Audiovox D1708ES User Manual

Audiovox portable dvd player withtwo 7" monitors
Hide thumbs Also See for D1708ES:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual , Manual
7" LC D M ON I TO R
D1708ES
PORTABLE DVD PLAYER WITH TWO 7" MONITORS
128-7396A

Advertisement

Table of Contents
loading

Related Manuals for Audiovox D1708ES

Summary of Contents for Audiovox D1708ES

  • Page 1 7" LC D M ON I TO R D1708ES PORTABLE DVD PLAYER WITH TWO 7" MONITORS 128-7396A...
  • Page 2 NOTICE: This Product incorporates copyright protection technology that is pro- tected by method claims of certain patents and other intellectual prop- erty rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited view- ing uses only unless authorized by Macrovision Corporation.

  • Page 3: Table Of Contents

    Contents A. Introduction..............4 B. Cautions and Warnings..........4 C. Contents...............6 D. Powering and installation ........6 E. Controls, Indicators, and Connectors......10 F. Loading and Playing a Disc........12 G. SETUP................13 H. Basic Operation............21 I. MENU................22 J. DISPLAY...............22 K. PLAYING AUDIO CDS..........28 L. PLAYING MP3 DISCS..........30 M.

  • Page 4: Introduction

    A. Introduction Thank you for choosing the D1708ES. The main features include two 7" Wide Screen (16:9 Aspect Ratio) Liquid Crystal Display (LCD) moni- tors and a DVD player. The unit applies the latest state of the art elec- tronics and is designed for use in hotels, vehicles or your home. The...
  • Page 5 hazardous to replace the battery incorrectly. Replace the battery only with the same or equivalent type. To protect the enviromnent, please dispose the battery properly. Do not use the unit in tem- peratures higher than 104 degrees Fahrenheit or 40 degrees Cel- sius.

  • Page 6: Contents

    C. Contents 1. 1 x 7’’ LCD Monitor & DVD Player Combo 2. 1 x 7” LCD Monitor 3. 2 x AC to DC Adapter 4. 1 x Remote Control with battery (CR2025) 5. 1 x Instruction Manual 6. 1 x Audio/Video Cable 7.
  • Page 7 7"LCD MONITOR Main Unit Back Panel Main Unit Right Side Figure 2...
  • Page 8 3. Installation Load the disc into the DVD compartment, and make sure that the unit is placed into the bag with the retention drawstring and mesh covering around the DVD door. Then tighten the retention drawstring across the top portion of the unit. 1) Installing the System onto the back of a seat in a car (Refer to Figure 3) Figure 3...
  • Page 9 2) Positioning the 2nd Monitor Option 1 Vehicle Headrest (Refer to Figure 4) Figure 4 Slide the Monitor into the pouch and attach the Velcro strap to secure the Monitor in the pouch. Loop the strap of the pouch around the headrest and pull the end of the strap while holding the buckle to tightly secure the pouch to the headrest Option 2 Flat Surface (Refer to Figure 5)

  • Page 10: Controls, Indicators, And Connectors

    E. Controls, Indicators, and Connectors 1. Unit View (Refer to Figure 6) Figure 6 1) Menu Button 8) Power Switch 9) Brightness Control 2) Up/Down/Left/Right/OK 10) Volume Control Buttons 3) Open Button 11) Headphone Jack 1 12) Headphone Jack 2 4) Previous/Next/Pause/ 13) E-Port Stop/Play Buttons...
  • Page 11 2. Single Monitor View (Refer to Figure 7) Figure 7 1). Brightness Control 2). Power Off/On Switch 3). AV In Jack 4). DC 9-12V Input Jack 5). Headphone Jack 6). Reverse Switch 7). Volume Control NOTE: Slide the Reverse Switch to rotate the picture 180 degrees.

  • Page 12: Loading And Playing A Disc

    3. Remote Control View (Refer to Figure 8) 1) Setup Button 2) Up Button 3) Skip- Button 4) Enter Button 5) Reverse/Left Keypad 6) DOWN Button 7) Numeric Button 8) Display Button 9) Zoom Button 10) Subtitle Button 11) Skip+ Button 12) A-B Repeat Button 13) Forward/Right Keypad 14) 1/All Repeat Button...

