“IMPORTANT SAFETY INSTRUCTIONS” “When using an electrical appliance, basic safety precautions should always be followed, including the following.” “Read all instructions before using this sewing machine.” “DANGER-- To reduce the risk of electric shock:” 1. “ This sewing machine should never be left unattended when plugged in. Always unplug this sewing machine from the electric outlet immediately after using and before cleaning.”...
Page 3
15. “Do not use bent needles.” to break.” 17. “ Switch the sewing machine off (“0”) when making any adjustments in the needle area, such as threading needle, changing needle, threading bobbin, or changing presser foot, etc.” 18. “ Always unplug sewing machine from the electrical outlet when removing covers, lubricating, or when making any other user servicing adjustments mentioned in the instruction manual.”...
ACCESSORIES 1. Needles 8. Darning plate 2. Bobbins 9. Zipper foot 3. Auxiliary spool pin 10. Buttonhole foot 4. Spool pin felt discs 5. Spool pin cap 6. Buttonhole opener/Seam Ripper and Brush 7. Screwdriver for needle plate The Foot that comes on your Sewing machine is called the General Purpose Foot and will be used for the majority of your sewing.
SETTING UP YOUR MACHINE A l w a y s d i s c o n n e c t t h e machine from power supply by removing the plug from the wall-outlet. Pin plug Set power/light switch at “OFF” Power line cord Machine socket Foot control...
SPOOL PINS Spool Spool pin felt discs HORIZONTAL SPOOL PIN Vertical spool pin Dik makara pimi Pull the spool pin towards you. Place thread Thread retaining slot spool on the pin and secure with a spool cap spool has a thread retaining slit, it should be placed to the right.
DARNING PLATE Darning plate Use the darning plate when you need to control fabric feeding for button sewing, free motion work and free motion darning. Raise needle and presser foot, and position darning plate onto Needle plate the needle plate with the two pins on the back inserted to the holes of needle plate.
WINDING THE BOBBIN Be sure to use Class 15 bobbins. 1.Place a spool of thread on the spool pin, and secure it with the spool pin cap. Pull the thread out from the spool and place it through thread guides as shown in illustration.Be sure to pull thread securely into the bobbin winding tension disk.
REMOVING BOBBIN CASE FROM SHUTTLE 1. Raise the needle to its highest position by rotating the hand wheel toward you (counter-clockwise). 2. Open the bobbin access cover by pulling it down. With your fingers, pull open the bobbin case latch as shown, and take out the bobbin case from the shuttle.
INSERTING BOBBIN CASE INTO SHUTTLE Locating groove 1. Hold the latch open, with locating pin straight up. 2. Slide the bobbin case onto the center spindle of the shuttle, keeping the thread toward you. groove at the top of the shuttle. 3.
Page 20
① ③ ② ④ ⑤ in the following order as illustrated. *Pass the thread through the thread take-up (3) from right to left. *Pass the thread through the eye of the needle (5) from front to back. (See following page for instructions on operation of the Automatic Needle Threader.) IMPORTANT: To verify that the machine is threaded properly in the tension discs, do this simple check: 1.)With the presser foot raised and the needle threaded, pull the thread.
USING AUTOMATIC NEEDLE THREADER Raise the needle to its highest position by rotating the hand wheel towards you (counter-clockwise). 1. Hook thread into thread guide as illustrated. 2. Pull down lever while holding the end of thread. 3. Rotate the lever to the rear of the machine. 4.
PICKING UP BOBBIN THREAD 1. Raise the presser foot lifter. 2. Holding needle thread loosely with your left hand, turn hand wheel toward you (counter-clockwise) with your right hand, first lowering the needle and continuing until the needle comes to its highest position. NOTE: A quick way to pick up the bobbin thread is, with straight stitch selected, touch and release the reverse switch.Your machine will perform one...
* "Heavy Duty" 11/80 orange band Cotton-wrapped Polyester 14/90 Bonded Knits 2045 Polyester Knits blue band Double Knit yellow shank Nylon Jersey / Tricot 16/100 purple band * For best sewing results, always use a SINGER branded needle. Knits...
