- Page 1 D1809 8" LCD MONITOR WITH DVD PLAYER PDF created with pdfFactory Pro trial version www.pdffactory.com...
- Page 2 Important Safety Instructions Some of the following information may not apply to your particular product; however, as with any electronic product, precautions should be observed during handling and use. Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water.
- Page 3 Wait for about one hour till the moisture evaporates before operating the unit. When using your portable DVD player, do not sit or stand too close to the screen. To use a headset safely, please keep the following in mind: - Do not play your headset at a high volume.
- Page 4 WARNING: EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. FCC Information This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference which may cause undesired operation.
- Page 5 Manufacturer/Responsible Party Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, NY 11788 This class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
-
Page 6: Table Of Contents
Content A. Introduction ... 7 B. DVD and Disc Information ... 7 C. Contents ... 8 D. Powering and installation ... 8 E. Controls, Indicators, and Connectors... 9 F. Loading and Playing a Disc ... 10 G. Basic Operation... 11 H. -
Page 7: Introduction
A. Introduction Thank you for choosing the D1809 portable DVD player. The main features include a 8" wide Screen (16:9 Aspect Ratio) Liquid Crystal Display (LCD) monitor and a DVD player. The unit applies the latest state of the art electronics and is designed for use in hotels, offices or your home. -
Page 8: Contents
C. Contents 1. 1 x 8’’ LCD Monitor and DVD Player 2. 1 x Remote Control with Battery (CR2025) 3. 1 x Audio/Video Cable 4. 1 x AC to DC Adapter 5. 1 x DC Power Adapter 6. 1 x Instruction Manual 7. -
Page 9: Controls, Indicators, And Connectors
E. Controls, Indicators, and Connectors 1. Unit View (Refer to Figure 2) 1) LCD Panel Shut Off Switch 2) Wide Screen Button 3) Stop Button 4) Previous Button 5) Next Button 6) Play/Pause Button 7) Menu Button 8) Up Button 9) Right Button 10) OK Button 11) Down Button... -
Page 10: Loading And Playing A Disc
18) ANGLE Button 19) PLAY/PAUSE Button F. Loading and Playing a Disc a. After connecting power to the unit, apply power to the DVD player by sliding the POWER ON/OFF switch to ON. The power indica- tor will be green. -
Page 11: Basic Operation
G. Basic Operation POWER OPEN PLAY PAUSE STOP NEXT PREVIOUS FORWARD REVERSE LEFT/RIGHT/UP/DOWN ENTER NUMBERS MENU REPEAT DISPLAY ANGLE SUBTITLE AUDIO ZOOM SETUP PDF created with pdfFactory Pro trial version Turn the unit on/off Remove/load the disc Start Play/Execute item or setting Still Picture (1 time) Stop at the present playing point / (2 times) Stop playback of the DVD/CD... -
Page 12: Menu
H. Menu A DVD is divided into sections called titles and chapters. When you play a DVD, a root menu of the disc will appear on the screen of your TV or Monitor. The contents of the menu vary from disc to disc. Press MENU during playback to display the menu. - Page 13 c. Press DISPLAY button a third time to display the Elapsed Time for the chapter. The heading will disappear automatically in 3 seconds. d. Press DISPLAY button a fourth time to display the Remaining Time for the chapter. The heading will disappear automatically in 3 seconds.
- Page 14 2. Angle During playback of a disc, press ANGLE button to display the avail- able angles for discs containing multi-angles*, with the current angle number (1) and the total number of angles (2) displaying. Press ANGLE button to select other angles. *NOTE: Not all discs contain this feature.
- Page 15 4. Audio During playback press AUDIO button to select the audio language you desire*, with the current Audio Channel Number (1) and the total number of Audio Channels (2) displayed. Press AUDIO again to select another audio language. The audio display will disappear automatically if the AUDIO button is not pressed within 3 seconds.
- Page 16 6. A-B Repeat a. During playback press A-B button to set the Starting Point A. b. Press A-B button a second time to set the Ending Point B and the player will repeatedly play the part between Point A and Point B.
- Page 17 7. Repeat a. During playback press 1/ALL button once to repeatedly play the current chapter. b.During playback press 1/ALL button again to repeatedly play the current title. c. During playback press 1/ALL button a third time to repeat all chapters and titles. PDF created with pdfFactory Pro trial version Chapter Repeat ON Screen Display Title Repeat ON Screen Display...
