ORIGINAL INSTRUCTIONS
OPERATOR'S MANUAL
T4.75F
T4.85F
T4.95F
T4.105F
Tractor
Part number 47593719
2
edition English
nd
October 2013
Replaces part number 47494640

Advertisement

Table of Contents
loading

Related Manuals for New Holland T4.75F

Summary of Contents for New Holland T4.75F

  • Page 1 ORIGINAL INSTRUCTIONS OPERATOR’S MANUAL T4.75F T4.85F T4.95F T4.105F Tractor Part number 47593719 edition English October 2013 Replaces part number 47494640...

  • Page 2: Table Of Contents

    Contents 1 GENERAL INFORMATION Note to the Owner ................1-1 Proposition 65 .
  • Page 3 RIGHT-HAND SIDE CONTROLS Console Right-hand console - Control identification ........3-27 REARWARD CONTROLS Console - Control identification .
  • Page 4 6 WORKING OPERATIONS FOUR WHEEL DRIVE (4WD) Four-wheel drive with electro-hydraulic control........6-1 DIFFERENTIAL LOCK Electrohydraulic differential lock .
  • Page 5 WHEELS AND TIRES Wheels and tires..............6-42 Tyre dimensions .
  • Page 6 EVERY 50 HOURS Rear wheel hub............... . 7-23 Lift and linkage .
  • Page 7 Change transmission oil ............. . . 7-41 Washing cooling system.
  • Page 8 10 ACCESSORIES Radio ..................10-1...

  • Page 9: General Information

    Your NEW HOLLAND dealer will instruct you in the general operation of your new equipment. Your dealer’s staff of factory-trained service technicians will be glad to answer any questions that may arise regarding the operation of your machine.

  • Page 10: Proposition 65

    1 - GENERAL INFORMATION Proposition 65 CALIFORNIA Proposition 65 Warning Diesel engine exhaust and some of its constituents are known to the State of California to cause cancer, birth defects and other reproductive harm. Battery posts, terminals and related accessories contain lead and lead compounds. Wash hands after handling.

  • Page 11: International Symbols

    1 - GENERAL INFORMATION International symbols TYPICAL RECOMMENDED SI (METRIC) UNITS IMPERIAL UNIT APPLICATIONS NAME SYMBOL NAME SYMBOL AREA acre hectare square meter m² square foot ft² square inch in² square millimetre mm² square inch in² ELECTRICITY ampere ampere volt volt microfarad µF...
  • Page 12 1 - GENERAL INFORMATION TYPICAL RECOMMENDED SI (METRIC) UNITS IMPERIAL UNIT APPLICATIONS NAME SYMBOL NAME SYMBOL TEMPERATURE (other than THERMODYNAMIC) degrees Celsius °C degrees Fahrenheit °F TIME hour hour minute minute second second TORQUE (includes BENDING MOMENT, MOMENT OF FORCE, and MOMENT OF A COUPLE) newton meter feet-pounds Ib ft...

  • Page 13: Introduction

    1 - GENERAL INFORMATION Introduction About this manual DANGER Improper operation or service of this machine can result in an accident. Do not operate this machine or perform any lubrication, maintenance, or repair on it until you have read and understood the operation, lubrication, maintenance, and repair information. Failure to comply will result in death or serious injury.

  • Page 14: Tractor Intended Use

    1 - GENERAL INFORMATION Tractor intended use NOTE: Your tractor is designed according to European • Do not use the tractor in combination with equipment directives related to health and safety risks; though it without having consulted the specific Operator’s Man- has been designed to minimize all the potential risks it is ual provided with the equipment.
  • Page 15 1 - GENERAL INFORMATION and owns the officially released software versions and • The tractor has only one operator station and this is a updates for your tractor. one man operated vehicle. There is no need for other people on or around the tractor during normal opera- •...

  • Page 16: Ecology And The Environment

    1 - GENERAL INFORMATION Ecology and the Environment Soil, air and water are essential elements for agriculture suitable disposal can be arranged according to na- and for life in general. If local legislation does not con- tional legislation or local regulations. trol the treatment of certain substances, the production Modern anti-freeze liquids and solutions, e.g.

  • Page 17: Identification Plates

    1 - GENERAL INFORMATION Identification plates Serial numbers identify the tractor and its main components. The identification data must be supplied by the dealer for requests for spare parts or service operations. Identification data is of fundamental importance in the event of theft of the tractor.
  • Page 18 1 - GENERAL INFORMATION FRAME IDENTIFICATION DATA PLATE The tractor’s frame number is stamped over the front sup- port. It gives the safety frame identification data. CAB IDENTIFICATION PLATE The cab identification plate is located at the rear on the left−hand side as shown in the figure.

  • Page 19: Component Identification

    1 - GENERAL INFORMATION Component Identification MOIL13TR00772FA Hand rail Fuel tank Steps Transmission Front axle Ballast Front light Hood/Engine 10. Indicator light MOIL13TR00756AA 11. Rear view mirror 12. Exhaust stack 13. Front work lights 14. Rear work lights 15. Rear widow emergency exit 16.
  • Page 20 1 - GENERAL INFORMATION MOIL13TR00771FA 1. Rear axle 2. Three point linkage 3. Hitch 4. Power take off 5. Rear lights 6. Remote control valves 1-12...

  • Page 21: Safety Information

    2 - SAFETY INFORMATION 2 - SAFETY INFORMATION###_2_### Safety rules and signal word definitions Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury. Throughout this manual and on machine decals, you will find the signal words DANGER, WARNING, and CAUTION followed by special instructions.

  • Page 22: Safety Information

    Any other use will require prior shaft cover, etc.). authorisation from NEW HOLLAND. 4. Never start or manoeuvre the tractor unless seated in It is advisable to keep a first aid kit on hand.
  • Page 23 2 - SAFETY INFORMATION Use of the tractor Select the most suitable wheel setting for the work in hand, i.e.: the setting that provides the best stability. DCSFTNEGB006S1A 10. Proceed with maximum caution when working with the wheels near the edge of ditches or slopes. 11.
  • Page 24 2 - SAFETY INFORMATION Stopping the tractor 1. When the tractor is stationary, never leave connected implements in the raised position. All implements must be lowered before stopping the engine. 2. Before leaving the driving position, move the gear lever to the neutral position, disengage the power take-off, apply the handbrake and stop the engine.
  • Page 25 2 - SAFETY INFORMATION DCSFTNEGB011S1A DCSFTNEGB013S1A Oil under pressure getting out can cause serious Before inspecting, cleaning or carrying out mainte- injuries. When looking for leaks use the appropri- nance on the tractor (or any implement connected ate safety equipment: screens, safety glasses and to the tractor), always ensure that the engine is gloves.

  • Page 26: Air Conditioning Safety Regulations

    4. Do not allow heat sources near the air-conditioning system; any repair work should be carried out by the system, as this may cause explosions. experienced technicians of the NEW HOLLAND Ser- vice Network. DCSFTNEGB017S1A 5. Coolant can freeze the skin and, above all, the eyes.

  • Page 27: Cab Guard

    2 - SAFETY INFORMATION Cab guard Comfort and safety inside the cab • Do not use the tractor beyond its limits of terrain gradi- ent and stability. Using the tractor beyond these limits may result in a roll over or a tip over. Observe the rec- Definition of Cab Category 1 ommendations in this manual and pay particular atten- tion when going down steep hills in a loaded condition.
  • Page 28 2 - SAFETY INFORMATION • Always use the correct implement (grab forks, buckets, bystanders to stand near or under the lifted bucket of a etc) for the specific task to ensure that the load is se- front – end loader. curely kept in place.

  • Page 29: Roll Over Protective Structure (Rops)

    2 - SAFETY INFORMATION Roll over protective structure (ROPS) OPERATOR PROTECTIVE STRUCTURE DANGER Crushing hazard! DO NOT operate the machine with the Roll-Over Protective Structure (ROPS) removed. Remove the ROPS only for service or replacement. Failure to comply will result in death or serious injury. D0032A DANGER Crushing hazard!

  • Page 30: Personal Protective Equipment (Ppe)

    2 - SAFETY INFORMATION Personal protective equipment (PPE) WARNING Personal Protective Equipment (PPE) required. When assembling, operating, or servicing the machine, wear protective clothing and PPE necessary for the particular procedure. Some PPE that may be necessary includes protective shoes, eye and/or face protection, hard hat, heavy gloves, filter mask, and hearing protection.

  • Page 31: Tractor Jacking Points

    2 - SAFETY INFORMATION Tractor jacking points WARNING Equipment failure could cause accident or injury! Only use rigging equipment that has the capacity to lift the loads that you are moving. Always check the rigging equipment each day for damaged or missing parts. Make sure other workers or bystanders are not under the load while it is moving.

  • Page 32: Hazardous Chemicals

    2 - SAFETY INFORMATION Hazardous chemicals Exposure to or contact with hazardous chemical substances can cause serious injuries. The fluids, lubricants, paints, adhesives, coolants, etc. required for the machine's operation can be harmful. In addition, they can attract domestic animals and people creating dangerous situations for health. The materials safety data sheets (MSDS) provide information on the chemical substances contained in a product, on the methods of safe storage and handling and on the first aid procedures to follow should such a product get accidentally spilled.

  • Page 33: Burn Prevention

    2 - SAFETY INFORMATION Burn prevention WARNING Hot surface possible! Wait for all components to cool before performing any operation. Failure to comply could result in death or serious injury. W0251A CAUTION Hot area! Use care when working near hot components. Wear protective gloves. Failure to comply could result in minor or moderate injury.

  • Page 34: Fire Or Explosion Prevention

    2 - SAFETY INFORMATION Fire or explosion prevention Fire Extinguisher Remove all litter or debris from the machine each day; especially check the engine area and exhaust system. Only operate your tractor when an approved fire extin- A spark or a naked light can cause the hydrogen in a guisher is installed.