  • Page 13: Setup

    G. SETUP Press ‘SETUP’ to display the General SETUP page on the screen. Press ‘SETUP’ again to exit the General SETUP page. The unit will resume it’s last playback mode. Main Setup Menu Screen Display 1) Press ‘SETUP’, the ‘General Setup Page’ will display on screen. a).
  • Page 14 b).Select ‘Angle Mark’ using the UP/DOWN buttons, and then press the RIGHT button to enter the submenu. Choose Angle Mark on or off using the UP/DOWN button and then press ENTER to confirm the setting. Press the LEFT button to return. Angle Mark Screen Display * On: The screen will show the angle mark icon.
  • Page 15 c). Select ‘Screen Saver’ using the UP/DOWN buttons. *On: Enable screen saver *Off: Disable screen saver (off) *NOTE: The DVD player will enter the Screen Saver mode after ap- proximately five minutes if the same image remains on the screen. Screen Saver Screen Display d).
  • Page 16 a). Select ‘Brightness’ by using the UP/DOWN buttons, then press EN- TER. Press the LEFT /RIGHT button to select the desired bright ness. To exit the Brightness adjustment, press ENTER again to re turn the main Menu. Brightness Screen Display b).
  • Page 17 d).Select ‘Saturation’ by using the UP/DOWN buttons, then press EN- TER. Adjust the Saturation by pressing the LEFT/RIGHT buttons. To exit ‘Saturation’ adjustment, press ENTER again to return to the main Menu. Saturation (Color) Screen Display 3).Select “Password” using the LEFT/RIGHT buttons, then press the ENTER button to enter “Password Setup Page”.
  • Page 18 NOTE: The Default Password is 3308 . This password is always ef- fective even after you have selected your own password and changed it. To avoid the possibility of others using the default password to set the parental level and change the password, you can record this default password in another area and delete it from this manual.
  • Page 19 c. Select ‘Disc Menu’ using the UP/DOWN buttons, then press RIGHT to enter the submenu. Select the Disc Menu Language you desire using the UP/DOWN buttons, then press ENTER to confirm the setting. Press LEFT to return. Preference Disc Menu Language Screen Display Note: Language and subtitle selection is only available for discs that are recorded in the above listed languages.
  • Page 20 e. Select ‘Default’ using the UP/DOWN buttons, then press RIGHT to enter the submenu. Press ENTER to make the setting return to the factory-set mode. NOTE: The parental setting is not affected by the default reset function. Loading Factory Setting Screen Display...

  • Page 21: Basic Operation

    H. Basic Operation POWER Turn the unit on/off Remove/load the disc OPEN PLAY Start Play/Execute item or setting SLOW Play at 1/2, 1/4, 1/8 or 1/16 times speed PAUSE Still Picture STOP (1 time) Stop at the present playing point / (2 times) Stop playing Go to the next chapter, track or scene dur- SKIP+(NEXT)

  • Page 22: Menu

    I. MENU A DVD is divided into sections called titles and chapters. When you play a DVD, a root menu for the disc will appear on the screen of your monitor. The contents of the menu vary from disc to disc. Press MENU during playback to display the menu.
  • Page 23 c. Press ‘DISPLAY’ a 3rd time to display the Elapsed Time for the chapter. The heading will disappear automatically in 3 seconds. Chapter Elapsed Time Screen Display d. Press ‘DISPLAY’ a 4th time to display the Remaining Time for the chapter.
  • Page 24 Angle Screen Display 3. SUBTITLE During disc playback press ‘SUBTITLE’ to select the subtitle language you desire*, with the current Subtitle Language Number (1) and the total Number of Subtitle Languages (2) displayed. If there are mul- tiple languages press ‘SUBTITLE’ again to select another subtitle lan- guage.
  • Page 25 4. AUDIO During playback press ‘AUDIO’ to select the audio language you desire*, with the current Audio Channel Number (1) and the total number of Audio Channels (2) displayed. Press AUDIO again to select another audio language. The audio display will disappear automatically if the ‘AUDIO’ button is not pressed within 3 seconds.
  • Page 26 6. A-B REPEAT a. During playback press ‘A-B’ the first time to set the Starting Point A-B Repeat Starting Point Screen Display b. Press ‘A-B’ the second time to set the B Ending Point. The player will repeatedly play the parts between Point A and Point B. A-B Repeat Ending Point Screen Display c.
  • Page 27 7. REPEAT a. During playback press ‘REPEAT’ once to repeatedly play the cur- rent chapter. Chapter Repeat Screen Display b. During playback press ‘REPEAT’ again to repeatedly play the current title. Title Repeat Screen Display c. During playback press ‘REPEAT’ a 3rd time to repeat all Chapters and Titles.

