Philips HR1861/ROW Service Manual

Philips Consumer Lifestyle
Service Manual
PRODUCT INFORMATION
Features:
- Unique micro-mesh fi lter
- Extra large Feeding Tube
- 2 L pulp container
- Easy-to-clean
- 2 speed control
- Rubber feet for extra stability
- Easy and convenient cord storage
Accessories (included):
- Juice Jug (1,5 L)
- Cleaning Brush
Safety:
- Safety locking system wih 2 brushed aluminium clamps.
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
offi cially laid down at this moment.
ASSEMBLY & DISASSEMBLY ADVICE
- No specifi c issues
REPAIR INSTRUCTION
- No specifi c issues
OPTIONAL (accessories)
- No specifi c issues
Published by Philips Consumer Lifestyle
10/09
TECHNICAL INFORMATION
- Power
- Voltage / frequency
- Juice Jug capacity
- Pulp Container capacity
- Cord length
- Speed rotations:
Packaging - F-Box
- Dimensions (L x W x H) : 355 x 245 x 445 mm
- Weight
Materials:
- Clamps
- Cleaning Brush
- Feeding Tube ring
- Filter
- Housing
- Juice Collector
- Juice Jug Lid
- Juice Jug
- Juicer Lid
- Pulp Container
- Pusher
- Spout
= changed
Printed in the Netherlands
HR1861/ROW
SAP coding: HR1861/ROW
: 700 W
: 220 - 240 V / 50 - 60 Hz
: 1,5 Litre
: 2,0 Litre
: 120 cm
Speed 1 : 6.000 rpm
Speed 2 : 11.000 rpm
: 6,35 kg
: Brushed Aluminium
: PP
: ABS
: Stainless Steel
: Brushed Aluminium
: ABS
: PP
: SAN
: SAN
: PP
: ABS
: Stainless Steel
© Copyright reserved
Juicer
Subject to modification
