- Page 1 D1917PK PORTABLE 9" LCD MONITOR AND DVD PLAYER PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com...
- Page 2 An LCD panel and/or video monitor may be installed in a motor vehicle and visible to the driver if the LCD panel or video monitor is used for vehicle information, system control, rear or side observation or navigation. If the LCD panel or video monitor is used for television reception, video or DVD play, the LCD panel or video monitor must be installed so that these features will only function when the vehicle is in “park”...
-
Page 3: Table Of Contents
Content A. Introduction ... 4 B. Cautions and Warnings ... 4 C. Contents ... 6 D. Powering and Installation ... 6 E. Vehicle Installation ... 7 F. Controls, Indicators and Connectors ... 8 G. Loading and Playing a Disc ... 9 H. -
Page 4: Introduction
A. Introduction Thank you for choosing the D1917PK portable DVD player. The main features include a 9" Wide Screen (16:9 Aspect Ratio) Liquid Crystal Display (LCD) monitor and a DVD player. The unit is designed for use with SD/MMC, MS memory cards and USB memory devices. - Page 5 operation, never cover or block the slots and openings with a cloth or other material. It is hazardous to replace the battery incorrectly. Replace the battery only with the same or equivalent type. In order to protect the environment, please dispose the battery properly. Do not use the unit in temperatures higher than 95 degrees Fahr- enheit or 35 degrees Celsius.
-
Page 6: Contents
7.Regional Coding Both the DVD player and disc are coded by region. These regional codes must match in order for the disc to play. If the codes don’t match, the disc won’t play. This unit’s code is region 1. DVDs with other regional codes cannot be played in this unit C. -
Page 7: Vehicle Installation
Carry Bag Closed Vehicle Headrest Vehicle Seat 1). Unfold the carry bag, and place the DVD player on the bag beneath the elastic straps. Ensure that the unit’s corners are secured by the elastic straps. 2). Secure the upper portion of the carry bag to headrest support bars using the headrest strap. -
Page 8: Controls, Indicators And Connectors
F. Controls, Indicators, and Connectors 1. Unit View (Refer to Figure 3) 1) Battery Release Button 2) DC 9V Input Jack 3) AV Jack 4) AV In/Out Switch 5) USB Port 6) Power ON/OFF Switch 7) SD/MMC/MS Card Slot 8) Power LED 9) Remote Control Sensor 10) Cover Open Switch * Connecting to headphone jack number 1 will disable the... -
Page 9: Loading And Playing A Disc
19) Play/Pause Button G. Loading and Playing a Disc a. After connecting power to the unit, power on the DVD player with the power switch. The power indicator will light. b. Open the disc tray by sliding the OPEN switch in the direction of the arrow. -
Page 10: Basic Operation
H. Basic Operation POWER OPEN PAUSE STOP PLAY Skip + NEXT Skip - PREVIOUS FORWARD REVERSE ANGLE LEFT/RIGHT/UP/DOWN ENTER NUMBERS MENU REPEAT DISPLAY SUBTITLE AUDIO SETUP WIDE PDF created with FinePrint pdfFactory Pro trial version Turn the unit on/off Remove/load the disc Press to pause play and again to re-start play. -
Page 11: Menu
I. Menu A DVD is divided into sections called titles and chapters. When you play a DVD’s root menu of the disc will appear on the screen of your TV or Monitor. The contents of the menu vary from disc to disc. Press MENU during playback to display the menu. - Page 12 2. SUBTITLE During disc playback press ‘SUBTITLE’ to select the subtitle language you desire*, with the current Subtitle Language Number (1) and the total Number of Subtitle Languages (2) displayed. If there are mul- tiple languages press ‘SUBTITLE’ again to select another subtitle lan- guage.
- Page 13 4. ZOOM During playback press ‘ZOOM’ mutiple times to enlarge the picture by 2X, 3X or 4X. 5. A-B REPEAT a. During playback press the ‘A-B’ button once to set the Starting Point A. b. Press ‘A-B’ a second time to set the Ending Point B and the player will repeatedly play the part between Point A and Point B.