  • Page 35: Getting In And Out Of The Machine

    2 - SAFETY INFORMATION Getting in and out of the machine WARNING Fall hazard! Jumping on or off the machine could cause an injury. Always face the machine, use the handrails and steps, and get on or off slowly. Maintain a three-point contact to avoid falling: both hands on the handrails and one foot on the step, or one hand on the handrail and both feet on the steps.

  • Page 36: Safety Signs

    2 - SAFETY INFORMATION Safety signs The safety decals on the following pages are positioned on your tractor in the locations shown in the drawings below. These safety decals are important both for your safety and that of personnel working with you. We recommend that you study these pages and find the positions of the safety decals on the tractor, checking that their meanings are clear.
  • Page 37 2 - SAFETY INFORMATION Positioned in several places on the tractor General Warning: Read and understand all the warning notes printed in this Operator's Manual with regards to the relevant part where the decal is applied. Positioned in several places on the tractor General Warning: danger due to mechanical moving parts.
  • Page 38 2 - SAFETY INFORMATION Location: On the intake manifold. Do not use ether on the cooling system. Location: Right-hand side on the starter motor. Location: right-hand side on the radiator. To avoid serious injury, keep hands and clothing away from the rotating fan, belts and any other rotating parts. (10) Location: On the internal part of the left−hand rear fender: do not operate on the power take-off with the engine run-...

  • Page 39: Controls/Instruments

    3 - CONTROLS/INSTRUMENTS CONTROLS/INSTRUMENTS###_3_### ACCESS TO OPERATOR'S PLATFORM WARNING Misuse hazard! The cab is an integral part of the machine's structure. DO NOT repair, weld, or straighten the cab. Contact your Dealer and follow their instructions to avoid reducing the structural integrity of the ma- chine.
  • Page 40 3 - CONTROLS/INSTRUMENTS Opening Front Windscreen To open, pull handle (1) upwards and push forward. The window will be held in position by special struts. MOIL13TR00492AA Rear Window To open, pull handle (1) upwards and push forward. The window will be held in position by special struts. MOIL13TR00493AA Windscreen washer spray nozzle For better windscreen cleaning, adjust the angle of the...
  • Page 41 3 - CONTROLS/INSTRUMENTS Rear view mirror external The mirror can be adjusted in two ways, as described below: • turn the support bracket (1) on its axis to adjust the an- gle of the mirror; • turn the mirror (2) into the position that provides the best rear view.

  • Page 42: Heating System

    3 - CONTROLS/INSTRUMENTS Heating system Adjustable vents On the roof inside the cab there are four adjustable vents (1). The vents can be adjusted independently to direct hot or cold air on the windscreen and side windows inside the cab. To open, press on one side and turn the vent to direct the air flow where required.

  • Page 43: Heating, Ventilation Or Air-Conditioning Control

    3 - CONTROLS/INSTRUMENTS Heating, ventilation or air-conditioning control The air-conditioning system can supply either cool or from entering the cab; it is also advised to close the re-cir- warm dehumidified air. culation vents. To use the system, proceed as follows. If only the dehumidification function on the air conditioning NOTICE: When the engine is not running, the air condi- system is required, without lowering the air temperature,...

  • Page 44: Annual Maintenance

    Cab air conditioning controls Annual maintenance At the start of the season, have the specialist personnel from the NEW HOLLAND service network carry out the following operations: • Check the oil level in the compressor • Check system pressure and, if necessary, fill the sys- tem with HFC R134 •...

  • Page 45: Cab Air Filter

    3 - CONTROLS/INSTRUMENTS Cab air filter DANGER Chemical hazard! The cab air filters are designed to remove dust from the air, but will not keep out chemical vapor. Extended periods of exposure to pesticides could cause death or personal injury. Follow the chemical manufacturer's directions for protection from dangerous chemicals.
  • Page 46 3 - CONTROLS/INSTRUMENTS Active-Carbon Air Filter DANGER Chemical hazard! When replacing the filter, pay attention to the sticker on the filter. For correct operation, the specified anti-pollen or active carbon filter must be used and cannot be interchanged. Failure to comply will result in death or serious injury. D0007A NOTICE: the active carbon air filters do not guarantee full when working in very dusty areas;...

  • Page 47: Operator's Seat

    3 - CONTROLS/INSTRUMENTS OPERATOR'S SEAT Operator seat DANGER Loss of control hazard! DO NOT make seat or steering adjustments while the machine is in motion. Ensure all adjustments are locked prior to use. Check the tightness of the securing screws and that the adjustment controls are working properly.
  • Page 48 3 - CONTROLS/INSTRUMENTS Safety belts WARNING Equipment failure could cause accident or injury! Always fasten seat belt securely before operating the machine. Inspect seat belt parts for wear and/or damage. To ensure operator safety, replace any and all damaged parts of the seat belt prior to oper- ation.

  • Page 49: Forward Controls

    3 - CONTROLS/INSTRUMENTS FORWARD CONTROLS Analogue dashboard MOIL13TR00381FA The indicator lights on the control panel inform you of the operational condition of the machine. Some of these indicate faults arising during operation. An indicator light coming on may be followed by a continuous or intermittent buzzer. Depending on the severity of the trouble, the alarm will sound.
  • Page 50 3 - CONTROLS/INSTRUMENTS Rear power take−off (amber) Lights up when the power take−off is engaged. Brake pedals not latched (red) The indicator lights up to signal when brake pedal latching is not blocked. This warning light is only active for markets that require signaling failed brake pedal latching. Handbrake (red) Indicates that the handbrake is on (with starter key inserted).
  • Page 51 3 - CONTROLS/INSTRUMENTS Trailer brake (red) Comes on, with the engine running, when the brakes are applied with the tractor brakes coupled together for road driving. The light comes on whenever the handbrake is on or when the brake fluid pressure is low. Fuel level low (amber) The light comes on when the tractor needs refuelling.

  • Page 52: Fuel Gauge

    3 - CONTROLS/INSTRUMENTS Speedometer/tachometer Engine rev counter and six−figure hour meter: the figures on the black background count the hours of work and that on the red background (last figure on the right) show the tenths of an hour. The green and blue sectors show the number of engine rpm required to reach standard power take−off speed.

  • Page 53: Digital Dashboard

    3 - CONTROLS/INSTRUMENTS Digital dashboard MOIL13TR00299FA 1. Left-hand digital display − This display shows the trac- 4. Fuel level histogram tor ground speed in -      km/h (-      mph) 5. Warning lights 2. Information display - The display shows information on 6.
  • Page 54 3 - CONTROLS/INSTRUMENTS MOIL13TR00298FA Stop warning light (red) If the red “Stop” warning light comes on, switch off the tractor immediately and look for the cause. A warning symbol will appear on the display confirming the location of the fault. Indicator lamp (amber) This indicator light comes on and the display shows a warning symbol .
  • Page 55 3 - CONTROLS/INSTRUMENTS High (HI) gear range indicator light (green) Lights up when the high gear range is selected (tractors with Power-Shuttle/Dual Command (2 Speed Power Shift) transmission only). Front lift (amber) This warning light comes on when the front lift is deactivated, or it briefly illuminates when starting the engine (even if the tractor is not equipped with the front lift).
  • Page 56 3 - CONTROLS/INSTRUMENTS Side lights (green) This warning light comes on when the position lights are switched on. Second trailer direction indicators indicator light (green) This indicator light flashes together with the tractor/trailer direction indicators, if the second trailer is connected. First trailer direction indicators indicator light (green) This indicator light flashes together with the tractor/trailer direction indicators, if the second trailer is connected.
  • Page 57 3 - CONTROLS/INSTRUMENTS Tachometer/rev-counter (1) Engine rev counter. To obtain the engine rpm, multiply the number indicated by the pointer by 100. Digital display (2) When the engine switches on, the digital display passes automatically to show the tractor ground speed, in km/h or MPH, depending on the set unit of measurement.
  • Page 58 3 - CONTROLS/INSTRUMENTS Multi-function display The liquid crystal multi-function display (1) can show use- ful and necessary information for the driver and a menu that supports the following setting functions: • Tractor ground speed calibration • Instrument cluster dimming • Buzzer on/off on pressing the buttons •...

  • Page 59: Front Controls

    3 - CONTROLS/INSTRUMENTS Front controls 1. Menu navigation button 2. Scroll and selection button 3. Hazard lights switch Press the left side (with the symbol) of the switch (3) to turn on the hazard light flashers; when pressed, the switch starts blinking. The panel light flashes at the same time as the direction indicators.
  • Page 60 3 - CONTROLS/INSTRUMENTS Front power take−off NOTE: Only for models with SuperSteer™ axle To engage the power take−off, lightly press the knob (1) and raise the collar (2). The warning light on the instrument cluster will come on to signal the PTO has engaged.

  • Page 61: Foot Throttle

    3 - CONTROLS/INSTRUMENTS Footbrakes WARNING Loss of control hazard! Uneven brake force exists on left-hand and right-hand brakes. Always use brake pedal coupler when traveling on public roads to en- sure brakes are actuated together. Failure to comply could result in death or se- rious injury.
  • Page 62 3 - CONTROLS/INSTRUMENTS 1. Power take−off engagement lever. To activate the power take−off, engage the clutch by setting the respective control lever (1) in the com- pletely raised position. MOIL13TR00540AA Adjusting the steering wheel The steering wheel is fitted with a height adjustment knob. To adjust, loosen the knob (1) and move the steering wheel to the desired height.

  • Page 63: Left-Hand Side Controls

    3 - CONTROLS/INSTRUMENTS LEFT-HAND SIDE CONTROLS Console Left-hand console - Control identification 1. Shuttle (mechanical shuttle control lever) NOTE: On the dual command (2 speed power shift) version of the Power Shuttle the lever (1) governs en- gagement/disengagement of the parking brake. MOIL13TR00998AA Handbrake To apply the handbrake, press the red button on the end of...

