- Page 1 890 WEIGHT HORN ATTACHMENT CLASS H PART # 7192801 REV. A USER’S GUIDE WARNING: Read and follow all directions for each step to insure proper assembly of this product. Version: 890107 Revision: 09/26/01...
-
Page 2: Important Safety Information
7. Inspect cables and their connections before using machine. Pay particular attention to the cable ends. DO NOT attempt to fix. Notify your authorized ParaBody dealer before use and have repairs made by an authorized service technician. 8. Make sure all spring loaded pull pins are fully engaged in the adjustment position and fully tighten thumbscrew before use. -
Page 3: Important Notes
Please note: * Thank you for purchasing the ParaBody 890 Weight Horn Attachment. Please read these instructions thoroughly and keep them for future reference. This product must be assembled on a flat, level surface to assure its proper function. * This product must be assembled on a flat, level surface to assure its proper function. DO NOT securely tighten any frame connections until the entire frame has been assembled, unless otherwise stated. -
Page 4: Parts List
FIGURE 1 STEP 1: INSTALLATION SHOWN FOR 888 SMITH MACHINE. 838 SQUAT RACK INSTALLATION SHOWN ON PAGE 6 &7. • Remove and discard the eight 9/16” CAP PLUGS from the UPRIGHT FRAMES as shown in FIGURE 1. PARTS LIST PART # DESCRIPTION 6799601 PLATE HOLDER... - Page 5 UPRIGHT FRAME 2 1/2 X 3” FIGURE 2 STEP 2: • Insert four 1-3/4” ROUND END CAPS (5) into the end of the four PLATE HOLDERS (1) as shown in FIGURE 2. • SECURELY assemble the four PLATE HOLDERS (1) to the UPRIGHT FRAMES as shown in FIGURE 2, using eight 1/2 X 3” BOLTS (2), eight 1/2”...
- Page 6 FIGURE 1 STEP 1: INSTALLATION SHOWN FOR 838 SQUAT MACHINE. 888 SMITH MACHINE INSTALLATION SHOWN ON PAGE 4 & 5. • Remove and discard the four 1/2 X 3” BOLTS, four 1/2” WASHERS, and four 1/2” LOCK NUTS from the CROSS BRACE as shown in FIGURE 1.
- Page 7 FIGURE 2 STEP 2: • Insert four 1-3/4” ROUND END CAPS (5) into the end of the four PLATE HOLDERS (1) as shown in FIGURE 2. • SECURELY assemble two PLATE HOLDERS (1) and the CROSS BRACE to the UPRIGHT FRAMES as shown in FIGURE 2, using four 1/2 X 3”...
-
Page 8: Maintenance
Please note: * We recommend cleaning your product (pads and frame) on a regular basis, using warm soapy water. Touch-up paint can be purchased from your ParaBody customer service representative at (800) 328-9714. * Inspect equipment daily. Tighten all loose connections are replace worn parts immediately. -
Page 9: Limited Warranty
ParaBody extends the following LIMITED WARRANTY to the original owner of the ParaBody products. The Warranty terms apply to IN HOME USE ONLY. 1. LIMITED WARRANTY ON FRAME AND WELDS. If the frame of the ParaBody product or a weld should crack or break, it will be repaired or replaced by ParaBody. - Page 10 Room 2610, Miramar Tower 132 Nathan Road, Tsimshatsui Kowloon, Hong Kong Phone: (852) 2891-6677 Fax: (852) 2575-6001 LIFE FITNESS www.parabody.com Life Fitness (UK) Ltd. Queen Adelaide Ely, Cambs CB7 4UB United Kingdom Phone CSS: (01353) 665507 Fax CSS: (01353) 666719 Life Fitness Benelux N.V.
