SERVICE MANUAL
T4.75 / T4.85 / T4.95 / T4.105 / T4.115
Tractor
PIN ZDJT13873 and above
Part number 47803847
English
November 2014
© 2014 CNH Industrial Italia S.p.A. All Rights Reserved.

Advertisement

Table of Contents
loading

Related Manuals for New Holland T4.75

Summary of Contents for New Holland T4.75

  • Page 1 SERVICE MANUAL T4.75 / T4.85 / T4.95 / T4.105 / T4.115 Tractor PIN ZDJT13873 and above Part number 47803847 English November 2014 © 2014 CNH Industrial Italia S.p.A. All Rights Reserved.
  • Page 2 [ZxJT0xxxx], T4.115 with cab, with hi-lo transmission [ZxJT0xxxx], T4.115 with cab, with hi-lo transmission, with Supersteer™ front axle [ZxJT0xxxx], T4.75 less cab, with mechanical or power shuttle transmission [ZxJT0xxxx], T4.75 with cab, with mechanical or power shuttle transmission [ZxJT0xxxx], T4.75 with cab, with hi-lo transmission [ZxJT0xxxx], T4.75 with cab, with hi-lo transmission, with Supersteer™...
  • Page 3 Link Product / Engine Product Market Product Engine T4.105 senza cabina, con Australia New Zealand F5DFL413L*A001 trasmissione meccanica o Power Shuttle [ZxJT0xxxx] T4.105 senza cabina, con Asia Pacific F5DFL413L*A001 trasmissione meccanica o Power Shuttle [ZxJT0xxxx] T4.105 senza cabina, con Middle East Africa F5DFL413L*A001 trasmissione meccanica o Power Shuttle [ZxJT0xxxx]...
  • Page 4 Power Shuttle [ZxJT0xxxx] T4.75 senza cabina, con Middle East Africa F5DFL413H*A002 trasmissione meccanica o Power Shuttle [ZxJT0xxxx] T4.75 con cabina, con trasmissione Middle East Africa F5DFL413H*A002 meccanica o Power Shuttle [ZxJT0xxxx] T4.75 con cabina, con trasmissione Europe...
  • Page 5 Product Market Product Engine T4.75 senza cabina, con Asia Pacific F5DFL413H*A002 trasmissione hi-lo [ZxJT0xxxx] T4.75 senza cabina, con Middle East Africa F5DFL413H*A002 trasmissione hi-lo [ZxJT0xxxx] T4.75 senza cabina, con Europe F5DFL413H*A002 trasmissione hi-lo [ZxJT0xxxx] T4.75 senza cabina, con Australia New Zealand F5DFL413H*A002 trasmissione hi-lo [ZxJT0xxxx] T4.85 senza cabina, con...
  • Page 6 Product Market Product Engine T4.85 senza cabina, con Australia New Zealand F5DFL413J*A001 trasmissione hi-lo [ZxJT0xxxx] T4.85 senza cabina, con Europe F5DFL413J*A001 trasmissione hi-lo [ZxJT0xxxx] T4.85 senza cabina, con Asia Pacific F5DFL413J*A001 trasmissione hi-lo [ZxJT0xxxx] T4.85 senza cabina, con Middle East Africa F5DFL413J*A001 trasmissione hi-lo [ZxJT0xxxx] T4.95 senza cabina, con...
  • Page 7 Product Market Product Engine T4.95 senza cabina, con Europe F5DFL413K*A001 trasmissione hi-lo [ZxJT0xxxx] T4.95 senza cabina, con Asia Pacific F5DFL413K*A001 trasmissione hi-lo [ZxJT0xxxx] T4.95 senza cabina, con Middle East Africa F5DFL413K*A001 trasmissione hi-lo [ZxJT0xxxx] T4.95 senza cabina, con Australia New Zealand F5DFL413K*A001 trasmissione hi-lo [ZxJT0xxxx] 47803847 15/12/2014 Find manuals at https://best-manuals.com...
  • Page 8 Contents INTRODUCTION Engine..................10 [10.001] Engine and crankcase ............. 10.1 [10.216] Fuel tanks .
  • Page 9 Front axle system ............... 25 [25.100] Powered front axle ..............25.1 [25.102] Front bevel gear set and differential .
  • Page 10 [35.723] Front loader bucket hydraulic system ..........35.8 Hitches, drawbars, and implement couplings........