  • Page 64: Parking Brake For Hydraulic Transmissions

    3 - CONTROLS/INSTRUMENTS Parking brake for hydraulic transmissions Parking lock NOTICE: On models with Power Shuttle and HI-LO when leaving the machine, besides applying the hand brake you must engage the parking brake Parking lock . Figure 1 configuration with HI-LO , Power shuttle. Figure 2 configuration with HI-LO , Power shuttle and creeper unit.

  • Page 65: Right-Hand Side Controls

    3 - CONTROLS/INSTRUMENTS RIGHT-HAND SIDE CONTROLS Console Right-hand console - Control identification 1. Gear lever. 2. Range gear lever. MOIL13TR00799AA Version with mechanically-operated lift 1. Lift-O-Matic™ - Mechanically-operated hydraulic lift. 2. Auxiliary control valve levers. 3. Hydraulic lift control levers. 4.
  • Page 66 3 - CONTROLS/INSTRUMENTS (1) Rotating beacon switch • Position (A) = beacon on. • Position (B) = beacon off. (2) Work lights switch • Position (A) = front and rear work lights on. • Position (C) = rear work lights on, front work lights off. •...

  • Page 67: Rearward Controls

    3 - CONTROLS/INSTRUMENTS REARWARD CONTROLS Console - Control identification Switches governing stabilizers and right hand lift rod 1. Switch governing right−hand lift rod adjustment 2. Push−button governing right and left hydraulic stabi- lizer extension. 3. Push−button for locking hydraulic stabilizers MOIL13TR00999AA EXTERIOR CONTROLS Console - Control identification...

  • Page 68: Display Settings

    3 - CONTROLS/INSTRUMENTS DISPLAY SETTINGS Instrument cluster - Program Information display or indicator brightness calibration If you want to change the instrument’s brightness, starting from the display (1), proceed as follows: • Turn the ignition key onto the first click, press the arrow (C) on the switch for at least 3 seconds and the display will show a symbol as in detail (2), to change the bright- ness of the indicators, or the arrow (D) to view the detail...
  • Page 69 3 - CONTROLS/INSTRUMENTS Changing clock hours/minutes If you want to change the hour, proceed as follows. Turn the ignition key onto the first click, holding down the symbol (B) on the switch for more than three seconds. • The central display shows "SETUP MENU" as in detail (1).
  • Page 70 3 - CONTROLS/INSTRUMENTS Changing 12 or 24 hour clock format If you want to display the set time in 12 or 24 hour mode, follow these instructions: Turn the ignition key onto the first click, holding down the symbol (B) on the switch for more than three seconds. •...
  • Page 71 3 - CONTROLS/INSTRUMENTS Changing unit of measurement If you want to turn audible warning on or off each time a button is pressed, proceed as follows: Turn the ignition key onto the first click, holding down the symbol (B) on the switch for more than three seconds. •...
  • Page 72 3 - CONTROLS/INSTRUMENTS Audible warning ON/OFF If you want to turn audible warning on or off each time a button is pressed, proceed as follows. Turn the ignition key onto the first click, holding down the symbol (B) on the switch for more than three seconds. •...
  • Page 73 3 - CONTROLS/INSTRUMENTS Speed calibration If rear tyres of a different size are to be fitted, with a dif- ference in radius of more than 13      mm (0.5      in) compared to the standard ones, it will be necessary to recalibrate the electronic control module so as to get the display of a specific ground speed.
  • Page 74 3 - CONTROLS/INSTRUMENTS Active fault codes display If you want to display the active fault codes, proceed as follows. Turn the ignition key onto the first click, holding down the symbol (B) on the switch for more than three seconds. •...

  • Page 75: Transmission

    3 - CONTROLS/INSTRUMENTS TRANSMISSION Transmission - Operating 4WD models By adopting different bevel gear pairs, all of the listed mechanical transmissions can develop a speed of 40      km/h (24.85      mph). Models with standard front axle: FRONT REAR 11/28 11/36...

  • Page 76: Transmission With Gear Reducer And Mechanical Reversing Mechanism

    3 - CONTROLS/INSTRUMENTS Transmission with gear reducer and mechanical reversing mechanism 30      km/h (18.6      mph) - 40      km/h (24.9      mph) - 16FWD + 16REV WARNING Unexpected machine movement! With the engine running and only the gear lever in neutral, the machine can engage and move suddenly if someone accidentally op- erates this lever.
  • Page 77 3 - CONTROLS/INSTRUMENTS SPEED AT MAXIMUM POWER Transmission 30      km/h (18.6      mph) version 16 FWD + 16 REV FORWARD SPEED REAR TIRES 13.6 R 28 14.9 R 28 340/85 R 28 RANGE GEAR 380/70 R 20 380/70 R 24 420/70 R 24 380/85 R 28...
  • Page 78 3 - CONTROLS/INSTRUMENTS SPEED AT MAXIMUM POWER Transmission 40      km/h (24.9      mph) version 16 FWD + 16 REV FORWARD SPEED REAR TIRES 13.6 R 28 14.9 R 28 340/85 R 28 RANGE GEAR 380/70 R 20 380/70 R 24 420/70 R 24 380/85 R 28...

  • Page 79: Transmission With Gear Reducer And Electrohydraulic Reversing Mechanism

    3 - CONTROLS/INSTRUMENTS Transmission with gear reducer and electrohydraulic reversing mechanism 30      km/h (18.6      mph) - 40      km/h (24.9      mph) - 16FWD + 16REV WARNING Unexpected machine movement! With the engine running and only the gear lever in neutral, the machine can engage and move suddenly if someone accidentally op- erates this lever.
  • Page 80 3 - CONTROLS/INSTRUMENTS SPEED AT MAXIMUM POWER Transmission 30      km/h (18.6      mph) version 16 FWD + 16 REV FORWARD SPEED REAR TIRES 13.6 R 28 14.9 R 28 340/85 R 28 RANGE GEAR 380/70 R 20 380/70 R 24 420/70 R 24 380/85 R 28...
  • Page 81 3 - CONTROLS/INSTRUMENTS SPEED AT MAXIMUM POWER Transmission 40      km/h (24.9      mph) version 16 FWD + 16 REV FORWARD SPEED REAR TIRES 13.6 R 28 14.9 R 28 340/85 R 28 RANGE GEAR 380/70 R 20 380/70 R 24 420/70 R 24 380/85 R 28...

  • Page 82: Parking Brake For Hydraulic Transmissions

    3 - CONTROLS/INSTRUMENTS Parking brake for hydraulic transmissions Parking lock NOTICE: On models with Power Shuttle and HI-LO when leaving the machine, besides applying the hand brake you MUST engage the parking brake Parking lock. Figure 1 configuration with HI-LO, Power shuttle. Figure 2 configuration with HI-LO, Power shuttle and creeper unit.

  • Page 83: Trol

    3 - CONTROLS/INSTRUMENTS Transmission with gear reducer, electrohydraulic reversing mechanism and HI-LO control 30      km/h (18.6      mph) - 40      km/h (24.9      mph) - 32 FWD + 16 REV WARNING Unexpected machine movement! With the engine running and only the gear lever in neutral, the machine can engage and move suddenly if someone accidentally op-...
  • Page 84 3 - CONTROLS/INSTRUMENTS SPEED AT MAXIMUM POWER 30      km/h (18.6      mph) transmission 32 FWD + 16 REV version FORWARD SPEED REAR TIRES 13.6 R 28 14.9 R 28 340/85 R 28 RANGE GEAR 380/70 R 20 380/70 R 24 420/70 R 24 380/85 R 28...
  • Page 85 3 - CONTROLS/INSTRUMENTS SPEED AT MAXIMUM POWER 40      km/h (24.9      mph) transmission 32 FWD + 16 REV version FORWARD SPEED REAR TIRES 13.6 R 28 14.9 R 28 340/85 R 28 RANGE GEAR 380/70 R 20 380/70 R 24 420/70 R 24 380/85 R 28...
  • Page 86 3 - CONTROLS/INSTRUMENTS Transmission with gear reducer, electrohydraulic reversing mechanism, HI-LO control and electrohydraulic clutch 30      km/h (18.6      mph) - 40      km/h (24.9      mph) - 32 FWD + 16 REV WARNING Unexpected machine movement! With the engine running and only the gear lever in neutral, the machine can engage and move suddenly if someone accidentally operates this lever.

  • Page 87: Electrohydraulic Clutch

    3 - CONTROLS/INSTRUMENTS Electro-hydraulic clutch The electro-hydraulic operation of the clutch allows the operator to control the movement of the tractor without using the clutch pedal by simply moving the gear lever from one gear to another, whether forwards or in reverse, without using the clutch pedal (1) fig.
  • Page 88 3 - CONTROLS/INSTRUMENTS Transmission disabled If the control unit detects an improper sequence of oper- ator controls, or problems in the system, it disables the transmission. If the red “ Stop” warning light (2) comes on, switch off the tractor immediately and look for the cause. A warning symbol will appear on the display (3) confirming the loca- tion of the fault.
  • Page 89 3 - CONTROLS/INSTRUMENTS SPEED AT MAXIMUM POWER 30      km/h (18.6      mph) transmission 32 FWD + 16 REV version FORWARD SPEED REAR TIRES 13.6 R 28 14.9 R 28 340/85 R 28 RANGE GEAR 380/70 R 20 380/70 R 24 420/70 R 24 380/85 R 28...
  • Page 90 3 - CONTROLS/INSTRUMENTS SPEED AT MAXIMUM POWER 40      km/h (24.9      mph) transmission 32 FWD + 16 REV version FORWARD SPEED REAR TIRES 13.6 R 28 14.9 R 28 340/85 R 28 RANGE GEAR 380/70 R 20 380/70 R 24 420/70 R 24 380/85 R 28...