CHANGING THE NEEDLE Flat side Needle Always disconnect the machine from power supply by removing the plug from the wall-outlet. Stop pin 1. Raise the needle bar to its highest position by turning the hand wheel toward you (counter-clockwise). 2. Loosen the needle clamp screw by turning it toward pimi you (counter-clockwise).
ADJUSTING TOP THREAD TENSION Under side Top side Well balanced Top stitch too tight Top stitch too loose Decrease tension Increase tension 90% of your sewing will be done with the tension control dial (on top of the machine) set at “ 5 ” . Helpful Hint: A slight adjustment to a higher number or a lower number may improve sewing appearance.
Page 27
STRAIGHT STITCHING The correct appearance of your stitching is largely determined by the balanced tension of both top and bobbin threads. The tension is well balanced when these two threads ‘lock’ in stitching is irregular, you will need to adjust the tension control. Make any adjustments with presser foot ‘down’.
FUNCTIONS OF CONTROL PANEL Stitch width/needle position of straight stitch Stitch length LCD display Stitch pattern number M a n u a l a d j u s t m e n t buttons for stitch width/ Buttons for pattern number needle position selection Manual adjustment buttons...
Manual adjustment buttons Manual adjustment buttons for stitch length for stitch width/needle position STITCH LENGTH AND STITCH WIDTH / NEEDLE POSITION ADJUSTMENT BUTTONS Your sewing machine will produce your stitching requirements at an 5/Default stitch Length and Width. Default settings of stitch length and width are underlined on the display. You can manually change the length, width or needle position for straight stitch according to your preference pushing manual adjustment buttons.
ADJUSTING BOBBIN THREAD TENSION BOBBIN THREAD TENSION REQUIRES ADJUSTMENT LESS FREQUENTLY THAN THE TOP THREAD TENSION. Fabric puckers If the tension is well balanced, but the fabric puckers badly, both top and bobbin thread tensions may be too tight and have to be adjusted.
CHANGING PRESSER FOOT Be sure needle is in the up position. Raise presser foot lifter. Presser foot lifter 1. Push presser foot release lever to remove the foot. 2. Place the desired foot on the needle plate aligning the presser foot pin with the foot holder. 3.
HELPFUL MESSAGES If an incorrect operation is made, a helpful message will be displayed. When a helpful Bobbin winder is moved to right (operating position) during sewing. ➡ Check bobbin winder and move it to left. ➡ ➡ Buttonhole lever is not lowered or raised. ➡...
REVERSE OPERATION BUTTON DUAL PURPOSE REVERSE/TACKING STITCH BUTTON Reverse sewing is carried out while the reverse stitch button is pushed. The machine will continue to sew in reverse as long as the reverse button is pressed. Reverse stitch button * Tacking stitch function for tie-off of other stitches ( The sewing machine makes 4 tiny tacking stitches to tie off the sewing on all patterns except straight, zigzag and...
QUICK REFERENCE TABLE OF STITCH LENGTH AND WIDTH 2. STARTING TO SEW PATTERN No. NEEDLE POSITION LENGTH AUTO MANUAL AUTO MANUAL CENTER LEFT - RIGHT 0.5 - 4.5 1.5 - 2.5 2.0 - 4.0 PATTERN No. PATTERN No. WIDTH LENGTH WIDTH LENGTH AUTO...
STRAIGHT STITCHING 100 stitch model : 80 stitch model : 60 stitch model : Straight stitch is most frequently used for all types of sewing. Let’s begin by following the steps below. may be desired. 1.SETTINGS A.Thread tension control Presser foot - General Purpose Foot B.
KEEPING SEAMS STRAIGHT To keep the seam straight, use one of the numbered guide lines on the needle plate. The numbers indicate distance from the needle at its center position. 7/8" (22 mm) 5/8" (16 mm) 3/8" (10 mm)
HAND-LOOK QUILT STITCH 100 stitch model : 80 stitch model : 60 stitch model : This stitch is designed to look like hand sewing for topstitching and quilting. 1. Thread bobbin with desired top stitching color. When sewing the machine will pull this thread to the top.
