- Page 1 5407927 Issue 1 June 2016 SM032033 ~ C00384575 HOTPOINT FREESTANDING PARTIAL FROST FREE FRIDGE FREEZERS Models Comm. Covered Code FFLAA58WDW 86522 FFLAA58WDG 86525 FFLAA58WDK 86670 Service Information Whirlpool Company UK Ltd © 2016 Reg. Office: Peterborough PE2 9JB Registered in London: 106725...
-
Page 2: Health And Safety
Indesit Company HEALTH AND SAFETY For the servicing of refrigeration products, containing Isobutane R600a refrigerant. These instructions are in addition to any other Company procedures already published. Published primarily for Indesit Company engineers working in the UK or Southern Ireland, for which these instructions are MANDATORY. -
Page 3: Health And Safety
Indesit Company HEALTH AND SAFETY 19. Isobutane is heavier than air and must not be vented within 3 metres of the following: sewer cover, cellar, drain or any similar construction lower than ground level, boiler air inlet/outlet, or near any possible source of ignition. -
Page 4: Table Of Contents
Indesit Company INDEX Health and Safety ............2 - 3 Index &... -
Page 5: Introduction
Indesit Company INTRODUCTION The FFLAA58W range was introduced during Dec.2014 for the UK market, manufactured in China. The interior of the fridge has three glass shelves, one vegetable glass cover and one vegetable bin, and is fitted with a Water dispenser in the door. The door has one removable bottle rack, two removable full width commodity racks. -
Page 6: Specifications
Indesit Company SPECIFICATIONS Colour Introduction Date White - W Graphite - G Black - K Dec. 2014 FFLAA58WDW FFLAA58WDG FFLAA58WDK GENERAL: Manufactured in: China Appliance Type: Freestanding Fridge Freezer Static / No-Frost: Partial No-Frost Doors Hinging - R/H Reversible: Plug / Cable Length: UK / 1.8 Metres... - Page 7 Indesit Company COMPRESSOR Manufacturer: ANHUI HEIZHI - GMCC or equivalent Winding Resistances: Start: 26.7Ω Run: 29.9Ω Capacitor: 3.5 uF REFRIGERANT Refrigerant / Grams: R600a Refrigerant Charge: 50 grams INTERIOR LIGHT LED Module fitted in thermostat housing. 220/240 Volt. Not user replaceable. HEATER RESISTANCES (Ω) 638 Ω...
-
Page 8: Product Description
Indesit Company PRODUCT DESCRIPTION: TEMPERATURE CONTROL HOUSING Thermostat Control with Light On/Off switch APPLIANCE INTERIOR Commodity Racks Control Fridge Shelves Vegetable Box Cover Vegetable Bottle Shelf Freezer Water Dispenser Drawers Adjustable Front Feet (2) Reversible Doors Service Manual UK English 8 of 18... -
Page 9: Door Handle Fitting Instructions
Indesit Company Fitting The Door Handles (not fitted when delivered) With the screw covers removed (unclipped), align the holes in each Door Handle End Cap with the corresponding holes in the edge of each door. Using a suitable Philips screwdriver, fit a screw through each End Cap hole into the door screw hole and tighten securely. -
Page 10: Door Reversal Instructions
Indesit Company DOOR REVERSAL Refer to the Safety Notes at the beginning of this document before carry out any work. The Grip Mat, Part Number C00222890 (5700072), must always be used as directed when leaning an appliance at an angle to reduce appliance movement. Note: Door reversal parts supplied with the product when new will be required to complete the Door Reversal. -
Page 11: Wiring Connection Information
Indesit Company WIRING CONNECTIONS - BLACK TIMER - TMDJX06ZR1 Thermostat Defrost Timer TMDJX06ZR1 6(H) 4(C) Brown White White Yellow/Green Yellow Chassis Defrost Compressor Thermostat Brown Yellow/ Green Yellow/Green Earth E aporator an Motor Chassis Blue PTC Start Chassis Light Defrost Swit h E aporator Brown... -
Page 12: Defrost Wiring And Circuit Description
Indesit Company DEFROST SEQUENCE - BLACK TIMER - TMDJX06ZR1 Defrost Sequence - 1st Phase The Defrost Timer runs all the time that the fridge thermostat is closed. Whilst the defrost timer switch is in the Run position (1-4) the compressor will run, cooling the cabinet. When the Defrost Timer switches to the Defrost position (1-2) the compressor will stop. -
Page 13: Connector Block Wiring
Indesit Company CONNECTOR BLOCK WIRING Rear Wall Connector Block Rear Wall Connector Block Internal Wiring: Plug positions: Live from Defrost Timer (4) & Live to Compressor Overload via Male 4 way plug HEATER EARTH DEFROST Chassis THERMOSTAT Earth DEFROST Timer Terminal 2 HEATER THERMAL FUSE Defrost... -
Page 14: Servicing & Dismantling Instructions
Indesit Company SERVICING & DISMANTLING INSTRUCTIONS Important Notes for Guidance: Before commencing any work refer to the Safety Notes and Safety Precaution at the beginning of this manual. Caution: When carrying out the following procedures care must be taken to protect the appliance and customers property, especially if the appliance is moved or laid down. - Page 15 Indesit Company E. Door Seals There is a moulding at the rear of the door seal that locates into a groove in the door liner to secure it. To remove, ease the seal away from the door liner at one of the corners then work around the door to release completely.
- Page 16 Indesit Company G: Defrost Thermostat and Thermal Fuse assembly Connector Block 4 Way block Defrost Thermostat with cable tie Thermal Fuse with cable tie Remove the Rear Duct Assembly as in F above. Unplug the Thermostat and Fuse connector block (containing 4 wires). These items are supplied as a pair with the connector.
- Page 17 Indesit Company Capacitor The capacitor is mounted on a bracket at the rear of Plastic the appliance next to the compressor near to the Sleeve terminal block. Unscrew 1 large nut from underneath the compressor bracket to release the capacitor. Cut 2 cable ties from the black plastic sleeve covering the connector plug.
- Page 18 Indesit Company Service Manual UK English 18 of 18...
