- Page 2 LBC-H-DRP-Lite User Manual Link Bridge HDBaseT HDMI Transmission System w/Dropping and Repeating Video SAFETY INSTRUCTIONS AND COMPLIANCE DECLARATIONS PLEASE OBSERVE THE FOLLOWING SAFETY PRECAUTIONS SURGE PROTECTION DEVICE RECOMMENDED This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc.
-
Page 3: Table Of Contents
4.0 MAINTENANCE AND TROUBLESHOOTING ....9 4.1 MAINTENANCE ..............9 4.2 TROUBLESHOOTING .............9 5.0 SPECIFICATIONS ............11 6.0 SERVICE PROCEDURE ..........12 6.1 REPLACEMENT POLICY ..........12 6.2 RETURN AND REPAIR SERVICE ......... 12 7.0 LIMITED WARRANTY ............ 13 Broadata Technical Support, (800) 214-0222... -
Page 4: Product Description
HDBaseT HDMI Transmission System w/Dropping and Repeating Video 1.0 PRODUCT DESCRIPTION The LBC-H-DRP-Lite can convert a single CAT-5e/6/7 input and 2-way IR control to a single CAT-5e/6/7 output and includes a simultaneous HDMI bypass output. It supports resolutions up to 1080p Full HD, 4K×2K timing, 3D and multi-channel digital audio formats (such as LPCM 7.1CH,... -
Page 5: Operation Controls And Functions
LINK LED will illuminate. 3. Power LED: Once the power supply is connected the LED will illuminate. 4. DC 24V: Plug the 24V DC power supply into the unit and connect the adapter to an AC outlet. Broadata Technical Support, (800) 214-0222... -
Page 6: Receiver Rear Panel
LBC-H-DRP-Lite User Manual Link Bridge HDBaseT HDMI Transmission System w/Dropping and Repeating Video 2.2 Receiver Rear Panel HDMI OUT CAT5e/6/7 OUT IR IN IR OUT LINK LINK EDID 1. HDMI OUT and LINK LED: Connect to HDMI display for instant image display or cascade with another family type transmitter. -
Page 7: Ir Blaster Cable Pin Assignment
Link Bridge HDBaseT HDMI Transmission System w/Dropping and Repeating Video 3.1 IR Blaster Cable Pin Assignment IR Blaster Power 5V IR Blaster Signal 3.2 IR Receiver Cable Pin Assignment IR Receiver IR Signal Power 5V Grounding Broadata Technical Support, (800) 214-0222... -
Page 8: Maintenance And Troubleshooting
However, observe the following light indicators to make sure that the unit is working properly: 4.2 Troubleshooting If the LBC-H-DRP-Lite units do not operate properly after installation, check for possible cable breaks, loose connections, and incorrect cable connections. If problems persist that may be fiber related, contact BCI at 1-800-214-0222 for further assistance. - Page 9 Both ends of the link are connected to the corresponding equipment and to the same corresponding channel port. c. Cable connections at both channels are securely fastened to each connector. Turn the power off, then back on to reset the link. Broadata Technical Support, (800) 214-0222...
-
Page 10: Specifications
LBC-H-DRP-Lite User Manual Link Bridge HDBaseT HDMI Transmission System w/Dropping and Repeating Video 5.0 SPECIFICATIONS Video/Audio Specifications HDMI Version 1.4 with 3D, 4Kx2K support Video Resolution Up to 4K2K@30Hz Protocol DDC/EDID Capable, HDCP 2.2 Video Bandwidth 300MHz/10.2Gbps Audio Formats Supports up to 7.1CH and Dolby... -
Page 11: Service Procedure
U.S. Please call Customer Service at 800-214-0222 for information. 6.2 Return/Repair Service The LBC-H-DRP-Lite System contains no user serviceable components. If you have a problem with your unit, please contact the Customer Service Department. To facilitate our return/repair processing please contact Broadata Communications, Inc. -
Page 12: Limited Warranty
HDBaseT HDMI Transmission System w/Dropping and Repeating Video 7.0 LIMITED WARRANTY Broadata Communications, Inc. (BCI) warrants, for a period of one year from date of shipment, each product sold shall be free from defects in material and workmanship. BCI will correct, either by repair, or at BCI’s election, by replacement, any said products that in our sole... - Page 13 LBC-H-DRP-Lite User Manual Link Bridge HDBaseT HDMI Transmission System w/Dropping and Repeating Video Broadata Technical Support, (800) 214-0222...
- Page 14 LBC-H-DRP-Lite User Manual Link Bridge HDBaseT HDMI Transmission System w/Dropping and Repeating Video Broadata Technical Support, Sales@Broadatacom.com...
- Page 15 LBC-H-DRP-Lite User Manual Link Bridge HDBaseT HDMI Transmission System w/Dropping and Repeating Video Broadata Technical Support, (800) 214-0222...
- Page 16 Broadata Communications, Inc. 2545 West 237th Street, Suite K Torrance, CA 90505 1-800-214-0222 (310) 530-1416 (310) 530-5958 (Facsimile) e-mail: CustomerService@Broadatacom.com Website: www.broadatacom.com 60000-LBCHDRPLITE...
