Lexmark MS81x Service Manual page 5

Assembly 1: Covers
Asm-index P/N Units/mach Units/FRU Description
1 40X7678
2 40X7726
3 40X7671
3 40X8404
4 40X7680
4 40X8403
5 40X7670
6 40X7690
7 40X7715
8 40X7725
9 40X7674
10 40X7669
11 40X7672
12 40X7679
12 40X8402
13 40X7677
14 40X7675
14 40X8397
15 40X8398
16 40X7604
17 40X7673
1 1 Rear door
1 1 Rear door support
1 1 Rear lower cover (integrated 550‑sheet tray)
1 1 Rear lower cover (integrated 250‑sheet tray)
1 1 Right cover (integrated 550‑sheet tray)
1 1 Right cover (integrated 250‑sheet tray)
1 1 Right inner cover
2 1 Torsion spring
2 1 Front door support link
1 1 MPF tray
1 1 Front door
1 1 Inner left cover
1 1 Controller board access cover
1 1 Left cover (integrated 550‑sheet tray)
1 1 Left cover (integrated 250‑sheet tray)
1 1 Bin sensor cover
1 1 Standard bin cover (integrated 550‑sheet tray) See
1 1 Standard bin cover (integrated 250‑sheet tray) See
1 1 Fuser wiper cover (hot roll fuser printer only)
2 1 Output bin guide
1 1 Top cover
Parts catalog
534
4063
Removal procedure
See "Rear door removal"
on page 280.
N/A
See "Rear lower cover
removal" on page 276.
See "Rear lower cover
removal" on page 276.
See "Right cover
removal" on page 278.
See "Right cover
removal" on page 278.
See "Right inner cover
removal" on page 304.
N/A
N/A
See "MPF tray removal"
on page 303.
See "Front door
removal" on page 284.
See "Left inner cover
removal" on page 291.
See "Controller board
access cover removal"
on page 341.
See "Left cover removal"
on page 273.
See "Left cover removal"
on page 273.
See "Output bin sensor
cover removal" on
page 320.
"Standard bin cover
removal" on page 324.
"Standard bin cover
removal" on page 324.
N/A
N/A
See "Top cover removal"
on page 278.
