Owner's Manual

Model

47905

5 MINUTE

I N S T A L L A T I O N

Form# 44119-01

7 Day Programmable

20121010

M T W T F S S

Table of Contents

Summary of Contents for Hunter 47905

Page 1 Owner’s Manual Model 47905 5 MINUTE I N S T A L L A T I O N Form# 44119-01 7 Day Programmable 20121010 M T W T F S S ©2012 Hunter Fan Co.
Page 2: Table Of Contents
Table of Contents At A Glance Know Your Thermostat � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �3 Setup Setting Date and Time �...
Page 3: Know Your Thermostat
The features section starting on page 30 of this manual will describe these settings. Most setting have been preset for optimal performance. If you need any assistance with installation or setup of your new Hunter Thermostat, please call us, our technical support staff are ready to help!
Page 4 Know Your Thermostat 1. Returns you to the Home screen. 2. Main display. 3. Allows access to scheduling options. 4. Adjusts time and temperature settings as well as moving up or down menu lists. 5. Allows access to the advanced features of the thermostat. 6.
Page 6 Know Your Thermostat 1. Will show when your thermostat or system is reporting a problem. 2. Displays time/day, instructions, help messages, and warnings. 3. Indicates help messages are available for this screen. 4. Shows when the thermostat is on the Home screen. 5.
Page 7 Know Your Thermostat FRIDAY 10:53 AM SCHEDULE RUNNING - AT HOME Auto Heat to At home Energy Savings: Good Best! ©2012 Hunter Fan Company...
Page 8: Setting Date And Time
Setting Day and Time Once you install the batteries, the thermostat will prompt you to set the current date, time, and system type. 1. “01” for current day will be flashing. Use the button to select your current day, then to move to month, and then year, until each is set.
Page 9 Set current date Set current time 01/01/2010 00:00 AM Home Home Schedule Next Back Next Pick Furnace type pick system type [ gas/oil] [ electric] [ conventl] [ heat pump] Home Schedule Back Next Back Next ©2012 Hunter Fan Company...
Page 10: Setting Your Schedule
Setting your Schedule Read the scheduling section thoroughly to ensure you understand your scheduling options and which will best fit with your lifestyle. The following notes should help you with scheduling: * The schedule time can be set in 15 minute increments, and remains the same for both Heat and Cool programs.
Page 11 Start Time: Start Time: Heat Temp: Sunday End Time: End Time: Heat Temp: Heat Temp: Cool Temp: Cool Temp: Cool Temp: Note: Use a pencil so these records may be changed at a later time if necessary. ©2012 Hunter Fan Company...
Page 12 Setting Your Schedule Schedule 1. Press the Button to enter Scheduling mode. 2. Start by pressing the first day you want to program on the day select screen. In this example we will use Monday. 3. The thermostat will show Monday as the selected day. Choose the period you want to program first: Away, Asleep, or At home on the screen.
Page 13 Home Home 8:00 4:00 Away A A ay 60 0 Schedule Schedule Heat to Asleep Asleep At home At home Cool to Energy Savings: Good Best! Cancel Cancel Back Next Done ©2012 Hunter Fan Company...
Page 14 Setting Your Schedule 6. Set the temperature for your heating cycle as indicated by the flashing ”Heat to” icon on your screen. Use and buttons to change the temperature and press Next 7. You will be asked to set your cooling cycle, indicated by the flashing “Cool to”. Set this temperature with your buttons and hit Next...
Page 15 A A ay Schedule Schedule Heat to Heat to Asleep Asleep At home At home Cool to Cool to Menu Menu Energy Savings: Energy Savings: Good Best! Good Best! Cancel Cancel Back Next Done Back Next Done ©2012 Hunter Fan Company...
Page 16 Setting Your Schedule 10. When you have completed scheduling your day, you will be returned to the copy day screen. The copy day screen will now show and ask you if you wish to Copy day to... copy the day you just scheduled to any other days. Select and choose the Copy day to...
Page 17 'copy day' to copy or 'done' to pick next day touch day(s) to copy to Home Home Copy day to... Schedule Cancel Cancel Done Done Schedule touch day to view/edit Home Schedule Turn Cancel Schedule ©2012 Hunter Fan Company...
Page 18: Temporary Temperature Change
Temporary Temperature Change With Temporary Temperature Change you have the ability to alter the temperature for only the current running schedule for one day. 1. Press the buttons to select a new temperature. 2. Press the button to save changes. Done Note: Temporary Temperature Change is not a permanent setting.
Page 19 Home Home Schedule Cool to Cool to Done Done temporary hold [resume] to run schedule Home 74 4 Schedule Auto At home Cool to Menu Energy Savings: Good Best! Resume ©2012 Hunter Fan Company...
