Quick Start Guide
/
ARC CBA850
ARC CBA850
FAILOVER & OUT-OF-BAND MANAGEMENT NETWORKING
WHAT'S INCLUDED:
AC Power Adapter
©2005-2016 Cradlepoint. All Rights Reserved.
|
Modem Antennas
+1.855.813.3385
|
cradlepoint.com
THANK YOU FOR CHOOSING
CRADLEPOINT
Cradlepoint is the leading provider of secure
cloud-managed 3G/4G/LTE networking solutions
for the Distributed Enterprise with hundreds
or thousands of locations. Our broad family
of high-performance routers are designed for
deployment in mission-critical applications
that require 24x7 connectivity.
Always Connected. Always Protected.
ARC CBA850 Key Features:
+
Plug-and-play
overlay failover
+
Cloud-managed
+
Integrated 3G/4G/LTE
+
Integrated Multi-
Carrier Software-
Defined Radio
+
Out-of-Band
Management
Go to cradlepoint.com/cba850 to learn more.
+
Mounting Hardware
+
Power-over-
Ethernet (PoE)
+
External antenna
options
+
IPv6 support
+
RJ45 serial console
port for direct
Out-of-Band
Management
1
Part Number: 170661-000
Advertisement
Related Manuals for Cradlepoint ARC CBA850
Summary of Contents for Cradlepoint ARC CBA850
- Page 1 ARC CBA850 THANK YOU FOR CHOOSING CRADLEPOINT FAILOVER & OUT-OF-BAND MANAGEMENT NETWORKING Cradlepoint is the leading provider of secure cloud-managed 3G/4G/LTE networking solutions for the Distributed Enterprise with hundreds or thousands of locations. Our broad family of high-performance routers are designed for deployment in mission-critical applications that require 24x7 connectivity.
-
Page 2: Device Details
DIN Rail Mounting Bracket Antennas Wall/Ceiling Mounting Bracket Omni-Directional Antennas Rollover Adapter for RJ45 12” Mag-Mount Antenna Ethernet Cable 4” Mini Mag-Mount Antenna RJ45 Rollover Serial Console Cable: 7ft & 14ft Model Numbers: CBA850 S4A452A ©2005-2016 Cradlepoint. All Rights Reserved. +1.855.813.3385 cradlepoint.com... -
Page 3: Getting Started
Insert the SIM card into the slot marked SIM 1 (use the other slot, SIM 2, for a secondary/backup SIM). The Cradlepoint ARC CBA850 requires a SIM with an activated wireless broadband data plan. Contact your carrier for details about selecting a data Be sure to insert the card with the notch-end first and the gold contacts plan and about the process for provisioning your SIM. -
Page 4: Mounting Recommendations
Connect to a Computer or other Network Equipment Connect via Ethernet to LAN 1 for local management. Connect LAN 2 (Default IP Passthrough 0/24) to networking equipment to Passthrough 3G/4G Internet to Ethernet. ©2005-2016 Cradlepoint. All Rights Reserved. +1.855.813.3385 cradlepoint.com... -
Page 5: First Time Setup Wizard
When you log in to the local administration pages for the first time, you will be automatically directed to the First Time Setup Wizard, which will walk you through basic steps to customize your Cradlepoint ARC CBA850. You have the ability to configure any of the following: Administrator Password... -
Page 6: Router Communication / Data Usage
The factory default configuration of the router is set the device for ten seconds. Reset returns the login password to the default password and resets all to communicate with Cradlepoint and other resources configuration changes. at regular intervals to access the latest firmware and modem updates, clock synchronization (NTP), and Enterprise Cloud Manager (ECM) membership.
