Lexmark MS81x Service Manual page 7

Assembly 2: Paper path
Asm-index P/N Units/mach Units/FRU Description
1 40X7602
2 40X7588
2 40X8399
3 40X7587
4 40X7585
5 40X7584
6 40X7583
7 40X7586
1 1 Upper redrive
1 1 Fuser access door (belt fuser printers only)
1 1 Fuser access door (hot roll fuser printers only) See
1 1 Inner guide deflector
1 1 Recoil spring
1 1 Duplex exit diverter
1 1 Media turn guide
1 1 Media vertical guide
Parts catalog
536
4063
Removal procedure
See "Upper redrive
removal" on page 325.
See "Fuser access door
removal" on page 318.
"Fuser access door
removal" on page 318.
See "Inner guide
deflector removal" on
page 285.
N/A
See "Duplex exit diverter
removal" on page 282.
See "Media turn guide
removal" on page 295.
See "Media vertical guide
removal" on page 296.