  • Page 11 [55.408] Warning indicators, alarms, and instruments ........55.9 [55.DTC] FAULT CODES.
  • Page 12 INTRODUCTION 47803847 15/12/2014...
  • Page 13 Contents INTRODUCTION Advice ................... 3 Note to the Owner WARNINGS FOR AIR CONDITIONING SYSTEM REPAIR OPERATIONS 4 Safety rules SAFETY REGULATIONS .
  • Page 14 Advice IMPORTANT NOTICE All maintenance and repair work described in this manual must be performed exclusively by NEW HOLLAND service technicians, in strict accordance with the instructions given and using any specific tools necessary. Anyone performing the operations described herein without strictly following the instructions is personally responsible for any eventual injury or damage to property.
  • Page 15 INTRODUCTION Note to the Owner WARNINGS FOR AIR CONDITIONING SYSTEM REPAIR OPERATIONS Starting the system at low temperatures can damage the compressor. Only operate the air conditioner when the engine is hot and the temperature inside the cab is at least 20 °C (68.00 °F). When disconnecting the hoses, close the ends with plastic caps to prevent foreign matter and humidity from getting inside the hoses.
  • Page 16 INTRODUCTION Safety rules SAFETY REGULATIONS TO PREVENT ACCIDENTS Most accidents or injuries that occur in workshops are the result of non--observance of simple and fundamental safety regulations. For this reason, IN MOST CASES THESE ACCIDENTS CAN BE AVOIDED: by foreseeing possible causes and con- sequently acting with the necessary caution and care.
  • Page 17 INTRODUCTION • Do not run the engine in confined spaces without suitable ventilation. • Do not smoke, use naked flames, or cause sparks in the area when fuel filling or handling highly inflammable liquids. • Never use naked flames for lighting when working on the machine or checking for leaks. •...
  • Page 18 INTRODUCTION • Never lubricate the vehicle when the engine is running. ELECTRICAL SYSTEMS • If it is necessary to use auxiliary batteries, remember that both ends of the cables must be connected as follows: (+) with (+) and (-) with (-). •...
  • Page 19 INTRODUCTION Personal safety CAB AIR CONDITIONING SYSTEM SAFETY REGULATIONS • The refrigerant must be handled with great care in order to avoid personal injury; always use safety goggles and gloves. • Liquid refrigerant can cause freezing of the skin and serious damage to the eyes, sometimes resulting in permanent blindness.
  • Page 20 INTRODUCTION Basic instructions BATTERY Before commencing any work on the vehicle, always disconnect and isolate the negative lead from the battery, unless otherwise indicated for a specific operation (for example: an operation to be carried out with the engine running), on completion of which the negative lead should be disconnected before proceeding with the work.
  • Page 21 INTRODUCTION NOTICES Wear limit values indicated for certain parts are recommended, but not binding. The terms “front”, “rear”, “right-hand” and “left-hand” (when referred to different parts) are intended as seen from the driving position with the tractor in the normal direction of movement. MOVING THE TRACTOR WITH THE BATTERY REMOVED External power supply cables should only be connected to the respective positive and negative cable terminals, using efficient clamps that guarantee adequate and secure contact.
  • Page 22 INTRODUCTION Special tools NOTES FOR EQUIPMENT The tools that NEW HOLLAND propose and illustrate in this manual are: • specifically researched and designed for use with NEW HOLLAND vehicles; • necessary to make reliable repair; • accurately built and strictly tested to offer efficient and long--lasting working means.
  • Page 23 2 l (0.5 US gal) Water and detergent liquid reservoir Decanted, filtered diesel Fuel tank 115 l (30 US gal) fuel NEW HOLLAND AMBRA API CJ-4 Engine oil 8.5 l (2 US gal) UNITEK MASTERGOLD MAT3521 ACEA E7/E9 SBL CJ-4 SAE 10W-40 NEW HOLLAND AMBRA 0.7 l (0.18 US gal)
  • Page 24 INTRODUCTION Part identification Use solely genuine parts, which guarantee the same quality, duration and safety as the original parts as they are identical to the ones fitted during production. Only genuine parts can offer this guarantee. When ordering spare parts, always provide the following information: •...
  • Page 25 INTRODUCTION 47803847 15/12/2014...
