58
0A2284
4
SCREW SWAGE 8-32 X 1/2 Z/YC
59
022152
14
WASHER LOCK #10
60
023897
15
WASHER FLAT #10 ZINC
61
022158
2
NUT HEX #10-32 STEEL
62
074130
1
LUG DIS SN-PLG I-T 22-18 CU
63
036261
4
RIVET POP .125 X .129-.133/#30
64
070370
2
WASHER MICA .203
65
023762
1
WASHER SHAKEPROOF EXT #10 STL
67
040479
4
MOUNT VIBR 1.0 X 1.0 X 1/4-20
68
022287
4
SCREW HHC 1/4-20 X 3/4 G5
69
022097
4
WASHER LOCK M6-1/4
70
022473
4
WASHER FLAT M6-1/4 ZINC
71
047246
4
WASHER FLAT 1/4 SPECIAL
72
0A2273
1
HINGE RAM PANEL
74
022188
2
NUT HEX #6-32 STEEL
75
0C2428
8
SCREW TAPTITE PH #6-32 X 1/2 ZYC
*
0A5705
1
FUSE 5A X LTTL215005 HLDRA4017 (NOT SHOWN)
78
057335
REF.
BLOCK TERM 20A 20 X 6 X 1100V
79
0C4167
REF.
BLOCK TERM 20A 14 X 6 X 1100V
80
055911
REF.
BLOCK TERM 20A 12 X 6 X 1100V
81
0441140156
REF.
WIRE ASSEMBLY
82
084717
1
ASSY TIME DELAY (13.3L GAS ONLY)
83
036908
1
SCREW PPHM #6-32 X 1-1/4 (13.3L GAS ONLY)
84
0C1229
1
DECAL WARNING
85
0E3783
1
DECAL WARNING REMOVE FUSE