  • Page 91: Operating Instructions

    4 - OPERATING INSTRUCTIONS 4 - OPERATING INSTRUCTIONS###_4_### COMMISSIONING THE UNIT Basic operating safety rules WARNING Inhalation/asphyxiation hazard! Make sure there is proper ventilation before starting the engine. Failure to comply could result in death or serious injury. W0091A WARNING Unexpected machine movement! Before starting the engine, move all operating controls to neutral or park lock position.
  • Page 92 If you have any doubts about any functional aspect of the tractor, contact you NEW HOLLAND dealer. The dealer can provide skilled personnel, original spare parts and the necessary equipment to carry out your service requirements.

  • Page 93: Starting The Unit

    4 - OPERATING INSTRUCTIONS STARTING THE UNIT Starting the engine Your tractor will guarantee reliable service if care is taken 5. Turn the starter key to position (C) figure 1. Release during the running−in period (first 50 hours of work), and the key as soon as the engine starts.
  • Page 94 4 - OPERATING INSTRUCTIONS Starting with grid heater (on request) Checks to be carried out before using the tractor WARNING Explosion hazard! Before operating the tractor, ensure that you are thor- DO NOT use ether starting fluid. Explosion, oughly familiar with the location and operation of the con- death, serious personal injury, or serious en- trols.

  • Page 95: Stopping The Unit

    4 - OPERATING INSTRUCTIONS STOPPING THE UNIT Stopping the engine Stopping the tractor • Reduce engine speed. • Depress the transmission clutch pedal and brake. When the tractor is stationary, move the main shift and range gear levers to neutral, release the clutch pedal and engage the handbrake Stopping the Engine NOTE: Before stopping the engine, allow it to idle at...
  • Page 96 4 - OPERATING INSTRUCTIONS...

  • Page 97: Transport Operations

    5 - TRANSPORT OPERATIONS 5 - TRANSPORT OPERATIONS###_5_### ROAD TRANSPORT Transporting the machine WARNING Transport hazard! The machine can slip or fall from a ramp or trailer. Make sure the ramp and trailer are not slippery. Remove all oil, grease, ice, etc. Move the machine on or off the trailer with machine centered on the trailer or ramp.

  • Page 98: Recovery Transport

    5 - TRANSPORT OPERATIONS RECOVERY TRANSPORT Towing the tractor WARNING Loss of control! Only tow at safe speeds. Use caution when making corners or meeting traffic. Failure to comply could result in death or serious injury. W0126A WARNING Hazard to bystanders! The operator must be the only person on the machine when towing.

  • Page 99: Working Operations

    6 - WORKING OPERATIONS 6 - WORKING OPERATIONS###_6_### FOUR WHEEL DRIVE (4WD) Four-wheel drive with electro-hydraulic control Only SuperSteer™ axle Front−wheel drive can increase the tractor’s grip on the surface: the benefits of this are particularly noticeable when working on uneven, muddy or slippery surfaces, on ploughed ground or in difficult conditions. Manual engagement Engage four−wheel drive by pressing button (1) fig.

  • Page 100: Differential Lock

    6 - WORKING OPERATIONS DIFFERENTIAL LOCK Electrohydraulic differential lock DANGER Steering is difficult with the differential lock engaged. An accident could result. During field operation, use the differential lock for traction improvement but release for turning at row end. Do not drive at high speeds or on roads with the differential lock engaged. Failure to comply will result in death or serious injury.

  • Page 101: Mechanical Differential Lock

    6 - WORKING OPERATIONS Mechanical differential lock DANGER Steering is difficult with the differential lock engaged. An accident could result. During field operation, use the differential lock for traction improvement but release for turning at row end. Do not drive at high speeds or on roads with the differential lock engaged. Failure to comply will result in death or serious injury.

  • Page 102: Remote Valves

    6 - WORKING OPERATIONS REMOTE VALVES General safety rules WARNING Unexpected movement! When starting the machine engine, make sure the remote valve levers are in the correct position BE- FORE you operate the key switch. This prevents an attached implement from moving unintentionally. Failure to comply could result in death or serious injury.

  • Page 103: Rear Remote Control Valve(S)

    6 - WORKING OPERATIONS Rear remote control valve(s) Before removing the protective caps for connecting the male couplings, remove all the debris that has accumulated on the pressure points to avoid contaminating the hydraulic system. Quick coupler One, two or three control valves using the same oil as the hydraulic lift circuit to which they are connected can be fitted to your tractor for remote control of single-acting and double-acting cylinders.
  • Page 104 6 - WORKING OPERATIONS Auxiliary control valve levers for models with mechanically controlled hydraulic lift Control levers (1) and (2) have two positions, as well as the central neutral position: • forward = down; • back = up. The control lever (3) can be in two positions, excluding the central neutral position: •...
  • Page 105 6 - WORKING OPERATIONS Flow divider Version with one flow control knob The knob (1) is used to control the oil flow rate of the remote valve (2), the remaining (excess) flow rate will be diverted to the other valves. MOIL13TR00594AA Version with two flow control knobs The knob (3) is used to control the oil flow rate of the top...
  • Page 106 6 - WORKING OPERATIONS Split control spool valves (with switch) On all the models, the control levers (2) and (3) for models with a mechanical lift or (4) and (5) with an electronic lift can be equipped with a button (6) so that each of them can control two spool valves.

  • Page 107: Electrohydraulically Controlled Side Hydraulic Valves

    6 - WORKING OPERATIONS Electrohydraulically controlled side hydraulic valves MOIL13TR01009FA Machines equipped with a cab have a block of distributors for remote controls fixed on the right-hand side of the driver's seat, controlled electronically. The block of distributors is split into two sections: •...
  • Page 108 6 - WORKING OPERATIONS Operation When the joystick (1) is operated with a crosswise move- ment, it operates the distributors on axis (X) and on axis (Y) . The same lever (1) when operated diagonally enables si- multaneous operation of two variable flow rate distribu- tors.

  • Page 109: Electrohydraulically Controlled Rear Remote Control Valves

    6 - WORKING OPERATIONS Electrohydraulically controlled rear remote control valves On request, two pairs of electro-hydraulically controlled side spool valves can be used to supply the same number of auxiliary rear hydraulic control valves. 1. Line control valves X, yellow 2.

  • Page 110: Side Hydraulic Valves

    6 - WORKING OPERATIONS Side hydraulic valves Only models with roll bars ROPS WARNING Pressurized system! Before disconnecting the couplers, you must: -lower the connected attachments, -stop the engine, -move the control levers forward and backward to discharge pressure from the hydraulic system. Failure to comply could result in death or serious injury.

  • Page 111: Rear Power Take-Off (Pto)

    6 - WORKING OPERATIONS REAR POWER TAKE-OFF (PTO) Power take off (PTO) The power take-off fitted on the tractor is used to transfer power from the engine directly to the implement. It can be controlled directly by the engine, or by the tractor's transmission. All tractors are fitted as standard with an independent power take-off at 540 ...
  • Page 112 6 - WORKING OPERATIONS 540/1000      RPM Power Take-Off speed Speed selection by changing output shaft Passing from one speed to the other takes place automatically by simply replacing the splined output shaft (2); • the speed of 540      RPM is obtained by fitting the 1 3/8      " output shaft with 6 splines;...

  • Page 113: Front Power Take-Off (Pto)

    6 - WORKING OPERATIONS FRONT POWER TAKE-OFF (PTO) Front Power Take-Off (PTO) - Safety rules WARNING Entanglement hazard! The Power Take-Off (PTO) guard must be installed when operating PTO-driven equipment. Failure to comply could result in death or serious injury. W0322A WARNING Entanglement hazard!

  • Page 114: Front Power Take-Off (Pto) - Operating

    6 - WORKING OPERATIONS Front Power Take-Off (PTO) - Operating The front Power Take-Off (PTO) transfers engine power directly to front mounted equipment via a 6 spline shaft. The PTO shaft rotates anti-clockwise (as viewed from the front) When the power take−off is not in use, always fit the safety cover (1) on the splined output shaft as shown in the fig- ure.

  • Page 115: Rear Hydraulic Lift

    6 - WORKING OPERATIONS REAR HYDRAULIC LIFT Hydraulic lift with mechanical control Draft control The hydraulic lift system uses the transmission oil, which is supplied by a gear pump driven by the engine timing Move position control lever (1) fully forward; gears.

  • Page 116: Lift-O-Matic® Control - Operating

    6 - WORKING OPERATIONS Lift-O-Matic® control - Operating The lever (1) is used to position the implement in an infi- nite number of positions. In both the lowering and raising phases, the implement stops at the height corresponding to the position where the lever is stopped. Lifting •...
  • Page 117 6 - WORKING OPERATIONS Adjusting the height limit of lift arm travel To achieve full lift height, turn the adjuster (1) fully anti- clockwise until the cam (2) is clear of the lever (3). MOIL13TR00375AA To adjust the upward travel of the implement, follow these guidelines: 1.

  • Page 118: Hydraulic Lift With Electronic Control

    6 - WORKING OPERATIONS Hydraulic lift with electronic control WARNING Crushing hazard! The lifting systems must be operated by qualified personnel who are aware of the correct procedures to follow. Make sure all lifting equipment is in good condition, and all hooks are equipped with safety latches.
  • Page 119 6 - WORKING OPERATIONS Inside controls The setting controls for the electronically controlled hy- draulic lift are located to the right of the driving seat (see page 33) and consist of four knobs: Lift controls 1 Height limit adjustment control. •...
  • Page 120 6 - WORKING OPERATIONS Lower arms up/down control knob The up/down movement of the arms is controlled by knob (1). Turn the knob clockwise to raise the arms or anti- clockwise to lower them. To the left of the knob (1) there is an indicator light: •...

  • Page 121: Position Control

    6 - WORKING OPERATIONS DANGER Crushing hazard! Activate external hydraulic control switches only while standing to the side of the machine (outboard of the rear tires). DO NOT climb on the implement or between the implement and the machine when the external hydraulic controls are enabled.
  • Page 122 6 - WORKING OPERATIONS Draft Control To work in draft control mode, set the position/draft sensi- tivity knob (1) to an intermediate position, bearing in mind that by turning it clockwise the frequency and extent of corrective interventions caused by tractor draft variations on the implement will increase.