  • Page 26 [ZxJT0xxxx], T4.115 with cab, with hi-lo transmission [ZxJT0xxxx], T4.115 with cab, with hi-lo transmission, with Supersteer™ front axle [ZxJT0xxxx], T4.75 less cab, with mechanical or power shuttle transmission [ZxJT0xxxx], T4.75 with cab, with mechanical or power shuttle transmission [ZxJT0xxxx], T4.75 with cab, with hi-lo transmission [ZxJT0xxxx], T4.75 with cab, with hi-lo transmission, with Supersteer™...
  • Page 27 Contents Engine - 10 [10.001] Engine and crankcase ............. . . 10.1 [10.216] Fuel tanks .
  • Page 28 [ZxJT0xxxx], T4.115 with cab, with hi-lo transmission [ZxJT0xxxx], T4.115 with cab, with hi-lo transmission, with Supersteer™ front axle [ZxJT0xxxx], T4.75 less cab, with mechanical or power shuttle transmission [ZxJT0xxxx], T4.75 with cab, with mechanical or power shuttle transmission [ZxJT0xxxx], T4.75 with cab, with hi-lo transmission [ZxJT0xxxx], T4.75 with cab, with hi-lo transmission, with Supersteer™...
  • Page 29 with cab, with hi-lo transmission [ZxJT0xxxx], T4.85 with cab, with hi-lo transmission, with Supersteer™ front axle [ZxJT0xxxx], T4.85 less cab, with hi-lo transmission [ZxJT0xxxx], T4.95 less cab, with mechanical or power shuttle transmission [ZxJT0xxxx], T4.95 with cab, with mechanical or power shuttle transmission [ZxJT0xxxx], T4.95 with cab, with hi-lo transmission [ZxJT0xxxx], T4.95 with cab, with hi-lo transmission, with Supersteer™...
  • Page 30 47803847 15/12/2014 10.1 [10.001] / 1...
  • Page 31 Contents Engine - 10 Engine and crankcase - 001 SERVICE Engine Remove (*) ................3 Remove (*) .
  • Page 32 T4.115 with cab, with mechanical or power shuttle transmission [ZxJT0xxxx] T4.115 less cab, with mechanical or power shuttle transmission [ZxJT0xxxx] T4.75 with cab, with mechanical or power shuttle transmission [ZxJT0xxxx] T4.75 less cab, with mechanical or power shuttle transmission [ZxJT0xxxx] T4.85 with cab, with mechanical or power shuttle transmission [ZxJT0xxxx]...
  • Page 33 Engine - Engine and crankcase 7. Raise the rear of the tractor with a hydraulic jack. Place a mechanical jack stand under the reduction gear case. Use a pneumatic gun to remove the retaining nuts of the left-hand rear wheel. Then remove the wheel. WLAPL4S10C110A 8.
  • Page 34 Engine - Engine and crankcase 11. Loosen the union of the radiator coolant return line of the cab heater. Drain and collect the engine coolant. WLAPL4S10C116A 12. Place a suitable container under the drain plug (1) for the gearbox-transmission oil. Loosen the plug. Drain the oil.
  • Page 35 Engine - Engine and crankcase 15. Loosen the fixing clamps (1). Extract the tubing from the turbine to the radiator intercooler (2). Perform the same operation for the tubing from the radiator inter- cooler to the engine (3). WLAPL4S10C119A 16. Loosen the clamp (2) that fastens the air intake duct to the turbine.
  • Page 36 Engine - Engine and crankcase 18. Disconnect all of the filter sensors. Loosen the clamp (4). Remove the entire filter together with the sen- sors, pressure sensing tubes, lambda probe, and heat shrouds by undoing the four screws (5) that secure it on the bottom cradle.
  • Page 37 Engine - Engine and crankcase 20. Detach the steering lines (1) and (2) and the tube sup- plying oil to the control valve (3). Remove the fixings of the bracket (4) from the engine. WLAPL4S10C125A 21. Detach the exhaust pipe of the power steering control valve on the gearbox control valve (2).
  • Page 38 Engine - Engine and crankcase 26. On the right-hand side, detach the cab heating pipes (1), the pipe inserted on the engine sleeve (2) coming from the expansion tank. Then loosen the clamps. Detach from the engine the lower (3) and upper rubber sleeves of the radiator–engine connection.
  • Page 39 Engine - Engine and crankcase 33. Hook the rear part of the engine to a hoist using chains or ropes for lifting. (Apply two eyebolts, one to the right-hand side and one to the left-hand side, on the upper part of the flange containing the flywheel.) Po- sition a fixed jack stand (2) under the clutch case (1) near the engine attachment flanging.