-
Page 18: Playing Audio Cds
d. Press 1/ALL button a fourth time, to resume normal playback. 8. Forward/Reverse Scan a. During playback press uu to scan forward at 2x, 4x, 8x,16x, 32x and normal speed. b. During playback press tt to scan backward at 2x, 4x, 8x,16x, 32x and normal speed. -
Page 19: Playing Jpeg Files
1. Using the Repeat Feature The default mode for the Repeat feature is OFF. Pressing 1/ALL button consecutively changes the repeat options: • Repeat One- repeats the track that is playing. • Repeat All - repeats the disc that is playing. •... -
Page 20: Connecting To Other Equipment
2. Connecting Headphones (Not included) Simply plug the headphones into either Headphone jack 1 or Headphone jack 2 on the left side of the DVD Player. (Refer to Figure 5) Plugging into Headphone jack 1 will disable the internal speakers. -
Page 21: Setup
M. Setup Press SETUP button to display the Main screen of the SETUP Menu on the screen. Press SETUP button again to exit the SETUP Menu and the unit will resume it’s last playback mode. 1) Press SETUP, the ‘GENERAL SETUP PAGE’ will display on the screen. - Page 22 b) Select ‘ANGLE MARK’ using the DOWN buttton, and then press the RIGHT button to enter the submenu. Choose Angle Mark on or off using the UP/DOWN button and then press ENTER button to confirm the setting. Press the LEFT button to return. * ON: The screen will show the angle mark icon.
- Page 23 *ON: Enables screen saver. *OFF: Disables screen saver. NOTE: The DVD player will enter the Screen Saver mode after e) Select ‘LAST MEMORY’ by using the DOWN button. and then press the RIGHT button to enter the submenu. Choose Last Memory on or off using the UP/DOWN buttons and then press ENTER button to confirm the setting.
- Page 24 2) Select ‘VIDEO’ by using the LEFT/RIGHT buttons, press ENTER button to enter the VIDEO SETUP PAGE. a) Select ‘BRIGHTNESS’ by using the UP or DOWN button, then press ENTER button. Adjust the Brightness by pressing the LEFT or RIGHT button. To exit Brightness Setting, press ENTER button again.
- Page 25 3) Select ‘PASSWORD’ using the LEFT or RIGHT buttons, then press the ENTER button to enter the submenu. Press ENTER button twice to enter the PASSWORD CHANGE PAGE. Input the Old Password or the Default Password, the New Password, and the Confirmed New Password. Press ENTER button to confirm the change.
- Page 26 4) With no disc inside the player select ‘PREFEREN’ using the LEFT or RIGHT button, then press ENTER button to enter the ‘PREFERENCE PAGE’. a) Select ‘AUDIO’ using the DOWN button, then press ENTER button to enter the submenu. Select the audio language you desire using the UP or DOWN buttons, then press ENTER button to confirm the setting.
- Page 27 b) Select ‘SUBTITLE’ using the DOW N button, then press ENTER button to enter the submenu. Select the desired subtitle language or OFF using the UP or DOWN buttons, then press ENTER to confirm the setting. Press LEFT to return. c) Select ‘DISC MENU’...
- Page 28 d) Select ‘PARENTAL’ using the DOWN button, then press ENTER button to enter the submenu. Select the parental level you desire using the UP or DOWN button for discs with lock-out function or multiple rating levels. These are listed from the lowest level (1 KID SAFE) to the highest level (8 ADULT).
-
Page 29: Specifications
Manufacturer: Great Power Battery (Zhuhai) Co., Ltd O. Rechargeable Built-in Battery Use The DVD player utilizes a long-life Li-Polymer battery for portability. Li-Polymer batteries feature high storage capacity and low level of degradation. This means the Li-Polymer batteries do not have “Memory Effect”... - Page 30 AC adaptor and will NOT charge with the car DC adaptor. 2. Recharge efficiency will degrade when environmental tempera- tures drop below 41 3. Do not leave the DVD player in a hot automobile or temperatures exceeding 122 explosion may result. PDF created with pdfFactory Pro trial version...
-
Page 31: Troubleshooting
No forward or reverse scan PDF created with pdfFactory Pro trial version SOLUTION • Make sure the DVD player is connected properly. Make sure all cables are securely inserted into the appropriate jacks. • You can’t advance through the opening... - Page 32 • Check the type of disc you put into disc tray. This DVD player only plays DVDs and audio CDs. • Your DVD player has been designed to process regional management information that is stored on DVD discs. The regional code for your player is 1 (The U.S.,U.S.
-
Page 33: Day Limited Warranty
90 DAY LIMITED WARRANTY Applies to Audiovox Video Products AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within ninety (90) days from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor. - Page 34 Audiovox Electronics Corporation 150 Marcus Boulevard Hauppauge, NY 11788 128-8573 (V1.0) www.audiovox.com Printed in China PDF created with pdfFactory Pro trial version www.pdffactory.com...