  • Page 123: Front Hydraulic Lift

    6 - WORKING OPERATIONS FRONT HYDRAULIC LIFT Hydraulic lift with mechanical control The front lift works with the transmission oil. It is operated by one of the rear mount remote valves illustrated in the figure. NOTE: If hydraulic stabilizer struts are installed, the lift can be connected to the distributor (1) or (2).
  • Page 124 6 - WORKING OPERATIONS Operation Version with mechanically controls lift The lift works in position control. It is operated with one of the two levers (1) or (2) that command the rear distributors with the "DIVERTER" function, that is to say by pressing the button (3).

  • Page 125: Hydraulic Lift With Electronic Control

    6 - WORKING OPERATIONS Hydraulic lift with electronic control WARNING Crushing hazard! The lifting systems must be operated by qualified personnel who are aware of the correct procedures to follow. Make sure all lifting equipment is in good condition, and all hooks are equipped with safety latches.
  • Page 126 6 - WORKING OPERATIONS Controls The two potentiometers (1) and (2) fig. 3, situated on the left-hand side of the dashboard (instrument cluster), enable regulating the lifting limit and the work position. The switch (1) fig. 4, on the right-hand side, enables lifting and lowering the implement.

  • Page 127: Rear 3-Point Hitch

    6 - WORKING OPERATIONS REAR 3-POINT HITCH Operating Instructions Adjustable top link The top link (1) can be connected to the support bracket by means of the two holes. Select the most suitable hole for attaching the implement. NOTE: When inserting the top link pivot pin (3) position it so that the safety pin enters in its safety hole as shown in the figure.
  • Page 128 6 - WORKING OPERATIONS Hydraulic adjustment of the right-hand lift rod (on request) The right-hand lift rod (2) fig. 2 is available with hydraulic adjustment using the specific switch • Press the switch (1) into position (A) to raise the rod; •...
  • Page 129 6 - WORKING OPERATIONS Adjust the lateral stabiliser struts (1) fig. 5, so that the lateral movement of the lower arms (1) does not exceed 12      cm (4.72      in)12 cm per side. It is possible to set the float mode of the lower lift arms (1) by rotating the pins (2) into a vertical position, so as to allow them to swing freely inside the slots (3).
  • Page 130 6 - WORKING OPERATIONS Converting from 1 to 2 category To allow both 1 and 2 category equipment to be used, the three-point linkage has: • a bush with an inside diameter of 19      mm (0.75      in) (1) for category implements, to be inserted in the spherical bushing at the end of the top link;...

  • Page 131: Attach The Implement

    6 - WORKING OPERATIONS Attach the implement With the lower arms fully lowered, adjust the length of the control cables (2), so that they do not drag on the ground when attached to the tractor. Correctly adjust the distance between the lower arm hook ends by tightening or loosening the spacer spring rod (3).
  • Page 132 6 - WORKING OPERATIONS The type of screws and nuts suited to lock the catches (1) are given in the chart. Cat. Hook UNI 5737 screw cl. 8.8 UNI 7473 cl.6S nut M6x40 opt. 7/32” x 1”1/2 M6 opt. 7/32” M6x45 opt.

  • Page 133: Additional Equipment Attachment Points

    M 20 x 2.5 400 - 450      N·m 38      mm (1.50      in) M 20 x 2.5 400 - 450      N·m Dimension T4.75F T4.95F T4.85F T4.105F 75      mm 75      mm 250 ...

  • Page 134: Torque Specifications

    M 20 x 2.5 400 - 450      N·m 35      mm (1.38      in) 400 - 450      N·m M 20 x 2.5 Dimension T4.75F T4.95F T4.85F T4.105F 95      mm 75      mm 70 ...

  • Page 135: Front 3-Point Hitch

    6 - WORKING OPERATIONS FRONT 3-POINT HITCH Operating Instructions A Power take−off shaft B Adjustable top link C Lower lift arms MOIL13TR00968AA With no implements connected It is advised to remove the horizontal arms when using the tractor without front−hitched implements (to avoid knock- ing into obstacles), or when on the public highway.
  • Page 136 6 - WORKING OPERATIONS Third position • Floating position with the lock pin inserted in the hole (4) and the holes (5) and (6) free. In this position the lifting arms are free to move vertically. MOIL13TR00971AA Positions for mounting the hook ends The hook ends (7) and (8) slide and can be secured in six different positions according to the width of the imple- ment.
  • Page 137 6 - WORKING OPERATIONS Quick fit implement linkage Fit the conical pick−up profiles (1) fig. 6 on the implement hitch pins. Move the tractor forward, in position in relation to the im- plement, then raise the lower arms: the implement will be hitched automatically.

  • Page 138: Swinging Drawbars

    6 - WORKING OPERATIONS SWINGING DRAWBARS Safety rules WARNING Collision hazard! During road transport, the drawbar must be locked in the center position, and the implement must be centered behind the tractor. Failure to comply could result in death or serious injury. W0324A WARNING Loss of control hazard!

  • Page 139: Swinging Drawbar

    6 - WORKING OPERATIONS Swinging drawbar Use the swinging drawbar for implements, agricultural machinery and trailers with two axles. Do not use for single−axle trailers as they apply excessive weight to the bar, which will risk tipping the tractor. The device can be supplied: •...

  • Page 140: Wheels And Tires

    6 - WORKING OPERATIONS WHEELS AND TIRES Wheels and tires WARNING Explosion hazard! Tires must be replaced by skilled personnel with the proper tools and technical knowledge. Unskilled personnel replacing wheels or tires could result in serious physical injuries, tire damage, and/or wheel distortion.
  • Page 141 6 - WORKING OPERATIONS Tire marking To indicate, dimensions, structure and specifications of use of a tire, the manufacturers have internationally adopted standard abbreviations and numbers. The draw- ing shows an example of the marking on a tire used for agricultural work.
  • Page 142 6 - WORKING OPERATIONS LOAD INDEX The loading index (IC) is a numerical index indicating the maximum permissible load on the tire, for the speed indicated by the relevant speed code, under the conditions specified by the manufacturer. Loading index per wheel • ...
  • Page 143 6 - WORKING OPERATIONS INFLATION PRESSURES For safe and long-lasting tire use, the following instructions must be closely observed. • Use the correct pressures for each axle and for the type of use planned. • Ensure tire pressures are not lower than the correct val- ues, to prevent overheating of the tires, which can lead - tire bursting;...

  • Page 144: Tyre Dimensions

    6 - WORKING OPERATIONS Tyre dimensions 2WD FRONT TIRES Tires Index radius Code 6.50 - 16 4.50E x 16 — 7.00 - 12 4.25 x 12 7.50 - 16 5.50F x 16 11L-15 F3 W8 x 15 4WD FRONT TIRES Tires Code Index radius...
  • Page 145 6 - WORKING OPERATIONS TIRE COMBINATIONS RECOMMENDED COMBINATIONS FOR 2WD MODELS Pressure bar Front tires Rear tires Front Rear 380/70 R 28 420/70 R 24 13.6 R 28 - 340/85 R 28 6.50 - 16 380/70 R 24 12.4 R 28 - 320/85 R 28 2.5 ...

  • Page 146: Wheel Track Adjustment

    6 - WORKING OPERATIONS WHEEL TRACK ADJUSTMENT Wheel tread settings Front 2WD wheel track adjustment To adjust the front wheel track, proceed as follows: • Raise the front of the tractor using a jack positioned in the middle of the axle; •...
  • Page 147 6 - WORKING OPERATIONS Wheel track adjustment front 4WD and rear 2/4WD You can fit the wheel disk with the camber directed in- wards or outwards. Each of these two disk positions provides a different track width, as shown on the following pages. When adjusting the wheel track, ensure that the points of the tire treads are still facing in the direction of forward travel, indicated by an arrow on the tire walls.
  • Page 148 6 - WORKING OPERATIONS Steering angle adjustment When using the narrowest tracks, the tires may touch the tractor body when the steered wheels are at full lock and the front axle is at maximum pivot position. To avoid this problem, the steering angle can be adjusted by means of screw (1) fig.

  • Page 149: Tire Combinations And Tread Positions

    6 - WORKING OPERATIONS Tire Combinations and Tread Positions 2WD FRONT WHEEL TRACKS DCSPFNEGB060S3A Tire 6.50 - 16 1146      mm (45.1      in) 1246      mm (49.1      in) 1346      mm (53.0      in) 1446 ...
  • Page 150 6 - WORKING OPERATIONS 4WD FRONT WHEEL TRACKS DCSPFNEGB048S3F TIRES 1157      mm 1255      mm 1355      mm 1189      mm 1289      mm 1387      mm 1487      mm 260/70 R 20 (45.6 ...
  • Page 151 6 - WORKING OPERATIONS 2/4WD REAR WHEEL TRACKS DCUTDNEGB075S3F TIRES 1108      mm 1280      mm 1316      mm 1332      mm 1368      mm — — — 380/70 R 20 (43.6      in) (50.4 ...

  • Page 152: Ballast

    6 - WORKING OPERATIONS BALLAST Ballast WARNING Crushing hazard! Counterweights are very heavy. Always use certified lifting equipment to remove and install the coun- terweights. Make sure the hardware securing the counterweight(s) to the machine is installed correctly and the clamp bolts are tightened fully before operating the machine. Failure to comply could result in death or serious injury.
  • Page 153 6 - WORKING OPERATIONS Rear axle ballasting 4 cast iron rings, of the weight of 50      kg (110.23      lb) each, for 28” and 30” tyres. NOTICE: Periodically check the tightness of the front and rear ballast locking bolts. DCSPVEGB009S5F 6-55...
  • Page 154 6 - WORKING OPERATIONS 6-56...