  • Page 28: Playing Audio Cds

    d. Press “REPEAT” a 4th time, to resume normal play. Repeat Off Screen Display K. PLAYING AUDIO CDS When playing an audio CD press the DISPLAY button on the remote to view time information. The screens below show you what information is available through the use of this function.
  • Page 29 c. Press ‘DISPLAY’ a 2nd time and “Total Elasped” appears along with the current track playing and the total time that the CD has been playing. Total Elapsed Screen Display d. Press ‘DISPLAY’ a 3rd time and “Total Remain” appears along with the current track playing and the amount of time remained on the CD.

  • Page 30: Playing Mp3 Discs

    L. PLAYING MP3 DISCS MP3 is a format for storing digital audio. An audio CD-quality song is compressed into the MP3 format with very little loss of audio quality while taking up much less disc space. CD-R /RW discs that have been encoded in MP3 format are compatible with this system.
  • Page 31 USING THE REPEAT FEATURE The default mode is Folder. Pressing REPEAT consecutively changes the repeat options: • Single • Repeat One (repeat playback of a song) • Repeat Folder (repeat playback of a specific folder) • Folder (normal playback) As you toggle through the options, the repeat option changes. The selected repeat option loops repeatedly until you turn it off.

  • Page 32: Playing Jpeg Files

    M. Playing JPEG file 1) Load the JPEG Disc into tray. 2) Select JPEG file by pressing “UP/DOWN” button. 3) You can preview the JPEG file by pressing “Play” or “ENTER”. 4) Pressing the “Left Key“ will rotate the picture 90 degrees counterclockwise.
  • Page 33 n. When “WINDOW V” is displayed on the screen, the picture will refresh from four window’s left side to right side. o. When “WIPE FROM EDGE TO CENTER” is displayed on the screen, the picture will refresh from 4 edges to center. 7) When previewing the file, pressing “ANGLE, SUBTITLE, AUDIO, NUMBER, AB, RETURN, REW/FF, SLOW”...

  • Page 34: Connecting To A Tv Or Another Monitor

    2. AV In Using “AV Jacks” connecting to a Game or Camcorder. ( Refer to Figure 10) a. Slide the AV In/Out switch to In. b. Connect one end of the supplied audio/video cable’s black (1/8” stereo plug) plug into the unit’s DVD’s AV jack, and connect the other end to the AUDIO OUTPUT jacks on your Game or Camcorder through an optional RCA cable(white = left channel, red = right channel, Yellow = Video).

  • Page 35: Specifications

    3. Connecting to Headphones Note: Optional wired headphones may be used with the unit. Simply plug in the headset to either Headphone 1 jack or Head- phone 2 jack on the right side of the DVD. ( Refer to Figure 12) Figure12 Plugging into Headphone jack 1 disables the internal speakers.

  • Page 36: Rechargeable Battery Installation And Use

    O. Specifications Compatible DISC: DVD/CD/MP3 Signal system: NTSC Panel size: 7 inch Resolution: 480 x 234 Frequency response: 20 Hz to 20 kHz Video output: 1 Vp-p/75 Ohm, unbalanced Audio output: 1.4Vrms/10kOhm Audio S/N: Better than 60 dB Dynamic range : Better than 85 dB Laser: Semiconductor Laser, Wave Length: 650 nm/795 nm Power source: DC 9V-12V Power consumption: 12 W, 1.0 Amp...

  • Page 37: P. Rechargeable Battery Installation And Use

    P. Rechargeable Battery Installation and Use The player utilizes a set of long-life Ni-Mh batteries for a portable power supply. Ni-MH batteries feature high storage capacity and low level of degradation. This means the Ni-MH batteries do not have “Memory Effect” and thus can be recharged safely regardless of whether the battery is fully or only partially discharged.

  • Page 38: Installing The Battery

    Installing the Battery Pack: 1. First, make sure the player is in “Power Off” mode and that the AC power supply has been disconnected. 2. Close the player cover. 3. Align the battery pack with the player module’s front edge. 4.

  • Page 39: Day Limited Warranty

    90 DAY LIMITED WARRANTY Applies to Audiovox Video Products AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 90 days from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor.