Page 42
INSERTING ZIPPERS To sew down the right side, attach left side of zipper foot to presser foot holder so that the needle passes through the opening on the left side of the foot. To sew down the left side, attach right side of foot to foot holder.
ZIGZAG STITCHING Under side 100 stitch model : 80 stitch model : 60 stitch model : SETTINGS :Presser foot - General Purpose Foot Top side :Thread tension control - 5 The top thread may appear on the bottom depending on the thread, fabric, type of stitch and sewing speed, but the bobbin thread must never appear on the top of the fabric.
MULTI-STITCH ZIGZAG 100 stitch model : 80 stitch model : 60 stitch model : SETTINGS : Presser foot - General Purpose Foot : Thread tension control - 5 This is a strong stitch because as its name implies, it makes three short stitches where the normal zig-zag makes only one.
SHELL STITCH 100 stitch model : 80 stitch model : 60 stitch model : SETTINGS : Presser foot - General Purpose Foot : Thread tension control - 5 Turn under the raw edge and press. Place the fabric right side up so that the zigzag part of the stitch sews just over the folded edge, pulling the fabric in to form a shell hem.
PLACEMENT OF PATTERNS Center position The satin stitch increases from the center needle position; making it possible to create center tapered stitch, as illustrated. SEWING ON A BUTTON 100 stitch model : 80 stitch model : 60 stitch model : SETTINGS : Presser foot - General purpose foot : Darning plate...
BLINDHEM STITCH 100 stitch model : 07, 08, 10 80 stitch model : 04, 05, 07 60 stitch model : 04, 05, 07 The blindhem stitch is primarily used for creating nearly invisible hems on curtains, trousers, skirts, etc. Settings : Presser foot - General Purpose Foot : Thread Tension Control: 5 - Regular blind stitch for normal woven fabrics.
Page 48
(1.3 cm) or less hem. On medium to heavyweight fabrics overcast the fabric’s raw edge. 2. Now fold the fabric as illustrated with the wrong side up. 3. Place the fabric under the foot. Turn the handwheel towards you (counter-clockwise) by hand until the needle swings fully to the left.
DECORATIVE AND STRETCH STITCHES Settings : Presser foot - General Purpose Foot : Thread tension control - 5 Stretch stitches are mainly for use on knit, or stretchable fabrics, but can also be used on woven materials. 100 stitch model : STRAIGHT STRETCH STITCH 80 stitch model : 60 stitch model :...
Page 50
100 stitch model : HONEYCOMB STITCH 80 stitch model : 60 stitch model : The Honeycomb stitch is ideal for smocking and useful for overcasting and attaching elastic and stretch lace. the fabric that you wish to smock. 2. Cut an underlay fabric (such as organdy) and place it under the shirring.
Page 51
FEATHER STITCH 100 stitch model : 80 stitch model : 60 stitch model : The pleasing appearance of this stitch enables it to be used for decorative topstitching or for attaching laces and trims. It is also ideal for quilting applications and edge-joining.
Page 52
60 stitch model : Useful for decorative stitching on borders and for use in heirloom sewing. The Entredeux stitch is most often sewn with a Wing Needle (SINGER Style 2040) to create holes in the stitch pattern. hole when using a Wing Needle.
Page 53
100 stitch model : 21, 22 PIN STITCH 80 stitch model : 18, 19 60 stitch model : 18, 19 The Pin stitch is a traditional stitch pattern used for picot-like edges and for applique work. BLANKET STITCH 100 stitch model : 23, 24 80 stitch model : 20, 21...
Page 54
100 stitch model : SLANT OVEREDGE STITCH 27, 28 80 stitch model : 24, 25 60 stitch model : 24, 25 OVERLOK Seams and overcasts in one operation to produce a narrow, supple seam, particularly suited to swimwear, sportswear, T-shirts, babywear in stretch nylon, jersey and cotton jersey.
100 stitch model : THORN STITCH 80 stitch model : 60 stitch model : It is a versatile stitch used for joining fabric pieces as well as for decorative machine stitching. REINFORCED OVEREDGE STITCH 100 stitch model : 80 stitch model : 60 stitch model : OVERLOK 100 stitch model :...