Page 20: Turning Off Scheduling
Turning Off Scheduling To turn off your schedule and have the thermostat permanently set to one temperature: 1. Press the Schedule button once. Turn 2. Press the button. Schedule 3. The help banner will show SCHEDULE OFF - PERMANENTLY HOLD TEMP AT. Use the buttons to adjust your temperature and press when finished.
Page 21 Save Cancel Schedule Toda A A ay schedule off - FRIDAY 6:53 pM permanently hold temp at schedule off Home Home 74 4 Schedule Schedule Auto Cool to Cool to Menu Save Done A A ay ©2012 Hunter Fan Company...
Page 22: Home Today
Home Today The Home Today feature allows you to override your schedule for 1 day. It can be used for example if you are home sick or off work on a day when you would normally have the thermostat‘s “Away” mode active. When used, the Home Today feature will select your At Home temperature to run for the course of the day until your scheduled Asleep time starts, then revert back to running your normal schedule.
Page 23 Energy Savings: Good Best! Good Best! Home Save Done Today A A ay Home today on until asleep [resume] to run schedule Home 74 4 Schedule Auto At home Cool to Menu Energy Savings: Good Best! Resume ©2012 Hunter Fan Company...
Page 24: Save Away
Save Away The Save Away feature allows you to save energy and money while you are away from your home outside of your normal Away schedule. This can include days you will be away for vacation, or a few hours away from your home, while running errands for example.
Page 25 [resume] to run schedule Home Home Hours 74 4 Schedule Schedule Heat to Auto At home Cool to Menu Energy Savings: Energy Savings: Good Best! Good Best! Cancel Next Done Resume Resume ©2012 Hunter Fan Company...
Page 26: Alerts
Alerts This chapter will outline the various alerts the thermostat will report to you and how to respond to them. 1. Low Battery: This will appear in the message window when your batteries are starting to run low on power and should be changed to avoid system interruptions, (Figure 1).
Page 27 Good Best! Home Save Toda A A ay FRIDAY 6:53 pM Replace batteries Replace filter Home Home 74 4 Schedule Schedule Auto At home Cool to Energy Savings: Good Best! Home Save Toda A A ay ©2012 Hunter Fan Company...
Page 28 Alerts 1. Auxiliary Heat: On multi-stage heat pumps this alert indicates your second stage heat is running. 2. Check System: Some heat pump systems are equipped with the ability to check system performance, indicated by the presence of an “L” wire attached to the backplate.
Page 29 74 4 74 4 Schedule Schedule Auto Auto At home At home Cool to Cool to Energy Savings: Energy Savings: Good Best! Good Best! Home Save Home Save Toda A A ay Toda A A ay ©2012 Hunter Fan Company...
Page 30: Menu Options
Menu Options Under your Menu options you have the ability to change many of the features of the thermostat. After making changes to each menu option, the thermostat will show “Updated” and save your changes. To access these options: Menu 1.
Page 31 & time Schedule Auto Reset filter Reset At home Schedule Cool to Lock Menu Energy Savings: More... Good Best! Home Save Cancel Toda A A ay reset filter [ no] [ yes] Home Schedule Cancel Done ©2012 Hunter Fan Company...
Page 32 Menu Options 1. Thermostat Lock: Your thermostat has the option of being locked to prevent unwanted temperature or schedule changes. Press the button. Use the Lock buttons to change the first digit to 0 through 9. will advance you to the Next next digit to be changed.
Page 33 FRIDAY 6:53 pM SCHEDULE RUNNING - AT HOME ENTER PASSCODE TO unLOCK Home Home 74 4 Schedule Schedule Auto At home Cool to Energy Savings: Lock Good Best! Home Save Cancel Done Next Toda A A ay ©2012 Hunter Fan Company...
Page 34 Menu Options By pressing the button you are entering into the advanced features of the More... thermostat. All of these settings have been set for optimal performance at the factory and do not need to be changed. There are 2 sections in the advanced settings: User starting on page 36 and System starting on page 40.
Page 35: Daylight Savings Time
[ x conventl] [ heat pump] Furnace type [ x gas/oil] [ electric] Stage one span [2], 1-3˚ Stage two span [2], 1-3˚ Autoseason span [5], 3-6˚ Temperature calibration [0], -2 - +2 Restore factory settings [ x no] [ yes] ©2012 Hunter Fan Company...
Page 36 Menu Options 1. Select [ user] in the message window and press to enter the user menu. Next 2. Beep: Turns the sound off so key presses do not make noise. Touch either [on] or [off] to make your selection then to move to the next feature.
Page 37 Cancel Cancel Next Back Next Done temperature degree scale daylight savings time [ x f] [ c] [ x on] [ off] Home Home Schedule Schedule Menu Menu Cancel Cancel Back Next Done Back Next Done ©2012 Hunter Fan Company...