-
Page 14: Playing Audio Cds
6. REPEAT a. During playback press ‘REPEAT’ repeatedly to cycle through the repeat modes. Chapter: Repeat the current chapter Title: Repeat the current title All: Repeat all chapters and titles Repeat Off: Resume normal playback K. Playing Audio CDs When playing an audio CD press the DISPLAY button constantly on the remote to view time information. -
Page 15: Playing Mp3 Discs
Total Elapsed: The current track playing and the total time that the Total Remain: Display Off: USING THE1/ALL REPEAT FEATURE The default mode for the Repeat feature is OFF. Pressing REPEAT consecutively changes the repeat options: • Track- repeats the track that is playing. •... - Page 16 4. Use the song. USING THE REPEAT FEATURE The default mode for the Repeat feature is OFF. Pressing REPEAT consecutively changes the repeat options: • Repeat One (repeat playback of a song) • Repeat Folder (repeat playback of a specific folder) •...
-
Page 17: Connecting To Other Electronic Equipment
M. Connecting to other Electronic Equipment 1. Connecting to a TV or another monitor a. Set the AV In/Out Switch to the “Out” Position. b. Connect one end of the audio/video cable’s black (1/8” plug) plug into the unit’s DVD AV jack and connect the other end to the AUDIO INPUT jacks on your TV or Monitor using the AV adapter cable (white = left audio channel, red = right audio channel, yellow = video). -
Page 18: Playing Jpeg File
N. Playing JPEG Files 1) Load the JPEG Disc into tray. 2) The DVD player will display a folder and the JPEGS contained within the folder in a thumbnail view. Choose the picture you desire by using the “UP” and “DOWN” buttons. -
Page 19: O. Setup
NOTE: Not all discs contain above features. The above features are c) Screen Saver *On: Enables screen saver *NOTE: The DVD player will enter the Screen Saver mode after ap- proximately three minutes if the same image remains on the screen. *Off: Disables screen saver (off) PDF created with FinePrint pdfFactory Pro trial version ”... -
Page 20: Setup
d) Last Memory *On: The unit will return to the last position on the disc. *Off: The unit will not return to the last position on the disc. Note: The Last position memory function will only work when the disc tray is open. 2.Video Quality Setup 1)In Setup menu, Press the Setup”... - Page 21 4) Press 5) Press the ENTER to confirm your selection. 6) Repeat steps 3-5 for other menus. Note: Press a) Audio b) Subtitle c) Disc Menu Note: Language and subtitle selection is only available for discs that are recorded in the above listed languages. If the selected language is not available, the player will play and display on the screen the original recorded language contained in the disc.
-
Page 22: P. Specifications
Please fully charge the battery prior to first use. NOTE: When the DVD player is used with the battery as a power source, ensure that the battery has been charged for at least eight hours prior to connecting it to the DVD player. -
Page 23: Specifications
2. To charge the battery, please connect the power jack directly into the DVD player and leave the POWER switch in the OFF position. PDF created with FinePrint pdfFactory Pro trial version F (10... - Page 24 2. Disconnect the DVD player from the AC power source. 2. Flip down the monitor. 3. Push the battery towards the rear of the DVD player until it locks into position. The lock position is indicated by a click. The battery will fit tightly to the player.
-
Page 25: Troubleshooting
R. Troubleshooting PROBLEM No sound or distorted sound Can’t advance through a movie The icon ( appears on screen Picture is distorted No forward or reverse scan PDF created with FinePrint pdfFactory Pro trial version SOLUTION • Make sure your DVD is connected properly. Make sure all cables are securely inserted into the appropriate jacks. - Page 26 CDs and MP3s. • Both the unit and the disc are coded by region. If the regional codes don’t match, the disc can’t be played. This DVD Player is Region Number 1. • The disc is dirty. Clean it.
-
Page 27: Day Limited Warranty
AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 90 days from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor. - Page 28 © 2007 Audiovox Electronics Corporation 128-8195 PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com...
