- Page 1 GEBV SERIES User Manual...
-
Page 2: Table Of Contents
Contents Notes ............- 1 - Product Introduction ......... - 2 - Production Instruction ........- 2 - Product Feature ..........- 2 - Product Structure ........- 3 - Technical Parameters ........ - 6 - OSD Menu tree ........... - 7 - Product Installation ........ -
Page 3: Notes
Notes Read this manual carefully before use. 1)To reduce the risk of electric shock, do not open the machine and maintain by yourself, please consult a professional service person. 2)To prevent fire or shock hazard, use the power after safety certification, the input voltage, current, voltage polarity and operating temperature must meet the requirements of this camera. -
Page 4: Product Introduction
Product Introduction 2.1 Production Instruction This series of cameras are adopted CMOS image sensor with high performance, which provides mega pixel resolution and supports HD video. Moreover, it supports monitoring signals coaxial transmission. Transmission distance can reach more than 300M based on 75-3 coaxial cable. -
Page 5: Product Structure
Product Structure The followings are the dimensions of some products. No further notice for the upgraded version. Photo 3-1 Indoor Dome Camera Photo 3-2 Indoor IR Dome Camera - 3 -... - Page 6 Photo 3-3 Outdoor IR Dome Camera Photo 3-4 Outdoor Vari-focal Dome Camera Photo 3-5 Outdoor IR Bullet Camera - 4 -...
- Page 7 Photo 3-6 Outdoor Vari-focal Bullet Camera Photo 3-7 Outdoor Vari-focal Bullet Camera - 5 -...
-
Page 8: Technical Parameters
Technical Parameters Signal System NTSC / PAL Image Sensor 1/2.7“ 2MP CMOS Sensor Active array size 1936(H) x 1096(V) Synchronization Internal synchronization Video OutPut CVI,TVI ,AHD (1080P@25fps, 1080P@30fps) CVBS (1280x576 , 1280x480) S/N Ratio 39dB(AGC OFF) Min. Illumination Color：0.1Lux@(F1.2，AGC ON) B&W：0.01Lux@(F1.2，AGC ON) Day &... -
Page 9: Osd Menu Tree
OSD Menu tree SECOND MENU MAIN MENU BRIGHTNESS 1～20 EXPOSURE GLOBE MODE CENTER LV 1~8 RETURN MODE RGIAN 1～16 BGAIN 1～16 RETURN DAY-NIGHT MODE EXT / AUTO / COLOR / B&W RETURN VEDIO SETTING CONTRAST 1～10 SHARPNESS 1～20 COLOR GAIN 1～20 1～15 FORMAT... -
Page 10: Product Installation
Product Installation 6.1 Note 1) Make sure the unit is powered off before installation. 2) Check power supply voltage consistent with the electric voltage to prevent voltage unworthy, resulting in damage to the device. 3) Do not use in the environment beyond the boundaries of the temperature, and maintain good ventilation to prevent the rain in order to reduce the risk of fire or electric shock. - Page 11 bracket or base. ② If the wooden wall, use self-tapping screws to mount. 3. Mounting the camera a. Dome Camera Adjust the lens position and make it aim at the monitoring points and present a clear picture, manually fix lens location and adjust the hemisphere cover.
-
Page 12: Connection
6.4 Connection Connection as show in the figure below - 10 -... -
Page 13: Appendix: Faq
Appendix: FAQ Q: No picture with power on A: It may result from abnormal power supply. Please check if the power supply voltage and its polarity are correct. Besides, please confirm if wires connection and monitors are normal. Q: Unclear image output A: It is caused by incomplete adjustment of the lens back focus. - Page 14 GENIE CCTV LTD. CCTV House, City Park, Watchmead, Welwyn Garden City, Hertfordshire, AL7 ILT Tel: +44 (0) 1707 330541 Fax: +44 (0) 1707 330543 www.geniecctv.com Edition. December 2016...