Page 38 Menu Options 5. Use Away Period: Gives you the option to bypass the “Away” period when scheduling. If someone is home all day, turning this feature off may make scheduling your thermostat easier. Touch either [Yes] to keep the away period or [no] to disable it, then select to move to the next feature.
Page 39 [ No] [ No] reminder 'days' reminder 'days' Home Home Home Home Schedule Schedule Schedule Schedule Menu Menu Menu Menu Cancel Cancel Cancel Cancel Next Next Done Done Next Next Done Done Back Back Back Back ©2012 Hunter Fan Company...
Page 40 Menu Options 1. Select [ system] in the message window and press to enter the system menu. Next 2. System Type: Allows you to select the type of system you have. Conventional systems typically use a compressor outside for cooling and a separate heating system inside, where as a heat pumps use the compressor outside for both heat and cool.
Page 41 [ heat pump] Home Home Schedule Schedule Menu Menu Cancel Cancel Next Back Next Done furnace type [ gas/oil] [ electric] stage one span Home Home Schedule Schedule Menu Menu Cancel Cancel Back Next Done Back Next Done ©2012 Hunter Fan Company...
Page 42 Menu Options 5. Span 2 : Unless you have a multi-stage conventional or heat pump system, there is no need to change the second stage span. If you do, use the buttons to adjust between 1, 2, or, 3. Press once this has been changed or if you need Next to make no changes.
Page 43 Menu Options stage two span auto season span Home Home Schedule Schedule Menu Menu Cancel Cancel Back Next Done Back Next Done temperature calibration '+ or - from current temp' Home Schedule Menu Cancel Done Back Next ©2012 Hunter Fan Company...
Page 44 Menu Options 1. Restore Factory Defaults : Allows you to reset all options back to factory condition. Touch either [no] to keep your settings or [yes] to lose your settings and restore factory defaults, then select to move back to the beginning of the advanced Next system options, or to return to the User/System selection menu.
Page 46: Energy Savings Bar
Energy Saver Bar The Energy Savings Bar indicates estimated energy savings. The preset schedules in the thermostat have been designed to give you optimal energy savings, or five bars. Altering these schedules has a direct impact on the energy savings indicator. Altering the temperatures and/or times that the schedules run could decrease the estimated energy savings.
Page 47 74 4 72 2 Schedule Schedule Auto Auto At home At home Cool to Cool to Energy Savings: Energy Savings: Good Best! Good Best! Home Save Home Save Toda A A ay Toda A A ay ©2012 Hunter Fan Company...
Page 48: Additional Features
Additional Features Armchair Programming There is no need to stand at the wall where the thermostat is mounted while programming or changing settings. Simply remove the thermostat from the wall and make the necessary changes in the comfort of a chair. You can also set your programming and settings before you even install the thermostat.
Page 49 If your primary heat runs for 30 minutes without reaching the set temperature or activating second stage heat, the stage timer will activate your second stage heat. (This option cannot be changed or disabled.) ©2012 Hunter Fan Company...
Page 50: Troubleshooting And Support
Troubleshooting and Support Problem: No display. Solution: 1. Check battery position and battery life. Problem: Program does not change at desired setting. Solution: 1. Check the time in all programs for proper AM/PM time. 2. Ensure thermostat is not in “Save Away” mode. 3.
Page 51 1. Check the system is in the right mode (heat or cool). 2. Be sure to wait up to 4 minutes for system protection if your system was just on. 3. Check breakers to make sure power is getting to your system 4. Replace the batteries. ©2012 Hunter Fan Company...
Page 52: Technical Support
Technical Support Technical Support If you need any assistance with installation or setup of your new Hunter Thermostat, please call us, our technical support staff is ready to help! USA: 1-888-830-1326 Canada: 1-866-268-1936 Hours of operation are from 7:00 am to 7:00 pm Monday - Friday and 8:00 am to 5:00 pm on Saturday, Central Time.
Page 53: Year Guarantee
IN RESPECT TO YOUR HUNTER THERMOSTAT IS LIMITED TO THE PERIOD OF THE EXPRESS WARRANTY SET FORTH ABOVE. This warranty is voided if your Hunter Thermostat is not purchased and used in the USA. This warranty excludes and does not cover defects, malfunctions or failures or...
Page 54 1 Year Guarantee Suite 400, Memphis, TN 38016. You will be responsible for all insurance and freight or other transportation charges to our factory. We will return your Hunter Thermostat freight prepaid. Your Hunter Thermostat should be properly packed to avoid damage in transit since we will not be responsible for any such damage.