  • Page 155: Maintenance

    7 - MAINTENANCE MAINTENANCE###_7_### GENERAL INFORMATION General safety before you service DANGER Improper operation or service of this machine can result in an accident. Do not operate this machine or perform any lubrication, maintenance, or repair on it until you have read and understood the operation, lubrication, maintenance, and repair information.
  • Page 156 7 - MAINTENANCE WARNING Improper operation or service of this machine can result in an accident. If you do not understand a maintenance procedure, or doubt your ability to perform a maintenance procedure correctly, see your authorized dealer. Failure to comply could result in death or serious injury. W0157A WARNING Personal Protective Equipment (PPE) required.

  • Page 157: Introduction

    7 - MAINTENANCE Introduction This section gives full details of the maintenance procedures required to keep the tractor in conditions of maximum efficiency. The lubrication and maintenance table provides rapid reference for this purpose. Maintenance frequency The service intervals at set times, given in this section, apply when the tractor is used under normal and not harsh conditions.

  • Page 158: Various Controls

    7 - MAINTENANCE Various controls Tires Check the following components regularly and, if any faults are detected, contact your dealer and replace the Always fit and remove tyres in perfectly clean conditions. damaged parts as necessary: Avoid working on the ground. •...

  • Page 159: Body Maintenance

    Body maintenance Protection against atmospheric agents Over the years, NEW HOLLAND have introduced a series of measures to protect the tractor from the deterioration and corrosion which can be caused by various external elements, such as those listed below: • salinity and atmospheric humidity •...
  • Page 160 7 - MAINTENANCE It is good practice to protect the paint by polishing it with specialised products (silicone waxes) from time to time and, when the paint starts to dull, you can use wax polish which has a slight abrasive action. Cab maintenance •...

  • Page 161: Break-In Period

    7 - MAINTENANCE Break-in period During the running-in period (approximately 50 hours of • front ballast retaining bolts; work), in addition to carrying out the operations indicated • front wheel toe-in and steering limiters; in this section for “Lubrication and Maintenance” after •...

  • Page 162: Fuel Supply

    7 - MAINTENANCE Fuel supply WARNING Fire hazard! When handling diesel fuel, observe the following precautions: 1. Do not smoke. 2. Never fill the tank when the engine is running. 3. Wipe up spilled fuel immediately. Failure to comply could result in death or serious injury. W0099A Fuel specifications Refuelling...

  • Page 163: General Specification - Biodiesel Fuels

    NOTICE: It is imperative that you check which blend is ap- filter life. In cold weather, this is more likely to happen. proved for your engine with your NEW HOLLAND dealer. Consult your NEW HOLLAND dealer for information on Be aware that the use of Biodiesel Fuel that does not...

  • Page 164: Opening The Hood

    7 - MAINTENANCE Opening the hood To access the engine components and carry out inspec- tion, lubrication and maintenance operations, the bonnet must be opened (1). The following instructions describe the procedure to be followed. The hood is hinged at the rear to allow easy and safe access to the various engine components.

  • Page 165: Fluids And Lubricants

    Fuel tank: 20.34 Decanted, filtered Reduced fuel tank: 17.70 diesel fuel Engine oil sump: NH330H 2.25 NEW HOLLAND T4.75F - T4.85F SAE 15W40 API CH-4 AMBRA NH324H ACEA E7/E5 Engine oil sump: MASTERGOLD HSP 2.51 SAE 10W30 T4.95F - T4.105F Brakes circuit 0.13...

  • Page 166: Engine Oil

    7 - MAINTENANCE Engine Oil The correct degree of engine oil viscosity depends on the environment temperature. Refer to the chart on the right when selecting the oil grade for your tractor engine. NOTE: In areas where prolonged periods of extreme tem- peratures are encountered, local lubrication practices are acceptable.

  • Page 167: Maintenance Chart

    7 - MAINTENANCE MAINTENANCE CHART Maintenance Chart Replace Change fluid Grease Filling Drain fluid Tighten Cleaning Adjust Level make up Check Interval Page Maintenance action pts. 7-15 Radiator expansion tank AS REQUIRED 7-15 Windscreen washer tank 7-15 Road light 7-16 Clutch pedal adjustment 7-16 Parking brake or parking lock...
  • Page 168 7 - MAINTENANCE Replace Change fluid Grease Filling Drain fluid Tighten Cleaning Adjust Level make up Check Interval Page Maintenance action pts. EVERY 1200 7-38 Cab air filters HOURS OR 7-38 Cab recirculated air filter ANNUALLY 7-38 Engine air filters 7-39 Fuel tank EVERY 1200...

  • Page 169: As Required

    7 - MAINTENANCE AS REQUIRED Radiator expansion tank 1. The level must always be above the “ MAX ” mark on the tank. If necessary, top up to reach the correct level through the cap (1). MOIL13TR00948AA Windscreen washer tank 1.

  • Page 170: Clutch Pedal Adjustment

    7 - MAINTENANCE Clutch pedal adjustment Manual versions 1. If the pedal position becomes uncomfortable (too high) or it will not reach its upper rest position (to prevent the clutch slipping), check that distance (A) on pedal (1) is 150      mm (5.91      in) for tractors without cabs, or 162 ...

  • Page 171: Tyre Pressure

    7 - MAINTENANCE Tyre pressure 1. Connect a pressure gauge to the pressure relief valve and check it is as prescribed. Check and adjust the front and rear tire pressures. Inspect the tread and sidewalls for damage. Adjust the tire pressures to suit the load being carried.

  • Page 172: Wheel Nuts Torque

    7 - MAINTENANCE Wheel nuts torque 1. Check the front and rear wheel nuts for tightness using a torque wrench (with a torque multiplier, where neces- sary). Always make sure that the front and rear wheels are symmetrically aligned in relation to the longitudinal axis of the tractor.

  • Page 173: At Warning Message Display

    7 - MAINTENANCE AT WARNING MESSAGE DISPLAY Engine air filters NOTE: When the warning light air filter blocked on the control panel illuminates, check for filter clogging. Replace the external cartridge every year or when cracks appear (visible by placing a light inside). Air filter discharge valve 1.

  • Page 174: Fuel Filter Water Drain

    If the indicator stays on, replace the filter even if it has not yet reached the time for it to be changed. • Figure 1, models T4.75F and T4.85F • Figure 2, models T4.95F and T4.105F MOIL13TR00640AA...

  • Page 175: Brake Fluid Level

    7 - MAINTENANCE Brake fluid level 1. Check that the fluid level never drops below the point marked (MIN) by the arrow on the reservoir. NOTICE: Illumination of the warning light on the control panel, indicates that the oil level in the reservoir is below the “MIN”...

  • Page 176: Every 10 Hours Or Each Day

    7 - MAINTENANCE EVERY 10 HOURS OR EACH DAY Engine oil level 1. Check the level with the engine on a flat surface with the engine switched off. Allow at least five minutes for the oil to settle in the sump: •...

  • Page 177: Every 50 Hours

    When working in particularly dusty or boggy environ- ments, the operation must be carried out frequently to expel any dust or water that has entered. MOIL13TR00643AA Lift and linkage 1. Using a grease gun, pump NEW HOLLAND A MBRA GR-9 M grease into the lubrica- ULTI PURPOSE GREASE tion fitting shown.

  • Page 178: 4Wd Steering Cylinders

    7 - MAINTENANCE 4WD steering cylinders 1. Using a grease gun, pump NEW HOLLAND A MBRA GR-9 M grease into the grease ULTI PURPOSE GREASE fittings shown (one on each side). DCSPFNEGB026S7A 2WD front axle pivot 1. Using a grease gun, pump NEW HOLLAND A...

  • Page 179: 4Wd Transmission Shaft

    7 - MAINTENANCE 4WD transmission shaft 1. Using a grease gun, pump NEW HOLLAND A MBRA GR-9 M grease into the lubricat- ULTI PURPOSE GREASE ing nipples shown. MOIL13TR00806AA 2WD right and left-hand stub axle 1. Using a grease gun, pump NEW HOLLAND A...

  • Page 180: Front Pto Coupling

    7 - MAINTENANCE Front PTO coupling 1. Using a grease gun, pump NEW HOLLAND A MBRA GR-9 M grease into the five lu- ULTI PURPOSE GREASE bricating nipples shown, located in front of the radiator. MOIL13TR00815AA 7-26...

  • Page 181: Every 100 Hours

    7 - MAINTENANCE EVERY 100 HOURS Transmission oil cooler 1. Check no dirt has accumulated on the fins and that they are not obstructed. If cleaning is necessary, release the catch (1), take out the cooler (2), and clean it as follows: Remove the protective mesh on the cooler and direct the jet of air or water through each fin, from the back to the front.

  • Page 182: Cab Air Filter

    7 - MAINTENANCE Cab air filter 1. Open the wire mesh guards (3), extract the cartridges (2) and clean them: by tapping gently on a flat surface with the outward− facing part downwards; with a jet of compressed air at a pressure of less than 6.9 ...

  • Page 183: Every 300 Hours

    Ensure that the belt is correctly located on the pulleys and that the belt tensioner is oper- ating correctly. A. T4.75F - T4.85F B. T4.95F - T4.105F MOIL13TR00656AA Transmission oil filter 1.

  • Page 184: Engine Air Filters

    7 - MAINTENANCE Engine air filters 1. Remove the cover (1), extract the external cartridge (2) and clean (see operation described on 7-19). NOTICE: The internal safety cartridge must never be cleaned or removed when cleaning the external cartridge, but it must be changed every three times the external cartridge (2) is cleaned.

  • Page 185: 4Wd Front Axle Final Drives

    If oil does not come out of the plug, top up through the plug hole. NOTICE: for quantity and type see "Refuelling table" in this section. DCSPFNEGB072S4A 4WD front axles stub 1. Inject NEW HOLLAND A GR-9 M MBRA ULTI PURPOSE grease in the two nipples shown (two on each GREASE side).