  • Page 40 Engine - Engine and crankcase 37. Insert a fixed jack stand (1) under the ballast support. Chock the front wheels with wooden wedges (2). WLAPL4S10C132AA 38. Position a fixed jack stand (3) under the support of the groove (1) of the drive of the front axle, inserting a wooden plug (2) between parts (3) and (1).
  • Page 41 Engine - Engine and crankcase 41. Check that there are no brackets between the engine and the cooling assembly. Detach the engine (2) from the front axle (3). Try to avoid incorrect maneuvers with the hoist in order to not damage the fins of the radiator on the axle with the engine fan (1).
  • Page 42 T4.115 with cab, with hi-lo transmission [ZxJT0xxxx] T4.115 less cab, with hi-lo transmission [ZxJT0xxxx] T4.75 with cab, with hi-lo transmission [ZxJT0xxxx] T4.75 with cab, with hi-lo transmission, with Supersteer™ front axle [ZxJT0xxxx] T4.75 less cab, with hi-lo transmission [ZxJT0xxxx] T4.85 with cab, with hi-lo transmission [ZxJT0xxxx] T4.85 with cab, with hi-lo transmission, with Supersteer™...
  • Page 43 Engine - Engine and crankcase 6. Then detach the lower pipe (3) on the condenser (1). Free the pipe from any straps or clamps. Disconnect the sensor (2) and take it to the cab. WLAPL4S10C107A 7. Raise the rear of the tractor with a hydraulic jack. Place a mechanical jack stand under the reduction gear case.
  • Page 44 Engine - Engine and crankcase 10. Remove the bolts that secure the central support (1) of the drive shaft. Remove the shaft complete with the support. Also remove the shim that adjusts the clearance of the shaft on the back. WLAPL4S10C115AA 11.
  • Page 45 Engine - Engine and crankcase 14. Loosen the fixing clamp (1) to the filter DPF and the support clamp (2). Remove the exhaust pipe (3). MOIL13TR01798AA 15. Loosen the fixing clamps (1). Extract the tubing from the turbine to the radiator intercooler (2). Perform the same operation for the tubing from the radiator inter- cooler to the engine (3).
  • Page 46 Engine - Engine and crankcase A small misalignment of the axis of the decoupler with respect to the axis of the turbine outlet (3) would produce an adjustment that would no longer be lengthwise, in line with the direction of the tractor, but abnormal transversal adjustment that would impair its durability.
  • Page 47 Engine - Engine and crankcase 20. Detach the steering lines (1) and (2) and the tube sup- plying oil to the control valve (3). Remove the fixings of the bracket (4) from the engine. WLAPL4S10C125A 21. Detach the exhaust pipe of the power steering control valve on the gearbox control valve (2).
  • Page 48 Engine - Engine and crankcase 26. On the right-hand side, detach the cab heating pipes (1), the pipe inserted on the engine sleeve (2) coming from the expansion tank. Then loosen the clamps. Detach from the engine the lower (3) and upper rubber sleeves of the radiator–engine connection.
  • Page 49 Engine - Engine and crankcase 33. Hook the rear part of the engine to a hoist using chains or ropes for lifting. (Apply two eyebolts, one to the right-hand side and one to the left-hand side, on the upper part of the flange containing the flywheel.) Po- sition a fixed jack stand (2) under the clutch case (1) near the engine attachment flanging.
  • Page 50 Engine - Engine and crankcase 37. Insert a fixed jack stand (1) under the ballast support. Chock the front wheels with wooden wedges (2). WLAPL4S10C132AA 38. Position a fixed jack stand (3) under the support of the groove (1) of the drive of the front axle, inserting a wooden plug (2) between parts (3) and (1).
  • Page 51 Engine - Engine and crankcase 41. Check that there are no brackets between the engine and the cooling assembly. Detach the engine (2) from the front axle (3). Try to avoid incorrect maneuvers with the hoist in order to not damage the fins of the radiator on the axle with the engine fan (1).
  • Page 52 T4.115 with cab, with mechanical or power shuttle transmission [ZxJT0xxxx] T4.115 less cab, with mechanical or power shuttle transmission [ZxJT0xxxx] T4.75 with cab, with mechanical or power shuttle transmission [ZxJT0xxxx] T4.75 less cab, with mechanical or power shuttle transmission [ZxJT0xxxx] T4.85 with cab, with mechanical or power shuttle transmission [ZxJT0xxxx]...