100 stitch model : WIZARD STITCH 80 stitch model : 60 stitch model : Used mainly for decorative machine stitching. MORE DECORATIVE STITCHES & IDEAS FOR DECORATIVE MACHINE STITCHING SETTINGS : Presser foot - General Purpose Foot : Thread tension control - 5 or -1 You should carry out a test sewing on an extra piece of the fabric being sewn to check the decorative pattern to be used.
BUTTONHOLE MAKING Tab A Tab B AUTOMATIC BUTTONHOLE USING BUTTONHOLE FOOT Your machine offers you two different widths of bartack, keyhole and round end buttonholes sewn by a system that measures the size of the button and calculates the size of buttonhole required.
Page 58
1. Select one of the buttonhole patterns. 2. Replace the presser foot with the buttonhole foot. (Refer to “Changing presser foot” on page 28.) 3. Insert the button into the buttonhole foot. (Refer to “Using buttonhole foot” above.) 4. Lower the buttonhole lever (C) so that it drops down vertically between the stoppers (A) and (B).
Page 59
* Sewing will be completed automatically in the following order. Buttonhole foot alignment position Fabric marking 9. When sewing is finished, use a buttonhole opener/ seam ripper to open up the fabric in the center of the buttonhole. Be careful not to cut any of the stitching. Spur CORDED BUTTONHOLES Destek...
MANUAL BUTTONHOLE * Use the automatic buttonhole foot up to 1 3/4 “(45 mm) in length, but don’t lower the buttonhole lever or a beep will sound. * U s e t h e s a t i n f o o t t o c r e a t e l a r g e r buttonholes.
3. CARING FOR YOUR MACHINE To ensure the best possible operation of your machine, it is necessary to keep the essential parts clean at all times. Always disconnect the machine from power supply by removing the plug from the socket-outlet. Always disconnect the machine from power supply by removing the plug from the wall-outlet.
CLEANING THE FEED DOGS AND SHUTTLE AREA Raise the needle to its highest position. 1.Remove the bobbin case from the shuttle. 2.Push aside the two shuttle keepers. 3.Remove the shuttle race cover and shuttle. Clean the feed dogs and shuttle area with the lint brush. NOTE:Put a drop of sewing machine oil on the center pin of the shuttle and shuttle race as indicated by the arrows.
Page 64
Cleaning the sewing machine and footcontroller After using, keep sewing machine and footcontroller clean, use dry rags to remove dust from the sewing machine and footcontroller. NOTE: Use dry rags to avoid electrical shock.
4.OPTION ACCESSORIES LARGE EXTENSION TABLE To place onto the machine, lift the supporting leg of the extension table, and slide the table Supporting leg Extension table HARD-SIDED COVER Carry your machine safely and keep dust-free in storage.
5. PERFORMANCE CHECKLIST GENERAL PROBLEMS Machine does not sew. * Power switch is turned off. - Turn on the switch. * Buttonhole lever is not raised when sewing stitch patterns. – Raise buttonhole lever. * Buttonhole lever is not lowered when sewing buttonhole. –...
6. 6699/6680 ONLY ACCESSORIES ROLLER FOOT When sewing leather, suede, plastic and velvet, fit the roller foot to aid the smooth flow of fabric. However, especially when sewing softer leather and suede, better results may be achieved by using the normal zigzag foot. INVISIBLE ZIPPER FOOT T h e I n v i s i b l e Z i p p e r F o o t p r o v i d e s a Machine Preparation...
BUTTON SEWING FOOT The Button Sewing Foot is designed to hold the button Machine Preparation Sewing Instructions 1. Attach the darning plate, insert fabric under 5. Select Zig-Zag Stitch. press foot. 6. Set stitch width so that needle clears both button 2.
BLIND STITCH FOOT Elastic Blind stitch for soft, stretchable fabrics. Regular blind stitch for normal woven fabrics. The Blind Stitch Foot is primarily used for Machine Preparation creating nearly invisible hems on curtains, trousers, skirts, etc. Sewing Instructions On medium to heavyweight fabrics overcast the fabric's raw edge. Now fold the fabric as with the wrong side up.