  • Page 186: Every 500 Hours

    EVERY 500 HOURS Engine oil and filter T4.75F — T4.85F NOTE: This operation describes the process of draining oil from the engine sump and changing the relevant oil filter. The frequency of 500 hours can anyhow be affected by other factors: Cold temperature operation Engines operating in temperatures below -12 ...

  • Page 187: Fuel Filter

    7 - MAINTENANCE Fuel filter T4.75F — T4.85F NOTICE: Before loosening or removing any components of the injection system carefully clean the area around the components involved in the maintenance work to prevent contaminating the system. To change the filter, proceed as follows: •...

  • Page 188: Fuel Pre-Filter

    7 - MAINTENANCE Fuel pre-filter T4.75F — T4.85F 1. Check periodically to ensure that the filter container (2) is clean. If it needs cleaning, proceed as follows; • First detach pipe (4) from the fuel tank and then pipe (1);...

  • Page 189: Every 600 Hours

    7 - MAINTENANCE EVERY 600 HOURS Engine oil and filter T4.95F — T4.105F NOTE: This operation describes the procedures for draining oil from the engine sump and changing the relevant oil filter. The frequency of 600 hours can anyhow be affected by other factors: Cold temperature operation Engines operating in temperatures below -12 ...

  • Page 190: Fuel Filter

    7 - MAINTENANCE Fuel filter T4.95F — T4.105F NOTICE: Before loosening or removing parts of the injection system, thoroughly clean the area surrounding the com- ponents involved in the maintenance work in order to avoid contaminating the system. To change the filter, proceed as follows: •...

  • Page 191: Fuel Pre-Filter

    7 - MAINTENANCE Fuel pre-filter T4.95F — T4.105F 1. Check periodically to ensure that the filter container (2) is clean. If it needs cleaning, proceed as follows; • first detach the pipe (4) from the fuel tank, then the pipe (1); •...

  • Page 192: Every 1200 Hours Or Annually

    7 - MAINTENANCE EVERY 1200 HOURS OR ANNUALLY Cab air filters 1. Remove the grilles (3), one on each side, and replace the internal cartridges (2). Before fitting new cartridges, clean the seats (1) with a damp cloth. NOTE: In this phase it is necessary to replace the active carbon filters too.

  • Page 193: Fuel Tank

    7 - MAINTENANCE Fuel tank 1. With the tractor on a level surface and the engine off, drain the fuel as described below: • place a container under the tank; • remove the plug and drain the fuel to eliminate any impurities in the tank.

  • Page 194: Every 1200 Hours Or Every 2 Years

    7 - MAINTENANCE EVERY 1200 HOURS OR EVERY 2 YEARS 4WD front axle housing 1. Place a container under the axle housing, unscrew the screw (2), and let all of the oil drain out. Fill up with new oil through the plug (1). NOTICE: for quantity and type see "Refuelling table"...

  • Page 195: Change Transmission Oil

    7 - MAINTENANCE Change transmission oil Transmission housing 1. Place a container under the plug holes (1) and (2) and drain off the oil. MOIL13TR00682AA Lift torsion bar 2. Place a container under the drive gear housing and drain off the oil through the plug hole (1). MOIL13TR00683AA Drive gear, 4−wheel drive 3.

  • Page 196: Washing Cooling System

    7 - MAINTENANCE Washing cooling system CAUTION Burn hazard! Hot coolant can spray out if you remove the filler cap while the system is hot. After the system has cooled, turn the filler cap to the first notch and wait for all pressure to release before proceeding. Failure to comply could result in minor or moderate injury.
  • Page 197 7 - MAINTENANCE Flushing the system (models without cab) WARNING Hot surface possible! Wait for all components to cool before per- forming any operation. Failure to comply could result in death or serious injury. W0251A Flush at least every 1200 hours of work or every 2 years and whenever switching from or to the anti-freeze mix- ture.
  • Page 198 7 - MAINTENANCE Flushing the system (models with cab) 4. The heating system uses fluid from the engine cooling system drawn off between the engine and the radiator. Flush the system as described for models without a cab, bearing in mind that the system can be completely drained by turning temperature adjustment control (1), fig.

  • Page 199: Every 1800 Hours

    7 - MAINTENANCE EVERY 1800 HOURS Fuel injectors - Check 1. Have your local dealer check the pressure settings. To remove from the engine, detach the lines and remove the connectors. NOTE: Before loosening or disconnecting any part of the injection system, thoroughly clean the area in which you are going to work.

  • Page 200: Electrical System

    7 - MAINTENANCE ELECTRICAL SYSTEM Battery WARNING Explosive gas! Batteries emit explosive hydrogen gas and other fumes while charging. Ventilate the charging area. Keep the battery away from sparks, open flames, and other ignition sources. Never charge a frozen battery. Failure to comply could result in death or serious injury.
  • Page 201 7 - MAINTENANCE NOTE: Batteries and storage batteries contain components that may be damaging to the environment if incorrectly disposed of after use. The manufacturer strongly advises that all “dry” batteries, used in electrical or electronic sys- tems, are returned to your local dealer. The dealer will dispose of (or recycle) the batteries correctly. This procedure is requested by law in certain countries.

  • Page 202: Fuses And Relays

    7 - MAINTENANCE Fuses and relays 12−way fusebox and relays 1. On all models, the 12−way fuse box (1) is located on the left−hand side of the central console, beneath the steering wheel. NOTE: When replacing a blown fuse, make sure that the new fuse has the same amp value.

  • Page 203: Fuses And Relays Location

    7 - MAINTENANCE Fuses and relays location Model without cab MOIL13TR00724FA NOTICE: Depending on your version some components described below might not be present. Fuses Ref. Fuse Protected circuits 10      A Horn, driving beam flashing 15      A Turn and hazard lights.
  • Page 204 7 - MAINTENANCE Ref. Fuse Protected circuits 10      A Circuit for right-hand tie rod control. 10      A Ventral control valves 5      A Battery cut-out circuit 10      A Rotating beacon 5      A Rear work lights circuit.

  • Page 205: Fuses And Relays Location

    7 - MAINTENANCE Fuses and relays location Model with cab MOIL13TR00725FA NOTICE: Depending on your version some components described below might not be present. Fuses Ref. Fuse Protected circuits 10      A Horn, driving beam flashing 15      A Turn and hazard lights.
  • Page 206 7 - MAINTENANCE Ref. Fuse Protected circuits 10      A Circuit for right-hand tie rod control. 25      A Ventral control valves 5      A Battery cut-out circuit 7.5      A Ventral control valves 5      A Ventral control valves 7.5 ...

  • Page 207: Fuses And Relays Location Fuses And Relays On Cab Right Hand Upright

    7 - MAINTENANCE Fuses and relays location Fuses and relays on cab right hand upright Cab relays 1. Front lights circuit. 2. Conditioner fan circuit. 3. Compressor circuit. 4. Rear lights circuit. DCSPVNEGB069S7B Fuses Pos. Fuse Protected circuits 15      A Front work lights.

  • Page 208: Headlight - Replace

    7 - MAINTENANCE MOIL13TR00695AA Headlight - Replace NOTE: When handling halogen bulbs, only touch the metal parts, never the bulb. If the bulb comes into contact with your fingers, the intensity of the light emitted will be reduced, adversely affecting its service life. In the event of contact, clean the bulb with a cloth soaked in alcohol and leave to dry.

  • Page 209: Tractor Storage

    7 - MAINTENANCE STORAGE Tractor storage NOTE: Take the following precautions if your tractor is going to remain unused for a prolonged period. Protect the engine as follows: • For storage periods of approx. one month: no steps are necessary if the engine oil has not yet exceeded 100 hours of work.

  • Page 210: Dual Command Calibration

    7 - MAINTENANCE CALIBRATIONS Dual command calibration WARNING Unexpected machine movement! The machine could move automatically during calibration. Park on a flat surface, engage the parking brake, and be sure that the area around the machine is clear before starting the calibration process. Failure to comply could result in death or serious injury.
  • Page 211 7 - MAINTENANCE 4. Press and release the arrow (1) fig. 4 or the push−but- ton (2) LO fig. 5. The display on the right will show a cursor shortly followed by the letter corresponding to the clutch involved in the setting with a three−digit num- ber that increases MOIL13TR00710AA 5.
  • Page 212 7 - MAINTENANCE LIST OF ERROR CODES “U” ELECTROHYDRAULIC TRANSMISSIONS U CODE MEANING Seat switch not activated. Correct start−up procedure was not used. Transmission oil temperature low (Below 10      °C (50.0      °F). Handbrake is not set. Engine RPM below 1150, increase throttle.

  • Page 213: Troubleshooting

    8 - TROUBLESHOOTING TROUBLESHOOTING###_8_### FAULT CODE RESOLUTION Display fault codes Indicator Audible Fault code Symbol Function (Amber) warning 14001 Rear PTO short to VCC 14002 Rear PTO short to GND Engine speed sensor short to VCC or open circuit 14011 Engine speed sensor short to GND 14012 5 V supply voltage too high...
  • Page 214 8 - TROUBLESHOOTING Indicator Audible Symbol Fault code Function (Amber) warning 14094 Seat switch short to GND 14101 Fuel contaminated sensor Not connected Alternator lamp not working 14103 Front PTO present but not configured 14106 14107 Front Hitch present but not configured 14108 Rear PTO sensor present but not configured 14201...

  • Page 215: Troubleshooting Engine

    8 - TROUBLESHOOTING TROUBLESHOOTING ENGINE WARNING Avoid injury! Always do the following before lubricating, maintaining, or servicing the machine. 1. Disengage all drives. 2. Engage parking brake. 3. Lower all attachments to the ground, or raise and engage all safety locks. 4.
  • Page 216 8 - TROUBLESHOOTING Problem Possible Cause Correction Engine overheating Radiator core clogged Clean radiator Engine overload Change to lower gear or reduce load Engine oil level low Top up fluid level Coolant level low Top up fluid level in expansion tank. Check system for leaks Radiator cap defective Replace cap...