  • Page 53 Engine - Engine and crankcase 3. Remove the three bolts (1) and the related dust cover for the compressor clutch. WLAPL4S10C142A 4. Ensure that the polyv belt (2) is perfectly housed on the fan pulley. 5. Move the belt (2) near to the compressor pulley. Keep- ing the tool 380200011 under the belt, hook the tool onto the compressor clutch at the innermost part in or- der to slightly force the belt.
  • Page 54 Engine - Engine and crankcase 9. Insert the three hooks of the chain in the eyelets on the engine. Using a hoist, lift the assembly off the platform support. 10. Position the engine (2) on the front axle (3), trying to avoid incorrect operations with the hoist so as not to let the engine fan damage the fins of the radiator (1).
  • Page 55 Engine - Engine and crankcase 14. Remove the fixed jack stand (1) previously fitted under the ballast support and the wooden wedges (2) locking the front wheels. WLAPL4S10C132AA 15. Remove the old sealing paste from the two surfaces between the engine and clutch case. 16.
  • Page 56 Engine - Engine and crankcase 21. Disconnect the hoist chains. Remove the jack stand (2) previously fitted under the clutch case (1). Retrieve the movable tool for dismantling tractors. WLAPL4S10C129A 22. Refit the bracket (2) supporting the cab connectors, cab power and cup filter (3). Connect the pipe that joins the latter to the mechanical priming pump on the sediment filter.
  • Page 57 Engine - Engine and crankcase 28. Refit the two supply and return lines to the cab heater (1) and the pipe (3) inserted on the lower sleeve com- ing from the expansion tank. Refit the upper and lower sleeves (4) of the engine radiator connection. Secure the straps and clamps tightening the pipes.
  • Page 58 Engine - Engine and crankcase 32. Connect the pipes to the power steering cylinder (1) and (2). Connect the power supply to the control valve (3). Refit the fixture (4). WLAPL4S10C125A 33. If it was necessary to remove the DPF support, pro- ceed as follows: 1 –...
  • Page 59 Engine - Engine and crankcase A small misalignment of the axis of the decoupler with respect to the axis of the turbine outlet (3) would produce an adjustment that would no longer be lengthwise, in line with the direction of the tractor, but abnormal transversal adjustment that would impair its durability.
  • Page 60 Engine - Engine and crankcase 40. Refit the transmission oil drain plug (1). Refill with oil using a pump. MOIL13TR00197AA 41. Refit the drive shaft together with the central support (1) and the retaining bolts. Insert the shim. Adjust the shaft end play.
  • Page 61 Engine - Engine and crankcase 44. Reconnect the air-conditioning lines (3) and the sen- sor (2) to the condenser (1). Fix them with clamps and brackets. WLAPL4S10C107A 45. Reconnect the air-conditioning lines (1) and (2) on the compressor. Secure the lines with clamps and brack- ets.
  • Page 62 T4.115 with cab, with hi-lo transmission [ZxJT0xxxx] T4.115 less cab, with hi-lo transmission [ZxJT0xxxx] T4.75 with cab, with hi-lo transmission [ZxJT0xxxx] T4.75 with cab, with hi-lo transmission, with Supersteer™ front axle [ZxJT0xxxx] T4.75 less cab, with hi-lo transmission [ZxJT0xxxx] T4.85 with cab, with hi-lo transmission [ZxJT0xxxx] T4.85 with cab, with hi-lo transmission, with Supersteer™...
  • Page 63 Engine - Engine and crankcase 2. Reposition the compressor and the relevant belt follow- ing this procedure: - Put the compressor back on the support and with the related pipe support. Secure with the bolts – To mount the polyv belt, use the specific tool 380200011.
  • Page 64 Engine - Engine and crankcase 5. Move the belt (2) near to the compressor pulley. Keep- ing the tool 380200011 under the belt, hook the tool onto the compressor clutch at the innermost part in or- der to slightly force the belt. WLAPL4S10C143A 6.
  • Page 65 Engine - Engine and crankcase 11. Reposition the movable tool for dismantling tractors (2) under the engine. Place a wooden block (1) in the point of contact between the tool and the engine. WLAPL4S10C140A 12. With the aid of the hoist, place the engine (1) on the tool (2).
