Omron K3NX Manual

Process meter
Hide thumbs Also See for K3NX:
Table of Contents

Advertisement

Quick Links

Process Meter
Advanced Intelligent Signal
Processor Accepts Voltage/Current
Input
1
Programmable through the front panel
or via RS-232C, RS-485, or RS-422
1
Programming with easy setup and
calibration
1
Multi-range function allows single
Process Meter to cover a wide range of
inputs
1
Easy-to-use scaling function with the
key programming method
1
Auxiliary power supply (80 mA at
12 VDC)
1
NEMA4/IP66 front panel
1
UL, CSA, and CE approved

Ordering Information

To order output and communication boards, refer to the separate K31 data sheet called Output and Communication Boards . See page 155.
3 BASE UNITS
Model
Basic model
Present value LED and front-panel control
keys. Can connect to any output board or,
without an output board, can be used for
display only.
Set value LED model
Present value LED, set value LED, and
front-panel control keys. Can connect to
relay contact, transistor, or combination
output boards.
Note: "Set Value LED" models must be used with an output board in order for them to operate.
9
Supply
y
Applicable
voltage
lt
output boards
t
K31-C1/C2/C5
100 to 240
VAC
K31-T1/T2
K31-B2/B4
K31-L1/L2/L3/
L4/L5/L6/L7/
L4/L5/L6/L7/
L8/L9/L10
12 to 24
K31-FLK1/
VDC
FLK2/FLK3/
FLK4/FLK5/
FLK6
K31-C1/C2/C5
100 to 240
VAC
K31-T1/T2
K31-B4
K31-L4/L5/L6/
L9/L10
L9/L10
12 to 24
K31-FLK4/
VDC
FLK5/FLK6
Part number
t b
d
Input type
DC voltage
DC current
K3NX-VD1A
K3NX-AD1A K3NX-VA1A
K3NX-VD2A
K3NX-AD2A K3NX-VA2A
K3NX-VD1C
K3NX-AD1C K3NX-VA1C
K3NX-VD2C
K3NX-AD2C K3NX-VA2C
K3NX
AC voltage
AC current
K3NX-AA1A
K3NX-AA2A
K3NX-AA1C
K3NX-AA2C

Advertisement

Table of Contents
loading

Related Manuals for Omron K3NX

Summary of Contents for Omron K3NX

  • Page 1: Ordering Information

    Model Supply Applicable voltage output boards Input type DC voltage DC current AC voltage AC current K31-C1/C2/C5 100 to 240 K3NX-VD1A K3NX-AD1A K3NX-VA1A K3NX-AA1A Basic model K31-T1/T2 K31-B2/B4 K31-L1/L2/L3/ L4/L5/L6/L7/ L4/L5/L6/L7/ L8/L9/L10 12 to 24 K3NX-VD2A K3NX-AD2A K3NX-VA2A K3NX-AA2A Present value LED and front-panel control K31-FLK1/ keys.

  • Page 2: Model Number Legend

    K3NX K3NX 3 MODEL NUMBER LEGEND Base Units K3NX - 2 3 4 1, 2. Input Sensors Codes 3. Supply Voltage 4. Display DC voltage input 1: 100 to 240 VAC A: Basic Model DC current input 2: 12 to 24 VDC...
  • Page 3 K3NX K3NX 3 CHARACTERISTICS Input signal DC voltage/current, AC voltage/current A/D conversion method Double integral method Sampling period 50 Hz: 12.5 times/s; 60 Hz: 15 times/s (selectable) Display refresh period Sampling period (sampling times multiplied by number of averaging times if simple average processing is selected.)

  • Page 4: Measuring Ranges

    K3NX K3NX 3 MEASURING RANGES Input range Measuring range Input impedance Reliability (See Note 2.) Instantaneous overload (30 seconds) ±0.1%rdg ±1 digit max. ±199.99 V ±400 V æ DC voltage 10 MΩ ±19.999 V ±200 V å 1 MΩ ±1.9999 V ä...

  • Page 5: Engineering Data

    3 DERATING CURVE FOR SENSOR POWER SUPPLY Note: The derating curve shown is for standard installation. The derating curve depends on the mounting direction. Ambient temperature (°C) Nomenclature 3 K3NX 1. SV Display 7. Status Indicators 2. PV Display 3. Comparative Output Status Indicators 4.

  • Page 6: Operation

    3 SETTING PROCEDURES The K3NX has four modes: RUN mode for normal operations, Setting mode for initial parameter input, Protect mode for lock-out configu- ration, and Maintenance mode for initializing set values and user calibration. The parameters that are accessible on any individual K3NX will vary depending on the Output Board installed.
  • Page 7 Comparative output H corresponding to instantaneous, fluctuating input from the moment the K3NX is turned ON until the end of the preset period. PASS Comparative output L The compensation time can be set in a range from 0 to 99.9...

  • Page 8: Terminal Arrangement

    K3NX K3NX Linear Output Range %,â- Remote/Local Selection + ø A linear output range can be set as required. A value Select remote programming when performing all settings through corresponding to the maximum output value and that the host devices and select local programming when performing corresponding to the minimum output value can be set.
  • Page 9 K3NX K3NX VA: AC Voltage Input AA: AC Current Input ANALOG ANALOG COM. COM. 0 to 1.9999 V 0 to 19.999 mA 0 to 199.99 mA 0 to 19.999 V 0 to 199.99 V 0 to 1.9999 A 0 to 400.0 V 0 to 10.000 A...

  • Page 10: Block Diagram

    Detects via the E3SA the change in reflected light according The change in the density of the dust is detected via the to the amount of aluminum deposition on the CRT. E3SA and discriminated by the K3NX. The input is processed and displayed in percentage by the Exhaust scaling function.
  • Page 11 E2CA 4 to 20 mA 10 mm E32-T16 K3NX K3NX Large 4 to 20 mA E3XA Alarm output BCD output K3NX Dimensions Unit: mm (inch) 3 K3NX PV Display 70.5 14.2 (2.78) (3.54) (3.58) 46.5 (1.83) (1.18) Panel Cutouts (1.73) (1.69) (1.89)

  • Page 12: Installation

    Installation 3 EXAMPLE OF CONNECTION TO PROGRAMMABLE CONTROLLER FOR K3N SERIES NOTE: DIMENSIONS SHOWN ARE IN MILLIMETERS. To convert millimeters to inches divide by 25.4. OMRON ELECTRONICS, INC. OMRON CANADA, INC. One East Commerce Drive 885 Milner Avenue Schaumburg, IL 60173...