  • Page 217: Electrical System - Troubleshooting Electrical System

    8 - TROUBLESHOOTING Electrical system - Troubleshooting ELECTRICAL SYSTEM Problem Possible Cause Correction The electrical system Battery terminals loose or corroded Clean and tighten terminals does not work Battery Check that battery charge is at least 12.6      V. Check electrolyte level and specific gravity Batteries not charging Terminals loose or corroded...

  • Page 218: Hydraulic Systems - Troubleshooting Hydraulic System

    8 - TROUBLESHOOTING Hydraulic systems - Troubleshooting HYDRAULIC SYSTEM Problem Possible Cause Correction The hydraulic system is Oil level low Top up system not working properly Hydraulic filter clogged Replace hydraulic filter Hydraulic system fault Call your Dealer Hydraulic fluid Fluid level too high or low Top up oil overheating...

  • Page 219: Rear Three-Point Hitch - Troubleshooting Hydraulic Lift And 3−Point Linkage

    8 - TROUBLESHOOTING Rear three-point hitch - Troubleshooting HYDRAULIC LIFT AND 3−POINT LINKAGE Problem Possible Cause Correction The linkage does not Linkage cylinder tubes not connected cor- Connect linkage cylinder tubes correctly move when the control rectly lever is actuated Linkage overload Reduce load Implement does not raise...

  • Page 220: Hydraulic Service Brakes - Troubleshooting

    8 - TROUBLESHOOTING Hydraulic service brakes - Troubleshooting Problem Possible Cause Correction Air in the braking system Pedals soft when engine Call your Dealer Pedal depresses fully with Brake piston seals leaking Call your Dealer engine off Brake discs worn Call your Dealer Brake release leaking Call your Dealer...

  • Page 221: Cab Climate Control - Troubleshooting

    8 - TROUBLESHOOTING Cab climate control - Troubleshooting Problem Possible Cause Correction Dust in cab Filter seal ineffective Check condition of filter seal Filter clogged Clean or replace filter Filter defective Replace filter Excessive air draughts Block draughts Poor recirculation air Filter clogged or air circulation filter clogged Clean or replace filter(s) Heater or humidifier radiator core clogged Call your Dealer Air−conditioning not...

  • Page 222: Alarms

    8 - TROUBLESHOOTING ALARM(S) Alarms The following tables show: • Start of activation of each single warning signalled on the performance display. • How each single operating fault is signalled to the op- erator. • Possible action to remove the trouble. Indicator Symbol lamp...
  • Page 223 8 - TROUBLESHOOTING Indicator Symbol lamp Audible Fault Meaning shown on associated Amber warning the display on the indicator indicator instrumen lamp lamp Brake fluid level too low Transmission oil temperature too high Fuel contaminated Battery voltage too high Module configuration 20/1 Module configuration 20/2...

  • Page 224: Alarms, Cause, Solutions

    8 - TROUBLESHOOTING Alarms, cause, solutions Fault POSSIBLE CAUSE SOLUTION The audible warning comes on with the related Engage the handbrake. The signal must stop. icon on the display when the operator leaves the driving seat without engaging the handbrake or with the seat safety switch broken.
  • Page 225 8 - TROUBLESHOOTING Fault POSSIBLE CAUSE SOLUTION The signal for the trouble is activated when the Top up the brake fluid level and check the oil level falls under the minimum or with the level level sensor works properly as described in sensor broken.
  • Page 226 8 - TROUBLESHOOTING 8-14...

  • Page 227: Specifications

    9 - SPECIFICATIONS SPECIFICATIONS###_9_### Dimensions and weights DCSPVNEGB001S9F Dimensions of 2WD models without cab T4.75F - T4.95F - Dimensions T4.85F T4.105F 2082.5      mm 2169.5      mm (82.0      in) (85.4      in) 3682      mm 3769 ...
  • Page 228 9 - SPECIFICATIONS DCSPVNEGB003S9F Dimensions of 4WD models without cab T4.75F - T4.95F - Dimensions T4.85F T4.105F 2348      mm 2435      mm (92.4      in) (95.9      in) 3947.5      mm 4034.5      mm (155.4 ...
  • Page 229 9 - SPECIFICATIONS DCSPVNEGB002S9F Dimensions of 2WD models with cab T4.75F - T4.95F - Dimensions T4.85F T4.105F 2161 - 2311      mm (85.1 - 91.0      in) 2082.5      mm 2169.5      mm (82.0      in) (85.4 ...
  • Page 230 9 - SPECIFICATIONS DCSPVNEGB004S9F Dimensions of 4WD models with cab T4.75F - T4.95F - Dimensions T4.85F T4.105F 2161 - 2311      mm (85.1 - 91.0      in) 2348      mm 2435      mm (92.4      in) (95.9 ...

  • Page 231: Rear Ballast

    32      kg (70.5      lb) Max. 6 rings WEIGHTS OF 2WD TRACTORS WITHOUT CAB WITHOUT BALLAST WEIGHTS T4.75F ● T4.85F 2762      kg (6089.2      lb) 2842      kg (6265.5      lb) T4.95F ● T4.105F WEIGHTS OF 4WD TRACTORS WITHOUT CAB WITHOUT BALLAST WEIGHTS 2832 ...

  • Page 232: Maximum Permitted Loads On Front And Rear Axle

    9 - SPECIFICATIONS Maximum permitted loads on front and rear axle WARNING Overturning hazard! The operator must know the correct OPERATING LOAD capacity of the machine before attempting to operate the machine. Always follow the recommended load limits. Failure to comply could result in death or serious injury. W0216A NOTICE: The total weight of the tractor, including the ballast and the weight of the implements carried, must not exceed the limits given in the table below.

  • Page 233: Maximum Permitted Loads On Drawbar

    9 - SPECIFICATIONS Maximum permitted loads on drawbar The maximum vertical load of the drawbar is given in the table below: Bar model Maximum vertical load 694.142.001 490      kg (1080      lb) CUNA-type drawbar — For the ITALIAN market only Vertical loading is not permissible.

  • Page 234: Technical Data

    COOLING Water, forced circulation by centrifugal pump Radiator with 3 lines of vertical copper pipes for T4.75F - T4.85F models and 4 lines of vertical copper pipes for mod. T4.95F - T4.105F. Cooling fan fitted on same shaft as water pump.
  • Page 235 9 - SPECIFICATIONS COOLING Water circulation from engine to radiator thermostatically controlled. TRANSMISSION Dry 11" double-plate clutch, with separate controls: pedal operation for gearbox and hand lever for power take-off. Plate material - manual transmissions: metal-ceramic Plate material - electro-hydraulic transmissions: organic PTO clutch: metal-ceramic Transmission housing Permanently engaged helical mesh with 4 gear ratios.
  • Page 236 2300      RPM 1032      RPM MECHANICALLY OR ELECTRONICALLY CONTROLLED REAR HYDRAULIC LIFT Oil supply is from the transmission by gear pump operated directly by the engine: NEW HOLLAND TYPE BOSCH TYPE pump speed with engine on full power: 2502      RPM...
  • Page 237 STEERING SYSTEM Hydrostatic control, independent circuit. Metal cartridge oil filter, fitted in oil reservoir. Gear pump operated directly by the engine, through timing gears: Type NEW HOLLAND with mechanical transmissions with electro-hydraulic transmissions A31 XRP2 pump speed with engine on full power: 2502 ...
  • Page 238 BATTERY 12      V - Capacity (amperage) 88/100      A, sealed, maintenance-free. Starter With electromagnet coupling: T4.75F - T4.85F 3.2      kW 4.2      kW T4.95F - T4.105F LIGHTS Two asymmetrical front headlamps using 55      W bulbs (white or yellow) Two front light clusters including: - position lights ( 5 ...
  • Page 239 10 - ACCESSORIES 10 - ACCESSORIES###_10_### Radio MOIL13TR00770FA Power ON/OFF button Press to turn on the radio. Press and hold to turn OFF. Function/volume selection knob Turn the knob (to the right/left) to regulate “VOL/BAS/TRE/BAL/FAD”. To select other functions, press the button until the desired function is shown on the display.
  • Page 240 10 - ACCESSORIES The Reset button is on the housing. The Reset button is to be activated for one of the following reasons: − Initial installation of the unit when all wiring is completed. − None of the buttons function. −...
  • Page 241 10 - ACCESSORIES How to select MP3/WMA files Searching by track number • Press (4) (A/PS) to activate track search. • Turn the volume knob (2) to the left or right to select the first digit desired. • Press the volume knob (2), the first digit is saved and the second one starts blinking. •...
  • Page 242 10 - ACCESSORIES • Turn knob (2) VOL (left/right) to select PLAYLIST – ARTISTS – ALBUMS – SONGS – GENRES – COMPOSER • Press SEL. If you are aware on how to use iPOD, the way to use the vehicle stereo feature is basically just the same. Take note of the equivalent key function below.
  • Page 243 10 - ACCESSORIES 522 - 1620      MHz with RDS Frequency range 522 - 1710      MHz without RDS 10,71      MHz Intermediate frequency 32      dB Sensitivity Radio LW 144 - 290      MHz Frequency range 10,71 ...
  • Page 244 10 - ACCESSORIES 10-6...
  • Page 245 Index ###_Index_### 2WD front axle pivot ........7-24 2WD front wheels .
  • Page 246 Electrohydraulically controlled rear remote control valves ..... . . 6-11 Electrohydraulically controlled side hydraulic valves ......Electrohydraulic differential lock .
  • Page 247 Oil filter models with power shuttle/dual command ......7-29 Opening the hood......... 7-10 Operating Instructions .
  • Page 248 For exact information about any particular product, please consult your New Holland dealer. Your success - Our specialty Copyright © 2013 CNH Europe Holding S.A. All Rights Reserved. New Holland is a registered trademark of CNH Europe Holding S.A. Boulevard Royal, 24 L-2449 Luxembourg.

This manual is also suitable for:

T4.85fT4.95fT4.105f

Table of Contents