  • Page 66 Engine - Engine and crankcase 16. Apply L ® 518™ sealing compound on the mat- OCTITE ing surfaces of the engine and clutch case. 17. Put a wooden wedge under the right-hand rear wheel. Make sure that the hand brake is fully applied and that all fixed and mobile stands are safely positioned.
  • Page 67 Engine - Engine and crankcase 22. Refit the bracket (2) supporting the cab connectors, cab power and cup filter (3). Connect the pipe that joins the latter to the mechanical priming pump on the sediment filter. 23. On the left-hand side, connect the cab power cable connector (1).
  • Page 68 Engine - Engine and crankcase 29. Reconnect the power steering control valve oil filter together with the support (3). Reconnect the oil drain line (2) from the power steering and the supply line to the control valve of the gearbox (1). WLAPL4S10C126A 30.
  • Page 69 Engine - Engine and crankcase 33. If it was necessary to remove the DPF support, pro- ceed as follows: 1 – Mount the upper support (1) on the right-hand one (2) with the three Allen screws. 2 – Mount the left-hand support (5) securing it to the engine with the three lower screws.
  • Page 70 Engine - Engine and crankcase 36. Refit the hood support of the air filter bracket (1). WLAPL4S10C121A 37. Reassemble the air filter unit (4) and the respective support (3). Fix the screws on the filter bracket and on the supply duct on the radiator. Refit the sleeve connected to the turbine (2), and the oil vapor duct (1).
  • Page 71 Engine - Engine and crankcase 40. Refit the transmission oil drain plug (1). Refill with oil using a pump. MOIL13TR00197AA 41. Refit the drive shaft together with the central support (1) and the retaining bolts. Insert the shim. Adjust the shaft end play.
  • Page 72 Engine - Engine and crankcase 44. Reconnect the air-conditioning lines (3) and the sen- sor (2) to the condenser (1). Fix them with clamps and brackets. WLAPL4S10C107A 45. Reconnect the air-conditioning lines (1) and (2) on the compressor. Secure the lines with clamps and brack- ets.
  • Page 73 Index Engine - 10 Engine and crankcase - 001 Engine - Install (*) ................. 23 Engine - Install (*) .
  • Page 74 [ZxJT0xxxx], T4.115 with cab, with hi-lo transmission [ZxJT0xxxx], T4.115 with cab, with hi-lo transmission, with Supersteer™ front axle [ZxJT0xxxx], T4.75 less cab, with mechanical or power shuttle transmission [ZxJT0xxxx], T4.75 with cab, with mechanical or power shuttle transmission [ZxJT0xxxx], T4.75 with cab, with hi-lo transmission [ZxJT0xxxx], T4.75 with cab, with hi-lo transmission, with Supersteer™...
  • Page 75 with cab, with hi-lo transmission [ZxJT0xxxx], T4.85 with cab, with hi-lo transmission, with Supersteer™ front axle [ZxJT0xxxx], T4.85 less cab, with hi-lo transmission [ZxJT0xxxx], T4.95 less cab, with mechanical or power shuttle transmission [ZxJT0xxxx], T4.95 with cab, with mechanical or power shuttle transmission [ZxJT0xxxx], T4.95 with cab, with hi-lo transmission [ZxJT0xxxx], T4.95 with cab, with hi-lo transmission, with Supersteer™...
  • Page 76 47803847 15/12/2014 10.2 [10.216] / 1...
  • Page 77 Contents Engine - 10 Fuel tanks - 216 SERVICE Fuel tank Remove ................. . 3 Install .
  • Page 78 Engine - Fuel tanks Fuel tank - Remove DANGER Heavy objects! Lift and handle all heavy components using lifting equipment with adequate capacity. Always support units or parts with suitable slings or hooks. Make sure the work area is clear of all bystanders. Failure to comply will result in death or serious injury.
  • Page 79 Engine - Fuel tanks 5. Disconnect the electrical connection (1). 6. Label and disconnect the fuel suction and return lines (2). MOIL12TR00541AA 7. Remove the bracket (1) that secures the fuel intake line and the fuel return line to the tank. Then remove the tank.
  • Page 80 Engine - Fuel tanks Fuel tank - Install DANGER Heavy objects! Lift and handle all heavy components using lifting equipment with adequate capacity. Always support units or parts with suitable slings or hooks. Make sure the work area is clear of all bystanders. Failure to comply will result in death or serious injury.
