MENU MODE

■ Settings menu items

D AM squelch level "SQL LEVEL"
Adjusts the squelch level for the AM mode operation.
In order to receive signals properly, the squelch must be
adjusted to the proper level.
• –010 to 010: Sets the AM squelch level to between –10 and 10.
D Squelch mode "SQL MODE"
Sets the squelch mode for the AM mode operation.
• MANUAL: Use "SQL LEVEL" to set the squelch level.
• AUTO: Prevents the audio from breaking up while receiving
weak signals.
D FM squelch level "FM SQL LV"
Sets the squelch level for FM mode operation.
• –010 to 010: Sets the FM squelch level to between –10 and 10.
D Headphones level "HP LEVEL"
Sets the headphones output level while receiving.
• AF GAIN: The output level is adjusted by [VOL].
• OFF (0): Mutes the headphones.
• 001 to 080: Sets the audio level to between 1 and 80.
19
D Intercom 1 microphone audio input level
"INCOM LV1"
Sets the intercom 1 microphone input level.
• OFF (0): Mutes the intercom 1 microphone.
• 001 to 080: Sets the intercom 1 input level to between 1 and 80.
D Intercom 2 microphone audio Input level
"INCOM LV2"
Sets the intercom 2 microphone input level.
• OFF (0): Mutes the intercom 2 microphone.
• 001 to 080: Sets the intercom 2 input level to between 1 and 80.
D Automatic noise limiter "ANL"
The ANL (Automatic Noise Limiter) function reduces noise
components while receiving, such as those caused by the
engine ignition systems.
• OFF: ANL function is OFF.
• ON: ANL function is ON.