OVERCASTING FOOT T h i s f o o t d e l i v e r s a c o n s i s t e n t a n d accurate overcasting stitch for a serged Machine Preparation effect using your sewing machine.
Page 74
NOT: Her üç modelin teknik özellikleri aynıdır.
Page 75
Malın ayıplı olduğunun anlaşılması durumunda tüketici, 6502 sayılı Tüketicinin korunması Hakkında Kanunun 11 maddesinde yer alan; a-) Sözleşmeden dönme, b-) Satış bedelinden indirim isteme, c-) Ücretsiz onarılmasını isteme, ç-) Satılanın ayıpsız bir misli ile değiştirilmesini isteme, haklarından birini kullanabilir. Tüketici şikayet ve itirazlarını; yerleşim yerinin bulunduğu veya tüketici işleminin yapıldığı...
Page 76
SERVİS İSTASYONLARI İLE YEDEK PARÇA MALZEMELERİNİN TEMİN EDİLEBİLECEĞİ YERLER ALAN İL/İLÇE UNVAN ADRES KODU TELEFON Adana / Ceyhan Bilir Makina-Ümit Yaşar Bilir B. Kırım Mah. Yaltır Cad. No: 66/A 613 98 16 453 68 02 Adana / Seyhan Çelik Ticaret-Tunç Çelik Sümer Mah.
Page 77
ALAN İL/İLÇE UNVAN ADRES KODU TELEFON 227 31 50 Bartın Arifoğlu Mob. Tic. San. Ltd. Şti. Kırtepe Mah. Hamam Sok. No: 3-8 212 69 25 Batman Avni Altun-Avni Ticaret Çarşı Mah. Bankalar Cad. No: 100 İsmetpaşa Mah. İbrahim Bey Cad. No: 6 212 58 89 Bilecik Osman Ada...
Page 79
ALAN İL/İLÇE UNVAN ADRES KODU TELEFON 544 21 31 İzmir / Ödemiş Mehmet Yapa Akıncılar Mah. Hürriyet Cad. Güngelen Psj. No: 14-Z 221 70 99 Kahramanmaraş Çalkaya D. T. M. Gıda İsmet Paşa Mah. Trabzon Cad. 221 24 53 San. ve Tic. A.Ş. İl Özel İdare İş...
Page 80
ALAN İL/İLÇE UNVAN ADRES KODU TELEFON 536 486 16 46 Manisa / Alaşehir Mustafa Yaslı 5 Eylül Mah. Kuyucak Cad. No: 23 462 46 22 Manisa / Demirci Mehmet Şengel Hacı Hasan Mah. Hükümet Cad. No: 6 Manolya Dikimevi Kurtuluş Mah. Yeşil Tuna Sok. No: 20 613 57 45 Manisa / Soma Net-San Elek.
Page 81
ALAN İL/İLÇE UNVAN ADRES KODU TELEFON Şanlıurfa Akkaya Pazarlama-Ömer Akkaya 12 Eylül Cad. No: 65/A 215 16 26 Şanlıurfa / Siverek İmam Tınığ Haliliye Mah. Kale Boğazı Cad. No: 81 552 40 66 Dağkapı Mah. Nesimi Cad. No: 17/B 616 68 89 Şırnak / Cizre Nefidet Arısoy Tekirdağ...
Page 82
6660/6680/6699 www.singer.com.tr Danışma Hattı: 444 99 09 ÜRETİCİ/İHRACATÇI FİRMA: İTHALATÇI FİRMA: SINGER SOURCING LTD için SİNGER DİKİŞ MAKİNALARI TİCARET ANONİM ŞİRKETİ JAGUAR INTERNATIONAL CORP. AYDINEVLER MAH. SANAYİ CAD. 2-6-8 SATA HIGASHI-MATCHI, MORIGUCHI-SHI,OSAKA NO:3 CENTRUM İŞ MERKEZİ 34854 570-0017, JAPAN KÜÇÜKYALI, MALTEPE - İSTANBUL tarafından üretilmiştir.
